KSS-500 Home Theater
Speaker Package
Owner's
Manual
Introduction
Congratulations! The KSS-500
Home Theater Speaker Package will
bring quality sound reproduction to
your home theater system. Installing
the speakers isn't difficult, but please
read and follow all of the instruc-
tions on these pages (and in the
manual that comes with the
subwoofer) to get maximum perfor-
mance from your new speakers.
If you're also connecting other
equipment, such as a receiver,
power amplifier, or pre-amplifier,
use this manual in combination with
the manuals that came with those
components.
Unpacking
In this box you should have:
• CFS-200 Front Speakers
(1 Left and 1 Right)
• CFS-200 Center Speaker (1)
• RS-05 Surround Speakers (2)
• 8-ft lengths of speaker wire (5)
Your SW-200 Powered Subwoofer
comes in a separate box.
About the speaker wire: If you you
need longer speaker wire, we
suggest you buy wire that is 18-
gauge or thicker. Remember, the
smaller the number, the thicker the
wire—so 18-gauge is thicker than
20-gauge.
Unpack the speakers carefully, and
examine them for shipping damage.
If they are damaged or fail to oper-
ate, notify your Kenwood dealer
immediately. If they were shipped to
you directly, notify the shipping
company without delay. Only the
person or company who originally
received the speakers can file a
claim against the carrier for shipping
damage. Keep the original cartons
and packing materials in case you
need to transport or ship your
speakers in the future.

Advertisement

   Related Manuals for Kenwood KSS-500

No related manuals

   Summary of Contents for Kenwood KSS-500

  • Page 1

    20-gauge. Unpack the speakers carefully, and examine them for shipping damage. If they are damaged or fail to oper- ate, notify your Kenwood dealer immediately. If they were shipped to you directly, notify the shipping company without delay. Only the person or company who originally received the speakers can file a...

  • Page 2: Safety Precautions

    Safety first Please read these safety instructions carefully. They can help prevent electrical shock, fire, and damage to the unit. Safety symbols We’ve placed these safety symbols on the back of electrically-powered CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN units to alert you to the danger of electrical shock.

  • Page 3

    If you are not sure of the type of power supply in your home, ask your Kenwood dealer or your local power company for help. To avoid the possibility of fire or electrical...

  • Page 4

    Connecting the CFS-200 Fr to your audio system If your receiver or amplifier has a subwoofer pre-amp output: Receiver or amplifier Connect one end of the left and right speaker wires to the LEFT and – RIGHT speaker connec- tors on the receiver or –...

  • Page 5

    If your receiver or amplifier has no subwoofer pre-amp output: SW-200 Subwoofer FROM AMPLIFIER – – LINE IN POWER AUTO VOLUME PHASE LOW PASS CONTROL CROSSOVER SHUTOFF STANDBY REV NOM – – TO SPEAKERS WARNING POWER TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLICANCE TO RAIN OR MOISTURE CAUTION WARNING:...

  • Page 6

    Connecting the Center and Surround Speakers to your audio system Connect one end of the center speaker wire to the CENTER speaker connectors on the receiver or amplifier. Black – Connect one end of the surround speaker wires to the SURROUND speaker connectors on the receiver or amplifier.

  • Page 7: Surround Speakers

    Placing the CFS-200 Left and Right Speakers • Place the speakers to each side of your TV screen, near ear level. • For the best stereo effect, place the speakers at least 2 ft from the side of the TV, but not so far from it that the ‘size’...

  • Page 8

    Frequency Response Nominal Impedance Sensitivity (1 W/1 m) Dimensions Height: Width: Depth: Weight KENWOOD USA CORPORATION PO Box 22745 Long Beach, California 90801-5745 Acoustic suspension 5 " cone woofer 1 " dome tweeter 70 watts 60 Hz – 22 kHz...
