- Page 2 SHIELD SmartCam USER MANUAL Limited Warranty Terms & Conditions Rosewill Limited warrants this product against defects in workmanship and material for a period of one (1) year from its original purchase date. You must present your receipt as proof of date of purchase for warranty validation. Any unit which proves defective during the stated period will be repaired without charge for parts or labor or replaced at the sole discretion of Rosewill.
-
Page 3: Table Of Contents
SHIELD SmartCam USER MANUAL CONTENT CONTENT PRODUCT INTRODUCTION VERVIEW ACKAGE ONTENT LAN) NSTALLATION UIDE IRED ONNECTION TO THE SHIELD OFTWARE NSTALLATION SHIELD NSTALLING EYE ON YOUR INDOWS EFAULT SERNAME AND ASSWORD SHIELDEYE LIVEWATCH UI DDING TO THE AMERA ATCH IDEO AND... -
Page 4: Product Introduction
SHIELD SmartCam USER MANUAL Congratulations on your purchase of this SHIELD Pan & Tilt IP camera. With this IP camera, you can secure your home day and night, watch your pets and family everywhere and every moment you want, and interact with your families anytime by online with smart phone viewing. -
Page 5: Package Content
SHIELD SmartCam USER MANUAL Package Content What’s in the box IP camera * 1 CD * 1 5V Power Adapter * 1 Bracket * 1 Network Cable * 1 Antenna * 1 User Manual * 1 If any of the items are missing, please contact your reseller. -
Page 6: Installation Guide (Wired Connection To The Lan)
SHIELD SmartCam USER MANUAL Installation Guide (Wired Connection to the LAN) 1. Connect the power adapter to the camera’s DC in port and plug the power adapter to an electrical outlet. 2. Connect the camera’s Network port to any available LAN port on your wireless router with supplied Ethernet cable. -
Page 7: Shieldeye Software Installation
SHIELD SmartCam USER MANUAL SHIELDeye Software Installation The camera is equipped with SHIELDeye software. SHIELDeye is an easy way for users to set up and control the camera that is connected on your home network from your computer. SHIELDeye allows you to connect multiple IP cameras, simultaneously record and playback videos you have just taken while your current recordings continue uninterrupted. -
Page 8: Shieldeye Livewatch Ui
The camera contains a unique device ID (DID) code that’s embedded on a QR code sticker. The DID helps you to connect your PC or Smart phone to the camera in just a few simple steps using SHIELD’s Peer-to-Peer (P2P) network technology. ... - Page 9 SHIELD SmartCam USER MANUAL Select to add your devices. (Option 2 is suggested) Select Smart P2P and Search Enter the Account and Password. Default: admin, 123456 then Save The camera you just added shows here. Make sure box with * are...
-
Page 10: Watch Your Video And Settings
SHIELD SmartCam USER MANUAL Watch Your Video and Settings Right click “Play Video” or Double click the camera to start the video. Basic Camera Controls You can control the image, audio, PTZ or others basic setting of your camera while you are watching the video via the functions below. -
Page 11: Local Menu
SHIELD SmartCam USER MANUAL Local Menu Play All Devices in the List Stop All Devices in the List Eyeplayer is playback of recording Multiple Image Window Device Log records video history Full Screen Mode System Setting Set up Trigger Alarm options... -
Page 12: Camera Wifi Setup
SHIELD SmartCam USER MANUAL Camera WiFi Setup So, you have got the camera installed successfully and been able to view what you want via the network but you may also want to avoid the cable running down the hallway? You could setup your IP camera wirelessly. - Page 13 SHIELD SmartCam USER MANUAL 3. After entering the Advanced Settings, you can find the Network Configuration in the left. Click on the Basic Network Settings, you can either choose DHCP or enter the Static IP connection which is applied to your wireless network and while using Static IP, enter the Http port as SearchTool shown for the IP camera.
-
Page 14: Connect By Iphone Or Android Smartphone
SHIELD SmartCam USER MANUAL Connect by iPhone or Android Smartphone Go to the Apple App Store or Google Play, search for SHIELDeye and download it for free and start watching live camera videos from your mobile device. Make sure you download the latest version of the SHIELDeye app. The following images are captured from the iOS version of the mobile app. -
Page 15: Shieldeye App Interface
SHIELD SmartCam USER MANUAL SHIELDeye App Interface 1. Camera: View camera list and setting some functions of the camera. 2. Pictures: View the snapshots of the mobile phone at viewing video. 3. Records: View recording file in mobile phone, and in storage card of remote camera when you view video. -
Page 16: Shieldeye App Camera Setup
SHIELD SmartCam USER MANUAL SHIELDeye App Camera Setup Before you can actually start watching anything on your smartphone, you need to first register the camera with the app as following: Adding a Camera via Smartphone 3 methods to add cameras:... -
Page 17: Shieldeye App Introduction
SHIELD SmartCam USER MANUAL SHIELDeye App Introduction Tilt Cruise Pan Cruise PTZ setting Flip Mirror Quit Resolution Snapshot Record Listen Talk Contrast Brightness Default Anamorphic Setting Note: Clicking Default, Note: If the video lags, we the screen may return to suggest you to change the default. -
Page 18: Advanced Settings
SHIELD SmartCam USER MANUAL Advanced Settings WiFi Setting Advanced Setting In WiFi Setting, you can search for Enter to the following screen to setup the available WiFi SSID automatically for the Advanced Setting. IP camera to connect to. User Setting... - Page 19 SHIELD SmartCam USER MANUAL Alarm Setting FTP Setting You can setup Motion Detect Armed, Click FTP Setting, you need to setup Alarm input Armed, IO Linkage on Alarm user information of FTP server in here and Alarmed Mail Notification. before you start it.
-
Page 20: Accessing The Camera Via Web Browser
SHIELD SmartCam USER MANUAL Accessing the Camera via Web Browser Open a web browser such as Internet Explorer (IE), Chrome, Firefox or Safari and enter the IP address of your camera in the address bar. Make sure your camera is connected to the network, otherwise nothing will show up. -
Page 21: Setting Up Email Alerts Via Web Browser (1/2)
SHIELD SmartCam USER MANUAL Setting up Email Alerts via Web Browser (1/2) When you camera detects some events, it can send alert and snapshots to your appointed email address. Please configure your email service details correctly and motion detection via camera’s web interface. -
Page 22: Setting Up Email Alerts Via Web Browser (2/2)
SHIELD SmartCam USER MANUAL Setting up Email Alerts via Web Browser (2/2) When you have completed the email configuration, click the Setup button to save your settings. Enable Motion Detection, Email Notifications and Schedules Now that your email account has been set up, it’s time to configure the motion detection settings of your camera. -
Page 23: Technical Support Details
SHIELD SmartCam USER MANUAL Technical Support Details SHIELD Technical Support Global E-mail: techsupport@rosewill.com http://www.rosewill.com... -
Page 24: Appendix
SHIELD SmartCam USER MANUAL Appendix Connecting to WAN Connecting to WAN is the way for users who want to view by their desktops or notebooks. The settings will be complicated and differ from various wireless routers. If users only intend to view by smartphones or other mobile devices, we suggest users to follow P14 for mobile devices settings.
