Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5
Preface CE Marking This device has been tested to and conforms to the regulatory requirements of the European Union and has at- tained CE Marking. The CE Mark is a conformity marking consisting of the letters “CE”. The CE Mark applies to products regulated by certain European health, safety and environmental protection legislation.
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 10
Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Preface Power Safety The computer has specific power requirements: • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a Power Safety steady, uninterrupted power supply. If you are unsure of your local power specifications, Warning consult your service representative or local power company.
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 16
Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 17
Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Preface Contents Notice ................................I EuP-Standby and Off Mode Power Consumption Statement: ..............II FCC Statement ............................IV FCC RF Radiation Exposure Statement: ..................... V Instructions for Care and Operation ......................VII Power Safety ...............................IX Polymer Battery Precautions ........................X Battery Precautions .............................XI Cleaning ..............................
Page 20
Preface System Map: LCD Panel Open - Model A ....................1-6 System Map: LCD Panel Open - Model B ....................1-7 LED Indicators ............................1-8 Keyboard- Model A ...........................1-9 Keyboard- Model B ..........................1-10 Function/Hot Key Indicators ........................1-11 Control Center ............................1-12 System Map: Front & Left Views ......................1-13 System Map: Right &...
Page 21
Preface Multi-In-1 Card Reader ..........................2-6 TouchPad and Buttons/Mouse ........................2-7 Gestures and Device Settings ........................2-9 Audio Features ............................2-12 Power Management Overview ..............................3-1 The Power Sources ............................3-2 AC/DC Adapter ............................3-2 Battery ................................3-2 Turning On the Computer ..........................3-3 Power Plans ...............................3-4 Power-Saving States ..........................3-6 Sleep ................................3-6 Hibernate ..............................3-7 Shut down ..............................3-7...
Page 22
Preface New Battery .............................3-13 Recharging the Battery with the AC/DC Adapter ...................3-13 Proper handling of the Battery Pack ......................3-14 Battery FAQ .............................3-15 Drivers & Utilities What to Install ............................4-1 Module Driver Installation ........................4-1 Driver Installation ............................4-2 Updating/Reinstalling Individual Drivers ....................4-4 User Account Control ..........................4-5 Windows Security Message ........................4-5 New Hardware Found ..........................4-5...
Page 23
Preface Audio .................................4-7 Windows Experience Index ........................4-8 Optional Drivers ............................4-9 BIOS Utilities Overview ..............................5-1 The Setup Utility ............................5-2 Failing the POST ............................5-3 Fatal Errors ..............................5-3 Non-Fatal Errors ............................5-3 Setup Screens .............................5-4 Main Menu ..............................5-5 System Time & Date (Main Menu) ......................5-5 SATA Port # (Main Menu) ........................5-6 System/Extended Memory: (Main Menu) ....................5-6 MB Series / BIOS Revision / KBC/EC firmware Revision ..............5-6...
Page 24
Preface USB 2.0 Combo Port Power / Powered USB 2.0 Port Power (Advanced Menu > Advanced Chipset Control) ..................5-8 Intel Smart Connect Technology (Advanced Menu) .................5-8 Intel(R) Rapid Start Technology (Advanced Menu) .................5-9 Intel Anti-Theft Technology (Advanced Menu) ..................5-9 SATA Mode (Advanced Menu) ........................5-9 Boot Logo (Advanced Menu) ........................5-10 Power On Boot Beep (Advanced Menu) ....................5-10 Battery Low Alarm Beep (Advanced Menu) ...................5-10...
Page 25
Preface When Not to Upgrade ..........................6-2 Removing the Battery ..........................6-3 Upgrading the Hard Disk Drive .........................6-4 Removing the Hard Disk ...........................6-5 Upgrading the Optical (CD/DVD) Device ....................6-7 Upgrading the Optical (CD/DVD) Device for Model A Computers ............6-7 Upgrading the Optical (CD/DVD) Device for Model B Computers ............6-10 Upgrading the System Memory (RAM) ....................6-11 Modules &...
Page 26
Preface Intel® WiDi Application Installation ......................7-32 Intel® Wireless Music Driver Installation ....................7-32 Intel® WiDi Application Configuration ....................7-33 Bluetooth & WLAN Combo Module ......................7-36 3rd Party Bluetooth (V4.0) Combo Driver Installation ................7-37 Intel Bluetooth Combo Driver Installation ....................7-38 Standard Bluetooth (V4.0) Configuration in Windows 7 ................7-39 3G Module ...............................7-43 Wireless Manager ............................7-46 Wireless Manager Installation .........................7-46...
Page 28
Preface Notebook Ports and Jacks .........................A-2 Control Center Overview ..............................B-1 Video Driver Controls Video Driver Installation ..........................C-1 Dynamic Video Memory Technology ......................C-1 Intel® Graphics & Media Control Panel ....................C-2 Display Devices & Options ........................C-4 Attaching Other Displays .........................C-5 Configuring an External Display in Windows 7 ..................C-8 HDMI Audio Configuration ........................C-11 Specifications Processors ..............................D-2...
Page 29
Preface Interface ..............................D-3 Card Reader ..............................D-3 Slot ................................D-3 Communication ............................D-3 Power Management ..........................D-3 Power ................................D-4 Indicators ..............................D-4 BIOS .................................D-4 Security ..............................D-4 Features ..............................D-4 Operating System ............................D-4 Environmental Spec ..........................D-4 Dimensions & Weight ..........................D-4 XXVII...
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system.
Quick Start Guide System Map: LCD Panel Open - Model A Figure 1 - 2 LCD Panel Open - Model A Built-in PC Camera Wireless Device Operation Aboard (Optional) Aircraft Built-In Microphone The use of any portable electronic Power Button transmission devices aboard air- craft is usually prohibited.
Quick Start Guide System Map: LCD Panel Open - Model B Figure 1 - 3 LCD Panel Open - Model B Wireless Device Built-in PC Camera Operation Aboard (Optional) Aircraft Built-In Microphone The use of any portable electronic transmission devices aboard air- Power Button craft is usually prohibited.
Quick Start Guide LED Indicators The LED indicators on the computer display helpful information about the current status of the computer. Icon Color Description Orange DC Power is Plugged In Green The Computer is On The Computer is in Sleep Blinking Green Mode Orange...
Quick Start Guide Keyboard- Model A The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 2, on page 1 - 11 for full function key combination details.
Quick Start Guide Keyboard- Model B The keyboard has an embedded numerical keypad for easy numeric data input, and Other Keyboards features function keys to allow you to change operational features instantly. See Table 1 - 2, on page 1 - 11 for full function key combination details.
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...
Quick Start Guide Control Center Press the Fn + Esc key combination, or double-click the icon in the notification area of the taskbar to toggle the Control Center on/off. The Control Center gives quick access to frequently used controls and en- ables you to quickly turn modules on/off (see Appendix B for full details).
Quick Start Guide System Map: Front & Left Views Figure 1 - 6 Front & Left Views LED Indicators Multi-in-1 Card Reader DC-In Jack RJ-45 LAN Jack External Monitor Port Vent/Fan Intake/ Outlet HDMI-Out Port Multi-In-1 Card Reader 2 * USB 3.0 Ports The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / RS MMC SD (Secure Digital) / Mini SD / SDHC / SDXC...
Quick Start Guide System Map: Right & Rear Views Figure 1 - 7 Right & Rear Views Model A 1. Microphone-In Jack 2. Headphone-Out Jack Model B 3. 1 *USB 2.0 Port (Model A) 2 *USB 2.0 Ports (Model B) 4.
Page 45
Quick Start Guide Disk Eject Warning Changing DVD Regional Codes Don’t try to eject a CD/DVD while the system is Go to the Control Panel and double-click accessing it. This may cause the system to Device Manager (Hardware and Sound), “crash”.
Quick Start Guide System Map: Bottom View - Model A Figure 1 - 8 Bottom View Model A Battery Component Bay Cover Vent/Fan Intake/ Outlet Hard Disk Bay Cover Speakers Overheating The CPU is not a user To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake while the computer is in use.
Quick Start Guide System Map: Bottom View - Model B Figure 1 - 9 Bottom View Model B Battery Component Bay Cover Vent/Fan Intake/ Outlet Hard Disk Bay Cover Speakers Overheating To prevent your computer from overheating make sure nothing blocks the Vent/Fan Intake The CPU is not a user while the computer is in use.
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Quick Start Guide Video Features You can switch display devices, and configure display options, from the Display control panel (in Appearances and Personalization) in Windows 7 (see over). To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearances and Personalization category.
Page 50
Quick Start Guide To access the Intel(R) Graphics and Media Control Panel: Click Advanced settings (Figure 1 - 11 on page 1 - 19) in the Display Settings control panel in Windows. Click Graphics Properties (button) (Figure 1 - 12) in the Intel Graphics & Media Control Panel tab. Right-click the desktop and select Graphics Properties from the menu.
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 18) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-In-1 Card Reader • TouchPad and Buttons/Mouse •...
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page D - 2). The Adjustment optical device is usually labeled “Drive D:”...
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Features & Components DVD Regional Codes To change the DVD regional codes: DVD Region Note Go to the Control Panel Double-click Device Manager (Hardware and Sound), then click the + next to DVD region detection is DVD/CD-ROM drives. device dependent, not Double-click on the DVD-ROM device to bring up the Properties dialog box, and OS-dependent.
Features & Components Multi-In-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Features & Components TouchPad and Buttons/Mouse The TouchPad is an alternative to the mouse; however, you can also add a mouse to Mouse Driver your computer through one of the USB ports. The TouchPad buttons function in much the same way as a two-button mouse. If you are using an ex- ternal mouse your op- erating system may be...
Page 60
Features & Components Once you have installed the TouchPad driver (see “Touchpad” on page 4 - 6) you can configure the functions from the Mouse control panel in Windows, or by double- clicking the TouchPad driver icon in the notification area. You may then config- TouchPad Scrolling ure the TouchPad tapping, buttons, scrolling, pointer motion and sensitivity options This computer model se-...
Features & Components Gestures and Device Settings The Synaptics Gestures Suite application allows you to use a specific gesture (ac- tion) on the surface of the TouchPad to perform specific actions to manipulate doc- Show Video uments, objects and applications. You can get a clearer view of the gestures in- volved by clicking the...
Page 62
Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the TouchPad surface and slide both fingers in the direction required (in a straight con- tinuous motion).
Page 63
Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the TouchPad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, from the HD VDeck icon on the desktop or VIA HD Audio Adjustment Deck control panel The sound volume level is set using the volume The volume may also be adjusted by means of the Fn + F5/F6 key combination.
Page 65
Features & Components Expert Mode will allow you to access more advanced configuration menus for Speaker, Microphone and Stereo Mix. Syncing Left & Right Volume Balance If you wish to adjust the left and right channel volume levels separately, you will need to adjust this from the VIA HD Audio Deck in Ex- pert Mode.
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the LCD and hard disk drive) or the whole system.
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack on the left of the computer.
Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 71
Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color...
Power Management Power Conservation Modes This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Power Conservation of inactivity. Adjust Power Conservation Modes from the Control Center: Modes The Energy Star setting Press the Fn + Esc key combination to toggle the Control Center on/off.
Power Management Battery Information Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Windows Mobility Center • Lower the brightness level of the LCD display. The system will decrease LCD brightness slightly to save power when it is not powered by the AC/DC adapter.
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 82
Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 83
Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 84
Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Drivers & Utilities Chapter 4: Drivers & Utilities Driver Installation & This chapter deals with installing the drivers and utilities essential to the operation or Power improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the latest versions of most available op- When installing driv- erating systems haven’t built in drivers and utilities.
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc and click Install Drivers (button), or Option Driv- Drivers Installer menu below.
Drivers & Utilities Manual Driver Installation Updating/Reinstalling Individual Drivers Click Browse CD/DVD (button) in the Drivers Install- If you wish to update/reinstall individual drivers it er application and browse to the executable file in the may be necessary to uninstall the original driver.To do appropriate driver folder.
Drivers & Utilities User Account Control New Hardware Found If a User Account Control prompt appears as part of If you see the message “New Hardware Found” dur- the driver installation procedure, click Continue or ing the installation procedure (other than when out- Allow, and follow the installation procedure as direct- lined in the driver install procedure), click Cancel to close the window, and follow the installation proce-...
Drivers & Utilities Hot Key Audio 1. Click 6.Install Hotkey AP > Yes. 1. Click 9.Install Audio Driver > Yes. 2. Click Next > Next. 2. Click Next. 3. Click Finish > Finish to restart the computer. 3. Click the button to agree to the license and click Next.
Drivers & Utilities Windows Experience Index After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- Windows Update ence Index (make sure the AC/DC adapter is plugged After installing all the drivers make sure you enable Win- in): dows Update in order to get all the latest security up- 1.
Drivers & Utilities Optional Drivers See the pages indicated in Table 4 - 1, on page 4 - 3 for the driver installation procedures for any modules in- cluded in your purchase option. Figure 4 - 3 - Option Drivers Note that you need to install both the WLAN &...
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- system (e.g.
BIOS Utilities The Setup Utility Each time you turn on the computer the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized distributor/supplier as soon as possible.
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting and port pow- er control. Advanced Menu 5 - 7...
BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control) You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is started up or restarted. Enabling the power setting will have the module retain the last power status (on or off) before any restart or shut down.
BIOS Utilities Intel(R) Rapid Start Technology (Advanced Menu) Enable/disable Intel(R) Rapid Start Technology from this menu. The rapid start hibernation mode can resume power within 5 to 6 seconds and can remember your SATA Mode computer's state with zero power. Selection If you have installed the Intel Anti-Theft Technology (Advanced Menu)
BIOS Utilities Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup. If you disable the Boot Logo you will not see the F2 Enter Setup or F7 Boot Options prompts on the screen, however you can still press these keys, while the boot screen is displayed, to perform the Enter Setup or Boot Option functions.
BIOS Utilities Security Menu Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your machine as it boots up after you turn it on. These settings do not affect your machine or network passwords which will be set in your...
BIOS Utilities Note: To clear existing passwords press Enter and type the existing password, then press Enter for the new password (without typing any password entry) and Enter again to confirm the password clearance. Password Warning If you set a boot pass- Set User Password (Security Menu) word (Password on boot You can set a password for user mode access to the Aptio Setup Utility.
BIOS Utilities TPM Configuration (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select TPM Configuration and press En- ter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu (see “Trusted Platform Mod- ule”...
BIOS Utilities TPM State (Security Menu > TPM Support Enabled) Select TPM State, press Enter and select Enable to change the TPM state to en- abled. You will then need to press F4 to save the changes and restart the computer. Figure 5 - 6 TPM State (Enabled) As the computer restarts press F2 to enter the BIOS again and go to the TPM Con-...
BIOS Utilities Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer.
BIOS Utilities Boot Menu Figure 5 - 8 Boot Menu BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
BIOS Utilities Boot Option Priorities (Boot Menu) Use the arrow keys to move up and down the menu, and go to either CD/DVD ROM Drive BBS Priorities or Hard Drive BBS Priorities and use the F5 and F6 keys to move the device’s boot priority up and down the list (the selected device will be highlighted in white).
BIOS Utilities Exit Menu Figure 5 - 9 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help.
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn the computer off, and turn it over. Please check with your Slide the latch in the direction of the arrow.
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page D - 2).
Upgrading The Computer Removing the Hard Disk Turn off the computer, and turn it over and remove the battery (see page Remove the screws & Lift the hard disk bay cover up from point Remove hard disk bay cover Figure 6 - 2 Hard Disk Bay Cover Removal Upgrading the Hard Disk Drive 6 - 5...
Page 118
Upgrading The Computer Slide the HDD assembly in the direction of arrow Remove the HDD assembly Remove the screw(s) and the adhesive cover Figure 6 - 3 Hard Disk Assembly Removal Reverse the process to install a new hard disk drive Replace the hard disk bay cover and screws.
Upgrading The Computer Upgrading the Optical (CD/DVD) Device The procedure for removing the optical device will depend upon your particular computer model: • See “Upgrading the Optical (CD/DVD) Device for Model A Computers” on page 6 - • See “Upgrading the Optical (CD/DVD) Device for Model B Computers” on page 6 - 10 Upgrading the Optical (CD/DVD) Device 6 - 7...
Upgrading The Computer Upgrading the Optical (CD/DVD) Device for Model A Computers Turn off the computer, and turn it over and remove the battery (see page Locate the component bay cover and remove screws Remove the component bay cover Figure 6 - 4 Removing the Component Bay Cover (Model A)
Page 121
Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Figure 6 - 5 Removing the Optical Device Drive (Model A) Reverse the process to install the new device. Replace the component bay cover and screws (see page Upgrading the Optical (CD/DVD) Device 6 - 9...
Upgrading The Computer Upgrading the Optical (CD/DVD) Device for Model B Computers Turn off the computer, and turn it over and remove the battery (see page Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device.
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page D - 2 details of supported module types). Turn off the computer, and turn it over and remove the battery (see page Locate the component bay cover and remove screws Remove the component bay cover...
Page 124
Upgrading The Computer The memory sockets are visible at point Figure 6 - 8 RAM Module Location Contact Warning Be careful not to touch Gently pull the two release latches on the sides of the memory socket in the the metal pins on the module’s connecting...
Page 125
Upgrading The Computer The RAM module will pop-up, and you can remove it. Single Memory Module Installation If your computer has a sin- gle memory module, then Figure 6 - 10 insert the module into the RAM Module Channel (JDIMM1) Removal socket.
Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard Aircraft This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Modules & Options PC Camera Module Before installing the PC Camera driver, make sure that the optional PC Camera is Latest PC Camera on. Use the Fn + F10 key combination (see “Function/Hot Key Indicators” on Driver Information page 1 - 11) or Control Center button to toggle power to the PC Camera module.
Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3.
Page 130
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 131
Modules & Options Figure 7 - 1 Audio Setup for PC Camera Right-click PC Camera Module 7 - 5...
Page 132
Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see Set Capture File below).
Page 133
Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 134
Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 135
Modules & Options Taking Still Pictures The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Modules & Options Wireless LAN Module If you have included an Intel® or 3rd Party Wireless LAN (or WLAN & Bluetooth Wireless Device combo) module in your purchase option, make sure that the WLAN module is on be- Operation Aboard fore installing the driver.
Modules & Options 3rd Party 802.11b/g/n Driver Installation (for WLAN Module) See over for information on installing the drivers for the 3rd party WLAN & Blue- tooth combo modules. If you see the message “Found New Hardware” click Cancel to close the window. 1.
Modules & Options 3rd Party 802.11b/g/n Driver Installation (Combo Modules) If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive. 2.
Modules & Options Intel® WLAN Driver Installation For a standard Intel® WLAN driver installation and configuration choose the Typ- ical Installation below and use the Windows OS for Wireless LAN control (see overleaf). If you want to use Intel® PROSet/Wireless WiFi Connection Utility as your WLAN interface, and/or add Intel®...
Page 140
Modules & Options Custom Installation (for Intel® ProSet and/or Intel® MyWiFi Technology): Note that if you wish to install Intel® MyWiFi you will need to install Micro- soft.net Framework 4.0 (or later version) before installing the driver as per the procedure below.
Modules & Options Connecting to a Wireless Network in Windows 7 Make sure the Wireless LAN module is turned on. Network and Click the taskbar wireless icon , and then double-click an access point to con- Sharing Center nect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net- setting changes, and creating a new network).
Page 143
Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 144
Modules & Options Click the taskbar icon to see any currently connected networks. To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Modules & Options Intel Connecting to a Wireless Network Using ® PROSet Wireless (For Intel® WLAN Modules Only) Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > WiFi Connection Utility). Click to select a network from the found list WiFi network access points, or click Refresh to update the list.
Page 146
Modules & Options Click Connect to connect to the select WiFi network access point. If the access point is encrypted then you will need to enter the password and click Figure 7 - 8 Intel® PROSet/ Wireless WiFi Connection Utility (Connecting &...
Modules & Options Intel My WiFi Configuration ® (For Intel® WLAN Modules Only) Intel® My WiFi Technology (Intel® MWT) uses your WLAN to transform your Intel® My WiFi Help system into a WiFi Personal Area Network, and enables you wirelessly share your To get help on Intel®...
Page 148
Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Make sure the Wireless LAN module is on. Access the Intel® WiFi Connection Utility from the Start menu (Start > All Programs > Intel PROSet Wireless > Intel(R) My WiFi Dashboard), or click the icon in the notification area of the taskbar (or right-click and select Open Dashboard).
Page 149
Modules & Options Intel® My WiFi Interface Help Wireless ON/OFF Configuration Options & Preferences Figure 7 - 10 Intel® My WiFi Utility - Interface Your Computer Wireless LAN Module 7 - 23...
Page 150
Modules & Options Intel® My WiFi Help Click the Help icon in the dashboard to bring up the Help menu and select and item from the Contents menu to obtain the help information. Help Figure 7 - 11 Intel® My WiFi Utility - Help Your 7 - 24 Wireless LAN Module...
Page 151
Modules & Options Preferences Click the Options icon and select Preferences to configure the options. Help Figure 7 - 12 Intel® My WiFi Utility - Preferences Your Computer Wireless LAN Module 7 - 25...
Page 152
Modules & Options Hotspot You can turn the computer into a hotspot to allow other devices to connect to it (and any locally connected devices), and also (if available) the internet. Click the Hotspot icon to turn the Hotspot on. The Hotspot settings tab shows the SSID and password (you will need to enter this information when accessing the hotspot from the client computer/device).
Page 153
Modules & Options Finding Devices You can find any Nearby Devices by clicking the Refresh button in the main window. Click again at any time to update the list. If a lot of devices are found they will be listed on multiple pages and you can use the left or right buttons to turn the pages.
Page 154
Modules & Options Favorite Devices The Favorite Devices tab is where you keep devices to which you connect most of- ten, and this is particularly useful in environments where many devices are listed nearby. A favorite device will display the icon To make any device a favorite just click to select it and select Add Favorite.
Page 155
Modules & Options Connect to a Device Click the device you want to connect to, and click the connect icon An invitation will be sent to the target device. The user must then accept the invitation. After the invitation is accepted the connection will be made. Use the Windows Network and Sharing Center to set permissions for viewing and sharing the resources on your computer with another connected computer.
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Modules & Options Intel Wireless Display Application ® The Intel ® Wireless Display Application (requires Intel® Centrino WLAN/ Compatible Combo module), in conjunction with a compatible video adapter (purchased sep- Adapters arately), allows you to display the contents of the notebook display on another dis- play (e.g.
Modules & Options Intel WiDi Application Configuration ® Click Start > All Programs > Intel Corporation > Intel(R) Wireless Display > Intel(R) Wireless Display, or double click the icon on the desktop. Click I agree to the terms of this license (button). The application will scan for any connected compatible adapters (or you can click the Scan for available adapters button to enable Intel My WiFi Technology).
Page 160
Modules & Options Click to select and detected adapters, and click Connect. The system will then prompt you to enter the 4-digit security code which will be displayed on the external TV Screen (or press the connect button on the wireless speaker adapter).
Page 161
Modules & Options You will then be prompted to enter a name for the video adapter and click Continue. Click Finished to complete the setup. Test Audio Adapter To verify a successful audio connection (for In- tel® Wireless Music), select the “Test your audio connection”...
Modules & Options Bluetooth & WLAN Combo Module If your purchase option includes the Combination Wireless LAN & Bluetooth Wireless Device module (either Intel® or 3rd Party) then install the driver as instructed overleaf. Operation Aboard Aircraft Use the Fn + F12 key combination or Control Center button to toggle power to the Bluetooth module.
Modules & Options 3rd Party Bluetooth (V4.0) Combo Driver Installation Note this driver is only required for the 3rd Party combo Bluetooth and WLAN module (Bluetooth V4.0). 1. Before installing the driver make sure the Bluetooth module is powered on (use Fn + F12 key combination), then insert the Device Drivers & Utili- ties + User’s Manual disc into the CD/DVD drive.
Modules & Options Intel Bluetooth Combo Driver Installation Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Modules & Options Standard Bluetooth (V4.0) Configuration in Windows 7 Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 166
Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 167
Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure 7 - 21 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 168
Modules & Options To Change Settings for the Bluetooth Device Click the notification area icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Modules & Options 3G Module If you have included an optional UMTS/HSPDA OR UMTS/HSPDA+ based 3G Module (Universal Mobile Telecommunications System or High Speed Packet Ac- cess) module (see “Communication” on page D - 3 for specification details) in your purchase option, you will have the appropriate application (Wireless Manager) pro- vided for your particular module.
Page 170
Modules & Options 3G Module USIM Card Installation Follow the instructions below to install the USIM card (which will be provided by your service provider). Power Safety Warning Turn off the computer, and turn it over. Slide the latch in the direction of the arrow.
Page 171
Modules & Options Before installing the application, make sure that the 3G module is ON (installing the driver with the module off will not allow the software to detect the module hard- ware correctly). Use the Fn + key combination (see Table 1 - 2, on page 1 - 3G Modules &...
Modules & Options Wireless Manager With the 3G module and USIM card (supplied by your service provider) installed you may then install the Wireless Manager application. The Wireless Manager Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard Aircraft puter.
Modules & Options Wireless Manager Application The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a PIN Number Profile”...
Page 174
Modules & Options The system will connect to your network. Connected will appear above the timer icon (the timer will indicate your connected time for the current session) Wireless Manager You can then access the internet, download e-mail etc. as per any internet Help connection.
Page 175
Modules & Options Click the Wireless Manager notification area icon to view the connection status, or wireless icon to view the Mobile Broadband Connection status Figure 7 - 27 Notification Area Icons (Connected) Notification Area The indicator will display the signal strength and radio access Icon technology.
Modules & Options Profiles Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click the Settings > Advanced. Click the Profiles (tab). Figure 7 - 28 Advanced Settings - Profiles 7 - 50 3G Module...
Page 177
Modules & Options Multiple profiles may be available from the USIM card and the first time the application starts it may require you to select a profile (Set Profile) to use for your connection. Figure 7 - 29 Multiple Profiles Found Automatic Profile Selection If Automatic selection is chosen, then the application will search the operator pro-...
Page 178
Modules & Options Selecting a Profile Click Manual selection (button). Click the Filter to view the drop-down list. Select the Profile you wish to use and click Apply to confirm the selection. Figure 7 - 30 Profile - Manual Selection (Filter) 7 - 52 3G Module...
Page 179
Modules & Options Creating a Profile Click Manual selection (button). Click the New. Deleting a Profile Enter a name you prefer for the profile. Enter the Access Point Name (APN). To delete a profile click Enter the User Name and Password if required (some service providers may not to select Manual selec- require this information and the fields may then be left blank).
Modules & Options Settings The Settings tab allows you at adjust the application features. Click to put a tick in Launch Wireless Manager at Windows startup to launch the application at Win- dows Startup. Figure 7 - 32 Settings The Advanced settings allows more detailed configuration. To access the Ad- vanced settings: Access the Wireless Manager program from the Start menu (Start >...
Page 181
Modules & Options Most USIM cards are protected by a Personal Identity Number (PIN). You may turn on or off the Request PIN at startup (click Apply to save any changes). You can PIN Notes also Change PIN (you will need to enter the new PIN in the two fields provided and click Apply to save any changes).
Page 182
Modules & Options Networks The mobile network list lists available networks at your location, and allows you to select a network which to connect. You must disconnect before being able to select Warning a network. Note that some applica- tions automatically Connection...
Modules & Options Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Wireless Manager, if your service supports SMS. SMS Utility Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 184
Modules & Options Messages Click the Messages tab to access the tabs displaying text messages. The tabs at the top of the menu display the Inbox, Drafts, Outbox, Sent and Trash menus. Inbox Drafts Outbox Sent Trash Figure 7 - 36 SMS Utility Messages Text messages are automatically saved to your computer and may be sorted in as-...
Modules & Options Sending a Text Message Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click SMS and the SMS Utility will then start. Click the New Message tab.
Page 186
Modules & Options Click Send to send the message or Save to save the message in the Drafts folder. Clicking the Clear icon clears both the Message and To fields. If radio is on then the message will be sent, however if the radio is off the message will be stored in the Outbox.
Page 187
Modules & Options Messages • Opening a text message: Double-click the message and the message will open in a new window (to close it click the close icon in the top right of the message). Figure 7 - 39 Click to close the message Close Message •...
Modules & Options Phonebook The Phonebook allows you to view and edit all your frequently used contacts, and is divided into Contacts and Groups . To access the Phonebook: Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 189
Modules & Options Contacts • New Contact: Click the New contact button to create a contact. Add the name and at least one phone number (Mobile, Work, Home and Other Import/Export fields are available) for the contact. Click the icon to expand the number Contacts details.
Page 190
Modules & Options Groups You can organize existing contacts into groups from the Groups tab. • New Group: Click the New group button to create a group. Click icon to expand the group details, and click a check box to add at least one phone number from the contacts for the group.
Modules & Options SMS Settings The SMS Utility Settings tab allows you at adjust the SMS features. Figure 7 - 43 SMS Utility Settings SMS Settings Message Length: You can set the number of blocks that can be sent (up to a length of 10 blocks).
Page 192
Modules & Options Send Click Delivery Report to automatically request a reply from a recipient. If you click to Send messages in Outbox automatically upon connection then messages writ- ten when the radio is off, will then be sent automatically the next time radio is turned on.
Page 193
Modules & Options Number You can choose to Use default service center number or you can uncheck the box and add your number manually if your service provider supplies a different number (click Apply to save the change or Default to return to the default number). Memory Phonebook memory status displays the number of contacts displayed on the USIM card.
Modules & Options Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.
Modules & Options Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu. Select TPM Configuration and press Enter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu.
Page 196
Modules & Options Select Pending operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership and press Enter). You will then need to press F4 to save the changes and restart the computer. Figure 7 - 47 Pending TPM operation...
Modules & Options Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver (if you do not do see the note below). 2. Insert the Device Drivers & Utilities + User’s Manual disc into the DVD drive.
Modules & Options Initializing TPM Run the application from the Infineon Security Platform Solution > Manage Security Platform item in the Start > Programs menu. Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
Page 199
Modules & Options Choose the Security Platform Features you want to use by clicking the appropriate tickbox. Enter a Basic User Password (and re-type to confirm it) and click Next. Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use the Security Platform Fea-...
Modules & Options Infineon Security Platform Settings Tool The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
Page 201
Modules & Options User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
Page 202
Modules & Options Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion.
Page 203
Modules & Options Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 54 Infineon Security Platform Settings Tool (Migration) Trusted Platform Module 7 - 77...
Page 204
Modules & Options Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 55 Infineon Security Platform Settings Tool (Password Reset) 7 - 78 Trusted Platform Module...
Page 205
Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
Page 206
Modules & Options Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 57 BitLocker Drive Encryption 7 - 80 Trusted Platform Module...
Page 207
Modules & Options Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 58 Infineon Security Platform Settings Tool (Advanced) Trusted Platform Module 7 - 81...
Modules & Options Intel Rapid Storage Technology ® Install the Intel Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - 9), or if you have set up your hard disks in a RAID configuration for Intel® Smart Re- sponse Technology (see overleaf).
Modules & Options Intel® Smart Response Technology Intel® Smart Response Technology is an Intel® Rapid Storage Technology (RST) caching feature that accelerates computer system performance by using the SSD as cache memory between the hard disk drive and system memory. System Requirements to support Intel®...
Modules & Options Enabling Intel Smart Response Technology Run the Intel® Rapid Storage Technology application from the All Programs menu. Click Enable acceleration either under Status or Accelerate. Figure 7 - 59 Enable Acceleration Select the SSD to be used as a cache device. Select the size from the SSD to be allocated for the cache memory (any remaining space on the SSD can be used for data storage using the simple data single-disk RAID 0 volume that is automatically created).
Page 211
Modules & Options Select the HDD (or RAID volume) to be accelerated (it is highly recommended that you accelerate the system volume or system disk for maximum performance). Select the acceleration mode, and then click OK (Enhanced mode is selected by default).
Page 212
Modules & Options The page will refresh and report the new configuration in Acceleration. Figure 7 - 61 Intel® Rapid Storage Technology Accelerate 7 - 86 Intel® Rapid Storage Technology...
Modules & Options Intel Rapid Start Technology Driver ® Intel(R) Rapid Start Technology can resume power from Hibernation within 5 to 6 seconds and can remember your computer's previous state with zero power. System Requirements to support Intel® Rapid Start Technology: •...
Modules & Options Intel® Rapid Start Technology Configuration Enable/disable Intel(R) Rapid Start Technology from the BIOS (see “Intel(R) Rapid Start Technology (Advanced Menu)” on page 5 - Go the Windows control panel and double-click Administrative Tools (System and Security)> Computer Management > Storage > Disk Management Right-click the SSD and select Shrink Volume from the menu.
Page 215
Modules & Options Enter the figure, which should be equal to amount of system memory (RAM) in your computer, in “Enter the amount of space to shrink in MB”. Figure 7 - 63 Shrink Volume Size Click Shrink (any unallocated file space may be formatted for storage use). ...
Page 216
Modules & Options Click the Start menu and type “CMD” in the search box. Click CMD from the found list. Figure 7 - 64 Search for CMD Prompt Type “DISKPART”. At the DISKPART command type “list disk”. Figure 7 - 65 Diskpart - List Disk 7 - 90 Intel®...
Page 217
Modules & Options 10. Type “select disk #” (# is disk number where you want to create the store partition, so refer to the results obtained from "list disk" for exact disk number). 11. The message “Disk # is now the selected disk.” will appear. Figure 7 - 66 Diskpart - Select Disk #...
Page 218
Modules & Options 14. Type “detail disk”. Figure 7 - 68 Diskpart - Detail Disk 15. Type “select Volume #” (# is volume of your storage partition so refer to results obtained from "detail disk" for the exact volume number). 16.
Page 219
Modules & Options 17. Type “set id=84 override” (the id must be set to 84). Figure 7 - 70 Diskpart - Set id=84 Override 18. The message “DiskPart successfully set the partition ID.” will appear. 19. Close the CMD window. 20.
Modules & Options Intel® Smart Connect Technology Intel® Smart Connect Technology periodically, and briefly, wakes the computer from Sleep mode in order to update information for certain applications (e.g. to get mail from Microsoft Outlook) as required. These updates can therefore be made without having to turn the computer on, and applications will be up to date when the computer resumes from Sleep mode (make sure that Intel Smart Connect Technol- ogy is enabled in the BIOS - see...
Modules & Options Intel® Smart Connect Technology Configuration Access the Intel(R) Smart Connect Technology application from the Start menu. Click Basic (tab) and adjust the slider to set the update frequency (note that the Wireless Device slider balances between “More Frequent Updates” and “More Battery Life”). Operation Aboard Note the sidebar warning about the use of Intel(R) Smart Connect Technology Aircraft...
Page 223
Modules & Options Click Advanced (tab) to access the Extended Power Savings settings. Extended Power Savings allows you to set a time period during which the computer will update less often (e.g. at night while you are asleep or whenever you are at work).
Page 224
Modules & Options Click the Help tab and click Topics to access the main Help menu. Intel WLAN Modules If your purchase option includes an Intel WLAN module, (with Intel’s PROSet Wireless Con- nection Utility stalled), Intel® Smart Connect Technology will search for WiFi net- works around you that...
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 230
Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 232
Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 233
Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 234
Troubleshooting Problem Possible Cause - Solution Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
Page 235
Troubleshooting Problem Possible Cause - Solution The PC Camera module cannot be The module is off. Press the Fn + F10 key combination in order to enable the detected. module (see “Function/Hot Key Indicators” on page 1 - 11). Run the camera application to view the camera picture.
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 237
Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 238
Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 239
Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio Bluetooth Connection Problems 8 - 15...
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Interface (Ports & Jacks) A - 1...
Interface (Ports & Jacks) Notebook Ports and Jacks Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards. Push the card into the slot and it will appear as a removable device. DC-In Jack Plug the supplied AC/DC adapter into this jack to power your computer.
Page 243
Interface (Ports & Jacks) Item Description Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions. Note: Broadband (e.g. ADSL) modems usually connect to the LAN port. Security Lock Slot To prevent possible theft, a Kensington-type lock can be attached to this slot.
Control Center Appendix B: Control Center Overview The following chapter will give a quick description of the functions of the Control Center. The Control Center gives quick access to frequently used controls, power management features and enables you to quickly turn mod- ules on/off.
Page 246
Control Center Power Modes You can set a Power Mode by clicking the appropriate icon at the top of the Control Center. Each power mode will affect the power status of modules (e.g. WLAN, Bluetooth, 3G or Camera), screen brightness, TouchPad power and Silent Mode.
Page 247
Control Center User Modes Power Saving Flight Entertainment Quiet Performance Defined Icon Power Plan Power Saver Balanced Power Saving Power Saving High Performance Power Conservation Mode Energy Star BIOS Default Energy Star Energy Star Performance Brightness WLAN Bluetooth BIOS Default PC Camera TouchPad Table B - 1- Power Modes...
Page 248
Control Center Power Status The Power Status icon will show whether you are currently powered by the battery, or by the AC/DC adapter plugged in to a working power outlet. The power status bar will show the current battery charge state. Brightness The Brightness icon will show the current screen brightness level.
Page 249
Control Center Sleep Click the Sleep button to bring up the Hibernate or Sleep buttons, and click either button to have the computer enter the appropriate power-saving mode (see “Power-Saving States” on page 3 - Display Switch Click the Display Switch button to access the menu (or use the + P key combination) and select the appro- priate attached display mode (see page 10).
Video Driver Controls Appendix C: Video Driver Controls The basic settings for configuring the LCD are outlined in “Video Features” on Video Card Options page 1 - Note that card types, specifications and driv- Video Driver Installation ers are subject to contin- updates Make sure you install the drivers in the order indicated in Table 4 - 1, on page 4 -...
Video Driver Controls Intel Graphics & Media Control Panel ® Advanced video configuration options are provided by the Intel Graphics and ® Application Mode Media Control Panel. To access the control panel: Note that all figures pic- Click Advanced settings in the Screen Resolution control panel in Windows. tured, and instructions Click the Intel(R)...
Page 253
Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...
Video Driver Controls Display Devices & Options Besides the built-in LCD you can also use an external monitor/flat panel display/TV connected to the external monitor port or to the HDMI-Out port (High-Definition Function Key Combination Multimedia Interface) as your display device. The table below outlines the display options.
Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the left of the computer. At least one other dis- To Clone Displays: play must be attached in Attach your external display to the appropriate port, and turn it on.
Page 256
Video Driver Controls To Enable Extended Desktop: Attach your external display to the appropriate port, and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 257
Video Driver Controls Display Profiles You can save display settings to be loaded at any time. Go to the Intel(R) G&M control panel and click Display. Configure the General Settings, Multiple Displays, Color Enhancement, Custom Resolution & Monitor/TV Settings to your preferences. Click Apply, and OK to confirm the settings change.
Video Driver Controls Configuring an External Display in Windows 7 You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your external display to the appropriate port, and turn it on. You can use the Fn + Go to the Screen resolution control panel (see “Video Features”...
Page 259
Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure C - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 260
Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your external display to the appropriate port, and turn it on.
Video Driver Controls HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals. Volume Indicator In some cases it will be necessary to go to the Sound control panel and manually configure the HDMI audio output as per the instructions below. Click the taskbar volume indicator when an...
Page 262
Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure C - 10 HDMI Device Properties C - 12 HDMI Audio Configuration...
Page 263
Video Driver Controls HDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Specifications Appendix D: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your distributor/supplier for details.
Specifications Processors Core Logic Video Adapter Intel® Core i7-3612QM (2.1GHz) Mobile Intel® HM77 Express Chipset Intel® HD Graphics 4000 (GPU is Dependent on Processor): Quad-Core Mobile Processor Display 6M L3 Cache, 22nm (22 Nanometer), Dynamic Frequency DDR3-1600MHz, TDP 35W Modell A: Intel Dynamic Video Memory Technology up to 1.7MB Intel®...
Specifications Power Features Full Range AC/DC Adapter Painted Style (For some Model designs in this series) AC input 100 - 240V, 50 - 60Hz, DC Output 19V, 3.42A or 18.5V, 3.5A (65 Operating System Watts) Removable 6 Cell Smart Lithium Ion Windows®...
Need help?
Do you have a question about the SERIUS 15S20 and is the answer not in the manual?
Questions and answers
