Electrical Requirements; Engine Type; Alternator; Dc Voltage - Contractor GEN4000/03237 Instruction Manual

ITEM

Electrical Requirements

Engine Type

Alternator

DC voltage

Fuel Tank

Estimated Run Time

Overall Dimensions

Weight

You will need this manual for the safety warnings and precautions, operating, inspection,
maintenance and cleaning procedures, parts list and assembly diagram. Keep your invoice
with this manual. Write the invoice number on the inside of the front cover. Keep this manual
and invoice in a safe and dry place for future reference.
The warnings, cautions and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that COMMON SENSE AND CAUTION ARE FACTORS
WHICH CANNOT BE BUILT INTO THIS PRODUCT, BUT MUST BE SUPPLIED BY
THE OPERATOR.
WARNING!
1. Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents.
2. Do not operate generators in explosive atmospheres, such as in the presence of flammable
liquids, gases, or dust. Generators create sparks, which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a generator. Provide barriers or
shields as needed.
4. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair,
clothing, and gloves away from moving parts. Loose clothes, jewelry, and long hair can be caught in
moving parts.
DESCRIPTION
6.5hp 3000 watt w/ peak surge wattage of 4000w
Electronic ignition system, recoil start 4 Cycle
Two Pole / Single Phase / 60 Hz
DC Output 12v @ 8.3amps
4 gallon tank capacity
7.8h continuous run time
24.25x17.25x18 in
101 Lbs.
SAVE THIS MANUAL

GENERAL SAFETY RULES

WORK AREA
-1 -
