- Page 1 TFT-LCD with VGA only 15” – 17” – 19” MANUAL LC-VT1503xx – LC-VT1704xx – LC-VT1904xx Europe North America Canvys – Visual Technology Solutions Canvys – Visual Technology Solutions A Division of Richardson Electronics GmbH A Division of Richardson Electronics (NASDAQ:RELL) Raiffeisenstraße 5 40W267 Keslinger Road;...
-
Page 2: Table Of Contents
4. Display Modes Memory Page 7 5. Signal Connector Pin-Outs Page 8 6. Power Saving Feature Page 8 7. Product Specifications Page 9 C. caveat emptor / Guarantee exclusion Page 10 D. Vendor Page 11 Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 1 of 12... -
Page 3: Fcc Statement
NEVER be blocked by placing the monitor on a bed, sofa, rug or other similar surface. This monitor should NEVER be placed near or over a radiator or heat register. This monitor should NOT be placed in built-in installation such as a bookcase unless proper ventilation is provided. Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 2 of 12... - Page 4 Unauthorized substitutions may result in fire, electric shock, or other hazards. 18. Upon completion of any service or repairs to this monitor, ask the service technician to perform routine safety checks to determine that the monitor is in safe operating condition. Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 3 of 12...
-
Page 5: Installing The Monitor
You can hold the AUTO/EXIT knob for more than 3 second to adjust the image quality automatically. The OSD menu will close automatically after 3 -10 seconds without operation and saves any changes you have made. Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 4 of 12... -
Page 6: Function Adjustment
Exit the Audio OSD menu 4. Colour / Colour Temperature User Adjust the R.G.B. gain level 6500K Select colour temperature to 6500°K 9300K Select colour temperature to 9300°K. Exit Close the Colour Temperature OSD menu Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 5 of 12... - Page 7 Adjust the horizontal position of the OSD menu Position OSD V. Adjust the vertical position of the OSD menu Position Exit Close the OSD Control OSD menu Recall Recall the factory default setting Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 6 of 12...
-
Page 8: Controller Features
48.4 15” – 19” Non-interlaced VESA/70 1024×768 56.5 15” – 19” Non-interlaced VESA/75 1024×768 60.0 15” – 19” Non-interlaced VESA/60 1280×1024 64.0 17” – 19” Non-interlaced VESA/75 1280×1024 80.0 17” – 19” Non-interlaced Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 7 of 12... -
Page 9: Signal Connector Pin-Outs
NUTEK specification 803299/94 the total time from indicated inactivity to Power Saving position A2 (VESA OFF) must not be set more than 70 minutes. We recommend you switch off the monitor when you do not intend to use it for awhile. Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 8 of 12... -
Page 10: Product Specifications
1280×1024 / SXGA Power Saving With EPA standard Plug & Play DDC 1/2B Ambient temperature Operation 5°C – 35°C Non-operating -20°C – 60°C Humidity Operating 20%-80% Storage 10%-90% *Specifications are subject to change without notice. Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 9 of 12... -
Page 11: Caveat Emptor / Guarantee Exclusion
• burn-in on the LCD panel caused by permanent display and spots forming on the LCD panel Canvys -VT15_17_19_VGAonly_EN_Manual.doc Heike Rettschlag 10 of 12... -
Page 12: Vendor
D. Vendor Canvys – Visual Technology Solutions A Division of Richardson Electronics www.canvys.com Europe North America Canvys – Visual Technology Solutions Canvys – Visual Technology Solutions A Division of Richardson Electronics GmbH A Division of Richardson Electronics (NASDAQ:RELL) Raiffeisenstraße 5 40W267 Keslinger Road;...
