Summary of Contents for Seagate ST400FM0093
- Page 1 Limited Warranty with Media Usage 2.5” models Media Usage Media Usage 2.5” models 1.8” models 2.5” models Standard drives ST800FM0013 Standard drives Standard drives Standard drives ST400FM0093 ST800FM0043 ST400FM0013 ST400FM0063 ST200FM0093 ST400FM0053 ST200FM0013 ST200FM0063 ST100FM0093 ST200FM0053 Self-Encrypting drives ST800FM0023 Self-Encrypting drives...
- Page 2 Publication number: 100708406, Rev. C October 2014 Seagate, Seagate Technology and the Wave logo are registered trademarks of Seagate Technology LLC in the United States and/or other countries. Seagate 1200 SSD and SeaTools are either trademarks or registered trademarks of Seagate Technology LLC or one of its affiliated companies in the United States and/or other countries.
-
Page 3: Table Of Contents
Seagate® Technology Support Services ........ - Page 4 Installation..............55 Seagate 1200 SSD Product Manual, Rev. C...
- Page 5 Additional information ........... . 77 Seagate 1200 SSD Product Manual, Rev. C...
- Page 6 SAS transmitters and receivers ..........75 Seagate 1200 SSD Product Manual, Rev. C...
-
Page 7: Seagate Technology Support Services
Authorized Service Centers • Warranty terms will vary based on type of warranty chosen: “Managed Life” or “Limited Warranty with Media Usage”. Consult the Seagate sales representative for warranty terms and conditions. For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/... -
Page 8: Scope
1200 SSD (Serial Attached SCSI) drives. Seagate 1200 SSD drives support the SAS Protocol specifications to the extent described in this manual. The SAS Interface Manual (part number 100293071) describes the general SAS characteristics of this and other Seagate SAS drives. The Self- Encrypting Drive Reference Manual, part number 100515636, describes the interface, general operation, and security features available on Self-Encrypting Drive models. -
Page 9: Applicable Standards And Reference Documentation
Section 10.3. Standards The Seagate 1200 SSD family complies with Seagate standards as noted in the appropriate sections of this manual and the Seagate SAS Interface Manual, part number 100293071. The drives are recognized in accordance with UL 60950-1 as tested by UL, CSA 60950-1 as tested by CSA, and EN60950-1 as tested by TUV. -
Page 10: European Union Restriction Of Hazardous Substances (Rohs)
Lead (Pb), in electronic products effective July 2006. A number of parts and materials in Seagate products are procured from external suppliers. We rely on the representations of our suppliers regarding the presence of RoHS substances in these parts and materials. Our supplier contracts require compliance with our chemical substance restrictions, and our suppliers document their compliance with our requirements by providing material content declarations for all parts and materials for the disk drives documented in this publication. -
Page 11: Reference Documents
TCG Storage Architecture Core Specification, Rev. 1.0 TCG Storage Security Subsystem Class Enterprise Specification, Rev. 1.0 Self-Encrypting Drives Reference Manual Seagate part number: 100515636 In case of conflict between this document and any referenced document, this document takes precedence. Seagate 1200 SSD Product Manual, Rev. C... -
Page 12: General Description
General description Seagate 1200 SSD drives provide high performance, high capacity data storage for a variety of systems with a Serial Attached SCSI (SAS) interface. The Serial Attached SCSI interface is designed to meet next-generation computing demands for performance, scalability, flexibility and high-density storage requirements. -
Page 13: Media Description
To provide a stable target capacity environment and at the same time provide users with flexibility if they choose, Seagate recommends product planning in one of two modes: Seagate designs specify capacity points at certain block sizes that Seagate guarantees current and future products will meet. -
Page 14: Factory-Installed Options
In order to determine if Thin Provisioning is supported and what features of it are implemented requires the system to send a READ CAPACITY 16 (9Eh) command to the drive. Thin Provisioning and the READ CAPACITY 16 (9Eh) command is defined in the Seagate SCSI Command Reference 100293068. Product Configuration... - Page 15 DATA Returned for 0x00 0x00 0x00 Random None Random Thin Provisioned LBA PI Returned for Scrambled None 0xFF 0xFF None None Thin Provisioned LBA PI data PI Check Performed Error reported to Host Seagate 1200 SSD Product Manual, Rev. C...
-
Page 16: Performance Characteristics
Performance characteristics This section provides detailed information concerning performance-related characteristics and features of Seagate 1200 SSD drives. Internal drive characteristics Flash Memory Type NAND MLC Emulated LBA Size 512, 520, 524, 528, 4096, 4160, 4192 or 4224 Native Programmable Page Size... -
Page 17: Format Unit Command Execution Time For 512-Byte Lba's (Minutes)
(MB/s) Peak 4KB random read/write command rate (IOPs) 110,000/40,000 110,000/25,000 Sustained 4KB random read/write command rate (IOPs) Sustainable 4KB Random combined 60,000 50,000 IOPS for 5 year Endurance (65%/35% R/W, 70% Duty Cycle) Seagate 1200 SSD Product Manual, Rev. C... - Page 18 Peak 4KB random read/write 110,000/50,000 110,000/50,000 command rate (IOPs) Sustained 4KB random read/write 110,000/15,000 110,000/7500 110,000/3700 command rate (IOPs) Sustainable 4KB Random combined 70,000 60,000 IOPS for 5 year Endurance (65%/35% R/W, 70% Duty Cycle) Seagate 1200 SSD Product Manual, Rev. C...
-
Page 19: Start/Stop Time
The START STOP UNIT command may be used to command the drive to stop. Stop time is 3 seconds (maximum) from removal of DC power. SCSI stop time is 3 seconds. There is no power control switch on the drive. Seagate 1200 SSD Product Manual, Rev. C... -
Page 20: Cache Control
When prefetch (read look-ahead) is enabled (enabled by DRA = 0), the drive enables prefetch of contiguous blocks from the medium when it senses that a prefetch hit will likely occur. The drive disables prefetch when it decides that a prefetch hit is not likely to occur. Seagate 1200 SSD Product Manual, Rev. C... -
Page 21: Reliability Specifications
JEDEC Specification JESD218. TBW is defined as 1x10 Bytes. 4. Limited Warranty with Media Usage provides coverage for the warranty period or until the SSD Percentage Used Endurance Indicator, as defined in Section 5.2.7, reaches 100 whichever comes first. Seagate 1200 SSD Product Manual, Rev. C... -
Page 22: Error Rates
Garbage Collection is automatically managed by the drive and requires no user interaction. The Seagate algorithm is tuned to operate only when needed to ensure reliable product operation. -
Page 23: Data Retention
Additionally, the Data Retention spec of the SSD needs to be considered to ensure the spec is met once the drive is worn out. Seagate has implemented a Lifetime Endurance Management technique which helps OEMS and user to avoid early wear out. -
Page 24: S.m.a.r.t
If the number of errors does not exceed the threshold before the interval expires, the error rate is considered to be acceptable. In either case, the interval and failure counters are reset and the process starts over. Seagate 1200 SSD Product Manual, Rev. C... -
Page 25: Thermal Monitor
If DST encounters an error during either of these tests, it reports a "diagnostic failed" condition. If the drive fails the test, remove it from service and return it to Seagate for service. 5.3.6.1 DST failure definition The drive will present a “diagnostic failed”... - Page 26 DST. If the field is not set to zero, the test failed for the reason reported in the field. The drive will report the failure condition and LBA (if applicable) in the Self-test Results Log parameter. The Sense key, ASC, ASCQ, and FRU are used to report the failure condition. Seagate 1200 SSD Product Manual, Rev. C...
-
Page 27: Product Warranty
Shipping When transporting or shipping a drive, use only a Seagate-approved container. Keep the original box. Seagate approved containers are easily identified by the Seagate Approved Package label. Shipping a drive in a non-approved container voids the drive warranty. Seagate repair centers may refuse receipt of components improperly packaged or obviously damaged in transit. Contact the authorized Seagate distributor to purchase additional boxes. -
Page 28: Physical/Electrical Specifications
• Idle mode power Idle mode power is measured with the drive powered up and ready for media access commands, with no media access commands having been received from the host. AC power requirements None. Seagate 1200 SSD Product Manual, Rev. C... -
Page 29: Dc Power Requirements
Maximum DC 3 0.75 0.24 6.63 Maximum (peak) DC 3 0.98 0.50 Operating current (sequential write) Typical DC 0.56 0.38 7.36 DC Maximum DC 3 0.75 0.40 8.55 Maximum (peak) DC 3 0.96 0.86 Seagate 1200 SSD Product Manual, Rev. C... - Page 30 Maximum DC 3 0.55 0.18 4.91 Maximum (peak) DC 3 1.03 0.36 Operating current (sequential write) Typical DC 0.52 0.30 6.20 DC Maximum DC 3 0.55 0.31 6.47 Maximum (peak) DC 3 1.03 0.71 Seagate 1200 SSD Product Manual, Rev. C...
- Page 31 Maximum DC 3 0.60 0.18 5.16 Maximum (peak) DC 3 0.82 0.34 Operating current (sequential write) Typical DC 0.48 0.24 5.28 DC Maximum DC 3 0.58 0.25 5.90 Maximum (peak) DC 3 1.04 0.56 Seagate 1200 SSD Product Manual, Rev. C...
- Page 32 Maximum DC 3 0.58 0.24 5.78 Maximum (peak) DC 3 0.95 0.44 Operating current (sequential write) Typical DC 0.52 0.38 7.16 DC Maximum DC 3 0.57 0.40 7.65 Maximum (peak) DC 3 0.82 0.86 Seagate 1200 SSD Product Manual, Rev. C...
- Page 33 Maximum DC 3 0.53 0.18 4.81 Maximum (peak) DC 3 0.73 0.36 Operating current (sequential write) Typical DC 0.47 0.30 5.95 DC Maximum DC 3 0.52 0.31 6.32 Maximum (peak) DC 3 0.74 0.68 Seagate 1200 SSD Product Manual, Rev. C...
- Page 34 Maximum DC 3 0.60 0.18 5.16 Maximum (peak) DC 3 0.82 0.34 Operating current (sequential write) Typical DC 0.47 0.24 5.23 DC Maximum DC 3 0.58 0.25 5.90 Maximum (peak) DC 3 1.04 0.51 Seagate 1200 SSD Product Manual, Rev. C...
- Page 35 Maximum DC 3 0.96 0.38 5.07 Maximum (peak) DC 3 1.14 0.85 Operating current (sequential write) Typical DC 0.79 0.75 6.36 DC Maximum DC 3 0.92 0.77 6.89 Maximum (peak) DC 3 1.50 1.82 Seagate 1200 SSD Product Manual, Rev. C...
- Page 36 Where multiple units are powered on simultaneously, the peak starting current must be available to each device. 4. Parameters, other than start, are measured after a 10-minute warm up. Seagate 1200 SSD Product Manual, Rev. C...
-
Page 37: Conducted Noise Immunity
The drive does not require power sequencing. The drive protects against inadvertent writing during power-up and down. 6.3.3 Current profiles The +12V and +5V current profiles for the Seagate 1200 SSD 2.5” drives are shown below. Figure 1. Current profiles for 800GB standard and 400GB High Endurance models... -
Page 38: Figure 2. Current Profiles For 400Gb Standard And 200Gb High Endurance Models
Figure 2. Current profiles for 400GB standard and 200GB high endurance models Figure 3. Current profiles for 200GB standard and 100GB high endurance models Seagate 1200 SSD Product Manual, Rev. C... -
Page 39: Figure 4. Current Profiles For 400Gb 1.8" Models
Figure 4. Current profiles for 400GB 1.8” models Figure 5. Current profiles for 200GB 1.8” models Seagate 1200 SSD Product Manual, Rev. C... -
Page 40: Power Dissipation
I/O rate for a drive in the system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 7. 400GB (at 6Gb) DC current and power vs. input/output operations per second Seagate 1200 SSD Product Manual, Rev. C... -
Page 41: Figure 8. 200Gb (At 6Gb) Dc Current And Power Vs. Input/Output Operations Per Second
I/O rate for a drive in the system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 9. 400GB (at 6Gb) DC current and power vs. input/output operations per second Seagate 1200 SSD Product Manual, Rev. C... -
Page 42: Figure 10. 200Gb (At 6Gb) Dc Current And Power Vs. Input/Output Operations Per Second
I/O rate for a drive in the system on the horizontal axis and read the corresponding +5 volt current, +12 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 11. 100GB (at 6Gb) DC current and power vs. input/output operations per second Seagate 1200 SSD Product Manual, Rev. C... -
Page 43: Figure 12. 400Gb (At 6Gb) Dc Current And Power Vs. Input/Output Operations Per Second
I/O rate for a drive in the system on the horizontal axis and read the corresponding +3.3 volt current, +5 volt current, and total watts on the vertical axis. To calculate BTUs per hour, multiply watts by 3.4123. Figure 13. 200GB (at 6Gb) DC current and power vs. input/output operations per second Seagate 1200 SSD Product Manual, Rev. C... -
Page 44: Environmental Limits
–40° to 158°F (–40° to 70°C) package ambient with a maximum gradient of 36°F (20°C) per hour. This specification assumes that the drive is packaged in the shipping container designed by Seagate for use with drive. Figure 14. Temperature check point location - 1.8-inch drives Figure 15. -
Page 45: Relative Humidity
Packaged Seagate finished drive bulk packs are designed and tested to meet or exceed applicable ISTA and ASTM standards. Vol- ume finished drives will be shipped from Seagate factories on pallets to minimize freight costs and ease material han- dling. -
Page 46: Figure 16. Recommended Mounting
This assumes system recov- ery routines are available. Operating abnormal translational random shaped profile 20 - 2000 Hz 11.08 GRMS This specification does not cover connection issues that may result from testing at this level. Note. Seagate 1200 SSD Product Manual, Rev. C... -
Page 47: Air Cleanliness
The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. Materials used in cabinet fabrication, such as vulcanized rubber, that can outgas corrosive compounds should be minimized or eliminated. -
Page 48: Mechanical Specifications
Refer to Figure 17 or 18 for detailed mounting configuration dimensions. See Section 10.3, “Drive mounting.” Weight: 0.353 pounds 160 grams These dimensions conform to the Small Form Factor Standard documented in SFF-8201 and Note. SFF-8223 found at www.sffcommittee.org. Figure 17. Mounting configuration dimensions (2.5” models) Seagate 1200 SSD Product Manual, Rev. C... -
Page 49: Figure 18. Mounting Configuration Dimensions (1.8" Models)
Weight: 0.220 pounds 100 grams These dimensions conform to the Small Form Factor Standard documented in SFF-8120 and Note. SFF-8144 found at www.sffcommittee.org Figure 18. Mounting configuration dimensions (1.8” models) Seagate 1200 SSD Product Manual, Rev. C... -
Page 50: About Fips
Figure 19. Example of FIPS tamper evidence labels. Image is for reference only, does not represent actual drive. Note. Seagate 1200 SSD Product Manual, Rev. C... -
Page 51: About Self-Encrypting Drives
The Trusted Computing Group (TCG) is an organization sponsored and operated by companies in the computer, storage and digital communications industry. The Seagate SED models comply with the standards published by the TCG. To use the security features in the drive, the host must be capable of constructing and issuing the following two SCSI commands: •... -
Page 52: Drive Locking
In addition to providing a locking mechanism to prevent unwanted firmware download attempts, the drive also only accepts download files which have been cryptographically signed by the appropriate Seagate Design Center. Three conditions must be met before the drive will allow the download operation: 1. -
Page 53: Power Requirements
PSID (Physical Secure ID) printed on the drive label must be provided. PSID is not electronically accessible and can only be manually read from the drive label or scanned in via the 2D barcode. Seagate 1200 SSD Product Manual, Rev. C... -
Page 54: Defect And Error Management
SCSI defect and error management involves drive internal defect/error management and SAS system error considerations (errors in communications between the initiator and the drive). In addition, Seagate provides the following technologies used to increase data integrity and drive reliability: •... -
Page 55: Auto-Reallocation
The drive will generate 8 bytes of Protection Information (e.g. 0xFFFFFFFF) to be stored on the media, but the 8 bytes will not be transferred to the host during a READ command. Type 3 - Seagate products do not support Type 3. 9.5.2 Setting and determining the current Type Level A drive is initialized to a type of PI by using the FORMAT UNIT command on a PI capable drive. -
Page 56: 10.0 Installation
10.0 Installation Seagate 1200 SSD drive installation is a plug-and-play process. There are no jumpers on the drive. SAS drives are designed to be used in a host system that provides a SAS-compatible backplane with bays designed to accommodate the drive. In such systems, the host system typically provides a carrier or tray into which the drive must be mounted. -
Page 57: Drive Mounting
(electrically isolating) method of mounting the drive in the host equipment. Increased radiated emissions may result if designers do not provide the maximum surface area ground connection between system ground and drive ground. This is the system designer’s and integrator’s responsibility. Seagate 1200 SSD Product Manual, Rev. C... -
Page 58: 11.0 Interface Requirements
11.2 Dual port support Seagate 1200 SSD SAS drives have two independent ports. These ports may be connected in the same or different SCSI domains. Each drive port has a unique SAS address. The two ports have the capability of independent port clocking (e.g. both ports can run at 12Gb/s or the first port can run at 12Gb/s while the second port runs at 6Gb/s.) The supported link rates are 1.5, 3.0, 6.0 or 12.0 Gb/s. -
Page 59: Scsi Commands Supported
11.3 SCSI commands supported Table 15 lists the SCSI commands supported by Seagate 1200 SSD drives. Table 15 Supported commands Command name Command code Supported CHANGE DEFINITION FORMAT UNIT [1] DPRY bit supported DCRT bit supported STPF bit supported IP bit supported... - Page 60 Unit Attention page (00h) Verify Error Recovery page (07h) Xor Control page (10h) Mode Sense (10) (Same Pages As Mode Sense (6)) Persistent Reserve In Read Full Status 5Eh/03h Read Keys 5Eh/00h Read Reservations 5Eh/001 Seagate 1200 SSD Product Manual, Rev. C...
- Page 61 Release (6) Release (10) Report Identifying Information A3h/05h Report LUNs Report Supported Operation Codes A3h/0Ch Report Supported Task Management Functions A3h/0Dh Request Sense Actual Retry Count bytes Extended Sense Field Pointer bytes Reserve (6) Seagate 1200 SSD Product Manual, Rev. C...
- Page 62 Write (6) Write (10) DPO bit FUA bit Write (12) Write (16) Write (32) 7Fh/000Bh Write And Verify (10) DPO bit Write And Verify (12) Write And Verify (16) Write And Verify (32) 7Fh/000Ch Seagate 1200 SSD Product Manual, Rev. C...
- Page 63 Xpwrite [1] Seagate 1200 SSD drives can format to 512, 520, 524, 528, 4096, 4160, 4192 and 4224 bytes per logical block. [2] Warning. Power loss during a firmware upgrade can result in firmware corruption. This usually makes the drive inoper- able.
-
Page 64: 11.3.1 Inquiry Data
53 54 32 30 30 46 4D 30 31 31 33 ST200FM0123 53 54 32 30 30 46 4D 30 31 32 33 ST100FM0013 53 54 31 30 30 46 4D 30 30 31 33 Seagate 1200 SSD Product Manual, Rev. C... -
Page 65: 11.3.2 Mode Sense Data
The following tables list the values of the data bytes returned by the drive in response to the MODE SENSE command pages for SCSI implementation (see the SAS Interface Manual ). DEF = Default value. Standard OEM drives are shipped configured this way. CHG = Changeable bits; indicates if default value is changeable. Seagate 1200 SSD Product Manual, Rev. C... - Page 66 CHG dc 01 00 0c 00 00 00 00 00 00 00 00 00 00 00 00 DEF 80 06 00 80 00 00 00 00 CHG 80 06 b7 80 00 00 00 00 Seagate 1200 SSD Product Manual, Rev. C...
- Page 67 CHG dc 01 00 0c 00 00 00 00 00 00 00 00 00 00 00 00 DEF 80 06 00 80 00 00 00 00 CHG 80 06 b7 80 00 00 00 00 Seagate 1200 SSD Product Manual, Rev. C...
- Page 68 CHG dc 01 00 0c 00 00 00 00 00 00 00 00 00 00 00 00 DEF 80 06 00 80 00 00 00 00 CHG 80 06 b7 80 00 00 00 00 Seagate 1200 SSD Product Manual, Rev. C...
- Page 69 CHG dc 01 00 0c 00 00 00 00 00 00 00 00 00 00 00 00 DEF 80 06 00 80 00 00 00 00 CHG 80 06 b7 80 00 00 00 00 Seagate 1200 SSD Product Manual, Rev. C...
-
Page 70: Miscellaneous Operating Features And Conditions
Details of the physical, electrical, and logical characteristics are provided within this section. The operational aspects of the Seagate SAS drives are provided in the SAS Interface Manual. Figure 22. Physical interface Seagate 1200 SSD Product Manual, Rev. C... -
Page 71: Figure 23. Sas Device Plug Dimensions
0.08 (4X) 0.30 0.05 (4X) SEE Detail1 33.43 0.05 15.875 15.875 1.27 (14X) 1.27 (6X) 0.84 0.05 (22X) 5.08 0.15 B 4.90 0.08 0.35MIN C OF DATUM B Figure 23. SAS device plug dimensions Seagate 1200 SSD Product Manual, Rev. C... -
Page 72: Figure 24. Sas Device Plug Dimensions (Detail)
SECTION A - A CONTACT SURFACE FLUSH 0.08 0.05 TO DATUM A 0.03 1.90 0.08 1.23 0.05 Detail 2 0.08 0.05 2.40 0.08 0.10 A SECTION B - B Figure 24. SAS device plug dimensions (detail) Seagate 1200 SSD Product Manual, Rev. C... -
Page 73: Figure 25. Micro Sas Device Plug Dimensions
Figure 25. Micro SAS device plug dimensions Seagate 1200 SSD Product Manual, Rev. C... -
Page 74: Figure 26. Micro Sas Device Plug Dimensions (Detail)
Figure 26. Micro SAS device plug dimensions (detail) Seagate 1200 SSD Product Manual, Rev. C... -
Page 75: 11.4.2 Physical Characteristics
12 Volts * - Short pin to support hot plugging [1] Behind a SAS Drive plug connector, P1 and P2 are only connected to each other. NC - No connection in the drive. Seagate 1200 SSD Product Manual, Rev. C... -
Page 76: 11.4.6 Sas Transmitters And Receivers
11.4.6 SAS transmitters and receivers A typical SAS differential copper transmitter and receiver pair is shown in Figure 27. The receiver is AC coupling to eliminate ground shift noise. Figure 27. SAS transmitters and receivers Seagate 1200 SSD Product Manual, Rev. C... -
Page 77: 11.4.7 Power
Table 26 LED drive signal State Test condition Output voltage LED off, high 3.6 V -100 μA < I < 100 μA LED on, low = 15 mA 0.225 V Seagate 1200 SSD Product Manual, Rev. C... -
Page 78: 11.5.2 Differential Signals
Additional information Please contact the Seagate representative for SAS electrical details, if required. For more information about the Phy, Link, Transport, and Applications layers of the SAS interface, refer to the Seagate SAS Interface Manual, part number 100293071. For more information about the SCSI commands used by Seagate SAS drives, refer to the Seagate SCSI Commands Reference Manual, part number 100293068. - Page 79 Seagate Technology LLC 10200 South De Anza Boulevard, Cupertino, California 95014, United States, 408-658-1000 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100708406, Rev.
