INSTRUCTION MANUAL FOR EXTERNAL POWER SUPPLY
OPERATION
Note: The charger is powered on even if you use the power supply
separately and the power consumption is less than 1W.
To use the power supply after you connect the device to it, set POWER
to turn it on with the power switch.
Please check all connections and confirm the wall AC outlet has power
before you switch on the power supply.
The LED will indicate output power from minimum to maximum.
ERROR MESSAGE
In case of an error all LEDs will turn off. Please turn off the POWER
and restart the power supply.
38
INSTRUCTION MANUAL FOR EXTERNAL POWER SUPPLY
SPECIFICATIONS
Input Voltage...................................................... ...100-240V AC
Input AC Frequency.........................................................50-60Hz
Output Voltage.........................................................12V DC±0.2V
Output Current............................................................18A±0.5A
Current Overload Protection....................................≥17.5A 500MS
Input Fuse..................................................................... 5A Fuse
Output Voltage Ripple......................................................<150mV
USB Output..................................................................5V / 2.1A
Power Efficiency..................................................................91%
Power Factor.....................................................................>0.98
Over Temperature Protection.............................................≥65℃
Cooling Method.........................................................Cooling Fan
Operating Temperature......................................................0-40℃
Operating Humidity............................................................0-90%
Specifications are typical; individual units might vary.
Specifications are subject to change and improvement without notice.
