CPU Cards
CZGG LU-10-X
PISA Single-Board Computer with
Embedded 1GHz CPU, VGA, SATA,
IDE, Dual Gb LAN, CompactFlash
Socket, USB & IrDA
USER'S MANUAL
VER. 1.2C • SEP 2007
No part of this manual may be reproduced without permission
®
CyberResearch
, Inc.
www.cyberresearch.com
25 Business Park Dr., Branford, CT 06405 USA
203-483-8815 (9am to 5pm EST) FAX: 203-483-9024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CZGG LU-10-X and is the answer not in the manual?

Questions and answers

Related Manuals for CyberResearch CZGG LU-10-X

Summary of Contents for CyberResearch CZGG LU-10-X

  • Page 1 ® CPU Cards CZGG LU-10-X PISA Single-Board Computer with Embedded 1GHz CPU, VGA, SATA, IDE, Dual Gb LAN, CompactFlash Socket, USB & IrDA USER’S MANUAL VER. 1.2C • SEP 2007 No part of this manual may be reproduced without permission ®...
  • Page 3 CyberResearch, Inc. In no event will CyberResearch, Inc. be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 ® CZGG LU-10-X Series CyberResearch CPU Cards Title CZGG LU-10-X Revision # Description Date of Issue Initial Release June 2006 1.1C Revision September 1 2007 1.2C Revision September 4 2007 ©Copyright 2007 CyberResearch, Inc.

  • Page 5: Table Of Contents

    CZGG LU-10-X CPU Card Connectors ............3 1.2.3 (Optional) LCDC LVDS-LUKE-A Daughterboard Connectors ....6 ................6 ECHNICAL PECIFICATIONS 1.3.1 CZGG LU-10-X CPU card Technical Specifications........6 1.3.2 (Optional) LCDC LVDS-LUKE-A Daughterboard Technical Specifications . 8 DETAILED SPECIFICATIONS ................9 ........... 10 OMPATIBLE YBER...
  • Page 6 Optional Accessory Items ............... 19 CONNECTORS AND JUMPERS ................. 20 .............. 21 ERIPHERAL NTERFACE ONNECTORS 3.1.1 CZGG LU-10-X Peripheral Interface Connectors ......... 21 3.1.2 LCDC LVDS-LUKE-A Peripheral Interface Connectors....... 23 3.1.3 Rear Panel Connectors................23 3.1.4 Jumpers....................24 ..............24...
  • Page 7 ONSIDERATIONS 4.1.1 Installation Notices ................. 61 ......................62 NPACKING 4.2.1 Unpacking Precautions................62 4.2.2 Checklist....................62 CZGG LU-10-X CPU C ............63 NSTALLATION 4.3.1 Preinstalled Components ................ 63 4.3.2 Components to Install ................63 4.3.3 DIMM Module Installation..............64 4.3.3.1 Purchasing the Memory Module............... 64 4.3.3.2 DIMM Module Installation...............
  • Page 8 ® CZGG LU-10-X Series CyberResearch CPU Cards AMI BIOS SETUP....................71 ....................72 NTRODUCTION 5.1.1 Starting Setup..................72 5.1.2 Using Setup ..................... 72 5.1.3 Getting Help.................... 73 5.1.4 Unable to Reboot After Configuration Changes........73 5.1.5 BIOS Menu Bar..................73 5.2..........................
  • Page 9 ® CyberResearch CPU Cards CZGG LU-10-X Series ......................... 123 SOFTWARE DRIVERS ..................126 ..............127 VAILABLE OFTWARE RIVERS ............... 127 HIPSET RIVER NSTALLATION ............133 UDIO RIVER NSTALLATION LAN D ................138 RIVER NSTALLATION BIOS CONFIGURATION OPTIONS ..............142 BIOS C ..............
  • Page 10 CyberResearch CPU Cards List of Figures Figure 1-1: CZGG LU-10-X CPU Card Overview (Front Side) ........4 Figure 1-2: CZGG LU-10-X CPU Card Overview (Reverse Side).......5 Figure 1-3: LCDC LVDS-LUKE-A Daughterboard Overview (Front Side) ....6 Figure 2-1: Data Flow Block Diagram................12 Figure 3-1: CZGG LU-10-X Connector and Jumper Locations (Front Side)..21...
  • Page 11 ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-28: JP4 Pinout Locations ................58 Figure 3-29: LVDS Jumper Pinout Locations............59 Figure 4-1: DIMM Module Installation................65 Figure 4-2: 18-bit TTL LCDC LVDS-LUKE-A Connectivity ........66 Figure 4-3: 24-bit TTL LCDC LVDS-LUKE-A Connectivity ........67 Figure 6-1: Access the 4in1_Extreme Folder ............
  • Page 12 ® CZGG LU-10-X Series CyberResearch CPU Cards List of Tables Table 1-1: Model Variations..................2 Table 1-2: Technical Specifications ................7 Table 1-3: LCDC LVDS-LUKE-A Technical Specifications........8 Table 2-1: Power Consumption .................19 Table 3-1: Peripheral Interface Connectors..............23 Table 3-2: Rear Panel Connectors................24 Table 3-3: Onboard Jumpers ..................24...
  • Page 13 Table 3-30: JP1 Jumper Settings................55 Table 3-31: Clear CMOS Jumper Settings ..............56 Table 3-32: CF Card Setup Jumper Settings ............57 Table 3-33: LVDS Jumper Settings................59 Table 4-1: Cables Provided by CyberResearch ............68 Table 5-1: BIOS Navigation Keys................73 CyberResearch, Inc. xiii 25 Business Park Drive P: (203) 483-8815;...
  • Page 14 ® CZGG LU-10-X Series CyberResearch CPU Cards List of BIOS Menus Menu 1: Main........................74 Menu 2: Advanced.......................76 Menu 3: CPU Configuration ..................77 Menu 4: IDE Configuration ..................78 Menu 5: IDE Master and IDE Slave Configuration ...........81 Menu 6: Floppy Configuration ...................85 Menu 7: Super IO Configuration ................86...
  • Page 15 ® CyberResearch CPU Cards CZGG LU-10-X Series Glossary AC ’97 Audio Codec 97 Hard Disk Drive ACPI Advanced Configuration and Power Integrated Data Electronics Interface Input/Output Advanced Power Management ICH4 I/O Controller Hub 4 ARMD ATAPI Removable Media Device L1 Cache Level 1 Cache...

  • Page 16: Cpu Cards

    ® CZGG LU-10-X Series CyberResearch CPU Cards ©Copyright 2007 CyberResearch, Inc.

  • Page 17: Introduction

    ® CyberResearch CPU Cards CZGG LU-10-X Series Chapter Introduction CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 18: Czgg Lu-10-X Cpu Card Overview

    CyberResearch CPU Cards CZGG LU-10-X CPU Card Overview The PISA form factor CZGG LU-10-X CPU card is fully equipped with a high performance, low power VIA processor and advanced multi-mode I/Os. 1.1.1 Models The CZGG LU-10-X series has 1 CPU card model. See Table 1-1.

  • Page 19: Czgg Lu-10-X Cpu Card Connectors

    CZGG LU-10-X CPU Card Connectors 1.2.1 CZGG LU-10-X Overview The CZGG LU-10-X is a single board computer (SBC) that can be ordered with an optional LCDC LVDS-LUKE-A daughterboard, which provides improved LVDS connectivity. The LCDC LVDS-LUKE-A is mounted on the CPU Card, over the TTL connector.

  • Page 20: Figure 1-1: Czgg Lu-10-X Cpu Card Overview (Front Side)

    CPU Cards Figure 1-1: CZGG LU-10-X CPU Card Overview (Front Side) The CZGG LU-10-X CPU card has the following connectors onboard and accessible on the front side of the CZGG LU-10-X (see Figure 1-1): 2 x IDE device connectors (primary and secondary)

  • Page 21: Figure 1-2: Czgg Lu-10-X Cpu Card Overview (Reverse Side)

    1 x Parallel port connector 1 x Power supply to mainboard connector 1 x Front panel connector 1 x Keyboard/mouse connector The CZGG LU-10-X CPU card also has the following jumpers accessible on the front side. Clear CMOS jumper LVDS voltage selection CF setup Figure 1-2 shows the connectors on the reverse side of the CZGG LU-10-X CPU card.

  • Page 22: Optional) Lcdc Lvds-Luke-A Daughterboard Connectors

    1-3). The jumper is used to set the voltage for the LVDS display. Technical Specifications 1.3.1 CZGG LU-10-X CPU card Technical Specifications CZGG LU-10-X CPU card technical specifications are listed in Table 1-2. Detailed descriptions of each specification can be found in Chapter 2 Detailed Specifications. ©Copyright 2007 CyberResearch, Inc.
  • Page 23 ® CyberResearch CPU Cards CZGG LU-10-X Series Specification CZGG LU-10-X Form Factor PISA 1GHz VIA LUKE processor System Chipset VIA VT8237R+ Display Dual 18-bit TTL LCD Memory Maximum Memory supported 1GB Support 333Mhz or 400MHz DDR 1x DDR DIMM socket supports up to 1GB...

  • Page 24: Optional) Lcdc Lvds-Luke-A Daughterboard Technical Specifications

    ® CZGG LU-10-X Series CyberResearch CPU Cards 1.3.2 (Optional) LCDC LVDS-LUKE-A Daughterboard Technical Specifications LCDC LVDS-LUKE-A technical specifications are listed in Table 1-3. Detailed descriptions of each specification can be found in Chapter 2 Detailed Specifications. Specification LCDC LVDS-LUKE-A Chipset...

  • Page 25: Detailed Specifications

    ® CyberResearch CPU Cards CZGG LU-10-X Series Chapter Detailed Specifications CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 26: Compatible Cyberresearch Backplanes

    CyberResearch, Inc. CPU Support The CZGG LU-10-X CPU card comes with a preinstalled 1GHz, ultra low voltage (ULV) VIA® Luke processor. The new VIA 'Luke' CoreFusion Processing Platform integrates the latest generation VIA Eden-N™ processor with the VIA CN400 Northbridge in a single, low power package.

  • Page 27: Data Flow

    CyberResearch CPU Cards CZGG LU-10-X Series The CZGG LU-10-X CPU card has a VIA VT8237R Plus Southbridge on board. A summary of the available Southbridge features is listed below. For more information on this chipset please visit the VIA website.

  • Page 28: Figure 2-1: Data Flow Block Diagram

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 2-1 shows the data flow between the two onboard chipsets and other components installed on the CPU card and described in the following sections of this chapter. Figure 2-1: Data Flow Block Diagram...

  • Page 29: Graphics Support

    Sharpening, Soft Focus, Embossing, and Neon Edge effects. LVDS Display Support The CZGG LU-10-X CPU card supports TTL displays. Using the optional LCDC LVDS-LUKE-A daughterboard enables connectivity to 18-bit or 24-bit flat panel displays. The LCDC LVDS-LUKE-A comes with an onboard VIA VT1631L Low Voltage Differential Signaling (LVDS) Transmitter.

  • Page 30: Memory Support

    2.24 to 2.75 supply voltage TQFP-100 Thin Quad Flat package Memory Support The CZGG LU-10-X CPU has one 184-pin dual inline memory module (DIMM) sockets and supports one 400MHz or 333MHz SDRAM DDR DIMM modules with a maximum RAM of up to 1GB.

  • Page 31: Drive Interfaces

    Provides LED pins for network operation status indication 2.5/3.3V power supply with 5V tolerant I/Os 0.25µm CMOS process 2.11 Drive Interfaces The CZGG LU-10-X can support the following drive interfaces. 2 x SATA drives 4 x IDE devices 1 x FDD 1 x Compact flash card CyberResearch, Inc.

  • Page 32: Sata Drive Support

    150MB/s. 2.11.2 IDE HDD Interfaces The CZGG LU-10-X southbridge chipset IDE controller supports up to four HDDs with the following specifications: Supports PIO IDE transfers up to 16MB/s Supports Ultra ATA/133 devices with data transfer rates up to 133MB/s 2.11.3...

  • Page 33: Infrared Data Association (Irda) Interface

    The CZGG LU-10-X CPU card has eight USB interfaces, seven internal and one external. The USB interfaces support both USB 2.0 and USB 1.1. 2.17 BIOS The CZGG LU-10-X CPU card uses a licensed copy of AMI BIOS. The features of the flash BIOS used are listed below: SMIBIOS (DMI) compliant...

  • Page 34: Power Consumption

    AVRack® Media Player Configuration Panel for improved user convenience 2.20 Power Consumption Table 2-1 shows the power consumption parameters for the CZGG LU-10-X CPU card when a 1GHz LUKE processor is running with one 256MB, 400MHz DDR module. ©Copyright 2007 CyberResearch, Inc.

  • Page 35: Packaged Contents

    Table 2-1: Power Consumption 2.21 Packaged Contents 2.21.1 Package Contents The following components are shipped with the CZGG LU-10-X. 1 x CZGG LU-10-X single board computer 1 x Mini jumper pack 1 x IDE flat cable 40p/40p/40p 2 x SATA cables...

  • Page 36: Connectors And Jumpers

    ® CZGG LU-10-X Series CyberResearch CPU Cards Chapter Connectors and Jumpers ©Copyright 2007 CyberResearch, Inc.

  • Page 37: Peripheral Interface Connectors

    CPU Cards CZGG LU-10-X Series Peripheral Interface Connectors All peripheral interface connectors and jumpers on both the CZGG LU-10-X and LCDC LVDS-LUKE-A are shown in the sections below. 3.1.1 CZGG LU-10-X Peripheral Interface Connectors Figure 3-1 and Figure 3-2 shows the onboard peripheral connectors, CPU card peripheral connectors and onboard jumpers.

  • Page 38: Figure 3-2: Czgg Lu-10-X Connector Locations (Reverse Side)

    CPU Cards Figure 3-2: CZGG LU-10-X Connector Locations (Reverse Side) Table 3-1 shows a list of the peripheral interface connectors on the CZGG LU-10-X CPU card Detailed descriptions of these connectors can be found in Section 3.2 on page 24.

  • Page 39: Lcdc Lvds-Luke-A Peripheral Interface Connectors

    Figure 3-3 shows the onboard peripheral connector and onboard jumper of the LCDC LVDS-LUKE-A daughterboard. Figure 3-3: LCDC LVDS-LUKE-A Overview 3.1.3 Rear Panel Connectors Figure 3-1 shows the rear panel connectors on the CZGG LU-10-X CPU card. Detailed descriptions of these connectors can be found in Section 3.3. Connector Type...

  • Page 40: Jumpers

    Table 3-2: Rear Panel Connectors 3.1.4 Jumpers Table 3-3 lists jumpers found on both the CZGG LU-10-X CPU card and the LCDC LVDS-LUKE-A. Detailed descriptions of these jumpers can be found in Section 3.3.4 on page 53. (See Figure 3-1 and Figure 3-3 for jumper locations)

  • Page 41: Figure 3-4: Atx Pson Pinouts

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-4: ATX PSON Pinouts PIN NO. DESCRIPTION PS_ON Table 3-4: ATX PSON Connector Pinouts CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 42: Audio Connector

    ® CZGG LU-10-X Series CyberResearch CPU Cards 3.2.2 Audio Connector CN Label: JAUDIO1 CN Type: 10-pin header (2x5) CN Location: See Figure 3-5 CN Pinouts: See Table 3-5 The onboard audio connector (JAUDIO1) is directly connected to an onboard AC’97 AUDIO CODEC.

  • Page 43: Compact Flash Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series PIN NO. DESCRIPTION PIN NO. DESCRIPTION ROUT_L LINR_L LOUT_L LINL_L MICIN Table 3-5: Audio Connector Pinouts 3.2.3 Compact Flash Connector CN Label: CN Type: 50-pin header (2x25) CN Location: See Figure 3-6 CN Pinouts: See Table 3-6 A compact flash memory module is inserted to the Compact Flash connector (CF1).

  • Page 44: Table 3-6: Compact Flash Connector Pinouts

    ® CZGG LU-10-X Series CyberResearch CPU Cards PIN NO. DESCRIPTION PIN NO. DESCRIPTION GROUND VCC-IN CHECK1 DATA 3 DATA 11 DATA 4 DATA 12 DATA 5 DATA 13 DATA 6 DATA 14 DATA 7 DATA 15 HDC_CS0# HDC_CS1 GROUND IOR#...

  • Page 45: Fan Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series 3.2.5 Fan Connector CN Label: FAN1 CN Type: 3-pin header CN Location: See Figure 3-7 CN Pinouts: See Table 3-7 The cooling fan connector provides a 12V, 500mA current to a system cooling fan. The connector has a "rotation"...

  • Page 46: Floppy Disk Connector

    ® CZGG LU-10-X Series CyberResearch CPU Cards 3.2.6 Floppy Disk Connector CN Label: FDD1 CN Type: 34-pin header (2x17) CN Location: See Figure 3-8 CN Pinouts: See Table 3-8 The floppy disk connector (FDD1) is connected to a floppy disk drive.

  • Page 47: Front Panel Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series -DSA -MOB -DIR -STEP -WDATA -PWE -TRK0 -WPT -RDATA -HDSEL -DSKCHG Table 3-8: Floppy Disk Connector Pinouts 3.2.7 Front Panel Connector CN Label: CN Type: 14-pin header (2x7) CN Location: See Figure 3-9...

  • Page 48: Figure 3-9: Front Panel Connector Pinout Locations

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 3-9: Front Panel Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION POWER LED SPEAKER PWR BUTTON 12-14 RESET 11-13 HDLED Table 3-9: Front Panel Connector Pinouts ©Copyright 2007 CyberResearch, Inc.

  • Page 49: Gpio Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series 3.2.8 GPIO Connector CN Label: DIO1 CN Type: 10-pin header (2x5) CN Location: See Figure 3-10 CN Pinouts: See Table 3-10 The General Purpose Input Output (GPIO) connector can be connected to external I/O control devices including sensors, lights, alarms and switches.

  • Page 50: Ide Connector (Primary)

    CN Location: See Figure 3-11 CN Pinouts: See Table 3-11 One primary 40-pin primary IDE device connector on the CZGG LU-10-X CPU card supports connectivity to Ultra ATA/133 IDE devices with data transfer rates up to 133MB/s. ©Copyright 2007 CyberResearch, Inc.

  • Page 51: Figure 3-11: Primary Ide Device Connector Locations

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-11: Primary IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3...

  • Page 52: Ide Connector (Secondary)

    CN Location: See Figure 3-12 CN Pinouts: See Table 3-12 One primary 44-pin secondary IDE device connector on the CZGG LU-10-X CPU card supports connectivity to Ultra ATA/133 IDE devices with data transfer rates up to 133MB/s. ©Copyright 2007 CyberResearch, Inc.

  • Page 53: Figure 3-12: Secondary Ide Device Connector Locations

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-12: Secondary IDE Device Connector Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3...

  • Page 54: Inverter Power Connector

    ® CZGG LU-10-X Series CyberResearch CPU Cards INTERRUPT HDC CS0# HDC CS1# HDD ACTIVE# GROUND GROUND Table 3-12: Secondary IDE Connector Pinouts 3.2.11 Inverter Power Connector CN Label: INV1 CN Type: 5-pin header (1x5) CN Location: See Figure 3-13 CN Pinouts: See Table 3-13 The inverter connector is connected to the LCD backlight.

  • Page 55: Ir Interface Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series PIN NO. DESCRIPTION EN_BL Table 3-13: Inverter Power Connector Pinouts 3.2.12 IR Interface Connector CN Label: CN Type: 5-pin header (1x5) CN Location: See Figure 3-14 CN Pinouts: See Table 3-14 The integrated infrared (IrDA) connector supports both Serial Infrared (SIR) and Amplitude Shift Key Infrared (ASKIR) interfaces.

  • Page 56: Keyboard Connector

    ® CZGG LU-10-X Series CyberResearch CPU Cards PIN NO. DESCRIPTION IRRX IRTX Table 3-14: IR Connector Pinouts 3.2.13 Keyboard Connector CN Label: CN Type: 3-pin header (1x3) CN Location: See Figure 3-15 CN Pinouts: See Table 3-15 The keyboard connector (CN2 is connected to a keyboard if the PS/2 connector on the rear panel is connected to a mouse.

  • Page 57: Figure 3-15: Keyboard Connector Pinout Locations

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-15: Keyboard Connector Pinout Locations PIN NO. DESCRIPTION L_KCLK L_KDAT Table 3-15: Keyboard Connector Pinouts CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 58: Lvds Connector

    CN Pinouts: See Table 3-15 WARNING: Make sure the daughterboard is correctly positioned on the CZGG LU-10-X CPU card connector pins. If the LCDC LVDS-LUKE-A is not correctly positioned irreparable damage to the CPU card, daughterboard and display may occur. Please refer to the installation instructions in Chapter 4.

  • Page 59: Parallel Port Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series LVDS clock output + LVDS clock output - LVDS data3 output + LVDS data3 output - LVDS data0 output + LVDS data0 output - LVDS data1 output + LVDS data1 output - LVDS data2 output +...

  • Page 60: Figure 3-17: Parallel Port Connector Pinout Locations

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 3-17: Parallel Port Connector Pinout Locations PIN NO. DESCRIPTION PIN NO. DESCRIPTION STROBE# DATA 0 DATA 1 DATA 2 DATA 3 DATA 4 DATA 5 DATA 6 DATA 7 ACKNOWLEDGE BUSY PAPER EMPTY...

  • Page 61: Sata Connectors

    CN Pinouts: See Table 3-18 The Serial ATA (SATA) drive connectors are connected directly to 150MB/s SATA drives. The CZGG LU-10-X supports two SATA drives transmitting at speeds of up to 150MB/s. Figure 3-18: SATA Connector Pinout Locations CyberResearch, Inc.

  • Page 62: Serial Port Connectors

    ® CZGG LU-10-X Series CyberResearch CPU Cards PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 3-18: SATA Connector Pinouts 3.2.17 Serial Port Connectors CN Label: COM1 and COM2 CN Type: 2x5 pin header CN Location: See Figure 3-19 CN Pinouts: See Table 3-19 The serial port connectors are used to connect to serial port devices.

  • Page 63: Ttl Interface Connector

    ® CyberResearch CPU Cards CZGG LU-10-X Series PIN NO. DESCRIPTION PIN NO. DESCRIPTION NDCD NDSR NRTS NCTS NDTR Table 3-19: Serial Port Connector Pinouts 3.2.18 TTL Interface Connector CN Label: TTL1 CN Type: 40-pin header (2x20) CN Location: CN Pinouts:...

  • Page 64: Cpu Cards

    ® CZGG LU-10-X Series CyberResearch CPU Cards PIN NO. DESCRIPTION PIN NO. DESCRIPTION +LCD +LCD +LCD DATA 10 FPP1 FPP2 FPP3 FPP4 FPP5 FPP6 FPP7 FPP8 FPP9 FPP10 FPP11 FPP12 FPP13 FPP14 FPP15 FPP16 FPP17 FPP18 FPP19 FPP20 FPP21 FPP22...

  • Page 65: Figure 3-21: Usbconnector Pinout Locations

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-21: USBConnector Pinout Locations PIN NO. DESCRIPTION USB_DT1- USB_DT1+ Table 3-21: USB2 Connector Pinouts PIN NO. DESCRIPTION PIN NO. DESCRIPTION USB_DT2- USB_DT3+ USB_DT2+ USB_DT3- Table 3-22: JUSB1 Connector Pinouts PIN NO. DESCRIPTION PIN NO. DESCRIPTION CyberResearch, Inc.

  • Page 66: External (Rear Panel) Connectors

    Table 3-24: JUSB3 Connector Pinouts External (Rear Panel) Connectors Figure 3-22 shows the CZGG LU-10-X CPU card rear panel. The peripheral connectors on the back panel can be connected to devices externally when the CPU card is installed in a chassis. The peripheral connectors on the rear panel are:...

  • Page 67: Vga Connector

    CN Location: See Figure 3-22 (labeled number 5) CN Pinouts: See Figure 3-24, Table 3-26 (VGA) The CZGG LU-10-X has a single 15-pin female connector for connectivity to standard display devices. CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 68: Lan Connectors

    CN Pinouts: See Table 3-27 (RJ-45 ) The CZGG LU-10-X is equipped with two built-in 10/100Mbps Ethernet controllers. The controllers connect to the LAN through two RJ-45 LAN connectors. There are two LED on the connector indicating the status of LAN. The pin assignments are listed in the following tables: ©Copyright 2007 CyberResearch, Inc.

  • Page 69: Usb Connector

    See Figure 3-22 (LAN labeled number 4) The CZGG LU-10-X has a single USB 2.0 port accessible on the rear panel. This port is able to connect to both USB 2.0 and USB 1.1 devices. The pin assignments are listed in the following tables: CyberResearch, Inc.

  • Page 70: Onboard Jumpers

    Figure: Jumper means removing the plastic clip from a jumper. The CZGG LU-10-X CPU card and daughter expansion board have nine onboard jumpers, two on the CPU card and six on the expansion daughterboard. The jumpers are described in Table 3-29.

  • Page 71: Figure 3-26: Jp1 Pinout Locations

    ® CyberResearch CPU Cards CZGG LU-10-X Series Jumper Label: Jumper Type: 6 pin header Jumper Settings: See Table 3-30 Jumper Location: See Figure 3-26 This jumper allows the user to set the voltage for the LCD panel. Before setting this jumper please refer to the LCD panel user guide to determine the required voltage.

  • Page 72: Reset Cmos Jumper

    ® CZGG LU-10-X Series CyberResearch CPU Cards 3.4.2 Reset CMOS Jumper Jumper Label: Jumper Type: 3 pin header Jumper Settings: See Table 3-31 Jumper Location: See Figure 3-27 If the CPU Card fails to boot due to improper BIOS setting, use this jumper to clear the CMOS data and reset the system BIOS information.

  • Page 73: Cf Card Setup

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 3-27: CLR_CMOS Pinout Locations 3.4.3 CF Card Setup Jumper Label: Jumper Type: 3-pin header Jumper Settings: Jumper Location: See Figure 3-28 The JP3 jumper sets the compact flash card as either the slave device or the master device.

  • Page 74: Figure 3-28: Jp4 Pinout Locations

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 3-28: JP4 Pinout Locations ©Copyright 2007 CyberResearch, Inc.

  • Page 75: Lvds Voltage Selection

    ® CyberResearch CPU Cards CZGG LU-10-X Series 3.4.4 LVDS Voltage Selection WARNING: Making the wrong setting on this jumper may cause irreparable damage to both the CPU card and the LCD screen connected to the onboard connector. Jumper Label: JP1 (on the optional LCDC LVDS-LUKE-A)

  • Page 76: Installation And Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards Chapter Installation and Configuration ©Copyright 2007 CyberResearch, Inc.

  • Page 77: Installation Considerations

    Failing to adhere to these precautions may lead to severe damage of the CPU card and injury to the person installing the CPU card. 4.1.1 Installation Notices Before and during the installation of the CZGG LU-10-X CPU card, please do the following: Read the user manual The user manual provides a complete description of the CZGG LU-10-X CPU card, installation instructions and configuration options.

  • Page 78: Unpacking

    Handle the CZGG LU-10-X by its edges. Do not touch the IC chips, leads or circuitry unnecessarily. Do not place a PCB on top of an anti-static bag. Only the inside of the bag is safe from static discharge.

  • Page 79: Czgg Lu-10-X Cpu Card Installation

    ® CyberResearch CPU Cards CZGG LU-10-X Series If one or more of these items are missing, please contact CyberResearch, Inc. and do not proceed further with the installation. CZGG LU-10-X CPU Card Installation WARNING! Never run the CZGG LU-10-X without an appropriate heatsink and cooler that can be ordered from CyberResearch or purchased separately.

  • Page 80: Dimm Module Installation

    The DIMM module can have a of 333MHz or 400MHz The DIMM can be either single-sided or dual-sided. 4.3.3.2 DIMM Module Installation The CZGG LU-10-X CPU Card has two DDR SDRAM DIMM sockets. To install the DIMM modules, follow the instructions below and refer to Figure 4-1. Step 1: Pull the two white handles on either side of the DIMM socket down.

  • Page 81: Optional Lcdc Lvds-Luke-A Daughterboard Installation

    WARNING: Installing the LCDC LVDS-LUKE-A daughterboard incorrectly may cause irreparable damage to the TTL display and the CZGG LU-10-X The LCDC LVDS-LUKE-A daughterboard supports 18-bit and 24-bit TTL devices. The LCDC LVDS-LUKE-A daughterboard is installed on the J1 and J3 connectors. If 18-bit TTL connectivity is required, Pin 27 and Pin 28 on J1 and J3 must be left uncovered.

  • Page 82: 18-Bit Ttl Connectivity

    ® CZGG LU-10-X Series CyberResearch CPU Cards 4.3.4.1 18-bit TTL Connectivity To correctly install the LCDC LVDS-LUKE-A daughterboard to support an 18-bit TTL display, please follow the instructions below. Step 1: Correctly orientate the LCDC LVDS-LUKE-A daughterboard. The VIA chipset on the LCDC LVDS-LUKE-A daughterboard should be on the side of the LCDC LVDS-LUKE-A facing the gold finger backplane connectors.

  • Page 83: 24-Bit Ttl Connectivity

    ® CyberResearch CPU Cards CZGG LU-10-X Series 4.3.4.2 24-bit TTL Connectivity To correctly install the LCDC LVDS-LUKE-A daughterboard to support a 24-bit TTL display, please follow the instructions below. Step 4: Correctly orientate the LCDC LVDS-LUKE-A daughterboard. The VIA chipset on the LCDC LVDS-LUKE-A daughterboard should on the side of the LCDC LVDS-LUKE-A facting the gold finger backplane connectors.

  • Page 84: Peripheral Device Connection

    Table 4-1: Cables Provided by CyberResearch 4.3.5.1 IDE Disk Drive Connector (IDE1) The cable used to connect the CZGG LU-10-X to the IDE HDD is a standard 44-pin ATA33 flat cable. To connect an IDE device to the CZGG LU-10-X follow the instructions below.

  • Page 85: Compact Flash Connector

    CF connector for CD drive connectivity, please follow these instructions. Step 1: Connect one end of a ribbon cable to the IDE2 connector on the CZGG LU-10-X CPU Card. Step 2: Connect the other end of the same ribbon cable in Step 1 to the IDE1 connector on the expansion daughterboard.
  • Page 86 ® CZGG LU-10-X Series CyberResearch CPU Cards Intentionally Blank ©Copyright 2007 CyberResearch, Inc.

  • Page 87: Ami Bios Setup

    ® CyberResearch CPU Cards CZGG LU-10-X Series Chapter AMI BIOS Setup CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 88: Introduction

    ® CZGG LU-10-X Series CyberResearch CPU Cards Introduction A licensed copy of AMI BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options are user configurable.

  • Page 89: Getting Help

    ® CyberResearch CPU Cards CZGG LU-10-X Series Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again.
  • Page 90 Installed BIOS ID Processor: Displays auto-detected CPU specifications Type: Names the currently installed processor Speed: Lists the processor speed Count: The number of CPUs on the CZGG LU-10-X System Memory: Displays the auto-detected system memory. Size: Lists memory size ©Copyright 2007 CyberResearch, Inc.

  • Page 91: Advanced

    ® CyberResearch CPU Cards CZGG LU-10-X Series The System Overview field also has two user configurable fields: System Time [xx:xx:xx]: Allows system time to be set. System Date [Day xx/xx/xxxx]: Allows the system date to be set. Advanced The Advanced menu (BIOS Menu 2) allows CPU and peripheral device configuration...

  • Page 92: Cpu Configuration

    CPU Cards BIOS Menu 2: Advanced NOTE: The floppy configuration function shown in the menu above is not available on the CZGG LU-10-X. 5.4.1 CPU Configuration The CPU Configuration menu (BIOS Menu 3) shows detailed CPU specifications. ©Copyright 2007 CyberResearch, Inc.

  • Page 93: Ide Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series BIOS Menu 3: CPU Configuration The CPU Configuration menu (BIOS Menu 3) lists the following CPU details: Manufacturer: Lists the name of the CPU manufacturer Brand String: Lists the brand name of the CPU being used...
  • Page 94 ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 4: IDE Configuration OnBoard PCI IDE Controller [Both] The OnBoard PCI IDE Controller BIOS option specifies the IDE channels used by the onboard PCI IDE controller. The following configuration options are available.
  • Page 95 ® CyberResearch CPU Cards CZGG LU-10-X Series Secondary IDE channels including the Primary Master, Primary Slave, Secondary Master and Secondary Slave. IDE Master and IDE Slave When entering setup, BIOS auto detects the presence of IDE devices. This displays the status of the auto detected IDE devices.

  • Page 96: Ide Master, Ide Slave

    ® CZGG LU-10-X Series CyberResearch CPU Cards 25 seconds 30 seconds 35 seconds The best setting to use if the onboard IDE controllers are set to a specific IDE disk drive in the AMIBIOS is “0 seconds” and a large majority of ultra ATA hard disk drives can be detected well within “5 seconds.”...
  • Page 97 ® CyberResearch CPU Cards CZGG LU-10-X Series BIOS Menu 5: IDE Master and IDE Slave Configuration Auto-Detected Drive Parameters The “grayed-out” items in the left frame are IDE disk drive parameters automatically detected from the firmware of the selected IDE disk drive. The drive parameters are listed as follows: Device: Lists the device type (e.g.
  • Page 98 ® CZGG LU-10-X Series CyberResearch CPU Cards supported. Ultra DMA: Indicates the highest Synchronous DMA Mode that is supported. S.M.A.R.T.: Indicates whether or not the Self-Monitoring Analysis and Reporting Technology protocol is supported. Type [Auto] The Type BIOS option determines the type of device that the AMIBIOS attempts to boot from after the Power-On Self-Test (POST) has completed.
  • Page 99 ® CyberResearch CPU Cards CZGG LU-10-X Series Auto (Default) This option allows the BIOS to auto detect the LBA mode control on the specified channel. Block (Multi Sector Transfer) [Auto] Disabled Selecting this option prevents the BIOS from using Multi-Sector Transfer on the specified channel. The data to and from the device occurs one sector at a time.

  • Page 100: Floppy Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards DMA Mode [Auto] The DMA Mode BIOS selection allows adjusts the DMA mode options. Auto (Default) The BIOS auto detects the DMA mode. Use this value if the IDE disk drive support cannot be determined.

  • Page 101: Super Io Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series 1.2MB, 5.25 in 720KB, 3.5 in 1.44MB, 3.5 in (Default) 2.88MB, 3.5in BIOS Menu 6: Floppy Configuration 5.4.4 Super IO Configuration The Super IO Configuration menu (BIOS Menu 7) sets or changes the configurations for the parallel ports and serial ports.
  • Page 102 ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 7: Super IO Configuration On Board Floppy Controller [Enabled] The OnBoard Floppy Controller options enables or disables the floppy drive controller. Disabled Allows BIOS to disable the floppy controller Enabled (Default)
  • Page 103 ® CyberResearch CPU Cards CZGG LU-10-X Series Serial Port1 Address [3F8/IRQ4] The Serial Port1 Address option allows BIOS to select the Serial Port 1 base address. Disabled No base address is assigned to Serial Port 1 (Default) Serial Port 1 I/O port address is 3F8 and the interrupt...
  • Page 104 ® CZGG LU-10-X Series CyberResearch CPU Cards Parallel Address [378] The Parallel Port Address BIOS option assigns the I/O port address of the parallel port. The following address options are available: Disabled No I/O port address is assigned to the parallel port...

  • Page 105: Hardware Health Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series Parallel Port IRQ [IRQ7] The Parallel Port Address BIOS option assigns the parallel port interrupt address. The following address options are available. IRQ5 Parallel port interrupt address is IRQ5 IRQ7 (Default) Parallel port interrupt address is IRQ7 5.4.5 Hardware Health Configuration...

  • Page 106: Acpi Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards If the H/W Health Function is enabled different system parameters and values are shown. The following hardware health parameters are monitored. System Temperatures: The following system temperatures are monitored CPU Temperature System Temperature...

  • Page 107: Advanced Acpi Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series Advanced ACPI Configuration Chipset ACPI Configuration 5.4.6.1 Advanced ACPI Configuration The Advanced ACPI Configuration menu (BIOS Menu 10) selects the ACPI state when the system is suspended. BIOS Menu 10: Advanced ACPI Configuration ACPI 2.0 Features [No]...
  • Page 108 ® CZGG LU-10-X Series CyberResearch CPU Cards system ACPI APIC Support [Enabled] The ACPI APIC Support BIOS option adds a pointer to an ACPI APIC table in the RSDT (Root System Description Table). The RSDT is an array of pointers that direct the system to the physical addresses of other description tables.

  • Page 109: Chipset Acpi Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series 5.4.6.2 Chipset ACPI Configuration The Chipset ACPI Configuration menu (BIOS Menu 11) allows the USB to rouse a system from a sleep state or a suspend state. BIOS Menu 11: Chipset ACPI Configuration...
  • Page 110 ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 12: Power Power Management/APM [Enabled] The Power Management/APM BIOS option provides access the advanced power management features. Disabled Disables the Advanced Power Management (APM) feature Enabled (Default) Enables the APM feature Power Button Mode [On/Off] The Power Button Mode BIOS option specifies how the power button functions.
  • Page 111 ® CyberResearch CPU Cards CZGG LU-10-X Series standby mode Suspend When the power button is pressed the system goes into suspend mode Display Activity [Ignore] The Display Activity BIOS option determines if activity on the Display is monitored or ignored. If activity is detected on the monitor, the system is activated from a suspended or sleep state.
  • Page 112 ® CZGG LU-10-X Series CyberResearch CPU Cards (Default) Wake event not generated by an incoming call Disabled Enabled Wake event generated by an incoming call Resume on Lan [Disabled] The Resume on Lan BIOS option specifies if the system is roused from a suspended or standby state when there is activity on the LAN.

  • Page 113: Usb Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series Specific Key If selected a Wake-Up password must be selected. The system can only be roused from the suspended state if the password is entered on the keyboard. Resume on PS/2 Mouse [Disabled] The PS/2 Mouse BIOS option specifies if the system is roused from a suspended or standby state when there is activity on the PS/2 mouse.
  • Page 114 ® CZGG LU-10-X Series CyberResearch CPU Cards The USB Configuration menu (BIOS Menu 13) gives information on the USB configuration and allows some USB features to be configured. BIOS Menu 13: USB Configuration USB Configuration The USB Configuration field shows the system USB configuration. The items listed are: Module Version: x.xxxxx.xxxxx...
  • Page 115 ® CyberResearch CPU Cards CZGG LU-10-X Series USB 4 ports Four ports are USB 1.1 compatible USB 6 ports Six ports are USB 1.1 compatible (Default) Eight ports are USB 1.1 compatible USB 8 ports USB 2.0 Ports Enable [Enabled] The USB 2.0 Ports BIOS option enables or disables the USB 2.0 controller...

  • Page 116: Pci/Pnp

    ® CZGG LU-10-X Series CyberResearch CPU Cards The controller is capable of operating at full speed FullSpeed (12Mbits/second) HiSpeed (Default) The controller is capable of operating at high speed (480Mbits/second) BIOS EHCI Hand-Off [Enabled] The BIOS EHCI BIOS option enables support for Ises without EHCI hand-off support. The EHCI ownership change is claimed by the driver.
  • Page 117 ® CyberResearch CPU Cards CZGG LU-10-X Series BIOS Menu 14: PCI/PnP Configuration [Part 1] Clear NVRAM [No] The Clear NVRAM specifies whether the contents of the NVRAM (Non-Volatile RAM) when the power is turned off. (Default) System does not clear NVRAM during system boot System clears NVRAM during system boot Plug &...
  • Page 118 ® CZGG LU-10-X Series CyberResearch CPU Cards This setting allows the operating system to change the interrupt, I/O, and DMA settings. Set this option if the system is running Plug and Play aware operating systems. PCI Latency Timer [64] The values stipulated in the PCI Latency Timer are in units of PCI clock cycles for the PCI device latency timer register.
  • Page 119 ® CyberResearch CPU Cards CZGG LU-10-X Series graphics chipset can be mounted on a PCI card. Always check with the adapter card manual first, before modifying the default settings in the BIOS. PCI IDE BusMaster [Disabled] The PCI IDE BusMaster BIOS option enables or prevents the use of PCI IDE busmastering.
  • Page 120 ® CZGG LU-10-X Series CyberResearch CPU Cards PCI IDE adapter card. Only select this slot if the adapter card is installed in PCI Slot 5. PCI Slot 6 PCI Slot 6 is selected as the location of the OffBoard PCI IDE adapter card. Only select this slot if the adapter card is installed in PCI Slot 6.

  • Page 121: Boot

    ® CyberResearch CPU Cards CZGG LU-10-X Series DM Channel 5 DM Channel 6 DM Channel 7 Reserved Memory Size [Disabled] The Reserved Memory Size BIOS option specifies the amount of memory that should be reserved for legacy ISA devices. (Default)

  • Page 122: Boot Settings Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards 5.6.1 Boot Settings Configuration The Boot Settings Configuration menu (BIOS Menu 15) configures advanced system boot options. BIOS Menu 16: Boot Settings Configuration Quick Boot [Enabled] The Quick Boot BIOS option speeds up the boot process.
  • Page 123 ® CyberResearch CPU Cards CZGG LU-10-X Series The Quiet Boot BIOS option allows the boot up screen options to be modified between POST messages or an OEM logo. Disabled (Default) Displays normal POST messages Enabled Displays OEM Logo instead of POST messages...
  • Page 124 ® CZGG LU-10-X Series CyberResearch CPU Cards Disables PS/2 mouse support and prevents the PS/2 Disabled mouse port from using system resources. Enabled Allows the system to use a PS/2 mouse. Auto (Default) Allows the system to automatically detect if a PS/2 mouse is being used.

  • Page 125: Boot Device Priority

    ® CyberResearch CPU Cards CZGG LU-10-X Series The Interrupt 19 Capture ROM BIOS option allows optional ROMs such as network controllers to trap BIOS interrupt 19. Disabled (Default) Does not allow optional ROM to trap interrupt 19 Enabled Allows optional ROM to trap interrupt 19...

  • Page 126: Hard Disk Drives

    ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 17: Boot Device Priority 5.6.3 Hard Disk Drives The Hard Disk Drives menu is similar to the Removable Drives BIOS Menu 18 and it specifies the boot sequence of the available HDDs. When the menu is opened, the HDDs...

  • Page 127: Removable Drives

    If system does not boot from the “1st Drive” it may also disabled. NOTE: There is no floppy disk function on the CZGG LU-10-X. The removable drives that may be listed include USB drives. CyberResearch, Inc.
  • Page 128 ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 18: Removable Drives ©Copyright 2007 CyberResearch, Inc.

  • Page 129: Cd/Dvd Drives

    ® CyberResearch CPU Cards CZGG LU-10-X Series 5.6.5 CD/DVD Drives The CD/DVD Drives menu is similar to the Removable Drives BIOS Menu 18 and it specifies the boot sequence of the available CD/DVD drives. When the menu is opened, the CD drives and DVD drives connected to the system are listed as shown below:...
  • Page 130 ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 19: Security Change Supervisor Password The default setting for the Change Supervisor Password is Not Installed. If you wish to install a supervisor password, select this field and enter the password. After the password has been added, a User Access Level option and a Password Check option appear.

  • Page 131: Chipset

    ® CyberResearch CPU Cards CZGG LU-10-X Series Change User Password The default setting for the Change User Password is Not Installed. If you wish to install a user password, select this field and enter the password. After the password has been added, Install appears next to Change User Password.

  • Page 132: Northbridge Via Cn400 Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 20: Chipset 5.8.1 Northbridge VIA CN400 Configuration The Northbridge VIA CN400 Configuration menu (BIOS Menu 20) configures the Northbridge chipset. ©Copyright 2007 CyberResearch, Inc.
  • Page 133 ® CyberResearch CPU Cards CZGG LU-10-X Series BIOS Menu 21: Northbridge Chipset Configuration The Northbridge VIA CN400 Configuration BIOS menu has three submenus DRAM Clock/Timing Configuration AFO Features Configuration V-LINK Features Configuration The Northbridge VIA CN400 Configuration BIOS menu has a single configurable option:...

  • Page 134: Dram Clock/Timing Configurations

    ® CZGG LU-10-X Series CyberResearch CPU Cards 5.8.1.1 DRAM Clock/Timing Configurations The DRAM Clock/Timing Configuration menu (BIOS Menu 20) configures the DRAM settings. BIOS Menu 22: DRAM Clock/Timing Configuration DRAM Frequency [Auto] The DRAM Frequency option specifies the DRAM frequency or allows the system to automatically detect the DRAM frequency.

  • Page 135: Agp Features Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series The Configure DRAM Timing by SPD determines if the system uses the SPD (Serial Presence Detect) EEPROM to configure the DRAM timing. The SPD EEPROM contains all necessary DIMM specifications the including speed of the individual components such as CAS and bank cycle time as well as valid settings for the module and the manufacturer's code.
  • Page 136 ® CZGG LU-10-X Series CyberResearch CPU Cards BIOS Menu 23: AGP Features Configuration Primary Graphics Adapter [AGP] The Primary Graphics Adapter selects the graphics adapter the system uses. (Default) PCI graphics adapter is used AGP graphics adapter is used VGA Frame Buffer Size [64MB] The VGA Frame Buffer Size BIOS option sets the memory buffer size for the VGA display.

  • Page 137: V-Link Features Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series Panel Type [07] The Panel Type option specifies the device the panel type. The user is prompted to enter number between 0 and 15. 5.8.1.3 V-Link Features Configuration The V-Link Features Configuration menu (BIOS Menu 20) configures the V-Link Features.

  • Page 138: Southbridge Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards Mode 4 V-Link Data 8X Supported [Disabled] The V-Link Data 8X Support controls the data transmission speed between the Northbridge and Southbridge chipsets. V-LINK Data 8x transmissions not supported and the Disabled transmission...

  • Page 139: Exit

    ® CyberResearch CPU Cards CZGG LU-10-X Series OnBoard AC’97 [Enabled] The OnBoard AC97 Audio enables or disables the AC’97 CODEC. Disabled The onboard AC’97 is disabled (Default) The onboard AC’97 automatically detected and enabled Enabled Exit The Exit menu (BIOS Menu 26) allows default BIOS values to be loaded, optimal failsafe values and to save configuration changes.
  • Page 140 ® CZGG LU-10-X Series CyberResearch CPU Cards If you have finished making configuration changes but do not want to save them and you want to exit the BIOS menus, select this option. Discard Changes If you have finished making configuration changes but do not want to save them but still want to continue working with BIOS, select this option.
  • Page 141 ® CyberResearch CPU Cards CZGG LU-10-X Series Intentionally Blank CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 142: Software Drivers

    ® CZGG LU-10-X Series CyberResearch CPU Cards Chapter Software Drivers ©Copyright 2007 CyberResearch, Inc.

  • Page 143: Available Software Drivers

    The CZGG LU-10-X board has three software drivers: Chipset Audio All three drivers can be found on the CD that came with the CZGG LU-10-X. To install the drivers please follow the instructions in the sections below: Chipset Driver Installation...

  • Page 144: Figure 6-2: Setup Utility Icon

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 6-2: Setup Utility Icon Step 4: The installation program begins to initialize. After the initialization process a welcome screen shown in Figure 6-3 appears. Click “N ” to continue the installation. Figure 6-3: VIA Chipset Driver Installation Welcome Screen Step 5: The “Readme”...

  • Page 145: Figure 6-4: Readme Information

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 6-4: Readme Information Step 6: The user is then prompted to select the installation type. A user can select “Normal Installation” or “Quick Installation.” (See Figure 6-5) Select the installation type and click “N ”...

  • Page 146: Figure 6-5: Via Chipset Driver Installation Type

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 6-5: VIA Chipset Driver Installation Type Step 7: The setup then prompts the user (see Figure 6-6) to select the drivers that must be installed on the system. There are three drivers: VIA PCI IDE Bus Driver AGP Driver (AGP3.0 Supported)

  • Page 147: Figure 6-6: Driver Selection

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 6-6: Driver Selection Step 8: The setup then prompts the user (see Figure 6-7) if the VIA PCI IDE Bus Driver must be installed on the system. Select install or uninstall. Click “N ”...

  • Page 148: Figure 6-7: Via Pci Ide Bus Driver Selection

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 6-7: VIA PCI IDE Bus Driver Selection Step 9: The drivers are then installed onto the system. After the installation is complete the user is prompted to restart the computer now or later. (See Figure 6-8) Select when the computer must be restarted.

  • Page 149: Realtek Audio Driver Installation

    To install the RealTek AC’97 Audio driver, please follow the steps below: Step 1: Insert the CD into the system that contains the CZGG LU-10-X board. Open the CD folder and locate the AUDIO DRIVER A3.79 directory. Open the directory and look for icon for the setup.exe installation file.

  • Page 150: Figure 6-10: Audio Driver Setup Preparation

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure 6-10: Audio Driver Setup Preparation Step 4: After install shield is prepared, the welcome screen shown in Figure 6-11 appears. To continue the installation process, click the “N ” button. The install shield starts to configure the new software as shown in Figure 6-12.

  • Page 151: Figure 6-11: Audio Driver Welcome Screen

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 6-11: Audio Driver Welcome Screen Figure 6-12: Audio Driver Software Configuration Step 5: At this stage the “Digital Signal Not Found” screen shown in Figure 6-13 CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815;...

  • Page 152: Figure 6-13: Audio Driver Digital Signal

    ® CZGG LU-10-X Series CyberResearch CPU Cards appears. To continue the installation process, click the “Y ” button. The installation notice shown below appears. Figure 6-13: Audio Driver Digital Signal Step 6: At this stage the clicking the “Y ” button in Figure 6-13 appears, the installation of the driver begins.

  • Page 153: Figure 6-14: Audio Driver Installation Begins

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 6-14: Audio Driver Installation Begins Step 7: After the driver installation process is complete, a confirmation screen shown in Figure 6-15 appears CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 154: Lan Driver Installation

    To install the LAN driver, please follow the steps below: Step 1: Insert the CD into the system that contains the CZGG LU-10-X. Open the LAN directory and locate the icon for the relevant Setup installation file. Once located, use the mouse to move the cursor over the icon and double click the mouse button.

  • Page 155: Figure 6-16: Lan License Agreement

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure 6-16: LAN License Agreement Step 3: If you accept the terms, click “Next.” You are then prompted for the directory the driver is stored in. (See Figure 6-17) Figure 6-17: Select the Driver Directory CyberResearch, Inc.

  • Page 156: Figure 6-18: Lan Driver Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards Step 4: After selecting the directory the driver is installed in, click “Next.” The screen in Figure 6-18 appears. Figure 6-18: LAN Driver Configuration Step 5: In Figure 6-18 you have three options.
  • Page 157 ® CyberResearch CPU Cards CZGG LU-10-X Series Intentionally Blank CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 158: Abios Configuration Options

    ® CZGG LU-10-X Series CyberResearch CPU Cards Appendix BIOS Configuration Options ©Copyright 2007 CyberResearch, Inc.
  • Page 159 ® CyberResearch CPU Cards CZGG LU-10-X Series A.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 5. System Overview ....................74 OnBoard PCI IDE Controller [Both]..............78 IDE Master and IDE Slave ..................79 Hard Disk Write Protect [Disabled] ..............79 IDE Detect Time Out (Sec) [35] ................79...
  • Page 160 ® CZGG LU-10-X Series CyberResearch CPU Cards Monitor IRQ# ......................95 Resume on Ring [Disabled] ..................95 Resume on Lan [Disabled]..................96 Resume on PME# [Disabled] ................96 Resume on KBC [Disabled] ..................96 Wake-Up Key ......................96 Resume on PS/2 Mouse [Disabled]..............97 Resume On RTC Alarm [Disabled]...............97 RTC Alarm Date (Days) ..................97...
  • Page 161 ® CyberResearch CPU Cards CZGG LU-10-X Series Boot From LAN Support [Disabled] ..............109 Change Supervisor Password................114 User Access Level [Full Access]............... 114 Change User Password..................115 Password Check [Setup]..................115 Top Performance [Disabled]................117 DRAM Frequency [Auto] ..................118 DRAM Timing by SPD [Auto by SPD] ...............

  • Page 162: Bwatchdog Timer

    ® CZGG LU-10-X Series CyberResearch CPU Cards Appendix Watchdog Timer ©Copyright 2007 CyberResearch, Inc.
  • Page 163 NOTE: The following discussion applies to the DOS environment. It is recommended you contact CyberResearch support or visit our website for specific drivers for other operating systems. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 164 ® CZGG LU-10-X Series CyberResearch CPU Cards NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system will reset. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds...
  • Page 165 ® CyberResearch CPU Cards CZGG LU-10-X Series Intentionally Blank CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 166: Caddress Mapping

    ® CZGG LU-10-X Series CyberResearch CPU Cards Appendix Address Mapping ©Copyright 2007 CyberResearch, Inc.

  • Page 167: Io Address Map

    ® CyberResearch CPU Cards CZGG LU-10-X Series C.1 IO Address Map I/O address Description Range 000-01F DMA Controller 020-021 Interrupt Controller 040-043 System time 060-06F Keyboard Controller 070-07F System CMOS/Real time Clock 080-09F DMA Controller 0A0-0A1 Interrupt Controller 0C0-0DF DMA Controller...

  • Page 168: Irq Mapping Table

    ® CZGG LU-10-X Series CyberResearch CPU Cards C.3 IRQ Mapping Table IRQ0 System Timer IRQ8 RTC clock IRQ1 Keyboard IRQ9 ACPI IRQ2 Available IRQ10 IRQ3 COM2 IRQ11 LAN/USB2.0/SATA IRQ4 COM1 IRQ12 PS/2 mouse IRQ5 SMBus Controller IRQ13 IRQ6 IRQ14 Primary IDE...
  • Page 169 ® CyberResearch CPU Cards CZGG LU-10-X Series Intentionally Blank CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 170: Dexternal Ac'97 Audio Codec

    ® CZGG LU-10-X Series CyberResearch CPU Cards Appendix External AC’97 Audio CODEC ©Copyright 2007 CyberResearch, Inc.

  • Page 171: Introduction

    CZGG LU-10-X Series D.1 Introduction The audio functionalities of the CZGG LU-10-X CPU card can be implemented using a separately purchased audio module, contact CyberResearch, Inc for further details. The audio kit is powered by a Realtek ALC655 is a 16-bit, full duplex AC’97 2.3 compatible audio CODEC with 48KHz sampling rate.

  • Page 172: Physical Connection

    ® CZGG LU-10-X Series CyberResearch CPU Cards D.2 Physical Connection Figure D-2: Audio Kit Connectors The audio kit comes with a PCI slot bracket for the installation into a PC case or rackmount chassis. Connect the 10-pin header to the AUDIO1 header as shown in Figure E-1, and if necessary, connect the CDIN1 and AUXIN1 to optical drives or other audio sources, e.g., an MPEG card, using a 4-pin cable.

  • Page 173: Sound Effect Configuration

    ® CyberResearch CPU Cards CZGG LU-10-X Series Figure D-3: Sound Effect Manager Icon D.4 Sound Effect Configuration After installing the audio CODEC driver, you should be able to use the multi-channel audio features. Click the audio icon from the Notification Area from system task bar (see Figure D-5).
  • Page 174 ® CZGG LU-10-X Series CyberResearch CPU Cards Figure D-4: Sound Effect Manager Icon [Control Panel] Figure D-5: Sound Effect Manager Icon [Task Bar] ©Copyright 2007 CyberResearch, Inc.

  • Page 175: Sound Effect

    ® CyberResearch CPU Cards CZGG LU-10-X Series D.5 Sound Effect You may select a pre-configured sound environment setting with the preset equalizer settings. You may also load an equalizer setting or make a new equalizer setting using the “Load EQ Setting” and “Save Preset” button. (See Figure D-7) Figure D-6: Setting Sound Effects D.6 Environment Simulation...

  • Page 176: Karaoke Mode

    ® CZGG LU-10-X Series CyberResearch CPU Cards Figure D-7: Sound Effects Properties Editor D.7 Karaoke Mode Figure D-8: Karaoke Mode ©Copyright 2007 CyberResearch, Inc.

  • Page 177: Equalizer Selection

    ® CyberResearch CPU Cards CZGG LU-10-X Series The Karaoke mode shown in Figure D-8 allows you to eliminate the vocal of the music you play or adjust the key to accommodate your range. The configuration options that come with the Karaoke function include: Voice Cancellation: This checkbox, when selected, disables the vocal part of the music your play in your computer while the background music remains.

  • Page 178: Speaker Configuration

    ® CZGG LU-10-X Series CyberResearch CPU Cards D.9 Speaker Configuration Figure D-10: Speaker Configuration In this functional window, you can configure your multi-channel speaker settings. Select the audio configuration from the No. of Speakers section on the left by clicking on one of the check circles.

  • Page 179: Speaker Test

    ® CyberResearch CPU Cards CZGG LU-10-X Series D.10 Speaker Test Figure D-11: Audio Configuration The audio configuration window in Figure D-11 allows you to test each connected speaker to see if your 4-channel or 6-channel audio operates properly. If any speaker malfunctions, you should then check the cabling or replace the malfunctioning parts.

  • Page 180: S/Pdif-In & S/Pdif-Out

    ® CZGG LU-10-X Series CyberResearch CPU Cards D.11 S/PDIF-In & S/PDIF-Out These functions are currently not supported. D.12 Connector Sensing Figure D-12: Connector Sensing Realtek ALC655 supports Jack Sensing functionality. If an audio device is plugged into the wrong connector, a warning message will display informing users to correct the physical connections.
  • Page 181 ® CyberResearch CPU Cards CZGG LU-10-X Series Figure D-13: EX Connection The “Audio Connector” column shows the settings used in the “Speaker Configuration” window. The “Current Connection” column shows the types of devices detected during test. If the result does not match the physical connection, an exclamation mark will appear. (See Figure D-14) CyberResearch, Inc.
  • Page 182 ® CZGG LU-10-X Series CyberResearch CPU Cards Figure D-14: Connector Sensing Test Result After closing the EZ-Connector screen, the following window should appear showing the latest connection status. ©Copyright 2007 CyberResearch, Inc.

  • Page 183: Hrtf Demo

    ® CyberResearch CPU Cards CZGG LU-10-X Series D.13 HRTF Demo Figure D-15: HRTF Demo The HRTF window in Figure D-15 allows you to adjust your HRTF (Head Related Transfer Functions) 3D positional audio before playing 3D applications. Select a preferred Environment mode and/or different Sound and Moving Path settings.

  • Page 184: General

    ® CZGG LU-10-X Series CyberResearch CPU Cards D.15 General The general window in Figure D-16 provides information about this AC’97 audio configuration utility including Audio Driver version, DirectX version, Audio Controller, and AC’97 Codec. You may also change the language of this utility through the Language pull-down menu.
  • Page 185 ® CyberResearch CPU Cards CZGG LU-10-X Series Intentionally Blank CyberResearch, Inc. 25 Business Park Drive P: (203) 483-8815; F: (203) 483-9024 Branford, CT USA www.cyberresearch.com...

  • Page 186: Eindex

    ® CZGG LU-10-X Series CyberResearch CPU Cards Index ©Copyright 2007 CyberResearch, Inc.
  • Page 187 ® CyberResearch CPU Cards CZGG LU-10-X Series 18-bit flat panel display, 7, 13, 42, 65, 66 COM2, 16, 151, 152 24-bit flat panel display, 13, 14, 42, 65, COM4, 6 compact flash, 2, 27, 57, 69 A200, 2, 5, 7, 14, 17, 34, 36, 50, 51, 52,...

  • Page 188: Table 1-2: Technical Specifications

    ® CZGG LU-10-X Series CyberResearch CPU Cards IDE device, 68, 79 PS/2 connector, 5, 7, 24, 40, 50, 51, 97, IDE device connectors, 4, 34, 36 99, 107, 108, 152 infrared, xv, 5, 17, 39 PS/2 keyboard, 50 inverter connector, 4...
  • Page 189 ® CyberResearch CPU Cards CZGG LU-10-X Series TTL, 3, 4, 7, 13, 23, 47, 48, 65, 66, 67 VGA, xv, 3, 6, 14, 50, 51, 52, 102, 120, UART, xv, 16 ultra low voltage, 10 VGA connector, 6, 50, 51...
  • Page 190 ® CZGG LU-10-X Series CyberResearch CPU Cards ©Copyright 2007 CyberResearch, Inc.
  • Page 191 Signal connections and programming are the two most common sources of difficulty. CyberResearch support personnel can help you solve these problems, especially if you are prepared for the call.
  • Page 192 ® CZGG LU-10-X Series CyberResearch CPU Cards Intentionally Blank ©Copyright 2007 CyberResearch, Inc.
  • Page 193 CyberResearch, Inc. will, at its option, repair or replace the defective item under the terms of this warranty, subject to the provisions and specific exclusions listed herein.
  • Page 194 ® CZGG LU-10-X Series CyberResearch CPU Cards Intentionally Blank ©Copyright 2007 CyberResearch, Inc.
  • Page 196 CyberResearch, Inc. 25 Business Park Drive Branford, CT 06405 USA P: (203) 483-8815; F: (203) 483-9024 www.cyberresearch.com...

Table of Contents
