LuxCom 1000BASE-T Operating Manual

LUXCOM Technologies Inc.
102 Walgreen Rd., Ottawa, Ontario, Canada
K0A 1L0
www.luxcom.com
Tel: +1 (613) 831-7777
Fax: +1 (613) 831-7778
email: sales@luxcom.com
WARRANTY & REPAIRS
Warranty
This Luxcom Technologies Inc. product is warranted
against defects in materials and workmanship for a
period of five years from the date of shipment. Luxcom
Technologies Inc. will, at its option, repair or replace
products which prove to be defective during the war-
ranty period, provided that they are returned to Luxcom
Technologies Inc. Repairs necessitated by misuse of
the product are not covered by this warranty. No other
warranties are expressed or implied, including, but not
limited to, the implied warranties of merchantability and
fitness for a particular purpose. Luxcom Technologies
Inc. is not liable for consequential damages.
Claims
If physical damage to the modem is found when the
product is received, notify the carrier and Luxcom
Technologies immediately. Luxcom Technologies will
arrange for repair or replacement.
Repacking For Shipment
If the modem needs to be shipped by commercial
transportation for service or repair, the sender must
request a Return Material Authorization number (RMA)
from Luxcom Technologies Inc. Before returning the
item, paperwork indicating the name, department,
company and telephone number of the sender, model
and serial number of the product and a brief description
of the problem must be enclosed.
Certification
Luxcom Technologies Inc. certifies that this modem met
its published specification at the time of shipment from
the factory.
PART NUMBERS
OM1000P-XX-LC
SFP Module for Fiber
SX = 850 nm multimode
LX = 1300 nm single/multimode
LXE = 1300 nm single/multimode
BU = 1300 nm TX singlemode single
fiber bi-directional
BD = 1500 nm TX singlemode single
fiber bi-directional
S80 = 1500 nm TX singlemode
No = none
Monitor Port Cable ................................ 91-325-0
Mounting Plate ...................................... MB-1
The OM1000P may be desktop mounted, or it may be
mounted in Luxcom's MB-1 mounting plate shown below.
The modem slides into the plate and is held in place with
two thumb lock screws.
MB-1 Mounting Plate
98-219-1
REV. 1.1
Sept 9, 2008
OM1000P OM1000P
1000BASE-T to 1000BASE-X
or
100BASE-TX to 100BASE-FX
Ethernet Media Converter
with
48V PoE Output
Operating Manual
FRONT
REAR
