Led Indicators And Control - Svec FD815 User Manual

Emission
Rich LED Indicator
Control DIP switch
Operating Temperature
Operating Humidity
Dimension
Weight
Power Supply
The Front Panel
The front panel of the switch is shown as below
The Rear Panel
The rear panel of the switch is shown as below
Control DIPswitch
Latched during hardware reset.
PIN 1 Control the HOME VLAN topology type:
OFF:Select 14VLANs(port#1~14) with 2 overlapping
ON :Select 15 VLANs(port#1~15) with 1 overlapping
FCC Class A, CE
System: Power, Trunk
Port: Link/Activity and Speed
Latched during hardware reset.
Control port Trunking, Port based
HOME VLAN and 2-level QoS functions.
°
0-50 C (32-122 F)
%
10 ~90 (non-condensing)
200 x138 x 40mm
700g
3.3VDC, 3A(external power adaptor)
ports (port#15,16) topology(default)
port (port#16) topology
