  • Page 2 SHIELD SmartCam USER MANUAL Limited Warranty Terms & Conditions Rosewill Limited warrants this product against defects in workmanship and material for a period of one (1) year from its original purchase date. You must present your receipt as proof of date of purchase for warranty validation. Any unit which proves defective during the stated period will be repaired without charge for parts or labor or replaced at the sole discretion of Rosewill.

  • Page 3: Table Of Contents

    SHIELD SmartCam USER MANUAL CONTENT CONTENT PRODUCT INTRODUCTION VERVIEW ACKAGE ONTENT LAN) NSTALLATION UIDE IRED ONNECTION TO THE SHIELD OFTWARE NSTALLATION SHIELD NSTALLING EYE ON YOUR INDOWS EFAULT SERNAME AND ASSWORD SHIELDEYE LIVEWATCH UI DDING TO THE AMERA ATCH IDEO AND...

  • Page 4: Product Introduction

    SHIELD SmartCam USER MANUAL Congratulations on your purchase of this SHIELD Pan & Tilt IP camera. With this IP camera, you can secure your home day and night, watch your pets and family everywhere and every moment you want, and interact with your families anytime by online with smart phone viewing.

  • Page 5: Package Content

    SHIELD SmartCam USER MANUAL Package Content What’s in the box IP camera * 1 CD * 1 5V Power Adapter * 1 Bracket * 1 Network Cable * 1 Antenna * 1 User Manual * 1 If any of the items are missing, please contact your reseller.

  • Page 6: Installation Guide (Wired Connection To The Lan)

    SHIELD SmartCam USER MANUAL Installation Guide (Wired Connection to the LAN) 1. Connect the power adapter to the camera’s DC in port and plug the power adapter to an electrical outlet. 2. Connect the camera’s Network port to any available LAN port on your wireless router with supplied Ethernet cable.

  • Page 7: Shieldeye Software Installation

    SHIELD SmartCam USER MANUAL SHIELDeye Software Installation The camera is equipped with SHIELDeye software. SHIELDeye is an easy way for users to set up and control the camera that is connected on your home network from your computer. SHIELDeye allows you to connect multiple IP cameras, simultaneously record and playback videos you have just taken while your current recordings continue uninterrupted.

  • Page 8: Shieldeye Livewatch Ui

    The camera contains a unique device ID (DID) code that’s embedded on a QR code sticker. The DID helps you to connect your PC or Smart phone to the camera in just a few simple steps using SHIELD’s Peer-to-Peer (P2P) network technology. ...
  • Page 9 SHIELD SmartCam USER MANUAL Select to add your devices. (Option 2 is suggested) Select Smart P2P and Search Enter the Account and Password. Default: admin, 123456 then Save The camera you just added shows here. Make sure box with * are...

  • Page 10: Watch Your Video And Settings

    SHIELD SmartCam USER MANUAL Watch Your Video and Settings Right click “Play Video” or Double click the camera to start the video. Basic Camera Controls You can control the image, audio, PTZ or others basic setting of your camera while you are watching the video via the functions below.

  • Page 11: Local Menu

    SHIELD SmartCam USER MANUAL Local Menu Play All Devices in the List Stop All Devices in the List Eyeplayer is playback of recording Multiple Image Window Device Log records video history Full Screen Mode System Setting Set up Trigger Alarm options...

  • Page 12: Camera Wifi Setup

    SHIELD SmartCam USER MANUAL Camera WiFi Setup So, you have got the camera installed successfully and been able to view what you want via the network but you may also want to avoid the cable running down the hallway? You could setup your IP camera wirelessly.
  • Page 13 SHIELD SmartCam USER MANUAL 3. After entering the Setup, click Network in the left. You can either choose Dynamic IP Address to enable DHCP or either the Fixed IP Address for static IP to input the IP address your ISP provides and enter HTTP Port as SearchTool shown, RTSP Port:554 as default.

  • Page 14: Connect By Iphone Or Android Smartphone

    SHIELD SmartCam USER MANUAL Connect by iPhone or Android Smartphone Go to the Apple App Store or Google Play, search for SHIELDeye and download it for free and start watching live camera videos from your mobile device. Make sure you download the latest version of the SHIELDeye app. The following images are captured from the iOS version of the mobile app.

  • Page 15: Shieldeye App Interface

    SHIELD SmartCam USER MANUAL SHIELDeye App Interface 1. Camera: View camera list and setting some functions of the camera. 2. Pictures: View the snapshots of the mobile phone at viewing video. 3. Records: View recording file in mobile phone, and in storage card of remote camera when you view video.

  • Page 16: Shieldeye App Camera Setup

    SHIELD SmartCam USER MANUAL SHIELDeye App Camera Setup Before you can actually start watching anything on your smartphone, you need to first register the camera with the app as following: Adding a Camera via Smartphone 3 methods to add cameras:...

  • Page 17: Shieldeye App Introduction

    SHIELD SmartCam USER MANUAL SHIELDeye App Introduction Tilt Cruise Pan Cruise PTZ setting Flip Mirror Quit Resolution Snapshot Record Listen Talk Contrast Brightness Default Anamorphic Setting Note: Clicking Default, Note: If the video lags, we the screen may return to suggest you to change the default.

  • Page 18: Advanced Settings

    SHIELD SmartCam USER MANUAL Advanced Settings WiFi Setting Advanced Setting In WiFi Setting, you can search for Enter to the following screen to setup the available WiFi SSID automatically for the Advanced Setting. IP camera to connect to. Time Setting...
  • Page 19 SHIELD SmartCam USER MANUAL FTP Setting Alarm Setting Click FTP Setting, you need to setup You can setup Motion Detect Armed, user information of FTP server in here Alarm input Armed, IO Linkage on Alarm before you start it. and Alarmed Mail Notification.

  • Page 20: Accessing The Camera Via Web Browser

    SHIELD SmartCam USER MANUAL Accessing the Camera via Web Browser Open a web browser such as Internet Explorer (IE), Chrome, Firefox or Safari and enter the IP address of your camera in the address bar. Make sure your camera is connected to the network, otherwise nothing will show up.

  • Page 21: More > Media Setting

    SHIELD SmartCam USER MANUAL More > Media Setting Video Settings We recommend you to use 60Hz for stable frequency. Higher Bit Rate provides higher resolution of videos, but also takes more bandwidth. Please adjust Data rate based to your network and storage size for recordings.

  • Page 22: Image Settings

    SHIELD SmartCam USER MANUAL Image Settings Double click to full screen : Long click to control the angle of camera More > Alarm Setting The camera can equipped with external alarm devices. Connect an external alarm detector to the input port, and the detector will send the signal when it detects any motions.

  • Page 23: Motion Detection

    SHIELD SmartCam USER MANUAL Motion Detection This size of detection area and position can be customized. Remember to click Apply after the settings are done, and motion detection starts to work. The higher value it represents, the higher sensitive it is. The camera will trigger on the alarm when any motion occurs in the detection area.

  • Page 24: Schedule Setting

    SHIELD SmartCam USER MANUAL Schedule Setting The alarm will be triggered only during the scheduled periods. You can select the scheduled periods you desire. You only need to click the corresponding time boxes to set them, and the time boxes will become green when you selected.

  • Page 25: Technical Support Details

    SHIELD SmartCam USER MANUAL Technical Support Details SHIELD Technical Support Global E-mail: techsupport@rosewill.com http://www.rosewill.com...

  • Page 26: Appendix

    SHIELD SmartCam USER MANUAL Appendix Connecting to WAN Connecting to WAN is the way for users who want to view by their desktops or notebooks. The settings will be complicated and differ from various wireless routers. If users only intend to view by smartphones or other mobile devices, we suggest users to follow P14 for mobile devices settings.
