Tarheel Antennas, Inc.
Instruction Manual
for the
Model 100A-HP
Continuous Coverage
HF Antenna
PROUDLY MADE IN THE
UNITED STATES OF AMERICA
18511 CR 304
St. Joseph, MO 64505
816-671-9409 / 816-364-2619 Fax
E-mail: sales@tarheelantennas.com
Technical Support
919-552-8788
E-mail: tarheelantennas@aol.com
www.tarheelantennas.com
Advertisement
Related Manuals for Tarheel Antennas 100A-HP
Summary of Contents for Tarheel Antennas 100A-HP
- Page 1 Tarheel Antennas, Inc. Instruction Manual for the Model 100A-HP Continuous Coverage HF Antenna PROUDLY MADE IN THE UNITED STATES OF AMERICA 18511 CR 304 St. Joseph, MO 64505 816-671-9409 / 816-364-2619 Fax E-mail: sales@tarheelantennas.com Technical Support 919-552-8788 E-mail: tarheelantennas@aol.com www.tarheelantennas.com...
- Page 2 Matching Coil Fuse Holder & Fuse 1 tube of Dielectric Compo und Manual Deluxe Package List for Model 100A-HP All of the above - - plus the following MT-1 Antenna Bracket Quick Disconnect for the Whip 21 ft. of RG-8X Coax with connectors installed...
-
Page 3: Installation
Installation Before installation of this antenna there are a few things you have to consider. To get peak performance you need to try to mount the antenna in a location where the decoupler (this is where the coil comes out of the antenna) is at least as high as the highest part of the vehicle. - Page 4 The MT-1 antenna bracket is designed to make your antenna mounting convenient and incredibly strong. Made to clamp to standard 1” pipe (1.312 OD) or bolted to a flat surface. (Picture 6) Picture 6 There are a few steps to make sure you install the MT-1 antenna bracket the way it is intended.
- Page 5 Included with the antenna is a special mix #31 ferrite core that needs to be mounted on the control wire as close to the antenna possible. Loop wire through the choke at least 3 times. (Picture 11) It is used to decouple the control cable from the antenna.
- Page 6 Now You Need To Install The Top Whip Whip Length versus Frequency Coverage 3 ft. --4.0 MHz to 32.0 MHz 4 ft.--3.7 MHz to 30.0 MHz 5 ft. --3.4 MHz to 29.0 MHz 6 ft. --3.2 MHz to 28.0 MHz 8 ft.
-
Page 7: Operation
IMPORTANT: Don’t make any adjustments to the matching coil until you read and understand the next paragraph. Now you need to go to the middle of 40 meters and check your SWR. Record that and then go to 80 meters and do the same. Your standing wave should be below 1.5 on both bands. If it is below 1.5 on both bands no adjusting is needed on the matching coil. - Page 8 Model 100A-HP -- 21.2 MHz with 5 ft. whip @ whip -- 29.0 MHz 1/2" of coil showing Model 100A-HP --14.2 MHz with 5 ft. whip @ 1 Model 100A-HP -- 7.1 MHz with 5 ft. whip @ 5" of 1/2" of coil showing coil showing...
- Page 9 Model 100A-HP -- 3.9 MHz with 5 ft. whip @ 15" Model 100A-HP -- 3.7 MHz with 5 ft. whip @ 16" of coil showing of coil showing Model 100A-HP -- 3.5 MHz with 5 ft. whip @ 18" of coil showing...
-
Page 10: Maintenance
Tarheel Antenna fails to perform due to quality or workmanship Tarheel Antennas will at our discretion either repair or replace at no charge for parts or labor. A return authorization number is required before warranty work can be performed.
