- Page 1 8CH/16CH H.264 Standalone DVR ADR-7616 User Manual Version 1.3...
- Page 3 Statement The information of the product in this manual is subject to change without prior notice and does not represent a commitment on the part of vendor, who assumes no liability or responsibility for any errors that may appear in this manual. This manual contains materials protected under International Copyright Laws.
-
Page 4: Table Of Contents
Table of Contents Section1 Introduction...........................5 1.1 Product Overview........................5 1.2 Product Features........................5 1.3 Product Specifications.......................5 1.4 Package .............................6 Section2 System Appearance & Installation ..................7 2.1 Front Panel..........................7 2.2 Rear Panel..........................10 2.3 HDD Installation........................12 Section3 Menu............................15 3.1 Menu Display...........................15 3.2 Menu Tree..........................16 Section4 Menu Setup .........................18 4.1 TIME............................19 4.2 RECORD..........................21... -
Page 5: Section1 Introduction
Section1 Introduction 1.1 Product Overview Designed for globally increasing surveillance requirements, ADR-7616 is a high performance 16ch standalone Digital Video Recorder. It takes H.264 compression format to not only improve video quality but also extend recording time over the same hard disk capacity, and the friendly UI design also enables users even unfamiliar with computer operations can easily control this DVR. -
Page 6: Package
120(100)fps at D1, 240(200)fps at Half-D1, 480(400)fps at CIF (NTSC(PAL)) Manual, Schedule, Alarm, Motion, Event, Mode Always Internal Support SATA HDD*4 (3.5”) Storage External Support eSATA RAID Alarm Input/Output 16/4/1 Via Browser Remote Monitoring & Remote control Network 3G mobile Option Pelco-D, Pelco-P protocol Power... -
Page 7: Section2 System Appearance & Installation
Section2 System Appearance & Installation 2.1 Front Panel 1. DVD-RW ● This can be used for file backup. 2. Jog and Shuttle ● Jog and shuttle enable user to operate DVR easier in handling such as fast forward, fast reverse playback and one frame movement in still picture. 3. - Page 8 will be released. c) PTZ (Pan, Tilt and Zooming) The camera(s) with panning, tilting and zooming function would be connected with one and some of video inputs of DVR. In order to control PTZ function of the camera, PTZ button should be pressed first. And then direction buttons for panning and tilting can be pressed.
- Page 9 7. Power Button (Power On/ Off button) This Power button can be pressed to turn off DVR power. When this button is pressed,password is requested. When right password is input, DVR power will be turned off. 8. USB 2.0 connector Used for F/W upgrade and data backup.
-
Page 10: Rear Panel
2.2 Rear Panel 1. FAN System fan 2. 16ch video inputs 16 channel composite video inputs with BNC connectors . NTSC or PAL video sources can be connected in DVR. But NTSC and PAL video sources for 16ch video inputs can not be mixed. - Page 11 and insert the wire in the hole below of connector pin. After releasing the pin, pull gently on the wire to make certain it is connected. To disconnect a wire, press and hold the connector pin above the wire and pull out the wire. 1) 16 alarm inputs: 1,2,3,4,…, 16,G(Ground) You can use external devices to signal the DVR responding to events.
-
Page 12: Hdd Installation
2.3 HDD Installation 1. First, open the upper casing by using a screwdriver to loosen the screws. The screws are located at the top (1), on the sides (4) and at the back (2) of DVR as indicated by the red circles. Remove the screws and keep them in a safe place for latter use. Once the upper casing is removed, the internal layout can be seen. - Page 13 3. Once the HDDs are installed into the HDD racks, place the racks back, align them with the holes on the chassis and tighten the screws. 4. Finally, connect the SATA and SATA power cable to the back of the HDDs Installed.
- Page 14 2.3 HDD Installation 1. Loosen the four screws holding the DVD-RW rack and remove the DVD-RW rack. 2. Remove the two screws on the DVD-RW rack and split it as the two part shown as below. 3. Position the two mounting plates on either side of the DVD-RW and then tighten them with screws.
- Page 15 5. Finally, connect the SATA and SATA power cable to the back of the DVD-RW. DVD- RW Installation is now completed.
-
Page 16: Section3 Menu
Section3 Menu 3.1 Menu Display ICON Description TIME System time/ date setup RECORD Recording parameters setup SCHEDULE Weekly recording schedule setup for Schedule recording mode MOTION Motion Area/ Sensitivity setup for Motion recording mode ALARM Alarm input type selection and Buzzer setup NETWORK Network parameters setup ADVANCED... -
Page 17: Menu Tree
3.2 Menu Tree 1.TIME 1.1 DATE SETUP 1.2 TIME SETUP 1.3 DATA DISPLAY FORMAT 1.4 TIME DISPLAY FORMAT 1.5 TIME ZONE SETUP 1.6 DAYLIGHT SAVING 2.RECORD 2.1 RESOLUTION 2.2 FPS 2.3 QUALITY 2.4 RECORD MODE 2.5 POST RECORD 2.6 LIVE AUDIO 3.SCHEDULE 4.MOTION 4.1 MOTION CH... - Page 18 7.1.4 SYSTEM INFO 7.1.5 EVENT LOG 7.1.6 FIRMWARE UPDATE 7.1.7 SETTING IMPORT/ EXPORT 7.1.8 USER MANAGEMENT 7.1.9 PERERCORD 7.1.10 DVR NUMBER 7.2 DISPLAY 7.2.1 CAMERA TITLE DISPLAY 7.2.2 RECODE MODE DISPLAY 7.2.3 AUTO-HIDE TOOLBAR 7.2.4 DWELL 7.2.5 DATE TIME POSITION 7.2.6 VGA MONITOR RATIO 7.2.7 RECORD DATE TIME 7.3 CAMERA...
-
Page 19: Section4 Menu Setup
Section4 Menu S etup For the first time using your DVR, you will want to establish the initial settings. This includes setting items such as time and date, record parameters, network and so on. In order to enter Main Menu for setup, first press MENU button of the front panel in DVR. NOTE: Password is necessary for entering main menu while AdminLock is set as ON (Default is OFF). -
Page 20: Time
4.1 TIME To access time setup, press ENTER button after moving highlight icon to TIME ICON in Menu. Time setup menu will appear on monitor shown as below. 1) DATE: Move Highlight icon to Date in the Time setup menu by using UP or DOWN button. Year, month and date can be changed after pressing ENTER button.
