Arda HM-20100630 Owner's Manual

Hide thumbs Also See for HM-20100630:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual
Range Hoods
Section 1 - Safety Information
Section 2 - Installation: Wall Mount Hoods
Section 3 - Installation: Island Mount Hoods
Section 4 - Use & Care Instructions
Section 5 - Control Functions
Section 6 - Troubleshooting Guide
Section 7 - Warranty & Registration
HM-20100630
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HM-20100630 and is the answer not in the manual?

Questions and answers

Related Manuals for Arda HM-20100630

Summary of Contents for Arda HM-20100630

  • Page 1 Section 1 - Safety Information Section 2 - Installation: Wall Mount Hoods Section 3 - Installation: Island Mount Hoods Section 4 - Use & Care Instructions Section 5 - Control Functions Section 6 - Troubleshooting Guide Section 7 - Warranty & Registration HM-20100630...

  • Page 2: Important Safety Information

    1. IMPORTANT SAFETY INFORMATION * Important: Read the complete manual carefully before installation* Intended for Domestic Kitchen Use Only WaRnInGS: TO REDUCE THE RISK OF FIRE, ELECTRICaL SHOCK OR PERSOnaL InJURY, PLEaSE OBSERVE THE FOLLOWInG: 1. InSTaLLaTIOn anD ELECTRICaL WORK MUST BE DOnE BY a qUaLIFIED PERSOn In aCCORDanCE WITH aLL aPPLICaBLE CODES anD STanDaRDS 2.
  • Page 3 Important safety information TO REDUCE THE RICK OF InJURY TO PERSOnS In THE EVEnT OF a RanGE TOP GREaSE FIRE, OBSERVE THE FOLLOWInG: 1. SMOTHER FLaMES with a close-fitting lid, cookie sheet or metal tray, and then turn off the burner. If the flames do not go out immediately, evacuate and call the fire department.

  • Page 4: Installation Instructions

    Installation Instructions Before You Start... 1. Read this manual carefully and completely. Grounded Outlet Box 2. aRDa range hoods conform to ETL/CSa standards. Please check your local building codes for any additional requirements. Grounding Pin 3. The appliance has been manufactured as class I, therefore ground connection is necessary.

  • Page 5: Fixing To The Wall

    Installing the Ductwork 1. Plan where the ductwork will run between the hood and the outside. arda hoods exhaust vertically up through the ceiling to the roof. They can be ducted to the rear behind the chimny duct through an outside wall. a short straight duct run will produce the most air flow.
  • Page 6 Before You Start... 1. Read this manual carefully and Grounding Pin completely. 2. aRDa range hoods conform to ETL/CSa standards. Please check your local building codes for any additional requirements. 3. The appliance has been manufactured as class I, therefore ground connection is necessary.

  • Page 7: Installing The Ductwork

    2. arda island hoods exhaust vertically up through the ceiling to the roof. They can be exhausted sideways above the ceiling to an eave cap.
  • Page 8 8. insert the lower cage over the upper cage. adjust the height to the necessary distance using screws supplied. (B) Front of range/cooktop 9. attach 6” aluminum duct (not included) to the prepared duct work in the ceiling. Seal all seams.

  • Page 9: Installing The Range Hood

    Installing the Range Hood Please note that to avoid damaging the hood, installation requires three people. 1. Remove grease filters from range hood. 2. With the assistance of two other people lifting the hood.from below, raise the unit until the Front of range/cooktop lower cage sits inside the range hood lower cage.

  • Page 10: Cleaning The Filter

    Cleaning the filter 1. Remove the filters from the range hood and wash them in a solution of water and liquid detergent, leaving to soak if necessary. Rinse thoroughly with warm water and leave to dry. 2. The filters may also be washed in the dishwasher. 3.

  • Page 11: Control Functions

    WARNING: Do not touch or change light bulbs while the hood is operating. Wait until the bulb has cooled before removing. Depending on your model of aRDa hood, there are three possible types of lighting. Incandescent , halogen and LED. The illumination is designed for use during cooking and not for prolonged general illumination of your kitchen.

  • Page 12: Incandescent Lights

    Check the plug is connected. no electrical supply. Check the main switch is Hood doesn’t turn on. turned on. Power cord is damaged Call aRDa service aluminum grease filters Clean the filters and replace clogged when dry. Poor airflow Charcoal filters clogged. Re- Replace the charcoal filters.

  • Page 13: Limited Warranty

    It further warrants the motor (part only) for an additional ONE YEAR. During the warranty period, Arda will, at its option, repair or replace, without charges, any product or part which is found to be defective under normal use and service.
  • Page 14 Place photocopy of proof of purchase here Visit us @ www.ardaappliances.ca...
  • Page 15 Distributed in north america by Integrated Appliances Ltd. 501 Oakdale Road, Toronto, Ontario M3n 1W7 Tel: 1 800 387 3924 Visit our website at www.ardaappliances.com...
