- Page 1 DMP-100 Digital Media Player Users Guide Version: V1.7 Date: 10 Oct 2006 Doc Number: DMP020 AVIONICS INNOVATIONS, INC. 2450 Montecito Road Ramona, CA 92065 Phone (760) 788-2602 Fax (760) 789-7098 www.avionicsinnovations.com...
-
Page 2: Revision History
Revision History Version Date Description V1.0 05-Jun-01 Initial Release V1.1 10-Jun-02 First production release V1.2 30-Jul-02 Added info on GPS triggering -Clarified single-level restore of interrupted tracks. V1.3 11-Sep-02 -Added persistent power up music track. -Added remote operations of PAUSE input. V1.4 14-Jan-03 Added “Jog Mode”... -
Page 3: Table Of Contents
Table of Contents Revision History....................2 Table of Contents .....................3 Overview ......................5 File Types .....................6 Speech Files....................6 Music Files....................6 Memory Cards....................6 Display ......................7 Front Panel Operations ..................7 TO SELECT LANGUAGES:................7 TO PLAY A SPEECH FILE: ................8 TO PLAY A MUSIC FILE:................8 TO PAUSE PLAYBACK: ................8 TO CANCEL PLAYBACK :................8 TO CHANGE VOLUME LEVEL:..............8... - Page 4 Running CardPrep ..................12 To add Speech Files: .................12 To add Music Files: ..................13 Adding Music Files Individually..............13 Adding a Folder of Music Files ..............14 Adding an Exported Playlist of Music Files..........15 To Select Triggers or Attributes:..............16 ♦ Discrete Triggers ................16 ♦...
-
Page 5: Overview
Overview The DMP-100 Digital Media Player is a self-contained unit which stores and replays pre- recorded audio tracks. The audio tracks are encoded in “Motion Picture Expert Group (MPEG) Level 3” format, commonly referred to as “MP3”. Audio files are stored in a removable CompactFlash™... -
Page 6: File Types
File Types Each audio file contained in the DMP-100 memory card must be designated as either “speech” or “music”. While the actual audio content is irrelevant, this designation controls how each file is presented on the DMP-100 display. Speech Files Every “Speech”... -
Page 7: Display
Display Turning the knob CCW or CW will scroll left or right through the top-level menu. The top- level menu consists of (from left to right): “CHOOSE LANGUAGES” (click for language selection menu) ♦ (title of SPEECH FILE 1) (click to play) ♦... -
Page 8: To Play A Speech File
TO PLAY A SPEECH FILE: Rotate the knob CW or CCW until the title of the desired file is displayed. If “RETURN TO MENU” is displayed at either position, push the knob and then rotate fully CW or CCW. Push the knob to begin playback. The file will be played once for each language enabled, if the file exists in those languages. -
Page 9: To Change Selections While Playing
TO CHANGE SELECTIONS WHILE PLAYING: Simply make your new track selection and push the knob (note that if the knob is not turned for four seconds while you are selecting the new track, the display will revert to the “PLAYING” screen). The currently-playing audio will fade down and your new selection will begin. -
Page 10: Jog Mode: Track Select And Volume Control With External Switches
If a track is playing, pushing the remote button will cause playback to pause. Pushing again will cause playback to resume. The external pushbutton works in parallel with the front panel knob: playback may be paused with one and resumed with the other. If no track is playing, you can turn the front panel knob until a desired track is displayed. -
Page 11: Volume Control
Volume Control When Jog Mode is enabled on a card, Triggers 1 and 2 are also redefined to control the volume on the DMP-100. Each activation of Trigger 1 simulates a push-and-turn counterclockwise, i.e. a decrement of volume. In a similar way, each activation of Trigger 2 simulates an increment of volume. -
Page 12: Preparing A Memory Card With Cardprep
Preparing a Memory Card with CardPrep Installing DMP100 CardPrep The DMP100 CardPrep software may be distributed on either the CompactFlash™ card included with the DMP-100, on a CD-ROM or downloaded from the Avionics Innovations website at www.avionicsinnovations.com. To install the software, simply run SETUP.EXE and follow the prompts. Running CardPrep CardPrep displays a simple menu bar across the top, and five different selection tabs. -
Page 13: To Add Music Files
3. Click on a title in the large box under (1), then click on a language in the large box under (2). Next, click on the box under (3) and either type in the path or click Browse to identify the MP3 file which corresponds to the selected title and language. -
Page 14: Adding A Folder Of Music Files
1. Click on the empty box under (1), type the name of the desired Music List, and press Add. Repeat for all remaining Music Lists. 2. Click on the empty box under (2), type the first music track to be displayed, and press Add. -
Page 15: Adding An Exported Playlist Of Music Files
Adding an Exported Playlist of Music Files Most MP3 manager applications allow you to create and manage Playlists. A Playlist is simply a list of MP3 tracks that you would like to group together. You could create a separate playlist for each CD in your collection (“White Album”, for example), or you can create a playlist with tracks from many different sources (“Night-Flying Music”, for example). -
Page 16: To Select Triggers Or Attributes
To Select Triggers or Attributes: The “Triggers and Attributes” tab allows you to select either Speech or Music tracks, and then to specify the following information: Discrete Triggers ♦ Click on the check box next to any available discrete trigger to associate that track with the corresponding trigger. -
Page 17: Endless Looping
selected as “Trigger First Time Only”. On the other hand, the same tour may desire that a “falling water” soundtrack be played whenever the flight approaches a waterfall, so this waypoint would be selected as “Trigger Every Time”. See “Notes on GPS Triggering” on page 22 for detailed information. Be sure to click on “Apply”... -
Page 18: To Select Setup Items
To Select Setup Items: Default Languages Enabled ♦ Select and highlight one or more languages to be enabled on power up. Note that this screen is potentially confusing: the desired language(s) must be highlighted to be selected. If none are highlighted, the list simply displays the languages on the card. Custom Card Titles ♦... -
Page 19: Selecting Internal Or External Chime
Selecting Internal or External Chime ♦ The DMP-100 may be interfaced to an external cabin chime or tone generator. A chime will be sounded whenever a speech track is selected or triggered (selecting or triggering a music track will not sound a chime.) When sounding an external chime, the DMP-100 will pause for several seconds before starting to play the track, to allow the chime to finish. - Page 20 To make changes to the text, simply click in a box on the right side, type in your new text and click “Save”. Use caution (and common sense) when making changes! Always refer to the original text in the left column to be sure you are not changing the intent of the text. As with all the other configuration settings in this section, any changes made here will only apply to this card.
-
Page 21: To Copy All Files And Settings To The Card
To Copy all Files and Settings to the Card: When you are ready to generate the actual memory card, click on the “Create Card” tab: CardPrep will run through your configuration settings and check for inconsistencies, such as languages with no associated speech tracks or empty music lists. Any inconsistencies will be displayed and described. -
Page 22: To Save Or Open A Card File
To Save or Open a Card File Your entire “workspace” can be saved to a card file (*.CRD) so that you can easily maintain multiple cards. Click on File in the menu bar at the top of the window, and then either Open, Save, or Save As as is typically used in most Windows applications. - Page 23 3) “Song #5” will fade down, “Speech #1” will play to completion, and “Song #5” will fade back up, restarting at the point where it was interrupted. Now consider the same scenario, except that “Speech #1” is itself interrupted by a GPS trigger for “Speech #2”.
