Page 1: Installation Guide
DMP-100 Digital Media Player Installation Guide Version: V1.7 Date: 07 Dec 2006 Doc Number: DMP010 AVIONICS INNOVATIONS, INC. 2450 Montecito Road Ramona, CA 92065 Phone (760) 788-2602 Fax (760) 789-7098 www.avionicsinnovations.com... -
Page 2: Revision History
Added “Test All Inputs” function Added installation checkout procedure Added External Dimensions drawing Added Wire Interconnect drawing -Improved behavior of external Pause for V1.7 07-Dec-06 better operation with cabin PA Systems. DMP-100 INSTALLATION GUIDE PAGE 2 OF 20 P/N DMP010 V1.7... -
Page 3: Table Of Contents
3.3.3 Discrete Triggers .................8 3.3.4 Jog Mode ..................9 3.3.5 Dedicated Annunciators for Triggers 1, 2 and 3 ......9 3.3.6 GPS Data..................9 Outputs.....................9 3.4.1 Audio ....................9 3.4.2 Discrete ..................10 Connector Pinouts.................11 DMP-100 INSTALLATION GUIDE PAGE 3 OF 20 P/N DMP010 V1.7... - Page 4 Dedicated Annunciators for Triggers 1, 2 and 3 ......14 4.1.11 Test External Outputs..............15 4.1.12 Test External Inputs..............15 Installation Checkout Procedure..........15 Troubleshooting and Error Messages ........16 Troubleshooting................16 Error Messages ................17 Drawings..................18 Mechanical Drawing..............18 Electrical Interconnect ..............18 DMP-100 INSTALLATION GUIDE PAGE 4 OF 20 P/N DMP010 V1.7...
-
Page 5: Introduction
In addition, the RS232 data from a panel-mount GPS may be connected to the DMP-100 to allow triggering of audio files based on geographic position. The DMP-100 accepts a power input of between 10VDC and 35 VDC and provides a single pair of ground-referenced stereo line-level audio output signals. -
Page 6: Mechanical
2.5” (6.35 cm) behind unit for mating connector and wiring. Mounting Considerations The DMP-100 should be installed in a normally heated, pressurized section of the aircraft, however the unit contains no moving parts and does not require special vibration isolation. -
Page 7: Inputs
PA system’s KEY signal, to momentarily pause the DMP-100 playback while the PA is in use. If a track is playing, the DMP-100 will be PAUSED for as long as the Pause/Play signal is active, and will resume playing when the signal returns to inactive. -
Page 8: Discrete Triggers
Example: Active High The annunciator lamp functions as a pull-down resistor. If a lamp is not used, it must be replaced by a resistor (1/4 W, 10K to 47K Ohms). DMP-100 INSTALLATION GUIDE PAGE 8 OF 20 P/N DMP010 V1.7... -
Page 9: Jog Mode
If enabled on the memory card using the CardPrep software, Jog Mode causes four of the available seven trigger inputs to be redefined: Triggers 6 and 7 are used to remotely step the DMP-100 through its menus. This is particularly useful for helicopter installations or any installation where the pilot needs to be able to quickly step back or ahead through the playlists and select a new track. -
Page 10: Discrete
1 Amp each. Maximum input voltage is 35 VDC on each. By default, BUSY is active anytime the DMP-100 is producing audio. However, the installer may configure BUSY to go active only for speech tracks, only for music tracks, for all types of tracks, or even to never go active at all. -
Page 11: Connector Pinouts
DIM14 Dimmer input, 0-14VDC* (see note) DIM28 Dimmer input, 0-28VDC* (see note) GPSIN RS-232 or RS-422/485 GPS serial data in NOTE: connect only one dimmer input, leave the others N/C DMP-100 INSTALLATION GUIDE PAGE 11 OF 20 P/N DMP010 V1.7... -
Page 12: Setup Mode
4.1.4 Display Brightness The DMP-100’s display can be set to one of four brightness levels, or can be set to allow an external dimmer input to select one of the four levels. Each push of the front panel knob cycles between 100%, 75%, 50%, 25% and EXT DIMMER. -
Page 13: Loud" Volume Level
Valid serial data is being received, and the data/signal OK GPS is reporting a valid position. Note: The DMP-100 will take 5 to 10 seconds to respond to a change in the GPS data. DMP-100 INSTALLATION GUIDE PAGE 13 OF 20... -
Page 14: External Pause Signal Type
“EDGE“ is selected, the play/pause function will toggle each time the external button is pressed-and-released. If “LEVEL” is selected, the DMP-100 will remain paused as long as the external button is held down, and will resume when the button is released. -
Page 15: Test External Outputs
1. Press and hold the button while turning on power. Release the button when the DMP-100 display first lights up. 2. The DMP-100 will be in SETUP mode. Advance through all the setup items as described above, and set the options to match your installation. Do NOT select the setup item: “Set LOUD volume level”... -
Page 16: Troubleshooting And Error Messages
Triggers and Attributes have changed, but not the actual MP3 tracks. Regenerate the card using the Create Card button. DMP-100 INSTALLATION GUIDE PAGE 16 OF 20 P/N DMP010 V1.7... -
Page 17: Error Messages
Error Messages In addition, the DMP-100 may display the following error messages: Display Meaning Possible Causes • Invalid Card, no The firmware update file, The card was not prepared firmware. “000.hex”, cannot be opened on using DMP100 CardPrep the CompactFlash card. -
Page 18: Drawings
7.0 Drawings Mechanical Drawing Electrical Interconnect DMP-100 INSTALLATION GUIDE PAGE 18 OF 20 P/N DMP010 V1.7...
