Acard ADR-7216 User Manual

16ch mpeg4 standalone dvr
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
16CH MPEG4 Standalone DVR
ADR-7216
User Manual
Version 1.7

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADR-7216 and is the answer not in the manual?

Questions and answers

Related Manuals for Acard ADR-7216

Summary of Contents for Acard ADR-7216

  • Page 1 16CH MPEG4 Standalone DVR ADR-7216 User Manual Version 1.7...
  • Page 3 Statement The information of the product in this manual is subject to change without prior notice and does not represent a commitment on the part of vendor, who assumes no liability or responsibility for any errors that may appear in this manual. This manual contains materials protected under International Copyright Laws.

  • Page 4: Table Of Contents

    Table of Contents Section1 Introduction...........................3 1.1 Overview............................3 1.2 Features............................3 1.3 Specifications..........................3 1.4 Package............................4 Section2 Appearance..........................5 2.1 Front Panel..........................5 2.2 Rear Panel..........................8 Section3 Installation...........................10 3.1 Before Installation........................10 3.2 HDD Installation........................12 3.3 DVD-RW Installation......................13 Section4 Menu............................14 4.1 Menu Display...........................14 4.2 Menu Tree..........................15 4.3 SYSTEM..........................17 4.4 DISPLAY..........................25 4.5 RECORD..........................27...

  • Page 5: Section1 Introduction

    UI design also enables users even unfamiliar with computer operations can easily control this DVR. Specially, Advanced network functions are added in ADR-7216 to fulfill the growing IP applications. This product also supports Pentaplex, which enables Live, Record, Playback, Backup and Network to be performed simultaneously.

  • Page 6: Package

    ● Video loss detection：Yes ● Power：DC 12V / 7A ● Dimension：430 (W) x 88 (H) x 340(D) mm ● 1.4 Package Digital Video Recorder ADR-7216*1 ● Power Adapter*1 ● Power Cord*1 ● Support CD (including PC_SW, User Manual) ● IR Remote Controller*1 ●...

  • Page 7: Section2 Appearance

    Section2 Appearance 2.1 Front Panel 1. DVD-RW This can be used for backup video. 2. Jog and Shuttle Jog and shuttle enable user to operate DVR easier in handling such as fast forward, fast reverse playback and one frame movement in still picture. 3.
  • Page 8 4. Channel Selection buttons Channel selection button from CH1 to CH16 can be used to display given channel on monitor. 5. Function buttons 1) FUNC This button is reserved for future use. 2) LOCK In order for only authorized person to operate buttons in front panel, this LOCK button can be utilized.
  • Page 9 10) PLAY/ PAUSE button If this button is pressed, playback picture will be frozen. If it is pressed again, playback will be restarted. 11) STOP button To stop playback, STOP button is used. 12) FF Press FF button to do high speed forward playback. It support 2 to 16 times playback speed.

  • Page 10: Rear Panel

    2.2 Rear Panel 1. FAN 2. 16CH Video Inputs 16 channel composite video inputs with BNC connectors . Since this DVR automatically detects video format (NTSC or PAL) as soon as power is ON, NTSC or PAL video sources can be connected in DVR. But NTSC and PAL video sources for 16CH video inputs can not be mixed.
  • Page 11 8. VGA Output VGA output can be connected to LCD monitor or CRT monitor with progressive scan directly which can receive analog R, G, B and synchronization signals. 9. RS232C (It can be utilized for future option.) 10/11. Alarm input and relay output 16 alarm inputs and 4 relay output with NO, NC To make secure connections on the Alarm Connector Strip, press and hold the button and insert the wire in the hole below of connector pin.

  • Page 12: Section3 Installation

    Section3 Installation 3.1 Before Installation The DVR picture is shown below. First, open the upper casing by using a screwdriver to loosen the screws. The screws are located at the top (1), on the sides (4) and at the back (2) of DVR as indicated by the red circles.
  • Page 13 Below are the instructions for connecting the 4 SATA ports on the mainboard of the DVR Four storage device combination options are listed below. Option1. SATA HDD*2 + DVD-RW*1 + eSATA Device*1 The two internal SATA HDDs need to be connected to the two SATA ports, SATA3 and SATA4 as shown in the picture.

  • Page 14: Hdd Installation

    3.2 HDD Installation Loosen the screws holding the two HDD racks in DVR case to remove the HDD rack, then install the HDD in place as shown below using the screws. Once the HDDs are installed into the HDD racks, place the racks back, align them with the holes on the chassis and tighten the screws.

  • Page 15: Dvd-Rw Installation

    3.3 DVD-RW Installation Loosen the four screws holding the DVD-RW rack in place as shown below and remove the DVD-RW rack then. Remove the two screws on the DVD-RW rack and split it as the two part shown as below. Position the two mounting plates on either side of the DVD-RW then tighten them with screws.

  • Page 16: Section4 Menu

    Section4 Menu 4.1 Menu Display Menu Icons Menu Icons ICON ICON NAME NAME ICON ICON NAME NAME SYSTEM SYSTEM NETWORK NETWORK DISPLAY DISPLAY COPY COPY RECORD ING RECORD ING EVENT EVENT CAMERA CAMERA SCHEDULE SCHEDULE...

  • Page 17: Menu Tree

    4.2 Menu Tree LANGUAGE LANGUAGE VIDEO FORMAT VIDEO FORMAT SEQ DWELL SEQ DWELL PASSWORD PASSWORD SPOT DWELL SPOT DWELL STOP KEY STOP KEY ADMIN LOCK ADMIN LOCK TIME/DATE OSD TIME/DATE OSD REC SETTING REC SETTING SUB-USER SUB-USER CAM NO OSD CAM NO OSD REMOTE CONT ID REMOTE CONT ID...
  • Page 18 <Enter the Menu > For the first time using your DVR, you will want to establish the initial settings. This includes setting items such as time and date, password, display, record mode, network and so on. In order to program Main Menu, first press MENU button of front panel in DVR. If ADMIN LOCK is set as YES (factory default is YES), below figure will be appeared.

  • Page 19: System

    4.3 SYSTEM To access SYSTEM SETUP, press ENTER button after moving highlight icon to SYSTEM in MAIN MENU. Below menu will be appeared on monitor. 1) LANGUAGE The OSD language which can be displayed in Menu can be selected. Whenever left or right button is pressed , supported language can be selected. For language selection by graphical user interface, ENTER button can be pressed.
  • Page 20 2) VIDEO FORMAT: NTSC/ PAL Video format is automatically detected after power ON. The detected video information will be displayed on VIDEO FORMAT. User don’t need to change video format. NOTE: It is recommended that power is “ON” after camera(s) connection for video format recognition.
  • Page 21 5) SUB-USERS : NOTE: This function is available only in ADMIN LOCK with “YES”. Sub-User function can provide multiple user with the differentiated DVR accessing from ADMIN, user1 to user4. The function(s) which each user can use is limited by ADMIN. In order to assign different functions for each user, SUB USERS of SYSTEM SETUP MENU can be selected.
  • Page 22 <The procedure for SUB-USER password modification> The initial password for SUB-USER is same as ADMIN’s password, “11111111”. The modification for each sub-user can be followed by specific user selection in MENU. NOTE: The SETUP (for MENU configuration setup) for the user should be “On” by ADMIN in advance.
  • Page 23 If SETUP (for MENU configuration setup) for the user isn’t set as “On” by ADMIN in advance, below error message, “ACCESS DENIED!” will be appeared on monitor. If password is not same, same window for password will be kept. 6) Remote ID : DVR can set remote ID from 01 t0 16 by manual or mouse at first.
  • Page 24 How to use Remote ID: Remote ID in REMOTE ID of SYSTEM MENU of DVR can be set by manual or mouse. Each DVR can have REMOTE ID from 01to 16. Factory initial setting is “Off”. It means that DVR don’t use Remote ID. If any number of Remote ID is pressed by FUNC + No.
  • Page 25 9) DATE/ TIME SET : Move Highlight icon to DATE/TIME SET in the SYSTEM Menu using DOWN or UP button. And then press ENTER to set the time. Below GUI will be appeared. NOTE: If you set a date and time that is older than some of your recorded images, it is not easy to manage recorded files.
  • Page 26 12) UPGRADE Firmware can be upgraded through USB memory driver. For more detail information, Section9 F/W Upgrade Please see “ ” NOTE: When all of menu setting are finished, escape menu mode, below figure “SAVE?” which ask to save all the setting will be appeared. If all the menu setting is needed to save, “Check Mark”...

  • Page 27: Display

    4.4 DISPLAY To access DISPLAY SETUP, press ENTER button after moving highlight icon to DISPLAY in MAIN MENU. DISPLAY SETUP will appear on monitor. 1) SEQ DEWLL TIME: NONE/ 1 to 60 seconds. SEQ DWELL TIME can be adjusted using LEFT or RIGHT button. Or after pressing ENTER button, SEQ DWELL TIME from none, 1 seconds to 60 seconds which decide a period of channel by channel can be selected by UP or DOWN button.
  • Page 28 4) CAM NO OSD: ON/ OFF When it is set as OFF, characters which indicates camera number will be disappeared on monitor. CAM NO OSD ON/ OFF can be changed using LEFT or RIGHT button. 5) VIDEO LOSS OSD: ON/ OFF VIDEO LOSS OSD ON/ OFF can be changed using LEFT or RIGHT button.

  • Page 29: Record

    4.5 RECORD To access RECORDING SETUP, press ENTER button after moving highlight icon to RECORD in MAIN MENU. RECORDING SETUP will appear on monitor. 1) STOP KEY: DISABLE/ ENABLE In case of manual recording, manual recording is started and stopped by the REC/ STOP button in the front panel of DVR.
  • Page 30 2) REC SETTING - Resolution: FULL (4 CIF, D1), HALF(2 CIF, Half D1), NORMAL (CIF) - Quality: VERY LOW, LOW, STANDARD, HIGH, VERY HIGH - FPS: 30 to 1 FPS.(NTSC)/ 25 to 1 FPS (PAL) - REC: MANUAL, Schedule, EVENT, OFF - Audio: ON or OFF - Lock: ON or OFF (If “Lock”...

  • Page 31: Event

    4.6 EVENT If EVENT is selected by ENTER button, below “EVENT SETUP” figure will be appeared. All the parameters related to EVENT Recording from CH1 to CH16 which include QUALITY, FRAME RATE, DURATION can be selected separately. EVENT Setup1 Selection EVENT Setup2 Selection Motion Area CH selection Motion Area Selection...
  • Page 32 2) Event Setup2 parameter Setting Sensitivity (5 step): Very Low, Normal, Very High Sensor: N.O or N.C Input: CH1 to CH16 Output: Trigger Output Selection Any output OFF, CH1 to CH4 can be selected. Buzzer: On/ Off Exit this menu. 3) MOTION AREA CH and 4) MOTION AREA Motion Area CH selection Motion Area selection...

  • Page 33: Schedule

    4.7 SCHEDULE SCHEDULE in the main menu can be selected by movement button such as LEFT, RIGHT or UP, DOWN button. If SCHEDULE is selected by ENTER button, below “Schedule Select” will be appeared. 1) “OFF” or “Weekly SET” or “ Daily SET” can be configured in Schedule Select. It can be selected by LEFT or RIGHT button.
  • Page 34 2) Weekly SET If “Weekly SET” is selected, below figure will be appeared. It is possible to configure ALARM, MOTION and MANUAL together in Weekly SET figure. Each mode from ALARM, MOTION to MANUAL can be changed by ENTER button. In Weekly SETUP Figure, movement button consists of LEFT, RIGHT or UP, DOWN button.

  • Page 35: Network

    4.8 NETWORK If NETWORK is selected by ENTER button, below “NETWORK SETUP” figure will be appeared. 1) CONNECT: STATIC or DHCP STATIC IP or DHCP of CONNECT can be selected by LEFT or RIGHT button. Or after pressing ENTER button, STATIC or DHCP can be selected by UP or DOWN button. And then ENTER button is used for confirming setting value.
  • Page 36 For assigning IP ADDRESS, SUBNET, GATEWAY and DNS in STATIC IP mode, ENTER button can be pressed on the column of IP address, SUBNET, GATEWAY and DNS. Then below NETWORK SETUP figure will be appeared. The 4 number group with 3 digit expressing IP ADDRESS, SUBNET, GATEWAY and DNS can be increased by UP button or decreased by DOWN button.
  • Page 37 8) NTP TIME SYNC: OFF/ON DVR can synchronize “standard time” with Time Server using Network Time Protocol. NOTE: If DNS server is not set properly in fixed IP address, this function will not be operated. 9) DDNS STATUS: Dynamic DNS status display (This DDNS status is just readable.) It is recommended not to use this DDNS service for fixed IP or IP sharing machine.

  • Page 38: Copy(Backup)

    4.9 COPY(BACKUP) BACKUP in the main menu can be selected by movement button such as LEFT, RIGHT or UP, DOWN button. If BACKUP is selected by ENTER button, below “BACKUP” figure will be appeared. 1) DEVICE: USB Storage or CD/DVD NOTE: the media type (USB Storage or CD/DVD) used for video backup also should be selected here.

  • Page 39: Hard Disk

    4.10 HARD DISK HDD DISK in the main menu can be selected by movement button such as LEFT, RIGHT or UP , DOWN button. If HDD is selected by ENTER button, below “HARD DISK” figure will be appeared. 1) OVERWRITE: HDD OVERWRITE can be used for repetitive recording in to same HDD space.
  • Page 40 2) FORMAT HDD: This support quick HDD format function. In order to format HDD in FORMAT HDD, after pressing ENTER button, “YES” or “NO” can be selected by LEFT or RIGHT button for HDD format 3) INFO: It shows total HDD capacity mounted in DVR.

  • Page 41: Camera

    4.11 CAMERA CAMERA in the main menu can be selected by movement button such as LEFT, RIGHT or UP, DOWN button. If CAMERA is selected by ENTER button, below “CAMERA SETTING” figure will be appeared. The movement from CAMERA NO to PTZ type in CAMERA SETTING can be done by UP or DOWN button.
  • Page 42 3) PTZ TYPE (Pan, Tilt and zooming protocol selection ): Panasonic/ Pelco-D/ PelcoP/ Techwin/ Niko/ DRX502A_DSC230s /KRE_301_302/ GC_755_NP/ TOA_CC554/ AS716LS and so on. The high end camera(s) with panning, tilting and zooming function would be connected with some of video inputs. The camera(s) has(have) its own control protocol needed to control panning, tilting and zooming, according to PTZ camera manufacturer.

  • Page 43: Section5 Searching For Playback

    Section5 Searching for Playback If search button is pressed for playback, all the search list with calendar style as below figure will be appeared. The search category such as ALL/ SCHEDULE/ MOTION/ ALARM/ MANUAL and TIME to find out recorded file much faster which want to play can be selected by DOWN or UP button.

  • Page 44: Section6 Live Display

    Section6 Live Display There are some of live display modes such as single (as full), QUAD, 9 picture, 16 picture. A) Full Picture B) QUAD picture C) 9 picture Display D) 16 picture Display Live audio selection for speaker output: One of audio channels which want to output through speaker can be selected by “MENU”...

  • Page 45: Section7 Backup Using Usb Memory Driver, Cd Or Dvd

    Section7 Backup using USB memory driver, CD or DVD 1) In order to search the file which is needed to copy in USB memory or CD or DVR, search button of front panel of DVR can be pressed. Below GUI will be appeared. 2) When Option “ALL”...
  • Page 46 4) If COPY(BACKUP) time is decided by ENTER button, Below GUI will be appeared. The channel(s) which want to copy can be selected here. According to channel selection, information about total file size to be copied will be shown. 5) It will start to copy the selected file, as soon as check box is pressed.

  • Page 47: Section8 Ptz Control

    Section8 PTZ Control a) Select the camera (which PTZ camera is connected) to control PTZ using Channel Selection button from CH1 to CH16 in front panel of DVR. b) Press PTZ button to select PTZ mode. PTZ MODE OSD will be displayed on upper right corner of monitor.

  • Page 48: Section9 F/W Upgrade

    Section9 F/W Upgrade 1) Copy upgrade firmware file, “dvr535352xx.tgz” into USB Memory Drive in advance. 2) Insert USB Memory Drive into USB port in front panel of DVR. 3) Press MENU button. 4) Select SYSTEM SETUP menu in main menu. 5) Move to UPGRADE of SYSTEM SETUP.
  • Page 49 6) While “Please wait” is appearing, F/W upgrade will be executed. It takes around 10 minutes. After completing F/W upgrade, your DVR will be automatically rebooted. 7) F/W Upgrade Completion S/W upgrade version will be seen on VERSION NO. of SYSTEM SETUP. Upgrade Version No.

  • Page 50: Section10 Client Software

    Section10 Client Software 10.1 Client Software (NetViewer, File Player, CMS) Installation CAUTION: If an older version of Client software or similar viewer software has been already installed on your computer, you should uninstall the software first. **Please follow below steps to finish client software installation 1) Insert the installation CD.
  • Page 51 4) Please select installation style in following dialog box. “Complete” can selected for normal installation. And then click Next. 5) Please wait for a while. 6) Installation is finished. And Net_View, File_Player and CMS icon will be shown in PC as below picture.

  • Page 52: Netviewer Software

    Note: Client Software consist of NetViewer, File Player and CMS. Requested PC System for Client Software are as below: Operation System: MS Windows 2000, XP ● CPU: Intel Pentium II 266MHz or higher ● RAM: 64MB or Higher ● VGA: AGP, Video RAM 8MB or Higher ●...
  • Page 53 2) Network Connection When this “CONNECT” icon is clicked, below “CONNECT ADDRESS” window will be appeared. A) How to add “CONNECT ADDRESS” NAME: Arbitrary name which can be remembered easily or be differentiated ● can be filled in “NAME”. ADDRESS: The IP address of DVR which want to access can be written in ●...
  • Page 54 “USER” and “ PASSWORD”, new “CONNECT ADDRESS” will be enrolled in address list. NOTE: One of easier way to add “CONNECT ADDRESS” is to click “ADD” after modification of “CONNECT ADDRESS” using “MODIFY”. It can be useful to add “CONNECT ADDRESS”, when there is at least one address list. B) How to delete “CONNECT ADDRESS”...
  • Page 55 4)Display Widow Selection A) Full Screen Display B) QUAD Picture Display C) 8 Pictures Display D) 16 Pictures Display Note: If one of 16ch pictures is double-clicked, the channel will become to be full picture. It return to 16 picture display with double-click once again. 5)PTZ Control Function Function...
  • Page 56 6)Local Setting When the “LOCAL SETTING” icon, of Main GUI is clicked, above sub-menu related to local setting will be appeared in main GUI. LOCAL SETTING consists of five parts which include OSD addition/ deletion, Motion-Alarm window pop-up, local recording path selection. Part1: OSD to add or delete the information of “channel number”...
  • Page 57 7)Remote Setting A) System configuration Video Format Video format is automatically detected after DVR power ON. The detected video information will be displayed on VIDEO FORMAT. User don’t need to change video format. Password Password can be changed using number button, 0 to 9 of keyboard. NOTE: The password of Factory Default in DVR is “1111”.
  • Page 58 TIME DATE OSG It defines that time and date OSG is added or deleted in display picture. POPUP It defines POP UP picture can be displayed as full screen or not, when motion is detected or alarm is triggered. The channel with motion detection or alarm triggered will be displayed as full screen during given seconds, about 30 sec.
  • Page 59 FRAME RATE: 60, 30, 15, 10, 5, 1, 0.5 IPS.(NTSC) AUDIO: ON/ OFF It defines whether audio signal with video together can be recorded or not. Recording of audio channel from CH1 to CH16 can be selected separately in 2) SELECT CH.
  • Page 60 F) EVENT SELECT CH: Recording parameters of video channel from CH1 to CH16 including quality, frame rate and so on can be adjusted separately. Before adjusting the parameter, channel number should be selected first. QUALITY: 5 levels (VERY LOW, LOW, STANDARD, HIGH, VERY HIGH) SENSITIVITY: 5 steps (VERY LOW, LOW, STANDARD, HIGH, VERY HIGH) FRAME RATE: 30, 15, 10, 5, 1FPS for NTSC.
  • Page 61 H) MONTH SCHEDULE Any day of a week from Monday to Sunday and any time of 24 hour can be reserved for MONTH SCHEDULE recording. Row of MONTH SCHEDULE consist of 24 hours. Column of MONTH SCHEDULE consist of Day1, Day2 and Day31. In the MONTH SCHEDULE, the schedule recording can be reserved separately.
  • Page 62 I) HDD “Total size” in shows the total capacity of all the HDD in DVR. “Free size” in is to show the remaining recordable capacity of HDD. “OVERWRITE” ON or OFF can be selected in . It is used for repetitive recording in to same HDD space.
  • Page 63 Playback procedure can be followed from Click “Play” for playback (PB). Select “minute” for PB. Select “hour” for PB. Select “channel” for PB. Select “date” for PB. If mouse button is double-clicked, Small picture will be changed and vice versa. Display “Playback time”.
  • Page 64 File download Click “Download”. * When selecting the minute for download, drag by mouse can be used. Select “minute” for PB. Select “hour” for PB. Select “channel” for PB Select “date” for PB. The downloaded files which was save in C:\DVRBACKUP\20080209 directory can be played using “File Player”.
  • Page 65 When “SAVE” icon is pressed, below sub-GUI of “SAVE” will be appeared and picture saving path will be requested as below figure. The file format for saving single picture is standard JPEG. When “PRINT” icon is pressed, below sub-GUI of “PRINT” will be appeared and picture printing path will be requested as below figure.
  • Page 66 11)Record “RECORD” can be utilized for saving live picture coming from remote DVR in local PC. If there is no changing of saving path to save picture, picture will be save in C:\DVRBACKUP. When “RECORD” icon is pressed, recording will be started with brighter “RECORD”...
  • Page 67 Mute ON or OFF can be selectable by “MUTE” icon. If “MUTE” icon is pressed for muting audio, volume indication will be disappeared like 13)Event Notification (Alarm, Motion) from remote DVR If motion in any channel is(are) detected or alarm is (are) triggered in any remote DVR, event information will be noticed to NetViewer as below picture.

  • Page 68: File Play Software

    10.3 File Play Software < File Player Program > < Icon Description > Name Name Folder Open Folder Open This “Folder Open” selection is for playback all the recorded files in same folder. If This “Folder Open” selection is for playback all the recorded files in same folder. If “Folder Open”...
  • Page 69 Volume Control and mute For audio playback with video, single channel which want to listen should be selected first using Single Channel Select or double click of that channel. The audio volume can be adjusted by dragging of left button of mouse.
  • Page 70 4) Single Channel Select “Each of 16 channel can be selected for full screen display by “ single channel select” CH01 CH02 CH03 CH04 CH05 CH06 CH07 CH08 CH09 CH10 CH11 CH12 CH13 CH14 CH15 CH16 10) Capture < CAPTURE procedure > Step1 Click “CAPTURE”...
  • Page 71 Step3 Then, this GUI will be appeared for path assignment to save “CAPTURE” image. Click “Confirm” (or “OK”) 11) File Conversion ( from MPEG4 to AVI) The MPEG-4 file format recorded in HDD can be converted into AVI file format which can be playback using common software like Windows media player installed in most of PC.

  • Page 72: Cms Software

    10.4 CMS Software 1) Main GUI of NetViewer Software < ICON description > Icon Description Network Connection and Disconnection Display Channel Selection for Full screen, QUAD, 8 picture and 16 picture display PTZ control for Pan, tilting, zooming and focusing Local Setting for OSD display and saving directory.
  • Page 73 2) Network Connection A) How to add Group in CONNECT GROUP for multiple DVR monitoring When “CONNECT” icon in main Window of CMS is clicked, below “CONNECT GROUP” window will be appeared. “Add Group” procedure is like Fill Group name (CMS_test5) in Input Group.
  • Page 74 B) How to add DVR in selected group If the “Group” is selected, same Group name will be appeared. Click “Group” Example NAME => MTG rm ADDRES: 16777009.goddns.org PORT => 10000 USER => admin PASSWORD => 11111111 View Channel => CH1 –CH4 (Select the Channel which you want to view in CMS Click “...
  • Page 75 B) How to delete DVR in selected group Click “ DELETE” First, click what to delete C) How to modify DVR in selected group Modify what want to modify Click “ MODIFY” First, click what to modify...
  • Page 76 D) How to start CMS monitoring Click “Group” Click “CONNECT” for CMS monitoring.
  • Page 77 E) How to delete group First, Select the Group which want to delete Click “Delete Group” F) How to modify (Rename) group First, Select the Group which want to delete Rename “the Group name” Click “Modify Group”...
  • Page 78 G) DVR movement between Group If CMS_test1 is double-clicked, below detail items will be appeared. Any item of one Group can be easily moved to another Group by drag and drop of mouse, after selecting one of any items in a Group. 3) Network Disconnection When “DISCONNECT”...
  • Page 79 **Below Function is the same as NetViewer software function. Please refer to 10.2 NetViewer Software** 4) Display Widow Selection 5) PTZ Control 6) Local Setting 7) Remote Setting 8) CAPTURE 9) RECORD 10) MIC ON, Volume Control and Mute 11) Remote Search 12) Event Notification If motion in any channel is(are) detected or alarm is (are) triggered in any remote DVR, event information will be noticed to CMS software as below picture.

  • Page 80: Appendix 1. Pin Description Of Connectors

    APPENDIX 1. Pin Description of connectors 1. USB Pin Descriptions (Front panel) 2. VGA Pin Descriptions Pin NO. Pin description Pin NO. Pin description D- (TX-) D+(TX+) No connected No connected SHIELD SYNC No connected No connected 3. RS485 Pin Descriptions Slave Unit like PTZ Camera Pin NO.
  • Page 81 4. Alarm Input & Outputs Pin Descriptions < Alarm Input Pin > < Alarm Output Pin > Pin NO. Pin description Pin NO. Pin description Sensor input 01 Relay output NO1 Sensor input 02 Relay output NC1 Sensor input 03 GND (Common) Sensor input 04 Relay output NO2...
