This Base Manual covers general information. International Refer to individual Technical Sheet for information on specific models. Countertop This manual includes, but is not limited to the following: LD510D P1329704M Commercial LD510P P1329705M DEL10D P1329706M Microwave DEL10E...
Telephone Number WWW.AMANA.COM ..........1-800-843-0304 WWW.JENNAIR.COM .......... 1-800-536-6247 WWW.MAYTAG.COM .......... 1-800-688-9900 CAIR Center in Canada ........1-800-688-2002 Amana Canada Product ........1-866-587-2002 Recognize Safety Symbols, Words, and Labels DANGER DANGER—Immediate hazards which WILL result in severe personal injury or death. WARNING WARNING—Hazards or unsafe practices which COULD result in severe personal injury or death.
Table of Contents Important Information ..........2 Disassembly Procedures Important Safety Information ........4-8 Disconnecting Wire Terminals ........ 21 General Information Door Assembly ............. 21 Placement of the Oven ..........9 Door Disassembly ..........22 Radio Interference ........... 9 Outer Case ............22 Earthing Instructions ..........
Page 7
8. Do not for any reason defeat the interlock switches. The basic design of the Amana or Menumaster There is no valid reason for this action at any time; microwave ovens make it an inherently safe device to nor will it be condoned by Maytag.
Page 8
Important Safety Information WARNING W ARNING Precautions to be observed before and during To avoid risk of electrical shock, personal injury or servicing to avoid possible exposure to excessive death, make sure these earthing instructions are microwave energy, or electrical shock disconnect followed.
General Information Placement of the Oven Radio Interference Do not install microwave next to or above source of Microwave oven operation may cause interference to heat, such as a deep fat fryer. This could cause the radio, television, or similar equipment. Reduce or microwave to operate improperly and could shorten the eliminate interference by doing the following: life of electrical components.
General Information Plug Receptacle Plug Receptacle 230 V / 13 AMP 230 V / 16 AMP Equipment requires a Equipment requires a 230 VAC, 50 Hz, 13 amp power supply 230 VAC, 50 Hz, 16 amp power supply Do not use a extension cord. If the product power cord is too short, have a qualified electrician install a three-prong receptacle.
Troubleshooting Procedures When you get a complaint from customers, evaluate the complaint carefully. If the following symptoms apply, instruct the customer in the proper use of the microwave oven. This can eliminate an unnecessary service call. CAUTION • Verify proper earthing before checking for trouble. •...
Page 12
Troubleshooting Procedures Trouble 1: The following visual conditions indicate a probable failed control circuit. 1. Incomplete segments. • Segment missing. • Partial segment missing. • Digit flickering (Note: Slight flickering is normal.) 2. Colon does not turn on or blink. 3.
Page 13
Troubleshooting Procedures (Electronic Models) Trouble 2: Oven does not operate at all, display window does not display any digits, and no input is accepted. Malfunction Replace the fuse, Check continuity Continuity of the Fuse blows. primary, of monitor switch monitor secondary, monitor with door closed.
Page 14
Troubleshooting Procedures (Electronic Models) Trouble 3: Display shows all digits programmed, but does not start cooking when the START pad is pressed. Malfunction Check continuity Time does not Replace the of secondary of secondary Continuity count down switch. secondary switch with door after START switch.
Page 16
Troubleshooting Procedures (Electronic Models) Trouble 5: No microwave oscillation even when oven light and fan motor operate. Disconnect wire Replace Failed No microwave leads from relay controller. Continuity controller. oscillation. RY2 and verify continuity of the relay. Continuity Check high Abnormal Replace high Failed high...
Component Testing Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires it. Illustration Component Test Results Thermal cutout Disconnect all wires from TCO. Measure resistance across terminals. Open at (145°C) 293°F and Magnetron TCO ..........
Page 18
Component Testing Procedures WARNING To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires it. Illustration Component Test Results Timer 7 minute Disconnect wire from terminals. Measure resistance of the following terminals: Terminal 3 to terminal 4 (timer motor)..
Power Test (Traditional Test Method) Test equipment required is Amana power test kit R0157397 (Fahrenheit), or Menumaster power test kit M95D5 (Celsius). 1. Fill the plastic container to the 1000 ml. line with cool tap water.
Microwave Leakage Testing WARNING To avoid risk of electrical shock, personal injury, or death, disconnect power to oven and discharge capacitor before servicing, unless testing requires it. Measurement With the Outer Panel WARNING Removed Check for radiation leakage after servicing. Should the leakage be more than 4mW/cm inform Maytag DANGER...
Disassembly Procedures To avoid the risk of electrical shock, personal injury, or WARNING death, disconnect power to oven and discharge capacitors before following any disassembly procedure. High voltage is present at the high voltage terminal of Door Assembly the high voltage transformer during any cooking cycle. CAUTION It is neither necessary or advisable to attempt measurement of the high voltage circuitry.
Disassembly Procedures To avoid the risk of electrical shock, personal injury, or WARNING death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Door Disassembly Outer Case 1. Disconnect power to oven. 1. Disconnect power to oven. 2.
Disassembly Procedures To avoid the risk of electrical shock, personal injury, or WARNING death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Timer Removal (Dial Models) Controller Removal (Electronic Models) 1. Disconnect power to oven and remove outer case 1.
Disassembly Procedures To avoid the risk of electrical shock, personal injury, or WARNING death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Interlock Switches Adjusting Interlocks The interlock monitor, primary, and secondary switches Primary switch is operated by top latch arm. act as a final safety switch, protecting the operator from Interlock Switch Removal microwave energy.
Disassembly Procedures To avoid the risk of electrical shock, personal injury, or WARNING death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Diode Magnetron 1. Disconnect power to oven and remove outer case, Magnetron is mounted on the side of the cavity. (see "Outer Case"...
Disassembly Procedures To avoid the risk of electrical shock, personal injury, or WARNING death, disconnect power to oven and discharge capacitors before following any disassembly procedure. Light Socket / Bulb Assembly Fan Motor 1. Disconnect power to oven and remove outer case, 1.
