LuxCom 100BASE-TX Operating Manual

LUXCOM Technologies Inc.
102 Walgreen Rd., Ottawa, Ontario, Canada
K0A 1L0
www.luxcom.com
Tel: +1 (613) 831-7777
Fax: +1 (613) 831-7778
email: sales@luxcom.com
WARRANTY & REPAIRS
Warranty
This Luxcom Technologies Inc. product is war-
ranted against defects in materials and workman-
ship for a period of five years from the date of
shipment. Luxcom Technologies Inc. will, at its
option, repair or replace products which prove to
be defective during the warranty period, provided
that they are returned to Luxcom Technologies Inc.
Repairs necessitated by misuse of the product are
not covered by this warranty. No other warranties
are expressed or implied, including, but not limited
to, the implied warranties of merchantability and
fitness for a particular purpose. Luxcom
Technologies Inc. is not liable for consequential
damages.
Claims
If physical damage to the modem is found when
the product is received, notify the carrier and
Luxcom Technologies immediately. Luxcom
Technologies will arrange for repair or
replacement.
Repacking For Shipment
If the modem needs to be shipped by commercial
transportation for service or repair, the sender
must request a Return Material Authorization
number from Luxcom Technologies Inc.
( RMA )
Before returning the item, paperwork indicating the
name, department, company and telephone
number of the sender, model and serial number of
the product and a brief description of the problem
must be enclosed.
Certification
Luxcom Technologies Inc. certifies that this
modem met its published specification at the time
of shipment from the factory.
PART NUMBERS
OM102P-XX-XX
ST = ST optical connector
SC = SC optical connector
LC = LC optical connector
MM = 1300 multi-mode optics
SM = 1300 singlemode optics
Monitor Port Cable ................................ 91-325-0
Mounting Plate ...................................... MB-1
The OM102P may be desktop mounted, or it may be
mounted in Luxcom's MB-1 mounting plate shown below.
The modem slides into the plate and is held in place with two
thumb lock screws.
MB-1 Mounting Plate
98-223-0
REV. 1.7
Sept. 06, 2011
OM102P OM102P
100BASE-TX to 100BASE-FX
Ethernet Media Converter
with
48V PoE Output
Operating Manual
FRONT
REAR
