Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals. Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Quick Start Guide System Startup Remove all packing materials. Place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack on the left of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Quick Start Guide Model Differences This notebook series includes two different model types that vary slightly in design style, color and general ap- pearance. Note that your model may appear slightly different from those pictured in this manual. See “Specifi- cations”...
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open Built-In PC Camera Wireless Device Operation Aboard Speakers Power Button Aircraft Hot Key Buttons The use of any portable Keyboard electronic transmission Built-In Microphone devices aboard aircraft is Touchpad &...
Quick Start Guide LED Indicators The LED indicators display helpful information about the current status of the computer. Icon Color Description Icon Color Description The (optional) Wireless LAN Orange DC Power is Plugged In Green Module is Powered On The (optional) Bluetooth Blinking Orange The Powered USB Port is On* Orange...
Quick Start Guide Hot Key Buttons & Keyboard These buttons give instant access to the default Internet browser and e-mail program, Other Keyboards and allow you to toggle the Silent Mode on/off with one quick button press. If your keyboard is damaged or you just Hot Key Function...
Quick Start Guide Keyboard The keyboard has a numerical keypad on the right for easy numeric data input, and features function keys to allow you to change operational features instantly. See Table 1 - 3, on page 1 - 10 for full function key combi- nation details.
Quick Start Guide Function/Hot Key Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. In addition to the basic function key combinations; visual indicators are available when the hot key utility is installed. Keys Function Keys...
Quick Start Guide System Map: Front & Left Views Figure 1 - 4 Front & Left Views LED Indicators DC-In Jack External Monitor Port RJ-45 LAN Jack e-SATA Port/USB 2.0 Combo Port HDMI-Out Port Vent/Fan Intake/ Outlet 2 * USB 3.0 Ports Multi-In-1 Card Reader ExpressCard Slot The card reader allows you to use the most popular digital storage card formats:...
Quick Start Guide System Map: Right & Rear Views Figure 1 - 5 Right & Rear Views S/PDIF-Out Jack Microphone-In Jack Headphone-Out Jack 4. 1 * Powered USB 2.0 Port 5. Optical Device Drive Bay (for CD/ DVD Device - see page Powered USB 2.0 Port 6.
Page 37
Quick Start Guide CD/DVD Emergency Eject Changing DVD Regional Codes If you need to manually eject a CD/ Go to the Control Panel and double-click De- DVD (e.g. due to an unexpected vice Manager (Hardware and Sound), then power interruption) you may push the click the + next to DVD/CD-ROM drives.
Quick Start Guide System Map: Bottom View Figure 1 - 6 Bottom View Battery Battery Information Docking Port RAM & CPU Bay Always completely dis- Cover charge, then fully charge, a Vent/Fan Intake/ new battery before using it. Outlet Completely discharge and charge the battery at least Hard Disk Bay...
Quick Start Guide 3.75G/HSPA Module USIM Card Installation If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to install the USIM card (which will be provided by your service provider), and then run the Mobile Partner ap- plication.
Quick Start Guide Docking Port Follow the instructions below before connecting the computer to the docking station, if included in your pur- chase configuration (Factory Option for Model A computers). Failure to open the cover of the docking port before connecting the computer to the docking station may result in irreparable damage to the connector on the docking station.
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see“Intel Video Driver Controls” on page B - To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel.
Page 43
Quick Start Guide To access the Intel(R) Graphics and Media Control Panel: Click Advanced settings (Figure 1 - 10 on page 1 - 18) in the Display Settings control panel in Windows. Click Graphics Properties (button) (Figure 1 - 11) in the Intel Graphics & Media Control Panel tab. Right-click the desktop and select Graphics Properties from the menu.
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • Optical (CD/DVD) Device • Multi-in-1 Card Reader • ExpressCard Slot •...
Features & Components Hard Disk Drive The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Features & Components Optical (CD/DVD) Device There is a bay for a 5.25" optical (CD/DVD) device (12.7mm height). The actual de- Sound Volume vice will depend on the module you purchased (see “Storage” on page C - 3). The Adjustment optical device is usually labeled “Drive D:”...
Features & Components Handling CDs or DVDs Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Features & Components DVD Regional Codes To change the DVD regional codes see “Changing DVD Regional Codes” on page 1 - DVD Regional Coding Table 2 - 1 Region Geographical Location DVD Regional Coding USA, Canada Western Europe, Japan, South Africa, Middle East &...
Features & Components Multi-in-1 Card Reader The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Features & Components ExpressCard Slot The computer is equipped with an ExpressCard/34/54 slot that reads Express Card/ ExpressCard 34 and ExpressCard/54 formats. ExpressCards are the successors to PCMCIA (PC Slot Cover Cards). Make sure you install the Card Reader driver (see “CardReader”...
Features & Components Touchpad and Buttons/Mouse The Touchpad is an alternative to the mouse; however, you can also add a mouse to Touchpad Scrolling your computer through one of the USB ports. The Touchpad buttons function in This computer model se- much the same way as a two-button mouse.
Features & Components Gestures and Device Settings The Synaptics Gestures Suite application allows you to use a specific gesture (ac- tion) on the surface of the Touchpad to perform specific actions to manipulate doc- Show Video uments, objects and applications. You can get a clearer view of the gestures in- You can configure the settings from the Device Settings tab in Mouse Properties:...
Page 54
Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 7 tinuous motion).
Page 55
Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Features & Components Audio Features You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Features & Components Optimizing Audio Recording Follow these instructions to optimize your audio recording. Double-click the taskbar icon to bring up the Realtek HD Audio Manager. Click the Microphone tab. Click the Noise Suppression button to prevent any background noise or feedback.
Features & Components Adding a Printer The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- ble to the printer.
Power Management Chapter 3: Power Management Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. Silent Mode AC/DC Adapter Use the key to tog- gle Silent Mode to re- Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ duce fan noise and save DC adapter will damage the computer and its components.
Power Management Turning On the Computer Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Power Management Power Plans The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 63
Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a Silent Mode power failure occurs the system can restore your work from the hard disk; if a power You can use Silent failure occurs when work is saved only to memory, then the work will be lost.
Power Management Configuring the Power Buttons The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Power Management Resuming Operation You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color...
Power Management Energy Star Power Saving This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Taskbar Icon of inactivity. If you want to enable Energy Star power saving then follow these in- If the taskbar icon does structions: not appear then click the...
Power Management Battery Information Follow these simple guidelines to get the best use out of your battery. Low Battery Warning Battery Power Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Power Management Conserving Battery Power • Use a power plan that conserves power (e.g Power saver), however note that Windows Mobility this may have an affect on computer performance. Center • Lower the brightness level of the LCD display. The system will decrease LCD The Windows Mobility brightness slightly to save power when it is not powered by the AC/DC adapter.
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Power Management Proper handling of the Battery Pack • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 74
Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 75
Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 76
Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Drivers & Utilities Chapter 4: Drivers & Utilities This chapter deals with installing the drivers and utilities essential to the operation or improvement of some of the computer’s subsystems. The system takes advantage of some newer hardware components for which the lat- est versions of most available operating systems haven’t built in drivers and utilities.
Drivers & Utilities Driver Installation Insert the Device Drivers & Utilities + User’s Manual disc and click Install Drivers/Option Drivers (button). Figure 4 - 1 - Drivers Installer Screens Check the driver installation order from Table , on page 4 - 3 (the drivers must be installed in this order) which is the same as that listed in the Drivers Installer menu.
Page 79
Drivers & Utilities Driver for Windows 7 with Service Page Driver for Windows 7 with Service Page Chipset Page 4 - 5 PC Camera Module Page 7 - 2 Video Page 4 - 5 Wireless LAN Module Page 7 - 10 Page 4 - 6 Fingerprint Reader Module Page 7 - 29...
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” dur- Insert the Device Drivers & Utilities + User’s Manual ing the installation procedure (other than when out- disc and click Install Drivers (button). lined in the driver install procedure), click Cancel Chipset to close the window, and follow the installation proce-...
Drivers & Utilities Modem (Optional) 1. Click 3.Install LAN Driver > Yes. If your model configuration includes a modem, there are two different modem modules available with this 2. Click Install Drivers and Software > Next. computer model series. Install using the instructions 3.
Drivers & Utilities Hot Key 1. Click 7.Install Hotkey AP Driver > Yes. 1. Click 9.Install MEI Driver > Yes. 2. Click Next > Next. 2. Click Next (for Model B computers you may click in the checkbox to select “Install Intel 3.
Drivers & Utilities Windows Experience Index After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- Windows Update ence Index (make sure the AC/DC adapter is plugged After installing all the drivers make sure you enable Win- in): dows Update in order to get all the latest security up- dates etc.
Drivers & Utilities Optional Drivers PC Camera Module See the pages indicated for the driver installation pro- “PC Camera Module” on page 7 - cedures for any modules included in your purchase op- tion. Wireless LAN Module “Wireless LAN Module” on page 7 - Fingerprint Reader Module “Fingerprint Reader Module”...
BIOS Utilities Chapter 5: BIOS Utilities Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- If your computer has never been set up, or you are making important changes to the ed for guidance in set- system (e.g.
BIOS Utilities The Setup Utility Each time you turn on the computer the system takes a few seconds to conduct a BIOS Settings POST, including a quick test of the on-board RAM (memory). Warning As the POST proceeds, the computer will tell you if there is anything wrong. If there Incorrect settings can is a problem that prevents the system from booting, it will display a system summary cause your system to...
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
BIOS Utilities Setup Screens The following pages contain additional advice on portions of the Setup. Along the top of the screen is a menu bar with menu headings. When you select a heading, a Setup Menus new screen appears. Scroll through the features listed on each screen to make chang- Setup menus es to Setup.
BIOS Utilities Intel® vPro™ technology Intel® vPro™ technology is supported by Model A computers only. This set of technology features, built into the computer’s motherboard, allows Information Technology departments remote access to the computer. This allows the IT depart- ment to monitor, maintain and manage computers regardless of the state of the op- erating system or the computer’s power state.
Page 92
BIOS Utilities Figure 5 - 2 Intel(R) Management Engine (Password Creation) Once you have entered the password you will then be taken to the platform config- uration screen. 5 - 6 Intel® vPro™ technology...
Page 93
BIOS Utilities Figure 5 - 3 Intel(R) Management Engine (Platform Configuration) The platform configuration screen allows you to setup Intel ME as per your require- ments (consult your IT administrator for the actual settings required). See “MEI” on page 4 - 7 “Intel®...
BIOS Utilities Main Menu Figure 5 - 4 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
BIOS Utilities SATA Port # (Main Menu) Pressing Enter opens the sub-menu to show the configuration of a optical Device/ HDD on the computer’s SATA Ports. System/Extended Memory: (Main Menu) This item contains information on the system memory, and is not user configurable. The system will auto detect the amount of memory installed.
BIOS Utilities Advanced Menu Figure 5 - 5 Advanced Menu Advanced Chipset Control (Advanced Menu) The sub-menu here allows you to adjust the Bluetooth Power Setting. 5 - 10 Advanced Menu...
BIOS Utilities Bluetooth Power Setting (Advanced Menu > Advanced Chipset Control) You can adjust the Bluetooth module power setting to your preference. The default setting (Disabled) will see the Bluetooth module powered off when the system is SATA Mode started up or restarted.
BIOS Utilities Boot Logo (Advanced Menu) Use this menu item to enable/disable the Boot Logo screen at system startup. Power On Boot Beep (Advanced Menu) Use this menu item to enable/disable the beep as the computer starts up. Battery Low Alarm Beep (Advanced Menu) Use this menu item to enable/disable the battery low alarm beep.
BIOS Utilities Security Menu Security Menu The changes you make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up after you turn it on. These set- tings do not affect your machine or network pass- words which will be set in your software OS.
BIOS Utilities Set User Password (Security Menu) You can set a password for user mode access to the Aptio Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless you choose to Password Warning set a Password on Boot (see below).
BIOS Utilities TPM Configuration (Security Menu) This sub-menu will allow you to enable/disable Trusted Platform Module (TPM) support, and to configure the TPM State. Select TPM Configuration and press En- ter to access the sub-menu. Press Enter to access the TPM Support menu and select Enable to display the full TPM configuration menu (see “Trusted Platform Mod- ule”...
BIOS Utilities TPM State (Security Menu > TPM Support Enabled) Select TPM State, press Enter and select Enable to change the TPM state to en- abled. You will then need to press F4 to save the changes and restart the computer. Figure 5 - 8 TPM State (Enabled) As the computer restarts press F2 to enter the BIOS again and go to the TPM Con-...
BIOS Utilities Pending TPM operation (Security Menu > TPM Support & TPM State Enabled) Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership). You will then need to press F4 to save the changes and restart the computer.
BIOS Utilities Boot Menu Figure 5 - 10 Boot Menu BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual When you turn the computer on it will look for an operating system (e.g.
BIOS Utilities Boot Sequence (Boot Menu) Use the arrow keys to move up and down the menu and use the F5 and F6 keys to move the device’s boot priority up and down the list (the selected device will be highlighted in white).
BIOS Utilities Exit Menu Figure 5 - 11 Exit Menu Click Save Changes and Reset to save all changes made. Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Setup defaults that will re- turn the Setup to its original state, and erase any previous changes you have made in a previous session.
Upgrading The Computer Chapter 6: Upgrading The Computer Overview This chapter contains information on upgrading the computer. Follow the steps out- lined to make the desired upgrades. If you have any trouble or problems you can con- Warranty Warning tact your service representative for further help.
Upgrading The Computer When Not to Upgrade These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake • Your system is still under warranty or a service contract upgrade proce- •...
Upgrading The Computer Removing the Battery If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Please check with your Turn the computer off, and turn it over. service representative Slide the latch...
Upgrading The Computer Upgrading the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 3).
Page 111
Upgrading The Computer Grip the tab and slide the hard disk in the direction of arrow Lift the hard disk out of the bay Figure 6 - 3 HDD Assembly Removal Remove the screw(s) and the adhesive cover Reverse the process to install a new hard disk drive (do not forget to replace all the screws and covers).
Upgrading The Computer Upgrading the Optical (CD/DVD) Device Turn off the computer, and turn it over and remove the battery. Locate the hard disk bay cover and loosen screws & Remove the hard disk bay cover Figure 6 - 5 Removing the HDD Cover 6 - 6 Upgrading the Optical (CD/DVD) Device...
Page 113
Upgrading The Computer Remove the screw at point , and use a screwdriver to carefully push out the optical device at point Reverse the process to install the new device. Figure 6 - 6 Removing the Optical Device Upgrading the Optical (CD/DVD) Device 6 - 7...
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 2 details of supported module types). Turn off the computer, and turn it over and remove the battery.
Page 115
Upgrading The Computer Carefully (a fan and cable are attached to the under side of the cover) lift up the bay cover. Carefully disconnect the fan cable , and remove the cover Fan Cable & Cover Make sure you reconnect the fan cable before screwing down the bay cov-...
Page 116
Upgrading The Computer The RAM module will pop-up, and you can remove it. Pull the latches to release the second module if necessary. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. Figure 6 - 10 RAM Module Removal...
Page 117
Upgrading The Computer 11. Replace the bay cover and screws (make sure you reconnect the fan cable before screwing down the bay cover). Cover Pins Note that there are cov- er pins need to be aligned with slots in the case to insure a proper cover fit, before screw- ing down the bay cover...
Modules & Options Chapter 7: Modules & Options Overview Wireless Device Operation Aboard Aircraft This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please The use of any portable contact your service representative.
Modules & Options PC Camera Module Make sure that the PC Camera module is on before installing the driver and use the Latest PC Camera Fn + F10 key combination (see “Function/Hot Key Indicators” on page 1 - 10) to Driver Information toggle power to the PC Camera module.
Modules & Options PC Camera Driver Installation 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. PC Camera Screen Refresh 2. Click Option Drivers (button). 3.
Page 122
Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 123
Modules & Options Figure 7 - 1 Audio Setup for PC Camera Right-click PC Camera Module 7 - 5...
Page 124
Modules & Options Camera Application The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Pre-Allocating File Size/Space Run the camera application from the desktop shortcut (it is recommended that you You may pre-allocate the set the capture file before the capture process - see “Set Capture File”...
Page 125
Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 126
Modules & Options Eliminating Screen Flicker If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 127
Modules & Options Taking Still Pictures The camera application allows you to take still pictures. Snapshot Folder Run the camera application from the desktop shortcut. Go to Options and select Take Picture. The Snapshot folder’s The picture (in JPEG format) will be placed in the Snapshot folder on the default location is on the desktop.
Modules & Options Wireless LAN Module If you have included an Intel® or 3rd Party Wireless LAN (or WLAN & Bluetooth Wireless Device combo) module in your purchase option, make sure that the WLAN module is on be- Operation Aboard fore installing the driver.
Modules & Options 3rd Party WLAN Driver Installation If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. 2.
Modules & Options Connecting to a Wireless Network in Windows 7 Make sure the Wireless LAN module is turned on. Network and Click the taskbar wireless icon , and then double-click an access point to con- Sharing Center nect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net- setting changes, and creating a new network).
Page 131
Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 132
Modules & Options Click the taskbar icon to see any currently connected networks. To disconnect from the wireless network you can click the taskbar wireless icon click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se- cure network.
Modules & Options Intel My WiFi Configuration ® Intel® My WiFi Technology uses your WLAN (for Intel WLAN modules only) module to allow you to connect up to eight other WiFi enabled devices (e.g. digital Intel® My WiFi Help cameras, other computers, cell phones, handheld devices etc.) to your computer To get help on Intel®...
Page 134
Modules & Options Intel® My WiFi Configuration You can configure the My WiFi settings as follows. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the taskbar icon Click Enable (on the first run of the program there will be no connected...
Page 135
Modules & Options Click Start and click Control Panel. Click Network and Sharing Center (Network and Internet). Click Change adapter settings. Figure 7 - 7 Network and Sharing Center Click Change adapter settings Wireless LAN Module 7 - 17...
Page 137
Modules & Options Click Sharing (tab) and select “Allow other network users to connect through this computer’s Internet connection”. Select Wireless Network Connection under Home networking connection. Click OK. Click “Allow other network users to connect through this computer’s Internet connection”.
Page 138
Modules & Options 10. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by double- clicking the taskbar icon 11. Click Profiles Figure 7 - 10 Intel®...
Page 139
Modules & Options 12. Click Profiles, click Intel Wireless PAN and click Edit or New (Note that all preset settings may not be editable - see sidebar). Figure 7 - 11 Profiles Profile Settings 13. You can change the Profile Name and Network Name to your personal Profiles that are preset preferences in General (tab).
Page 140
Modules & Options 14. Click Security (tab). 15. Change the Security Type to WEP and the Encryption Type to 64bit. 16. Enter a password (8 characters long) in the Password box. Figure 7 - 13 Intel® My WiFi Profile Settings - Security 7 - 22 Wireless LAN Module...
Page 141
Modules & Options 17. Click Sharing (tab). 18. It is recommended that the Filter Network Traffic and DHCP and DNS Server are Disabled. Figure 7 - 14 Intel® My WiFi Profile Settings - Sharing Wireless LAN Module 7 - 23...
Page 142
Modules & Options 19. Click Advanced (tab). 20. It is recommended that the Default Channel is set to Channel 1, 6 or 11. 21. Click OK to save the settings. Figure 7 - 15 Intel® My WiFi Profile Settings - Advanced 7 - 24 Wireless LAN Module...
Page 143
Modules & Options 22. Double-click Wireless Network Connection in Network Connections. 23. Click Details to display the Network Connection Details. Figure 7 - 16 Wireless Network Connection Details Wireless LAN Module 7 - 25...
Page 144
Modules & Options 24. Access the Intel® My WiFi Utility from the Start menu (Start > Programs/All Programs > Intel PROSet Wireless > Intel My WiFi Technology), or by clicking the taskbar icon 25. To add a new device follow the instructions in the devices’ user guide for connecting to a WiFi network.
Modules & Options Windows Mobility Center The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. To access the Windows Mobility Center: Click Start, and click Control Panel (or point to Settings and click Control Panel).
Modules & Options Security Modules (Fingerprint & TPM) The encrypted channel between the Trusted Platform Module security chip (see Password Warning “Trusted Platform Module” on page 7 - 73) and the fingerprint reader with Au- thenTec TrueSuite software (see “Fingerprint Reader Module”...
Modules & Options Fingerprint Reader Module The fingerprint reader module provides a high level of security for your computer. Make sure you have administrator’s rights to your computer, and have a Windows password enabled for full security protection. Fingerprint Reader Driver Installation 1.
Modules & Options User Enrollment Click Start > Programs/All Programs > Protector Suite > Control Center, or double click the notification area icon (click Initialize). Fingerprint On the first run of the program you will be asked to click the Accept button to Enrollment accept the license.
Page 149
Modules & Options Click the button above any of the fingers to begin the enrollment process for that finger. Swipe the finger until the progress bar reaches 100% to enroll that finger. Fingerprint Repeat the process for all the fingers you wish to enroll (see sidebar), and then Enrollment click Save and Continue.
Page 150
Modules & Options 11. Right-click the taskbar icon and select Start Control Center (and then swipe a finger) to allow you to Edit Fingerprints, register Applications, edit Settings and access the Help menu etc. You can also run the Control Center etc. from the Protector Suite item in the Programs/All Programs menu 12.
Modules & Options Fingerprint Control Center Features Application Launcher Help The Application Launcher allows you to register applications to be launched when assigned to a particular finger. Simply copy the application icon on to one of the reg- For more information on istered fingers and ten click OK to close the application window.
Modules & Options Bluetooth Module If your purchase option includes the Combination Wireless LAN & V3.0 Blue- Wireless Device tooth module (either Intel® or 3rd Party) then install the driver as instructed over- Operation Aboard leaf. Aircraft Use the Fn + F12 key combination to toggle power to the Bluetooth module (see The use of any portable electronic transmission de- “Function/Hot Key Indicators”...
Modules & Options Intel Bluetooth Combo Driver Installation Note this driver is required only for the Intel combo Bluetooth and WLAN module only. High Speed Bluetooth Data Transfer 1. Before installing the driver make sure the Bluetooth module is powered The Combination Wire- on (use Fn + F12 key combination), then insert the Device Drivers &...
Modules & Options Standard Bluetooth Configuration in Windows 7 Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 155
Modules & Options To Add a Bluetooth Device Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 156
Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing. Figure 7 - 24 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 157
Modules & Options To Change Settings for the Bluetooth Device Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Modules & Options 3rd Party Bluetooth Combo Driver Installation Note this driver is required only for the combo Bluetooth and WLAN module only. High Speed Bluetooth 1. Before installing the driver make sure the Bluetooth module is powered Data Transfer on (use Fn + F12 key combinations), then insert the Device Drivers &...
Modules & Options 3rd Party Bluetooth & WLAN Combo Settings This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Make sure the Bluetooth module is powered on. Resuming From Sleep Double-click the My Bluetooth application on the desktop (or access it from the Mode Programs/All Programs menu).
Page 160
Modules & Options Click General Settings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 28 General Settings 7 - 42 Bluetooth Module...
Page 161
Modules & Options Click File Transfer Settings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 29 File Transfer Settings Bluetooth Module 7 - 43...
Modules & Options Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 27 on page 7 - 41).
Modules & Options Bluetooth & WLAN Combo Module Configuration Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Module & Make the device discoverable (to do this check your device documentation). Resuming From Sleep Mode To Turn the Bluetooth Module On...
Page 164
Modules & Options You will then be presented with a menu of options to select from. Figure 7 - 32 Bluetooth Device Options Click the appropriate button to connect to the device. 7 - 46 Bluetooth Module...
Page 165
Modules & Options You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Modules & Options 3.75G/HSPA Module If you have included an optional 3.75G/HSPA (High Speed Packet Access) module (see “Communication” on page C - 4 for specification details) in your purchase op- tion, you will have the appropriate application provided for your particular module. Follow the instructions on page 7 - 50 to install the USIM card (supplied by your...
Page 167
Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see “Function/Hot 3.75G/HSPA Key Indicators”...
Page 168
Modules & Options 3.75G/HSPA Module USIM Card Installation Follow the instructions below to install the USIM card (which will be provided by Power Safety your service provider). Warning Turn off the computer, and turn it over. Before you undertake any Slide the latch in the direction of the arrow.
Modules & Options Wireless Manager With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Wireless Manager application. The Wireless Wireless Device Manager application allows you to directly access your HSPA internet service from Operation Aboard the computer.
Modules & Options Wireless Manager Application The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a PIN Number Profile”...
Page 171
Modules & Options The system will connect to your network. Connected will appear above the timer icon (the timer will indicate your connected time for the current session) You can then access the internet, download e-mail etc. as per any internet Wireless Manager connection.
Page 172
Modules & Options Click the Wireless Manager notification area icon to view the connection status, or wireless icon to view the Mobile Broadband Connection status Figure 7 - 37 Notification Area Icons (Connected) Notification Area The indicator will display the signal strength and radio access Icon technology.
Modules & Options Profiles Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click the Settings > Advanced. Click the Profiles (tab). Figure 7 - 38 Advanced Settings - Profiles 3.75G/HSPA Module 7 - 55...
Page 174
Modules & Options Multiple profiles may be available from the USIM card and the first time the application starts it may require you to select a profile (Set Profile) to use for your connection. Figure 7 - 39 Multiple Profiles Found Automatic Profile Selection If Automatic selection is chosen, then the application will search the operator pro-...
Page 175
Modules & Options Selecting a Profile Click Manual selection (button). Click the Filter to view the drop-down list. Select the Profile you wish to use and click Apply to confirm the selection. Figure 7 - 40 Profile - Manual Selection (Filter) 3.75G/HSPA Module 7 - 57...
Page 176
Modules & Options Creating a Profile Click Manual selection (button). Click the New. Deleting a Profile Enter a name you prefer for the profile. Enter the Access Point Name (APN). To delete a profile click Enter the User Name and Password if required (some service providers may not to select Manual selec- require this information and the fields may then be left blank).
Modules & Options Settings The Settings tab allows you at adjust the application features. Click to put a tick in Launch Wireless Manager at Windows startup to launch the application at Win- dows Startup. Figure 7 - 42 Settings The Advanced settings allows more detailed configuration. To access the Ad- vanced settings: Access the Wireless Manager program from the Start menu (Start >...
Page 178
Modules & Options Most USIM cards are protected by a Personal Identity Number (PIN). You may turn on or off the Request PIN at startup (click Apply to save any changes). You can PIN Notes also Change PIN (you will need to enter the new PIN in the two fields provided and click Apply to save any changes).
Page 179
Modules & Options Networks The mobile network list lists available networks at your location, and allows you to select a network which to connect. You must disconnect before being able to select Warning a network. Note that some applica- tions automatically Connection...
Modules & Options Text Messaging Service (SMS) In addition to standard internet services you may also send and receive SMS text messages using the Wireless Manager, if your service supports SMS. SMS Utility Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 181
Modules & Options Messages Click the Messages tab to access the tabs displaying text messages. The tabs at the top of the menu display the Inbox, Drafts, Outbox, Sent and Trash menus. Inbox Drafts Outbox Sent Trash Figure 7 - 46 SMS Utility Messages Text messages are automatically saved to your computer and may be sorted in as-...
Modules & Options Sending a Text Message Access the Wireless Manager application from the Start menu (Start > All Pro- grams > Wireless Manager > Wireless Manager) or the desktop shortcut Click SMS and the SMS Utility will then start. Click the New Message tab.
Page 183
Modules & Options Click Send to send the message or Save to save the message in the Drafts folder. Clicking the Clear icon clears both the Message and To fields. If radio is on then the message will be sent, however if the radio is off the message will be stored in the Outbox.
Page 184
Modules & Options Messages • Opening a text message: Double-click the message and the message will open in a new window (to close it click the close icon in the top right of the message). Figure 7 - 49 Click to close the message Close Message •...
Modules & Options Phonebook The Phonebook allows you to view and edit all your frequently used contacts, and is divided into Contacts and Groups . To access the Phonebook: Access the Wireless Manager application from the Start menu (Start > All Pro- grams >...
Page 186
Modules & Options Contacts • New Contact: Click the New contact button to create a contact. Add the name and at least one phone number (Mobile, Work, Home and Other Import/Export Contacts fields are available) for the contact. Click the icon to expand the number details.
Page 187
Modules & Options Groups You can organize existing contacts into groups from the Groups tab. • New Group: Click the New group button to create a group. Click icon to expand the group details, and click a check box to add at least one phone number from the contacts for the group.
Modules & Options SMS Settings The SMS Utility Settings tab allows you at adjust the SMS features. Figure 7 - 53 SMS Utility Settings SMS Settings Message Length: You can set the number of blocks that can be sent (up to a length of 10 blocks).
Page 189
Modules & Options Send Click Delivery Report to automatically request a reply from a recipient. If you click to Send messages in Outbox automatically upon connection then messages writ- ten when the radio is off, will then be sent automatically the next time radio is turned on.
Page 190
Modules & Options Number You can choose to Use default service center number or you can uncheck the box and add your number manually if your service provider supplies a different number (click Apply to save the change or Default to return to the default number). Memory Phonebook memory status displays the number of contacts displayed on the USIM card.
Modules & Options Trusted Platform Module The TPM security chip allows you to create and manage digital certificates for user and platform authentication. This type of security is usually administered within large enterprises and organizations, and therefore requires implementation by a sys- tem administrator before users can access security features.
Modules & Options Enabling & Activating TPM Restart the computer. Enter the Aptio Setup Utility pressing F2 during the POST/startup. Use the arrow keys to select the Security menu Select TPM Configuration and press Enter. Select TPM Support and press Enter, select Enable and press Enter. Select TPM State, press Enter and select Enabled to change the TPM state to enabled.
Page 193
Modules & Options Select Pending TPM operation, press Enter and select the option you require (if you are initializing TPM you should select Enable Take Ownership) and press Enter. You will then need to press F4 to save the changes and restart the computer.
Modules & Options Trusted Platform Module (TPM) Driver Installation 1. Make sure you have enabled and activated the TPM in the BIOS before installing the driver (if you do not do see the note below). 2. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Modules & Options Initializing TPM Run the application from the Infineon Security Platform Solution > Manage Security Platform item in the Start > Programs menu. Click User Settings (tab) and click Yes, or right-click the icon in the notification area of the taskbar, and select Security Platform Initialization (or click the Security Platform State taskbar bubble).
Page 196
Modules & Options Choose the Security Platform Features you want to use by clicking the appropriate tickbox. Enter a Basic User Password (and re-type to confirm it) and click Next. Help Right-click the icon the notification area of the taskbar to bring up the menu to select Help or How to use the Security Platform Fea-...
Modules & Options Infineon Security Platform Settings Tool The Infineon Security Platform Settings Tool allows you to manage and check the TPM state, manage your password information, and to backup and restore the TPM Menus data. As TPM is usually administered within large enterprises and organizations, Note that not all the your system administrator will need to assist you in managing the information here.
Page 198
Modules & Options User Settings This page allows the settings to be configured for the currently logged in Infineon Security Platform user including the ability to change the password, configure se- cure e-mail, file and folder encryption and Enhanced Authentication. You can also import or delete certificates protected by the security platform.
Page 199
Modules & Options Backup Here you can configure backup and restore operations. Backup files contain the computer identification and user identification information which is used to match the machine name and user name with the current machine and user during restora- tion.
Page 200
Modules & Options Migration The Migration tab is used to help securely transfer keys and certificates from one platform to another. Figure 7 - 64 Infineon Security Platform Settings Tool (Migration) 7 - 82 Trusted Platform Module...
Page 201
Modules & Options Password Reset Use Password Reset to reset basic user passwords when required. Figure 7 - 65 Infineon Security Platform Settings Tool (Password Reset) Trusted Platform Module 7 - 83...
Page 202
Modules & Options BitLocker BitLocker Drive Encryption can be used in conjunction with the TPM to encrypt data on the disk and is done via the Microsoft BitLocker Control Panel Applet. Click Configure and select a drive to be encrypted and then follow the Wizard to begin the encryption process.
Page 203
Modules & Options Access the Microsoft BitLocker Drive Encryption control panel applet from the Windows control panel (System and Security). Figure 7 - 67 BitLocker Drive Encryption Trusted Platform Module 7 - 85...
Page 204
Modules & Options Advanced Configure all the Security Platform owner and policy settings from the Advanced tab. The settings that can be changed are for the local computer only. Figure 7 - 68 Infineon Security Platform Settings Tool (Advanced) 7 - 86 Trusted Platform Module...
Modules & Options IRST Driver Install the Intel Rapid Storage Technology to support your SATA drive if set up in AHCI mode in the BIOS (see “SATA Mode (Advanced Menu)” on page 5 - 11). 1. Insert the Device Drivers & Utilities + User’s Manual disc into the CD/ DVD drive.
Modules & Options ® Intel Management and Security Status (Model B Only) Access the Intel Management and Security Status control panels from the Start ® menu in Windows. These features allow users and IT Administrators to enhance and protect computing assets. Your system administrator will need to assist you in managing some of the information here.
Page 207
Modules & Options General The General tab provides basic information on Intel® AMT, Intel® Standard Man- ageability, Level 3 Manageability Upgrade, Intel® Anti-Theft and Intel® RPAT sta- tus and events. Figure 7 - 70 Intel Management & Security Status General Intel®...
Page 208
Modules & Options Intel® Active Management Technology The Intel® AMT tab will be shown if you system is configured to support it. This allows your network’s IT professionals to remotely discover, heal and protect your computer. Figure 7 - 71 Intel Management &...
Page 209
Modules & Options Intel® Anti-Theft This tab displays information on Intel® Anti-Theft information. Click on the link to connect to an Intel site to get more information on Intel® Anti-Theft technology. Figure 7 - 72 Intel Management & Security Status Intel®...
Page 210
Modules & Options Advanced The Advanced tab provides additional information on the system. Figure 7 - 73 Intel Management & Security Status Advanced For Intel PRO Wireless 2200BG 7 - 92 Intel® Management and Security Status...
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 216
Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 218
Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 219
Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help. Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 220
Troubleshooting Problem Possible Cause - Solution Other Keyboards If your keyboard is damaged or you just want to make a change, you can use any standard USB keyboard. The system will detect and enable it automatically. However special functions/hot keys unique to the system’s regular keyboard may not work.
Page 221
Troubleshooting Problem Possible Cause - Solution The PC Camera module cannot be The module is off. Press the Fn + F10 key combination in order to enable the detected. module (see “Function/Hot Key Indicators” on page 1 - 10). Run the BisonCap program to view the camera picture.
Page 222
Troubleshooting Problem Possible Cause - Solution A yellow exclamation mark appears The IRST driver will fix this known issue. Install the IRST driver (see “IRST alongside PCI Simple Communications Driver” on page 7 - 87). Controller (Other Devices) in Device Manager.
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 224
Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 225
Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 226
Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio 8 - 16 Bluetooth Connection Problems...
Troubleshooting Intel® Centrino Advanced WLAN & Bluetooth V3.0+HS Combo Modules Note that, at the time of going to press, Intel® Centrino® Advanced-N 6230 or Intel® Wireless-N 1030 WLAN & Bluetooth V3.0+HS combo modules use the standard Bluetooth configuration in Windows 7 (see “Standard Bluetooth Configuration in Windows 7”...
Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards.
Page 230
Interface (Ports & Jacks) Item Description HDMI-Out Port The HDMI-Out (High-Definition Multimedia Interface) is an audio/video connector interface for transmitting uncompressed digital streams. This allows you to connect an external monitor, TV or Flat Panel Display etc. as a display device by means of a HDMI cable. Note that HDMI carries both audio and video signals.
Page 231
Interface (Ports & Jacks) Item Description USB 2.0/1.1 Ports These USB 2.0 compatible ports (USB 2.0 is fully USB 1.1 compliant) are for low-speed peripherals such as keyboards, mice or scanners, and for high-speed peripherals such as external HDDs, digital video cameras or high-speed scanners etc. Devices can be plugged into the computer, and unplugged from the computer, without the need to turn the system off (if the power rating of your USB device is 500mA or above, make sure you use the power supply which USB 3.0 Port...
Intel Video Driver Controls Appendix B: Intel Video Driver Controls DVMT Notes The basic settings for configuring video are outlined in “Video Features” on page 1 - DVMT is not local video Intel Video Driver Installation memory. Make sure you install all the drivers in the order indicated in Table , on page 4 - DVMT is not user-con- figurable.
Intel Video Driver Controls Intel Graphics & Media Control Panel ® Advanced video configuration options are provided by the Intel Graphics and ® Application Mode Media Control Panel. To access the control panel: Note that all figures pic- Click Advanced settings in the Screen Resolution control panel in Windows. tured, and instructions Click the Intel(R)...
Page 235
Intel Video Driver Controls You may make changes to any of the graphics properties by clicking the appropriate menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and...
Intel Video Driver Controls Display Devices & Options Besides the built-in LCD you can also use an external monitor/flat panel display/TV connected to the external monitor port or to the HDMI-Out port (High-Definition Function Key Combination Multimedia Interface) as your display device. The table below outlines the display options.
Intel Video Driver Controls Attaching Other Displays If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the left of the computer. At least one other dis- To Clone Displays: play must be attached in Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 238
Intel Video Driver Controls To Enable Extended Desktop: Attach your display to the external monitor port or HDMI-Out port, and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 239
Intel Video Driver Controls Display Profiles You can save display settings to be loaded at any time. Go to the Intel(R) G&M control panel and click Display. Configure the General Settings, Multiple Displays, Color Enhancement, Custom Resolution & Monitor/TV Settings to your preferences. Click Apply, and OK to confirm the settings change.
Intel Video Driver Controls Configuring an External Display in Windows 7 You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your display to the external monitor port or HDMI-Out port, and turn it on. You can use the Fn + Go to the Screen resolution control panel (see “Video Features”...
Page 241
Intel Video Driver Controls You can configure the displays from the Multiple Displays menu. Figure B - 7 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s) •...
Page 242
Intel Video Driver Controls Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Intel Video Driver Controls HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals. In some cases it will be necessary to go to the Sound control panel and manually configure the HDMI audio output as per the instructions below. Click Start, and click Control Panel (or point to Settings and click Control Panel).
Page 244
Intel Video Driver Controls Double-click the connected HDMI device (or right-click and select Properties) to adjust the HDMI settings from the control panel tabs. Click OK to close the control panel (see notes overleaf). Figure B - 10 HDMI Device Properties B - 12 HDMI Audio Configuration...
Page 245
Intel Video Driver Controls HHDMI Notes • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications • To play audio sources through your external display’s (TV or LCD) speakers If you are using a third you will need to go to the audio configuration control panel on the display and party...
Specifications Appendix C: Specifications Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Specifications BIOS Keyboard & Pointing Device Interface AMIBIOS Isolated Full Size WinKey Keyboard with One Powered USB 2.0 Port Independent Numeric Keys Model A: One eSATA / USB 2.0 Combo Port Built-in TouchPad (integrated scrolling One 32Mb SPI Flash ROMs Two USB 3.0 Ports key functionality) with Multi Gesture One External Monitor Port...
Specifications Communication Power Management Security 10/100/1000 MB Base-TX Ethernet LAN Supports Wake on LAN Security (Kensington® Type) Lock Slot Supports Wake on USB BIOS Password Intel® Centrino® Advanced-N 6230 (2*2 Fingerprint Reader Module with Trusted 802.11 a/g/n) Half Mini-Card PCIe WLAN & Power Platform Module Support Bluetooth 3.0 Combo Module (Factory Op-...
Need help?
Do you have a question about the Serius 15S10 and is the answer not in the manual?
Questions and answers
