- Page 1 TA-COMP10 Direct Drive Compressor Operating Manual...
-
Page 2: Table Of Contents
Index Important Safety Instructions Electrical Safety Use of Extension Cords General Safety Rules Assembly & Operating Instructions Automatic On/Off Switch Overload Protection Reset Procedure Pressure Regulator Pressure Gauges Safety Valve Shutting Down Your Compressor Environmental Responsibilities Maintenance The Compressor & Its Components Trouble Shooting... -
Page 3: Important Safety Instructions
Important Safety Instructions When using this product, basic safety precautions should always be followed, including – DO NOT OPERATE A COMPRESSOR WHEN UNDER THE INFLUENCE OF ALCOHOL OR DRUGS. 1) Read all instructions prior to using the product. 2) To reduce the risk of injury, close supervision is necessary when the compressor is in use near children or infirm persons. -
Page 4: General Safety Rules
General Safety Rules. ear and eye protection 1) Always wear when you use this product, or are in the vicinity of the product when it is use. 2) Do not use the compressor in areas near combustible materials, combustible fumes or dust. respirator or mask 3) Always use a when spray painting or whenever there is a possibility vapors... -
Page 5: Assembly & Operating Instructions
Assembly & Operating Instructions. 1) Remove all parts from the carton and layout in a clear, level and dust free space. 2) Attach wheels and axle assemblies using bolts, washers and nuts supplied. Wheel Assembly. 3) Handle welded to tank. Handle Assembly. - Page 6 6) Ensure oil is added from the bottle supplied until the marker in the sight glass is level with the red indicator line. Sight Glass Empty Sight Glass Overfull Sight Glass Correct Sight Glass 7) When the correct amount of oil has been added, screw the BREATHER PLUG SUPPLIED back into position as shown below.
-
Page 7: Automatic On/Off Switch
Automatic On / Off The compressor is equipped with an automatic On/Off pressure switch. The compressor will only run when the switch is in the “I” or “On” position. Once the tank has reached the maximum preset pressure, the pump will automatically shut off. The pump will automatically turn back on once the pressure in the tank drops below the minimum preset pressure. -
Page 8: Pressure Regulator
Pressure Regulator This compressor is fitted with an Air Pressure Regulator. It allows regulation of the output air pressure. Some air tools require a higher operating pressure than others. Please refer to the air pressure requirements of your tools for the proper settings for the regulator. NOTE. -
Page 9: Shutting Down Your Compressor
Shutting Down Your Compressor When you have finished using your compressor, follow these steps: 1) Close the air outlet taps. 2) Switch off the compressor. 3) Disconnect tools and/or accessories from the air hose. 4) Disconnect the air hose. 5) Locate the drain valve on the underside of the tank. 6) Open the drain valve to release remaining pressurised air from within the tank. -
Page 10: The Compressor & Its Components
The Compressor & Its Components Air Filter On/Off Switch Regulator Inlet Outlet Tool Pressure Gauge Tank Pressure Gauge Tank Drain... -
Page 11: Trouble Shooting
Trouble Shooting Trouble Possible Cause Possible Remedy Not connected to power Check connection supply Motor will restart when pressure Compressor will not start Tank full of air drops below preset minimum On/Off Switch in "Off" position Set switch to "On" position Trouble Possible Cause Possible Remedy...
