- Page 1 User Manual...
-
Page 3: Table Of Contents
Contents Product Overview ························································· 03 Product Package Contents ········································ 03 Parts Description ······················································· 03 System Requirements ··················································· 04 Installing Seowon WiMAX CM ····································· 05 Common Operations ···················································· 08 Getting Started ·························································· 08 Connecting to Network ·············································· 09 Disconnecting from Network ····································· 11 Minimizing Compact View window ····························... -
Page 4: Product Overview
Product Overview Product Package Contents USB Modem User Manual Parts Description Lighting area USB Connector Lighting color : Powered ON Purple : Stand by Blue : Connected... -
Page 5: System Requirements
System Requirements Pentium IV Processor or faster, 128MB RAM CPU & memory or more Interface USB 2.0 Supported OS Windows XP / Windows Vista / Windows 7... -
Page 6: Installing Seowon Wimax Cm
Installing Seowon WiMAX CM ▶ Turn on your computer. Close all other applications. ▶ Insert a USB modem into your USB port. ▶ Your computer will recognize the modem and automatically start the installation. - Page 7 Installing Seowon WiMAX CM If the installation program does not launch automatically, go to My ▶ Computer. Select ‘WiMAX Installation Disk’ and double click it. [Desktop] [My Computer] [WIMAX Installation Disk] ▶ ▶...
- Page 8 Installing Seowon WiMAX CM Or you click the RIGHT mouse button on WiMAX CD drive. ▶ Select ‘Install WiMAX device’ and then the installation sequence will begin. [Desktop] [My Computer] [WIMAX Installation Disk (RIGHT ▶ ▶ mouse button)] [Install WiMAX device (Select)] ▶...
-
Page 9: Common Operations
Common Operations Getting Started To start Seowon WiMAX CM, ▶ Double click on the Seowon WiMAX CM icon on your desktop. Click [Seowon WiMAX CM] Or click on the Windows Start menu ▶ and select ‘Seowon WiMAX CM’ from the list of programs. [Start] [Program] [Seowon WiMAX CM]... -
Page 10: Connecting To Network
Common Operations Connecting to Network : EAP-TTLS ▶ After the installation is complete, enter your Log-in ID and Password. If “Save login and password” is checked, Seowon WiMAX CM will save your ID and PW. (You just need to click “connect” next time Seowon WiMAX CM launches.) ▶... - Page 11 Common Operations Connecting to Network : EAP-TLS ▶ After the installation is complete, Seowon WiMAX CM will try to connect automatically. Then, the messages of “Connecting”, “IP Obtaining…”, and ▶ “Connected to WiMAX” will appear.
-
Page 12: Disconnecting From Network
Common Operations Disconnecting from Network If you want to end your current connection, simply click the ▶ Disconnect “ ” button... -
Page 13: Minimizing Compact View Window
Common Operations Minimizing Compact View window You can minimize the application by clicking on ‘x’ icon in ▶ Compact View window. It will then appear in the Windows task bar. ▶ To restore Compact View window, click the Right mouse button on Seowon WiMAX tray icon, and select [Open]. -
Page 14: Extending Compact View Window
Common Operations Extending Compact View window ▶ Click on ‘ ’, at the upper right side of Compact View window. Or select [Option] on Seowon tray icon. Then, Extended View window will appear. The Extended View window includes three pages: Network, ▶... -
Page 15: Preferences In Extended View Window
Common Operations Preferences in Extended View window Network page ▶ Displays information of Maximum / Current connection speed as well as that of Received / Send. The strength of Signal (CINR/RSSI), IP-address, MAC address and BSID are also shown in Network page. Click on “Info.”... - Page 16 Common Operations Preferences in Extended View window Information page ▶ Displays information concerning Seowon WiMAX CM version, Driver version, Device S/W and Device name. ▶ If you want to visit the homepage of Seowon, click the underlined URL when you are connected.
-
Page 17: Settings Page
Common Operations Preferences in Extended View window Settings Page ▶ Allows you to set the below functions. Auto Launch ▶ Seowon WiMAX CM launches automatically when Windows starts. Auto Connect ▶ Seowon WiMAX CM connects to the Internet automatically when it launches. -
Page 18: Upgrading The Usb Modem
Common Operations Upgrading the USB Modem Update for Seowon WiMAX CM ▶ In case “Notify update a new S/W” is checked in the setting page ▶ (see page15), it will automatically tell you whether updates are available when you are connected. the Internet. - Page 19 Common Operations Upgrading the USB Modem Update for Seowon WiMAX CM cont. ▶ If “Notify update” is unchecked (see page15), go to the Information page. Click the “Check for Update” button as below. If update detected, click the “Update” button to upgrade Seowon WiMAX CM.
-
Page 20: Firmware Update
Common Operations Upgrading the USB Modem Firmware Update ▶ When you for the first time installed Seowon WiMAX CM or when ▶ update is completed, Seowon’s software automatically checks if there is updatable Firmware available. Click the “Update” button to upgrade the firmware if available. ▶... -
Page 21: Exiting Connection Manager
Common Operations Exiting Connection Manager ▶ lick the Right mouse button on Seowon WiMAX tray icon, and select [Close]. Click [Close] ▶ Click the right mouse button on Seowon WiMAX tray icon. When the Pop-up menu appears, select [Exit]. Click [Exit]... -
Page 22: System Requirements (Mac Os X)
System Requirements (MAC OS X) CPU & memory Intel Core 2 Duo or faster, DDR2 or more Interface USB 2.0 Supported OS Mac OS X version 10.5.3 or more... -
Page 23: Installing Seowon Wimax Cm (Mac Os X)
Installing Seowon WiMAX CM (MAC OS X) Turn on your computer. Close all other applications. ▶ Insert a USB modem into your USB port. ▶ Your computer will recognize the modem. ▶ ▶ Please click on the CD-shaped icon and the installation. - Page 24 Installing Seowon WiMAX CM (MAC OS X) Getting Started and Uninstall To start WiMAX CM, ▶ Double click on the Seowon WiMAX CM icon on your Applications. Click [WiMAX CM] Click [GdmUninstall]...
-
Page 25: Common Operations (Mac Os X)
Common Operations (MAC OS X) Connecting to Network ▶ After the installation is complete, Seowon WiMAX CM will try to connect automatically. ▶ Then, the messages of “Connecting”, “IP Obtaining…”, and “Connected to WiMAX” will appear. -
Page 26: Product Specification
Product Specification Item Specification Standards IEEE 802.16e Model SWU-3400AN Frequency Band Wide Band (2.496~2.690GHz) Channel 5 and 10MHz Bandwidth Size 32mm x 67mm x 8.8mm Weight Output Power 200mW (23dBm) Operating - 10degree ~ + 50degree Temperature Relative 0% ~ 85% Humidity... -
Page 27: Care And Maintenance
Care and Maintenance Read following instructions carefully. It will help you protect your warranty coverage. Use the device in clean and dry areas. The device is not water- ▶ resistant. Dusty environments could affect electronic components. Do not disassemble the device. In need of help or repair, contact ▶... -
Page 28: Safety Information
Safety Information Caution Do not use the device in any potentially explosive/inflammable ▶ area. Abide by all instructions and signs. Do not use the device where using wireless devices is prohibited ▶ or may cause interference or danger, such as in hospitals and airplanes. -
Page 29: Legal Information
Legal Information FCC ID : V7MSWU-3400AN FCC Part 15.19 This device complies with part 15 of the FCC Rules. Operation is subject to The following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. -
Page 30: Warranty Information
Warranty Information Quality Warranty This product is the result of high-class craftsmanship based on strict quality control procedures. • In case of Product failure or malfunction during normal usage, your product will be repaired free of charge within the Limited Warranty period. •... - Page 32 SEOWON INTECH.CO.,LTD. R&D Center 689-47, Kumjung-Dong, Kunpo-City, Kyunggi-Do,435-862, Korea TEL 82-31-428-9531 FAX 82-31-428-9599 E-mail wimax@seowonintech.co.kr www.seowonintech.co.kr...
