Opticon PHL-8100 Quick Manual

OVERVIEW
Scanner LED Indicator
Scan Key
Charger LED Indicator
F1 Key
F2 Key
Fn Key
Power Key
USB/Serial/
Synchronization Port
DC Power Jack
Reset
Scan Window
GSM/GPRS/EDGE
indication (Availability
depends of PDT model)
GSM/GPRS/EDGE
Receiver
indication (Availability
depends of PDT model)
Right Scan Key
Reserve Hotkey
LCD Touchscreen
F3 Key
F4 Key
Alpha Key
Enter Key
MIC
Alpha-Numeric Key
Hand Strap
Battery Cover Latch
Battery Cover
Stylus
Speaker
Earphone Jack Connector
BEFORE GETTING STARTED BEFORE GETTING STARTED
1. Open the package and check every
accessory:
Battery Pack Battery Pack USB Client USB Client
(2200mAh) (2200mAh) Cable for Terminal Cable for Terminal
Power Adapter Power Adapter Ear/Microphone Set Ear/Microphone Set
Main Unit
(5VDC/2.6A) (5VDC/2.6A)
with Stylus
Quick Guide Quick Guide
(Not Shown) (Not Shown)
Power Cord Power Cord
!
CAUTION:
The device will be powered on when you install Battery Pack.
Power off device after touch screen calibration and charge batteries
for at least 6 hours. Do not turn on the device for the first time until
batteries are charged for at least 6 hours. Always charge batteries
℃ ℃ ℉ ℉
at 0 ~45 (32 ~113 ) environment temperature. The Charger
LED will be turned to green color when battery charging is finished.
2. Installing the Battery Pack
1) Detach the Hand Strap.
2) Turn the battery cover latches downwards and lift
the battery cover away.
3) Insert the Battery Pack into the battery compartment with the
label facing out, and make sure the battery fits into place.
4) Place the battery cover by inserting the top first, and then press
the bottom in firmly. Turn the battery cover latches upwards to
secure the cover to the PDT.
3. Connect Power Adapter to charge the PDT
1) Insert DC connector into bottom case of the PDT.
2) Connect Power Cord to power adapter.
3) Insert power cord to AC Outlet.
USING THE KEYPAD USING THE KEYPAD
The keypad comprises 25 keys (numeric, arrow,
functional and Fn) and 3 scan buttons.
1) Key toggle between the Numeric and Alpha modes.
Alpha
2) Key allows the toggle between upper-case letters and
Caps
lower-case ones. When enable Caps Lock Mode, the Icon A
shows at Task bar .
3) Press to toggle Function Mode.
Fn
Special Characters
Special Functions
Sequence of Keys
Sequence of Keys Description Description
: \ Launch of Application 1
Alpha 1 : \ F 1
，
Alpha * . , ; . ； F 2 Launch of Application 2
[ ]
Alpha 0 F 3 Launch of Application 3
[ ]
Alpha # = % F 4 Launch of Application 4
= %
Special Characters
Special Functions
Sequence of Keys Description Sequence of Keys Description
@
Fn Fn
1 : \
'
Fn 2 Fn
A B C
＋
Fn 3 Fn Ta b
D E F
－
Fn 6 Fn Caps Audio Mute
M N O
Fn 8 & Fn 4
T U V G H I
＊
Fn Fn
9 WXYZ 5 J K L
/
Fn # Fn 7
= % PQRS
0
[ ]
* Start Menu
. , ;
BATTERY PRODUCT SAFETY
Lithium-ion Battery Packs might get hot, explode, ignite
and/ or cause serious injury in case of misuse.
Please follow the safety warnings listed below:
A.Do not throw the battery into fire. Do not expose the battery to
high temperatures.
B. Do not connect the positive Battery Pack with negative
Battery Pack to each other with any metal object (like wire).
C. Do not carry or store Battery Pack together with metal objects.
D. Do not pierce the Battery Pack with nails or drills, strike the battery
pack with a hammer, step on the Battery Pack or otherwise expose
it to strong impacts, shocks or excessive force.
E. Do not solder directly onto the Battery Pack.
F. Do not expose Battery Pack to liquid or allow the battery contacts
to get wet.
G. Do not disassemble or modify the Battery Pack.The Battery Pack
contains safety and protection measures, which, if damaged,
may cause the Battery Pack to generate heat, explode or ignite.
H. Do not discharge the batteries outside the PDT. Do not use the
battery in another device then the PDT or series battery chargers.
Otherwise, the Battery Pack can be damaged, the Battery Pack
can be damaged or its life expectancy reduced. If the device
causes any abnormal current to flow, it may cause the Battery
Pack to become hot, explode or ignite and cause serious injury.
I. In the event the Battery Pack leaks and the fluid gets into one's
eye, do not rub the eye.
Rinse well with water and immediately seek medical care.
If left untreated,the battery fluid could cause damage to the eye.
" "
Laft
Rigth
Esc
Paste
Del
Copy
Space
