  • Page 1 Dual Mode USB Modem User Manual...

  • Page 3: Table Of Contents

    Contents Product Overview Product Package Contents ……………………………… USB Modem Layout ……………………………………… ……………………………………… System Requirements Preparing USB Modem Installing USIM card ……………………………………… ………………………… Installing Connection Manager Basics Getting Started …………………………………………… Data Status Indication …………………………………… ………………………… Connection Manager Interface Common Operations Connecting to Network …………………………………… Auto Switch …………………………………………………...

  • Page 4: Product Overview Product Package Contents

    Product Overview Product Package Contents USB Modem User Manual USB Modem Layout LED status indicator Rear cover connector...

  • Page 5: System Requirements

    System Requirements Pentium IV Processor or faster, 128MB RAM or CPU & memory more Interface USB 2.0 Supported OS Windows XP / Windows Vista / Windows 7 Free HD space 80MB or more...

  • Page 6: Preparing Usb Modem Installing Usim Card

    Preparing USB Modem Installing USIM card ▶ Remove the Rear Cover of your USB Modem by gently sliding it to the arrow indicated below. ▶ Carefully slide the USIM card into your modem until it lies flat in the USIM holder with gold-colored contacts facing down. USIM ...

  • Page 7: Installing Connection Manager

    Insert your USB modem into a USB port of your computer. ▶ Your computer will recognize the modem and automatically start the installation. Click “WIMAX Installation Disk”. ▶ ▶ Choose a language used for the installation process.(Optional) * The language selected here will become the default language for the Connect Manage interface.
  • Page 8 Preparing USB Modem Installing Connection Manager ▶ If the installation program does not launch automatically, go to My Computer. Select „WiMAX Installation Disk‟ and double click it. [Desktop] ▶ [My Computer] ▶ [WiMAX Installation Disk]...
  • Page 9 Preparing USB Modem Installing Connection Manager ▶ Or you click the RIGHT mouse button on WiMAX CD drive. Select „Install WiMAX device‟ and then the installation sequence will begin. ▶ ▶ [Desktop] [My Computer] [WIMAX Installation Disk (right mouse button)] ▶...
  • Page 10 Preparing USB Modem Installing Connection Manager After installation is properly completed, you can see the two devices in ▶ the „Device Manager‟. [Desktop] ▶ [My Computer(click right mouse button)] ▶ [Properties] ▶ [Device Manager] ▶ If your device manager shows an exclamation mark (!) on top of the icon as seen below, please go to Troubleshooting (see page 34).

  • Page 11: Basics Getting Started

    Basics Getting started ▶ To start Seowonintech Connection Manager, Double click on the Seowonintech CM icon on your desktop. Click [Seowonintech CM] ▶ Or click on the Windows Start menu and select „Seowonintech CM‟ from the list of programs. ▶ ▶...

  • Page 12: Data Status Indication

    Basics Data Status Indication WiMAX – RED, BLUE. HSDPA – RED, ORANGE You can find the network connection status of your modem by referring to a multi-colored LED status indicators as seen the below chart. LED color indication Status WiMAX...

  • Page 13: Connection Manager Interface

    HSDPA Area – has “Connect” button, and other Text and Icon indicating „ ▶ HSDPA network connection status.‟ * Clicking on WiMAX or HSDPA Area expands or reduces a relevant interface Area. (see page 18) <Default> Title Bar Menu Bar...
  • Page 14 Produces a short menu: “Manual” Minimizes CM to the Windows Taskbar. Miniaturize CM to the System Tray. Connects to the Network (WiMAX or HSDPA). Cancels Connecting task (applicable only in WiMAX). Indicates “Connect (and Cancel)” is temporarily disabled: this status is usually seen when CM is connecting/ disconnecting to HSDPA network or when your host system fails to detect USB Modem.
  • Page 15 Data Rcd – The amount of data received since the current network connection was initiated(in bytes). NSP Name / Network – The name of Network service provider (WiMAX/HSDPA) Elapsed Time – The amount of time that has elapsed since the current network connection was initiated.
  • Page 16 Device not found – USB Modem is unplugged into Ready to connect – USB Modem is ready to connect to WiMAX or HSDPA network. WiMAX Connected – USB Modem is connected to WiMAX network. HSDPA Connected – USB Modem is connected to HSDPA...
  • Page 17 Basics Connection Manager Interface Minimizing the Main Window ▶ You can place the Connection Manager in the Windows Taskbar if you click„ ‟ icon at the upper-right corner of the main window. ▶ Or click „ ‟ icon next to „ ‟ icon to reduce the main Window to a Miniature CM icon in the System Tray.
  • Page 18 Basics Connection Manager Interface Restoring the Main Window ▶ You can restore Main Window by clicking the CM icon in the Windows Taskbar. ▶ You can restore the Main Window by clicking the miniature CM Icon in the System Tray. ▶...

  • Page 19: Common Operations Connecting To Network

    Common Operations Connecting to Network Select your preferred type of network ▶ If you want to connect to WiMAX network, click WiMAX Area (Upper). ▶ If you want to connect to HSDPA network, click HSDPA Area. (Lower).
  • Page 20 Common Operations Connecting to Network Connect to WiMAX Network ▶ Enter User ID/Password in the WiMAX tab of the Settings (see page 31). ● Click [Connect] in the WiMAX Area in the Main Window. ● The messages such as „Connecting‟ and „WiMAX Connected‟ will appear.
  • Page 21 Common Operations Connecting to Network Disconnect from WiMAX Network ▶ Click [Disconnect] in the WiMAX Area in the Main Window. WiMAX connection is disabled and HSDPA turns „Ready to connect‟.
  • Page 22 Click [Connect] of the HSDPA area in the Main Window. The message such as „Connecting‟ and „HSDPA Connected‟ will appear. ● WiMAX turns into the sleep mode, waiting for a future connection. ● When WiMAX network is properly established, following figures will ●...
  • Page 23 Common Operations Connecting to Network Disconnect from HSDPA Network ▶ Click [Disconnect] in the HSDPA area of the Main Window. ● HSDPA connection is disabled. ● Then, WiMAX Area turns into „Ready to connect‟ mode.
  • Page 24 Common Operations Connecting to Network Unlock USIM card (HSDPA) ▶ If your USIM card‟s Lock is set, a text of “USIM card is lock” reads in HSDPA Area as seen in 1) figure below. To unlock USIM, you enter the PIN as follows. If a valid PIN is input, you are allowed to connect to HSDPA 1) Click the marked area.

  • Page 25: Auto Switch

    Auto Switch Auto-Switch notification ▶ When WiMAX (or HSDPA) is disconnected, if „Auto Switch‟ is checked in Settings, a dialogue box of „Auto Switch‟ will automatically appear as seen below. If you click [Yes], your USB Modem starts to connect to...
  • Page 26 WiMAX is connected) ▶ When you are in areas with weak WiMAX signals, you may lose WiMAX connection. Then, a dialogue box of “Auto Switch” will automatically appear as seen below. If you click [Yes], your USB Modem starts to...
  • Page 27 (when HSDPA is connected) ▶ When USB Modem detects WiMAX signal over the set threshold (see page 30) or when HSDPA signal is so weak that you may lose the HSDPA connection, A dialogue box of “Auto Switch” will automatically appear as seen below.

  • Page 28: Update

    Common Operations Update Update by OTA (Optional) ▶ Upon connecting to WiMAX network each time, the Connection Manager checks for any F/W updates. ▶ When updates found available, the Connection Manager produces a dialogue like below. If you select [Yes], the relevant updates will begin.

  • Page 29: Information

    Common Operations Information ▶ Click Menu in the menu bar of the Main Window. Select Information. It produces a new window with three tabs: WiMAX, HSDPA and Application. ● WiMAX Tab includes info about WiMAX Device, SW, Network, etc. ●...

  • Page 30: Settings

    Common Operations Settings ▶ Click Menu in the menu bar of the Main Window. It will produce a new window appears with three tabs: Application, WiMAX and HSDPA. Settings allows you to configure many individual preference features in each tab.

  • Page 31: Application Tab

    Ex) The WiMAX threshold value „3‟ means: 1) WiMAX HSDPA : when WiMAX signal strength found less than (＜) 3 during WiMAX connection 2) WiMAX HSDPA : when WiMAX signal strength found greater than or equal to (≥) 3 during HSDPA connection * The default threshold value is 0.
  • Page 32 Common Operations Settings ▶ WiMAX Tab ● allows you to enter your User ID and Password for Authentication ▶ HSDPA Tab ● allows you to create/edit profiles of User name, Password, Phone Number, and APN for HSDPA connection. - To ensure that your USB Modem properly establishes Network connection, please configure User‟s network information at first...
  • Page 33 Common Operations Settings ▶ HSDPA Tab (USIM PIN) ● You can enable or disable the Lock feature of your USIM card. - If “PIN enable” is selected, you are prompted to enter a PIN to start your USB Modem 1) Enable/Disable - Select your preferred radio button.

  • Page 34: Exiting Connection Manager

    Common Operations Exiting Connection Manager ▶ In the Main Window of the Connection Manager, ● Click [Menu] and select [Exit]. ▶ Or in the Windows System Tray, ● Click the RIGHT mouse button on a miniature CM icon and select [Exit].

  • Page 35: Troubleshooting

    I clicked [Connect] in WiMAX Area in the Connection Manager, ● but my USB Modem is not trying to connect to the WiMAX network. - Check WiMAX‟s signal strength indicator in the Connection Manager. - If it is displayed as LOW, try moving to another location.

  • Page 36: Product Specification

    Product Specification Item Specification Standards IEEE 802.16e-2005 for WiMAX Mode WiMAX HSDPA 2.1GHz SWU-6400 SWU-6200 Frequency (WCDMA, HSDPA) Band 900/1800MHz 2.3GHz 2.5GHz 3.5GHz (GPRS, EDGE) Channel 5, 8.75, 5, 10MHz 3.5, 5, 7, 10MHz Bandwidth 10MHz 8.75,10MHz Size 35.5mm x 89mm x 12mm Weight 43.5g...

  • Page 37: Care And Maintenance

    Care and Maintenance Read following instructions carefully. It will help you protect your warranty coverage. ● Use the device in clean and dry areas. The device is not water-resistant. Dusty environments could affect electronic components. Do not disassemble the device. In need of help or repair, contact an ●...

  • Page 38: Safety Information

    Safety Information Caution ● Do not use the device in any potentially explosive/inflammable area. Abide by all instructions and signs. Do not use the device where using wireless devices is prohibited or may ● cause interference or danger, such as in hospitals and airplanes. Do not store the device near electronic appliances that generate strong ●...

  • Page 39: Legal Information

    Legal Information EU Regulatory Conformance Hereby, SEOWON INTECH Co., Ltd. declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. For the declaration of conformity, visit the Web site http://www.seowonintech.co.kr/en/customer/regulatory.asp 1588 Reduction of Hazardous Substances...

  • Page 40: Warranty Information

    Warranty Information Quality Warranty This product is the result of high-class craftsmanship based on strict quality control procedures. ● In case of Product failure or malfunction during normal usage, your product will be repaired free of charge within the Limited Warranty period. ●...
  • Page 41 Memo...
  • Page 42 Memo...
  • Page 43 Memo...
  • Page 45 SEOWON INTECH.CO.,LTD. R&D Center 689-47, Kumjung-Dong, Kunpo-City, Kyunggi-Do,435-862, Korea TEL 82-31-428-9531 FAX 82-31-428-9599 E-mail wimax@seowonintech.co.kr www.seowonintech.co.kr...
