Signal Flow Schematic; Technical Specs - Matrix Elements VB-800 Field Manual

Technical Specs:

Number of Channels:
Pre-Amp section:
Tone Controls:
Power Section:
Dimemsions:
Weight:
Supply Voltage:
Average Supply Current:
Mains Connector:
Input Impedance:
Effects Send:
Effects Return:
Effects Send Level:

SIGNAL FLOW SCHEMATIC

Low Input
1
x2 ECC83/12AX7 valves
Passive (Bass, Mid, High)
MosFet powered delivering
@ 16 ohms: 150W
@ 8 ohms: 300W
@ 4 0hms: 420W
304mm x 185mm x 80mm (w
11.8" x 7.09" x 3.15" (w
1.8kg / 4lbs
110v/230v +/- 15%
5A/2.5A (Full Load 110/240v)
10A IEC
1M ohm
3K ohm
10K ohm
0v - 1v (0 to +6db)
10
d h)
x x
d h)
x x
