G60UH(X) series units are mid−efficiency gas furnaces
used for upflow or horizontal applications only, manufac-
tured with Lennox Duralok Plus heat exchangers formed of
aluminized steel. G60UH(X) units are available in heating
capacities of 44,000 to 132,000 Btuh and cooling applica-
tions up to 5 tons. Refer to Engineering Handbook for prop-
er sizing.
Units are factory equipped for use with natural gas. Kits are
available for conversion to LPG operation. G60UH(X) model
units are equipped with the Two−Stage / Variable Speed Inte-
grated SureLight control. G60UH(X) unit meets the Califor-
nia Nitrogen Oxides (NO
x
sonal Efficiency requirements. All units use a redundant gas
valve to assure safety shut−off as required by C.S.A.
All specifications in this manual are subject to change. Pro-
cedures outlined in this manual are presented as a recom-
mendation only and do not supersede or replace local or
state codes. In the absence of local or state codes, the
guidelines and procedures outlined in this manual (except
where noted) are recommendations only and do not consti-
tute code.

TABLE OF CONTENTS

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
G60UH(X) SERIES UNITS
) Standards and California Sea-
. . . . . . . . . . . . . .
. . . . . . . . . . . . . .
. . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . .
Corp. 0204−L2
Revised 09−2006
G60UH−1 MODEL SHOWN
Improper installation, adjustment, alteration, service
1
or maintenance can cause property damage, person-
al injury or loss of life. Installation and service must
2
be performed by a qualified installer, service agency
5
or the gas supplier.
10
11
12
Electric shock hazard. Can cause injury
19
or death. Before attempting to perform
any service or maintenance, turn the
19
electrical power to unit OFF at discon-
20
nect switch(es). Unit may have multiple
power supplies.
22
23
25
Sharp edges.
33
Be careful when servicing unit to avoid sharp edges
which may result in personal injury.
35
Page 1
G60UH(X)
IMPORTANT
WARNING
WARNING
© 2002 Lennox Industries Inc.
