FRIEDLAND Wirefree Remote Control Installation And Operating Instructions

These instructions should be read in conjunction
with your System Installation and Operating
Manual and be retained for future reference.

Introduction

These Remote Control units are designed for use with
Friedland Response Wirefree Intruder Alarm systems
operating at 433MHz only.
Arm/
Instant-Arm
Part-Arm/
Delay-Arm
Disarm
The Remote Control Unit is used to Arm and Disarm the
system. The Remote will activate the Instant-Arm, Part-Arm
or Delay-Arm functions dependant upon which type of
system it will be used with, (refer to your System Installation
and Operating Manual).
The Remote Control also incorporates a Personal Attack
(PA) switch. Activating the PA switch will immediately
initiate a Full Alarm condition whether the system is Armed
or Disarmed, (unless the system is in Service, Test or
Program mode).
Wirefree Remote Control
Installation and Operating
Transmit LED
Slide up
to operate
Personal Attack
Instructions
Any number of Remote Controls can be used with your
system, providing they are all coded with the same system
House Code.
The Remote Control is powered by a CR2032 type Lithium
cell which under normal conditions will have an expected
life in excess of 1 year. Under normal battery conditions
the LED on the Remote control will only illuminate when a
button is pressed. However, under low-battery conditions
this LED will continue to flash after the button has been
released. When this occurs the batteries should be
replaced as soon as possible.
Configuring the Remote
House Code
Dip Switches
Jumper Link
Battery Clip
Battery
Ensure that the system is in Test/Service Mode.
1. Remove the rear cover by undoing the small screw on
the rear of the Remote Control.
Control
