Insignia NS-PSD5321 Quick Setup Manual

Congratulations on your purchase of a
high-quality Insignia product. Your
NS-PSD5321 speaker system is designed
for reliable and trouble-free performance.
FEATURES
Multi-function Control Pod
# ITEM DESCRIPTION
1 Power LED Lights blue when the speaker system is turned on.
2 Master volume control Rotate clockwise to turn the volume up or counter-clockwise to turn the volume down.
3 (headphone) Plug your headphones into this jack.
output jack Note: With headphones connected, speaker sound will be muted.
Connect a second source, such as an MP3 player, to this jack.
4 AUX input jack
Slide the switch on the back of the control pod to turn on/off the speaker system.
5 Power switch
Connects the control pod to the subwoofer.
6 Subwoofer cable
Connect this cable to an audio line out jack (usually green) on a computer.
7 AUX cable
8 BASS volume control Rotate clockwise to turn bass volume up or counter-clockwise to turn bass volume
down.
The control pod wire is permanently attached to the subwoofer here.
9 Control pod wire
10 To Speaker jack Plug the connector from the speakers into this jack.
The power cord is permanently attached to the subwoofer here.
11 Power cord
PACKAGE CONTENTS
• Satellite speakers (2)
• Subwoofer with Control pod
• Quick Setup Guide
Subwoofer
Before using your new product, please read these instructions to prevent any damage.
Quick Setup Guide
Powered Computer Speakers with Subwoofer
SETTING UP YOUR SPEAKER SYSTEM
Positioning your speaker system
1 Place the speakers on opposite sides of the device
they are connected to and as far apart as possible.
2 Place the subwoofer on the floor.
Connecting to a computer
1 Make sure that the computer and your speaker
system are turned off and unplugged from the
power outlet.
2 Connect the control pod to your computer by
plugging the AUX cable with the green connector
that is hardwired into the control pod into the
audio line out, speaker, or headphone jack on the
computer (this jack is usually green).
AUX cable with
green connector
I
NS-PSD5321/NS-PSD5321-C
3 Connect the satellite speakers to the subwoofer by
plugging the connector into the "To Speaker" jack
on the subwoofer.
4 Plug the AC cable into a wall outlet or power strip.
5 Turn on the computer and your speaker system.
6 Use the master and bass volume controls on the
control pod to control the volume of your speaker
system.
Note: You may need to adjust volume levels on your
computer or source devices as well.
Connecting to portable audio devices
1 Make sure that the portable audio device and your
speaker system are turned off and unplugged.
2 Connect the headphone jack of your audio device
to the AUX input jack on your control pod using an
AUX cable (not included).
3 Plug the AC cable into a wall outlet or power strip.
4 Turn on the audio device and your speaker system.
5 Use the controls on your audio device to control
playback.
Notes:
• This connection will override your computer source
connection while it's plugged in.
• You can control playback volume using the control pod.
AUX cable
(not included)
