Dismantling:
Insert the dismantling key into the key hole of device until the hook
lock is open, then get the device and key out.
Troubleshooting
If you come up against some problems shown in the following
table, please first check if wires are properly connected. If wi-
res are properly connected but there are still problems, please
contact the nearest service agents and do not disassemble the
machine by yourself.
Faults
Failure of being
powered on
12
Noises and sound
distortion
Failure of Radio
Stop working
www.multilaser.com.br
Analyze Causes Solutions
It is not powered If the vehicle
on power is properly
installed, turn the
shift knob to ACC.
Fuse is burnt. Make sure no
short circuit
occurs on the line
and replace the
fuse.
It is mute or the Adjust the volume
volume is at zero. to your required
level.
Wires are impro- Check the wiring
perly connected. diagram and make
sure wires are
properly connec-
ted.
Poor contact Please pull out
the device and
reinsert it.
Speaker cables Check the speaker
are pressed by cables.
screws.
Speaker cables Properly connect
are short-circui- wires.
ted.
Antenna is not Properly connect
pulled out or con- the antenna and
nection is wrong. pull it out as long
as possible.
Weak signal Rotate the an-
tenna to proper
direation.
CPU can not work Turn off the power
normally. and power it on
again.
Files are dama-
ged.

Specifications

FM
Tuning range
Aerial terminal
Intermediate frequency
Usable sensitivity
Selectivity
Signal-to-noise ratio
Harmonic distortion at 1
kHz
Separation
Frequency response
Power amplifier section
Outputs
Speaker impedance
Maximum power output
General
Outputs
Tone controls
Power requirements
Dimensions Approx.
Mounting dimensions Approx.
Mass
Note:
This unit cannot be connected to a digital preamplifier or an
equalizer. Design and specifications are subject to change
without notice.
Skip this file and
please select next
file.
FM tuning interval:
100 kHz
switchable
87.5 ~ 107.9 MHz
(at 100 kHz step)
External aerial connector
10.7 MHz
11 dBf
75 dB em 400 kHz
65 dB (stereo), 68 dB (mono)
1 kHz
0.7 % (stereo), 0.5 % (mono)
33 dB at 1 kHz
30 ~ 15,000 Hz
Speaker outputs
(sure seal connectors)
4 ~ 8 Ω
45 W 4 (em 4 Ω)
Audio outputs
Power aerial relay control
lead
Bass ±9 dB at 100 Hz
Treble ±9 dB at 10 kHz
12 V DC car battery
(negative earth)
178 x 50 x 130 mm
187 x 57 x137 mm
Approx. 0.6 kg
