- Page 1 Range Hoods Owner’s Manual Page 2 - Safety and Installation Guide Page 4 - Wall Mount Hoods Page 9 - Island Mount Hoods Page 14 - Use & Care instructions Page 18 - Warranty...
-
Page 2: Important Safety Information
Important safety InformatIon Intended for domestIc kItchen use only ImpoRtant: befOre installatiOn Read tHe complete manual caRefully Warnings: to Reduce tHe RISK of fIRe, electRIcal SHocK oR peRSonal InJuRy, pleaSe oBSeRVe tHe folloWInG: • Installation and electrical work must be done by a qualified TECHNICIAN in accordance with all applicable codes and standards. - Page 3 Important safety InformatIon Important safety InformatIon Grease fire In tHe eVent of a RanGe top to Reduce tHe RISK of InJuRy to peRSonS, oBSeRVe tHe folloWInG: • SMOTHER FLAMES with a close-fitting lid, cookie sheet or metal tray, then turn off the burner. If the flames do not go out immediately, evacuate and call the fire department.
- Page 4 4. Decide where to install the 120V receptacle within the dimensions of the decorative chimney. 5. Calculate the required height of the decorative chimney. ARDA range hoods will usually fit on walls higher than 7 ½’ and lower than 8 ½’ depending on the mounting height of the range hood.
- Page 5 Wall mounted hood - InstallatIon Step C: Installing the Ductwork Roof Cap 1. Arda hoods exhaust vertically up through the ceiling to the roof. They can be ducted to the rear behind the decorative chimney duct through an outside wall.
- Page 6 Distance Between Width of Decorative Model of Hood to Mounting Mounting Screws Chimney Screws (d) HAE22 26 cm / 10 ¼” 35 cm / 13 ¾” 30.4 cm / 12” HAE52T 26 cm / 10 ¼” 17.5 cm / 6 ⅞”...
- Page 7 Wall mounted hood - InstallatIon Step F: Mounting the hood Warning: If unit is being installed above an installed cooking appliance, ensure the unit is turned off and is completely cooled before beginning installation. CAUTION: While installing the hood, take precautions not to scratch your unit. Remove tool belts and large belt buckles and any other sharp items while handling the unit.
- Page 8 Wall mounted hood - InstallatIon Step G: Installing the Decorative Chimney Duct 1. Carefully loosen but do not separate the telescopic chimney duct pieces (i & j). The inside piece is the top and attaches to the wall at the ceiling.
-
Page 9: Island Hood - Installation
4. Install 110/120V electric plug on the ceiling within the dimensions of the decorative chimney. 5. Calculate the required height of the mounting cage and decorative chimney. ARDA island hoods will usually fit in ceilings between 8 1/2” and 9 1/2” high depending on the mounting height of the range hood. - Page 10 Short straight duct runs will provide the most air flow. Wall Cap 3. Arda Island Hoods exhaust vertically up through the ceil- ing to the roof. They can be exhausted sideways through a bulkhead or above the ceiling to an eave cap.
- Page 11 Island hood - InstallatIon Step F: Mounting Height Calculation 1. For an island hood installation, you will need to consider the following when calculating the mounting height (c): The minimum mounting height -- in general, the minimum mounting height above an electric •...
- Page 12 Island hood - InstallatIon Step F: Mounting to the Ceiling CAUTION: While installing the hood, take precautions not to scratch your unit. Remove tool belts and large belt buckles and any other sharp items while handling the unit. Cover lower working surface with a soft blanket.
- Page 13 Island hood - InstallatIon Step H: Installing the Range Hood IMPORTANT: Please note that to avoid injury and damage to the hood, this step of the installation requires three people. 1. Before mounting the hood, plug the unit in and test all functions for proper operation. •...
- Page 14 Controls: Arda hoods come with a variety of controls depending on the model choice. Delay timers, when included, turn off the hood in a set amount of time to assit in removing adours from your kitchen.
- Page 15 WARNING: Do not touch or change light bulbs while the hood is operating. Wait until the bulb has cooled before removing. Depending on your model of ARDA hood, there are two possible types of lighting: incandescent and halogen. The hood lights are designed for use during cooking and not for prolonged general illumination of your kitchen.
-
Page 16: Cleaning The Filter
use & care InstructIons wires) press down the locking lever (to unlatch the locking pin) and gently pull the two sections apart. 4. Remove the cover on the fixture, by placing a small flathead screwdriver between the inner and outer ring of the fixture in the area marked “OPEN,” and prying loose the inner ring (c). 5. -
Page 17: Troubleshooting Chart
Ensure the plug is connected No electrical supply Ensure the main switch is Hood doesn’t turn on turned ON Power cord is damaged Call ARDA service Aluminum grease filters Clean the filters and replace clogged when dry Poor airflow Charcoal filters clogged... -
Page 18: Limited Warranty
(part only) for an additional ONE YEAR. During the warranty period, Arda will, at its option, repair or replace, without charges, any product or part which is found to be defective under normal use and service. - Page 19 place a photocopy of proof of purchase here Visit our website at www.ardaappliances.com - 19 -...
- Page 20 Distributed by: Arda Appliances NA. 501 Oakdale Road, Toronto, Ontario M3N 1W7 Tel: 416-646-2500 Fax: 416-646-2505 1 800 268-4086 www.ardaappliances.com 2013-07-29...
