- Page 1 Distributed by: BEST MATERIALS ® Ph: 800-474-7570, 602-272-8128 Fax: 602-272-8014 www.BestMaterials.com Email: Sales@BestMaterials.com RT2 CAP NAILER OWNER S MANUAL • Operation • Maintenance • Safety • Warranty PLEASE READ! This manual contains important information about product safety.
-
Page 2: Table Of Contents
Important Information • Warnings • Tool Specifications • Tool Assembly • Loading the Tool • Operating the Tool • STINGER™ RT2 Schematic • STINGER™ RT2 Parts List • Hitachi® NV50A1 Parts List • Maintenance and Storage • Warranty • Troubleshooting... -
Page 3: Important Information
This document serves as an addendum to the Hitachi NV50A1 Instruction Manual included with this product. Please take the time to read and understand the information contained in the NV50A1 instruction manual and STINGER RT2 Owner s Manual before operating or maintaining the STINGER RT2 Cap Nailer. -
Page 4: Warnings
4. To prevent accidental injuries: – Handle the tool with care – Always assume that the tool contains fasteners – Always disconnect the air hose from the STINGER™ RT2 when: • loading nails and/or caps • performing inspections, maintenance or repairs • ... - Page 5 www.nationalnail.com WARNINGS AIR SUPPLY AND CONNECTIONS • Use only clean, regulated compressed air as a power source for this tool. Do not use bottle gases, combustible gases or oxygen as a power source for the tool as the tool may explode. • ...
- Page 6 • Use only 1-1/4 STINGER NailPac cap fasteners with the STINGER RT2 Cap Nailer. Never use any fasteners that are not specified for use in the tool. The RT2 holds 1 reel of steel caps (1500 caps) and 1 coil of collated nails (1500 nails).
-
Page 7: Tool Specifications
(.99 ltr/cycle at 7 kgf/cm Air inlet 3/8 NPT Fasteners STINGER NailPac (National Nail product number 0136072) Consists of 2 coils of 1-1/4 ring shank nails (1,500 nails per roll) and 2 reels of 1 diameter steel caps (1,500 caps per reel). TOOL ASSEMBLY 1. ... -
Page 8: Loading The Tool
LOADING THE TOOL USE 1-1/4 STINGER NAILPAC CAP NAILS ONLY Lynch Pin Spool Hub The image cannot be displayed. Your computer may not have enough memory to open the image, or the image may have been corrupted. Restart your computer, and then open the file again. -
Page 9: Operating The Tool
• the tool is not in use • leaving the work area • moving the tool to another work location • handling the STINGER RT2 to another person • storing the tool 2. For optimal performance, clean and lubricate cap feed moving parts and feed path before each day of use with a dry silicone lubricant. - Page 10 Toggle Valve (Cap Spacing) 6. The STINGER RT2 can be used in an automatic mode or manual mode. Setting the Auto/Manual Toggle Valve to Manual (MAN) requires the Pushbutton Actuator to be depressed each time the user desires to place a cap and nail. With Auto/Manual...
-
Page 11: Stinger™ Rt2 Schematic
Assembly 137 STINGER™ RT2 SCHEMATIC 43 42 (119, 131 on back side of APU) 42, 43 Assembly 136 2, 6... - Page 12 Assembly 140 Assembly 139 STINGER™ RT2 SCHEMATIC Assembly 145 65, 66, 67 Assembly 141...
- Page 13 STINGER™ RT2 SCHEMATIC Assembly 143 Assembly 144 Assembly 142...
- Page 14 STINGER™ RT2 SCHEMATIC Assembly 138...
-
Page 15: Stinger™ Rt2 Parts List
STINGER™ RT2 PARTS LIST Noted on Location NN Item # Description 1 Units Description 2 Schematic 610002 Hitachi NV50A1 Nailer 136964 NV 50 Handle Bolt SHCS 1/4 - 20 x 3/4 652551 Hitachi 877851 Feeder Spring Feeder Spring 650435... - Page 16 STINGER™ RT2 PARTS LIST Noted on Location NN Item # Description 1 Units Description 2 Schematic 136954 Cover Spring Lock Washer # 6 Lock Washer 136953 Cover Spring Flat Washer # 6 Flat Washer 136952 Cover Spring Nut # 6 - 32 Nut...
- Page 17 STINGER™ RT2 PARTS LIST Noted on Location NN Item # Description 1 Units Description 2 Schematic 136912 Top Wheel Bracket Top Wheel Bracket 136911 Bottom Wheel Bracket Bottom Wheel Bracket 136909 Helper Wheel Bracket Bolt SHCS 10 - 24 x 1...
- Page 18 STINGER™ RT2 PARTS LIST NN Item # Description 1 Units Description 2 136825 Ball Actuator Assembly 136958 Ball Actuator Ball Actuator 136904 MAV3 - 3 Way Valve MAV3 - 3 Way Valve 136955 10-32 to 1/8 Barb 10-32 to 1/8 Barb...
-
Page 19: Hitachi Nv50A1 Parts List
www.nationalnail.com HITACHI NV50A1 PARTS LIST NNC # Hitachi # Description 650004 872645 O-Ring (P-9) 650009 872971 Retaining Ring (E-Type) for D3 Shaft - *** 650015 873570 O-Ring (P-18) 650022 874820 Plunger O-Ring 650024 875246 Washer - *** 650034 875638 O-Ring (S12) 650036 875642 Safety Plunger (B) -
Page 20: Hitachi Nv50A1 Parts List
www.nationalnail.com HITACHI NV50A1 PARTS LIST NNC # Hitachi # Description 650395 877468 Sub Stopper Spring 650396 877469 Nail Guide Cover 652294 877470 Cover 650398 877471 Cover Plate 650400 877475 Feed Piston 650401 877476 Bumper 650402 877477 Feed Piston Cover (A) 650403 877478 Feed Piston Cover (B) - Page 21 Eye Protector 650591 949866 Roll Pin D3 x 30 Parts marked with *** are included with part 650478 - Magazine Assembly Notes For questions and inquiries regarding the STINGER™ RT2, please contact: General information - 800-746-5659 Repair and parts - 616-261-2147...
-
Page 22: Maintenance And Storage
Whenever repairs or replacement of parts inside the body occur, check the piston O ring for adequate grease lubrication. 4. Never use any parts other than genuine STINGER replacement parts. 5. Periodically clean the magazine and nose of the tool with a mild solvent. -
Page 23: Warranty
2. The warranty is not transferable. 3. The warranty is voided by any of the following: a. Abuse, misuse, or damage to the tool b. Use of parts other than genuine STINGER parts c. Use of fasteners not designated for use in the tool d. ... -
Page 24: Troubleshooting
www.nationalnail.com TROUBLESHOOTING Disconnect the air hose from the tool when performing inspections, maintenance or repairs. PROBLEM: CORRECTION: 1. Nail not driven deep enough • Check the air pressure - recommended 95-110 psi • Check air supply - recommended 3/8 hose and fittings;... -
Page 25: Replacement Parts
Contact Inside Sales at 800-746-5659 to place an order for replacement parts. Visit our website at www.nationalnail.com to learn more about our products and services. 2964 Clydon SW, Grand Rapids MI 49519, USA Phone: 800-968-6245 Fax: 616-531-5970...
