Definitive Technology W Studio Owner's Manual page 13

IR Remote Control Function and Data List
W Studio's remote control codes are discrete IR (Infrared) codes. Custom installers may want to have access to the standard codes that enable
the SoloCinema Studio's remote functions to be programmed into a universal controller.
Below are the remote control function and data lists for these functions:
IR Remote Control Function and Data list for the W Studio Sound Bar
Standard Codes
NEC Transmission Format using Definitive Technology Custom Code (A): 0x0A56
BUTTON Screen Print
Power power symbol
Mute mute symbol
SRC1 HDMI 1
SRC2 HDMI 2
SRC3 HDMI 3
SRC4 AUX
SRC5 OPT.
SRC6 Bluetooth
CENTER + CENTER +
CENTER - - CENTER
MENU MENU
^ ^
v v
ENTER ENTER
< <
> >
VOLUME + VOLUME +
VOLUME - - VOLUME
BASS + BASS +
BASS - - BASS
MOVIE MOVIE
MUSIC MUSIC
IR Remote Control Function and Data list for the W Studio Sound Bar
Discrete Codes
NEC Transmission Format using Definitive Technology Custom Code (B): 0x0A58
NAME FUNCTION: SoloCinema
Power ON DISCRETE_POWER_ON
Power OFF DISCRETE_POWER_OFF
Mute DISCRETE_MUTE
Unmute DISCRETE_UNMUTE
Menu ON DISCRETE_MENU_ON
Menu OFF DISCRETE_MENU_OFF
RF Update Discrete RF Module Update Mode
www.definitivetech.com
FUNCTION: SoloCinema Studio
Power toggle: On / Off (standby)
Power toggle: On/Off (standby)
Select: Source 'Input 1'
Select: Source 'Input 2'
Select: Source 'Input 3'
Select: Source 'Input Analog'
Select: Source 'Input Digital'
Select: Source 'Input Bluetooth'
®
Center Level: adjust Up (+)
Center Level: adjust Down (-)
Menu toggle: On / Off
OSD Navigation: Up
OSD Navigation: Down
OSD Navigation: Enter/Select
OSD Navigation: Left
OSD Navigation: Right
Master Volume: adjust Up (+)
Master Volume: adjust Down (-)
Subwoofer Level: adjust Up (+)
Subwoofer Level: adjust Down (-)
Select: 'Movie' audio DSP
processing mode
Select: 'Music' audio DSP
processing mode
Custom Code
DECIMAL Ccode Ccode'
136 0x0A 0x56
138 0x0A 0x56
150 0x0A 0x56
151 0x0A 0x56
152 0x0A 0x56
153 0x0A 0x56
154 0x0A 0x56
155 0x0A 0x56
192 0x0A 0x56
193 0x0A 0x56
17 0x0A 0x56
10 0x0A 0x56
11 0x0A 0x56
14 0x0A 0x56
12 0x0A 0x56
13 0x0A 0x56
212 0x0A 0x56
208 0x0A 0x56
214 0x0A 0x56
210 0x0A 0x56
140 0x0A 0x56
141 0x0A 0x56
Custom Code
DECIMAL Ccode Ccode'
87 0x0A 0x58
88 0x0A 0x58
92 0x0A 0x58
93 0x0A 0x58
202 0x0A 0x58
203 0x0A 0x58
0x0A 0x58
0x0A 0x58
0x0A 0x58
0x0A 0x58
0x0A 0x58
195 0x0A 0x58
Studio
owner's manual
Data Code
Dcode Dcode'
0x88 0x77
0x8A 0x75
0x96 0x69
0x97 0x68
0x98 0x67
0x99 0x66
0x9A 0x65
0x9B 0x64
0xC0 0x64
0xC1 0x3F
0x11 0x3E
0x0A 0xF5
0x0B 0xF4
0x0E 0xF1
0x0C 0xF3
0x0D 0xF2
0xD4 0x2B
0xD0 0x2F
0xD6 0x29
0xD2 0x2D
0x8C 0x73
0x8D 0x72
Data Code
Dcode Dcode'
0x57 0xA8
0x58 0xA7
0x5C 0x6D
0c5D 0xA2
0xCA 0x35
0xCB 0x34
0x00
0x00
0x00
0x00
0xC3 0x32
0x9D 0x62
13
