- Page 1 RFC10HB – 10 F ARAD YBRID APACITOR Installation & Operation Serial Number: Date of Purchase:...
-
Page 2: Table Of Contents
2.7 volts (per cell) give the Rockford Hybrid Capacitor the highest energy storage capacity and power density of any other commercially available components of comparable size and weight. To add the finishing touch to your new system order your Rockford Fosgate apparel, which include everything from T-shirts and jackets to hats and sunglasses. -
Page 3: Safety Instructions
• DO NOT make any connections to a capacitor if the connecting polarity cannot be properly identified. Applying reversed polarity will damage capacitor cells. ONTENTS OF ARTON A model RFC10HB Hybrid Capacitor Module Charging Resistor Installation & Operation Manual Warning Label Visit our web site for the latest information on all Rockford products. -
Page 4: Design Features
ESIGN EATURES The following features are the results of the unique patented manufacturing process that enables the Rockford Hybrid Capacitor to deliver many charge and discharge cycles with greater energy and power per unit weight and volume. High Energy The amazingly high specific capacitance and lower weight of Rockford's Hybrid Capacitor yields an energy per kilogram figure that is twice that of any other commercially available Electric Double Layer Capacitor (EDLC). -
Page 5: Mounting Locations
NSTALLATION This section focuses on some of the vehicle considerations for installing your new Rockford Fosgate Hybrid Capacitor. Pre-planning your system layout and best wiring routes will save installation time. When deciding on the layout of your new system, be sure that each component will be easily accessible for making adjustments. -
Page 6: Charging/Connecting Hybrid Capacitor To Battery
NSTALLATION ATTENTION: Make sure the battery and all other power sources are disconnected. ATTENTION: When installing high voltage audio equipment, such as capacitors and amplifiers, we recommend using “full-spec” AWG (American Wire Gauge) type wire for your power and ground wires. CAUTION: Ensure correct polarity during the following connections. -
Page 7: Discharging The Hybrid Capacitor
NSTALLATION NOTE:If a reverse polarity has been connected to the capacitor, a warning buzzer will sound when power is applied. Immediately disconnect the capacitor from power, ensure it has been discharged and reconnected to correct polarity. Connect the Blue wire from the charge card to the Positive (+) power wire leading to the capacitor module. -
Page 8: Specifications
CAUTION: To prevent injury due to hazardous chemicals, do not touch the capacitor if the safety vent has ruptured. Have the system looked at by a qualified technician for repair and/or disposal. PECIFICATIONS MODEL- 10 Farad Hybrid Capacitor RFC10HB Rated Capacitance – 77°F (25°C) 10 Farad (Constant Current Discharge (5A) 15.0v–>3.0v) Capacitance Tolerance ±10%... -
Page 9: Limited Warranty Information
Some states do not allow limitations on the length of an implied warranty, so this limitation may not apply. No person is authorized to assume for Rockford Fosgate any other liability in connection with the sale of the product. - Page 10 OTES...
- Page 11 OTES...
- Page 12 Rockford Fosgate Rockford Corporation 546 South Rockford Drive Tempe, Arizona 85281 U.S.A. In U.S.A., (480) 967-3565 - Customer Service 1-800-669-9899 In Europe, Fax (49) 8503-934014 In Japan, Fax (81) 559-79-1265 www.rockfordfosgate.com 04/07 B.M. Printed in China 1230-53683-02...
