Page 1: Installation Manual
GPS NAVIGATION SYSTEM DNX SERIES DNX7360BT MONITOR WITH DVD RECEIVER DDX SERIES DDX7036BT INSTALLATION MANUAL © B54-4778-00/00 (MW/M2W/XW) DNX7360BTM DDX7036BTM... -
Page 2: Accessories Installation Procedure
Accessories ...1 ...1 ...1 ...1 DNX7360BT, ...2 DNX7360BTM only ...1 DNX7360BT, DNX7360BTM only ...1 ...6 DNX SERIES/ DDX SERIES Installation Procedure 1. To prevent a short circuit, remove the key from the ignition and disconnect the - battery. 2. Make the proper input and output wire connections for each unit. - Page 3 product is first powered on works properly, the front panel will automatically move into the position (initial setting angle) shown in (Fig. 2). (Fig. 1) (Fig. 2) After the Installation After the installation, perform the Initial Setup by referring to the instruction manual. ¤...
- Page 4 Connect to the terminal that is grounded when either the telephone rings or during conversation. ⁄ To connect the Kenwood navigation system, consult your navigation manual. Depending on what antenna you are using, connect either to the control terminal of the motor antenna, or to the power terminal for the booster amplifier of the film-type antenna.
- Page 5 Reverse sensor wire (Purple/White) REVERSE Steering remote control input (Light Blue/Yellow) STEERING WHEEL REMOTE CONT REMOTE INPUT Dimmer control wire (Orange/White) ILLUMI Mute control wire (Brown) MUTE Motor antenna control wire (Blue) ANT. CONT Power control wire (Blue/White) P.CONT Bluetooth Microphone (Accessory !) (see page 8) Cooling fan GPS Antenna (Accessory #)
-
Page 6: System Connection
System Connection USB terminal Accessory 3 Accessory 2 To Camera control terminal (Green/Red) (Green/White) To Relay Box (Blue/Red) (Blue/Red) DNX SERIES/ DDX SERIES USB device or iPod (commercially available) Audio input (iPod/AV Input 2 switchable) Resistance-free stereo type mini plug (3.5φ) Visual input (iPod/AV Input 2 switchable) Resistance-free mini plug (3.5φ) Accessory 4... -
Page 7: Optional Accessory Connection
DDX7036BT, DDX7036BTM only USB terminal Navigation System (Optional Accessory) ⁄ Navigation units that can be connected to this unit. (As of December, 2009): • KNA-G630 • KNA-G630CN For latest information, access the www.kenwood.com/cs/ce/. Connection cable (Included in the Navigation System) English... -
Page 8: Installing The Microphone Unit
Installing the Microphone Unit 1. Check the installation position of the microphone (accessory !). 2. Remove oil and other dirt from the installation surface. 3. Install the microphone. 4. Wire the microphone cable up to the unit with it secured at several positions using tape or the like. -
Page 9: Installing The Escutcheon
Installing the Escutcheon For General Motors 1. Cut out accessory 6 to meet the shape of the opening of the center console. 2. Attach accessory 6 to the unit. Cut out to meet the shape of the opening in the vehicle. For Volkswagen 1. -
Page 10: Attaching The Monitor Panel
Installation for Monitor/Player Unit Installation the Monitor/Player unit Bend the tabs of the mounting sleeve with a screwdriver or similar utensil and attach it in place. ⁄ • Make sure that the unit is installed securely in place. If the unit is unstable, it may malfunction (eg, the sound may skip). -
Page 11: Removing The Unit
Removing Monitor/Player Unit Removing the Hard Rubber Frame (escutcheon) 1. Engage the catch pins on the removal tool 5 and remove the two locks on the lower level. Lower the frame and pull it forward as shown in the figure. Accessory 5 Lock ⁄...
