AV28BT7ENS / AV28BT7ENB
AV28BT7EES / AV28BT7EEB
AV28BT7EPS / AV28BT7EPB

SPECIFIC SERVICE INSTRUCTIONS

DISASSEMBLY PROCEDURE

REMOVING THE REAR COVER
1. Remove the 8 screws marked A .
2. Withdraw the rear cover toward you.
REMOVING THE FRONT AV + HEADPHONE JACK
BOARD ASS'Y
After removing the rear cover.
1. Remove the 2 screws marked B , and remove the FRONT AV +
HEADPHONE JACK BOARD ASS'Y.
REMOVING THE FRONT CONTROL PWB
After removing the rear cover.
1. Remove the MAIN PWB ASS'Y.
2. Remove the 5 screws marked C , and remove the FRONT
CONTROL PWB.
REMOVING THE SPEAKER
After removing the rear cover.
1. Remove the 4 screws marked D , and remove the SPEAKER.
2. Remove an opposite side similarly.
REMOVING THE MAIN PWB
After removing the rear cover.
1. Draw out back and remove the MAIN PWB ASS'Y,
CAUTIONS)
Be careful enough when developing a main chassis.
The wire of a POWER TRANSFER does not separate
and short-circuit with other parts.
6
No.51883
