- Page 1 VPS-300D Video Presentation System Version: 1.0 Date: Nov. 3rd, 2009...
-
Page 2: Table Of Contents
Table of Contents 1. Overview ..................... 3 2. Specification ....................5 3. Quick Start ....................6 4. Client Utility ....................9 Starting Program ................. 9 Login ...................... 10 Buttons Description ................10 Start/Stop Presentation ..............11 Open Admin Web Page .............. -
Page 3: Overview
1. Overview VPS is a must-have device for your meeting room! It turns your existing "wired" projector into a "high-end wireless" projector. With the revolutionary Plug-and-Show, 4-to-1 split screen and PDA wireless projection features, VPS makes every of your presentation and meeting efficient and successful. Plug &... - Page 4 Features ■ Support Windows Vista, XP, 2000 and Mobile 5/6 ■ Plug and Show! No installation required … just plug in the accompanied token to a USB port, and hassle free presentation can be started in seconds. ■ 4-to-1 split screen projection! Turn one projector into four, increase meeting productivity right away.
-
Page 5: Specification
2. Specification Dimension 117mm(W) x 140mm(D) x 27mm(H) Weight 279g Wireless Standards IEEE 802.11g LAN Standards IEEE 802.3u Data Rate Wireless: up to 54Mbps LAN: 10/100 Mbps with auto MDI/MDIX Wireless Channels 11 (US, Canada) 13 (Europe) 14 (Japan) Protocol TCP/IP IP Configuration Automatic: DHCP... -
Page 6: Quick Start
3. Quick Start 1) Connect projector VGA cable to VPS box VGA connector and turn on projector power. 2) Turn on VPS box. ♦ When Projector shows the default menu on the screen as below, it indicates the VPS box is ready now. 3) Make sure your PC WLAN is enabled already, and connect your PC with VPS box. - Page 7 address shown on the left corner of projector screen. 5) Download the client software. Please select the” Windows Vista / XP / 2000” or ”Windows Mobile 5.0” and execute the installation program. ♦ After install the program, VPS shortcut will come out on the PC screen.
- Page 8 6) Make sure your personal firewall allows VPS software to pass through. 7) Enter the LOGIN CODE ♦ You can see the login code on the projector screen 8) Click the “Play” button to start projection!
-
Page 9: Client Utility
4. Client Utility 4.1 Starting Program After you download VPS Windows program via web page successfully, then follow below steps to start. 1) Click VPS icon to execute the program. 2) Program start to search for VPS box automatically, 3) If VPS box founded then “Login Code” dialog box will be pop up on the PC screen. -
Page 10: Login
4.2 Login 1) After “Login Code” dialog box shown, enter login code to start presentation. 2) You can see the login code shown on the projector screen. 4.3 Buttons Description 1) After login successfully, you will see main UI of VPS application. 2) Click following buttons to manipulate VPS Application. -
Page 11: Start/Stop Presentation
Project to Split #4 Pause projecting Stop projecting Refresh projecting screen Server Login Code While projecting in progress, this icon is blinking Function menu Minimize the program Exit the program 4.4 Start/Stop Presentation Click to project desktop (Full screen or split screen) Click to stop presentation. -
Page 12: Searching Server
4.6 Searching Server Click “Search Server” to search for VPS box. -
Page 13: Make Vps Token
4.7 Make VPS Token Click “Make VPS Token” to make a USB VPS Token, please follow the steps with the wizard:... -
Page 15: System Information
4.8 System Information Click “Info” to show system information. It includes product model name, IP address and other information. 4.9 VPS for PDA To project your PDA screen with VPS, please follow the steps: Enable your WiFi and connect to VPS Open the browser and enter Server IP address to download VPS client software for PDA version. -
Page 16: Exit Program
4.10 Exit Program Click to exit this program. 5. Web Management Home Page 6. Make sure your PC connect to VPS box successfully. 7. Open your browser, it will enter VPS home page automatically. 8. If not, enter your IP address on the browser, you can see the IP on the projector screen. -
Page 17: Download Software
Download Software 1. Select “Download software” function. 2. Please select the”Windows Vista / XP / 2000” or ”Windows Mobile 5.0” and execute the installation program. 3. Follow Installation Wizard instructions to proceed till the installation process complete. 4. If pop up “Windows Security Alert” because Windows firewall block this program. -
Page 18: Conference Control
Notice: When using IE8.0 version, please close the “Smart Screen Filter” under safety settings. Then re-access VPS web management again to download the driver. Conference Control 1) This function allows you to host a meeting smoothly without projector cable swapping and each participant can show their presentation easily. 2) Select “Conference Control”... - Page 19 4) After login, you can see a User List on the screen which indicates all of users connected to VPS box. 5) There are three columns, “Computer Name”, “Play Control” and “IP Address”. 6) Play Control，There are six buttons, including Play(Full) , Play Split #1 , Play Split #2 ,Play Split #3...
-
Page 20: Login Web Admin
Login Web Admin 1. Click [Admin] and then enter password to login web page. 2. The password default value is “admin”. System Status Click [System Status], shows current system status. Model Name: Product model name Versions:... -
Page 21: Network Setup
1. Firmware version no.: Product firmware version number. Network Status: 1. IP address：IP address of VPS device. 2. Subnet Mask：subnet mask 3. Default Gateway：default gateway 4. Wireless MAC address：wireless MAC address 5. Wire MAC address：wire MAC address Connection Status: 1. Projecting status: which is “Waiting for projecting” or “Projecting” 2. - Page 22 an IP address assigned to it by the server. When the VPS box is connected to a LAN that does not have a DHCP server, the VPS box becomes the DHCP server in the network. < IP Setup> ♦ You can select “obtain IP address automatically” or “Use the following address”...
-
Page 23: Projection Setup
Projection Setup Click [Projection Setup] button ♦ <Resolution>: 1024*768, 1280x768 and 800*600. ♦ <Color Depth>: provide VPS output with 16bit or 32 bit color depth. It depends on your PC settings. ♦ <Screen Refresh Rate>: This is VGA output refresh rate, provides 60 Hz and 75Hz to suit for different kinds of projectors. -
Page 24: Change Passwords
Change Passwords Click [Change Password] button, to change password value. ♦ <Enter New Password>: enter new password you want to change for each category. ♦ <Confirm New Password>: double confirm new password. ♦ <Apply>: Confirmation and Save modifications. -
Page 25: Reset To Default
Reset to Default Click [Reset to Default] button to restore factory default settings. <Apply>: Confirmation and action. *** Another way to restore Factory Default Settings, Follow below procedures. 1. Press [Reset] button and Hold. 2. Turn on VPS box. 3. Wait for over 10 seconds and relief [Reset] button. 4. -
Page 26: Firmware Upgrade
5.10 Firmware Upgrade Click [Firmware Upgrade] button to upgrade firmware. 1. Firstly, you have to get latest firmware image file from your vendor. 2. Click <Browse> to specify file name you want to upgrade. 3. Click <Upgrade> to start. 4. A warning message shown and count down counter on the screen. 5. -
Page 27: Reboot System
5.11 Reboot System Click [Reboot System] button, to restart system ♦ <Reboot>: reboot system automatically. 5.12 Logout... -
Page 28: Appendix
6. Appendix Accessories 1 VPS-300D 2 VPS-300D Antenna 3 USB Token 4 Adaptor DC 5V, 2.5A 5 Mounting Bracket 6 Bracket Fix Screws 4PCS 7 Mounting Screws 2PCS Packaging Specification Dimension 155mm(W) x 195mm(D) x 110mm(H) Weight 900g... -
Page 29: Wall Mounting Instruction (Optional)
Wall Mounting Instruction (Optional)
