Bellman BE1345 User Manual

User manual, Bellman Alarm clock (GB)
Bellman Visit Alarm clock, model BE1345, is a table top clock with extra functions:
● It signals when one of the transmitters in the Visit system is triggered; when the door bell or telephone
rings or the Baby-cry or fire alarm is activated
● Snooze function
● Wake-up alarm with a sound signal with increasing intensity and volume and/or clear flashes.
● The number of flashes and their interval is automatically adjusted depending on the surrounding light
● Two Bellman Visit Bed-shakers (accessory) can be connected for wake-up through vibrations.
● The clock face is illuminated and lights up for wake-up and also when the snooze button is pressed.
● The alarm clock can be connected to a telephone outlet to signal for incoming calls, and also to an
external trigger.
● It has a built-in, rechargeable back-up battery that is activated upon power failure or when the clock is
not connected to the mains supply.

How to get started:

1) Power supply:
Connect the power adapter to the inlet (13) marked DC IN 7.5V on the backside of the unit.
Let the unit be connected for 24 hours first time of usage to allow the back-up battery to fully charge. This
will increase the life span of the battery. Normally, 16 hours is required to fully recharge an empty battery.
Please note! Use only the attached power adapter type G075040D25.
The rechargeable battery (NiMH) steps in when the clock no longer is powered via the power adapter.
A fully charged battery lasts approximately one week of normal usage, but it is recommended to always let the unit be
connected to the adapter.
Power supply indicator (2)...
... shines with a constant green light during normal usage when the power adapter is connected.
... flashes with green light during power failure or when the power adapter is not connected.
... flashes with a red light when the back-up battery is low and needs to be recharged.
2) Adjusting time
Use the knob (12) on the back of the unit to set the correct time.
3) Adjusting time for wake up
1) Set the time for wake up using the knob (11) on the back of the unit.
2) The wake-up alarm is turned on or off using the knob (6) marked 'ALARM' on the right side of the unit.
3) When the alarm is on, a red indicator inside the snooze button is lit.
Please note! Only available when the unit is connected to the mains supply.
4) Wake-up can happen through sound and/or flashes as well as through vibrations (accessory). The sound and the flashes are
activated through the switches marked (8) and (10) on the back of the unit.
Set these in desired mode.

Wake up

Wake up happens through a sound signal with increasing intensity and volume, with clear and distinct flashes and through
vibrations if the Bellman Visit Bed-shaker, model BE1270, (accessory) is connected. If the alarm is not turned off within 30
