Summary of Contents for Proview JK-195XU

  • Page 2 ENGLISH FEDERAL COMMUNICATIONS COMMISSION (FCC) STATEMENT Th i s equ ipm en t h as be en t es ted an d f ound to comply wi th the limits of a c lass B digit al devi ce. Pu rs uan t to Part 15 of the FC C Rules . Thes e l imi ts ar e design ed t o pr ovid e reas on abl e p rotecti on agains t har mful int erfer ence in a r es id ential i n s tall at io n.
  • Page 3 ENGLISH IMPORTANT SAFETY INSTRUCTIONS WARNING To reduce the risk of fire or electric shock, do not expose this equipment to rain or moisture. CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO AVOID THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
  • Page 4 ENGLISH IMPORTANT SAFETY INSTRUCTIONS To prevent any injuries, the following safety precautions should be observed in the installation, use, servicing and maintenance of this equipment. Before operating this equipment, please read this manual completely, and keep it nearby for future reference. Do not place the equipment on any uneven or unstable carts, stands, tables, shelves etc..
  • Page 5 ENGLISH IMPORTANT SAFETY INSTRUCTIONS Do not attempt to service the equipment yourself. Opening and removing the covers may expose you to dangerous voltage or any other hazards and may void your warranty. Refer service from qualified personnel. Do not place or drop any other objects on top. Do not insert anything into the ventilation holes of your equipment.
  • Page 6 ENGLISH ANTENNA CONNECTION EXAMPLE OF OUTDOOR ANTENNA GROUNDING If an outdoor antenna is connected, follow the precautions below: An outdoor antenna should not be located anywhere that can be in contact of overhead power lines, or any other electric light or power circuits.

  • Page 7: Note To Catv System Installer

    ENGLISH ANTENNA CONNECTION Cable TV (CATV) Connection NOTE TO CATV SYSTEM INSTALLER T h i s r e mi n d e r i s p r o v i d e d t o c a l l t h e C AT V s y s t em i ns t a lle rs a t t en t io n t o A rt ic le 8 20- 40 o f th e Nati o n a l E l e c t r i c a l C o d e ( N E C ) t h at p r o vid es g u id e lin es f o r p ro p e r g ro u n d in g an d, i n p art i c u l a r, s p e c i f i es t h a t t h e c a b l e g ro u n d s ha ll b e co n n ec t e d t o t he g ro u n d in g s ys t e m o f th e b u i l d i n g a c c u r a t e l y, o r a s c l o s e t o t h e p o in t o f c a b le en t ry a s p o s s ib le .
  • Page 8 ENGLISH ANTENNA CONNECTION ANTENNAS The antenna requirements for good color TV reception are more important than those of a black & white TV reception. For this reason, a good quality outdoor antenna is strongly recommended. The following is a brief explanation of the type of connection that is provided with the various antenna systems.

  • Page 9: Table Of Contents

    ENGLISH CONTENT PREPARATION ....................9 Features ................................9 Package Contents ............................10 LCD TV ................................. 11 Front View ..............................11 Rear View ..............................12 Remote Control ..............................13 Using your LCD TV............................15 INSTALLATION ...................... Connecting a TV Cable or an Antenna ......................16 Connecting a DVD Player ..........................

  • Page 10: Preparation

    ENGLISH PREPARATION Congratulations on the purchase of your new High Def inition Compatible Television. In order to maximize the potential of this television, you must use it in conjunction with a High Def inition Signal Source, utilizing a proper High Def inition receiving unit (of ten referred to as a “set-top”...

  • Page 11: Package Contents

    ENGLISH Package Contents Once you open the box, make sure all of the following contents are included. If you’re missing any items, please return this product to the original place of purchase. LCD TV Remote control/ Video Cable Audio Cable AAA batteries Power Cord User Guide...

  • Page 12: Lcd Tv

    ENGLISH LCD TV Front View PHONES VOL. VOL. MENU SOURCE ITEM DESCRIPTION 1 IR Infrared Receiver (IR) 2 POWER Turns the LCD TV on and off. The LED light indicates when the LCD TV 3 LED is activated (green light indicates on and amber indicates off). 4 SOURCE Chooses from different input signal sources.

  • Page 13: Rear View

    ENGLISH LCD TV Rear View ITEM DESCRIPTION 1 AC IN Connects the AC power cord. Connects to the audio or video equipment with left and 2 AUDIO IN 1 right audio output jacks of the component (Y, Pb/Cb, Pr/Cr). Connects to the component (Y, Pb/Cb, Pr/Cr) video jacks 3 COMPONENT on your DVD player, HDT V Tuner source, or video equipment.

  • Page 14: Remote Control

    ENGLISH Remote Control POWER Turns the LCD TV on and into standby mode . Press to select PC mode. Selects the Multi-channel TV Sound. Options: Stereo, SAP , and Mono. CAPTION To select the C.C. Mode to be ON or OFF.
  • Page 15 ENGLISH Remote Control Installing the batteries in your remote control Pull the tab of the back cover and pull up on the cover to open the batter y compar tment of the remote control. Inser t two A A A size batteries. Make sure to match the (+) and (-) ends of the batteries with the (+) and (-) ends indicated in the batter y compar tment.

  • Page 16: Using Your Lcd Tv

    ENGLISH Using your LCD TV You may adjust the tilt angle of the LCD TV about +15 deg. / -0 deg. Always turn the LCD T V off when the LCD T V is not in use for a long period. The Power button is only used for switching the LCD T V into standby mode, it does not disconnect the device from the main power source.

  • Page 17: Installation

    ENGLISH INSTALLATION Refer to the owner’s manual of the external equipments to be connected. When connecting external equipments, do not connect any AC power cords to wall outlets until you have completed all the connections. Connecting a TV cable or Antenna Basic Connection: Connecting cable or an antenna .

  • Page 18: Connecting A Dvd Player

    ENGLISH Connecting a DVD Player For best picture quality, if your equipment has (Y Pb/Cb Pr/Cr) video output, please use component cable instead of a standard video or S-video cable. METHOD A (AV) Use a Component cable to connect the Y/Pb(Cb)/Pr(Cr) jacks on the DVD player to your LCD TV.

  • Page 19: Connecting A Vcr & A Video Camera

    ENGLISH Connecting a VCR & a Video Camera METHOD A (AV) Use an Audio cable to connect the VCR’s/ VIDEO CAMERA’s audio output jacks to your LCD TV. Use a S-Video cable to connect your LCD TV and VCR player/ VIDEO CAMERA. METHOD B (AV) Use an A/V cable to connect the VCR’s/ VIDEO CAMERA’s composite output jacks...

  • Page 20: Connecting A Tv Box And Satellite Receiver

    ENGLISH Connecting a TV Box and Satellite Receiver METHOD A (AV) Use a D-SUB cable to connect the TV Cable Box D-SUB connector to your LCD TV. Use an Audio cable to connect the TV Cable Box and your LCD TV. METHOD B (AV) Use a component cable to connect the Y/Pb(Pb)/Pr(Cr) jacks on the satellite receiver to to your LCD TV.

  • Page 21: Using The Features

    ENGLISH USING THE FEATURES Basic Operation Turning the TV On and Off After connecting a CATV / antenna to your LCD TV, and connecting the unit to a power source, an amber LED light indicates the LCD TV is activated. Press the button, the LED green light indicates on.

  • Page 22: Osd Menu Operation

    ENGLISH OSD Menu Operation The main menu provides access to the following menus: Video Adjust picture setting such as brightness, contrast,saturation and color temp. Audio Adjust sound option and effects. Parental Allows you to set up the TV to block programs according to their content and rating levels.

  • Page 23: Audio

    ENGLISH Video OPTION DESCRIPTION Color Temp. Standard: Select to give the white colors a neutral tint. Warm: Select to give the white colors a reddish tint. Cool: Select to give the white colors a bluish tint. Advanced Auto : Allows you to select the image auto adjust to be Yes or No.

  • Page 24: Parental

    ENGLISH Parental The Parental settings allows you to set up the TV to block programs according to their content and rating levels. OPTION DESCRIPTION Enter PIN You can set up the TV to block program by entering your four digit password.(The default factory password is “1111”.) After enter the correct PIN , the Parental Controls menu will display “Correct PIN”...

  • Page 25: Setup

    ENGLISH Parental OPTION DESCRIPTION Movie Rating Allows you to select the Block MPAA Unrated to be OFF or General Audiences. Movie is appropriate for all ages. Parental Guidance Suggested. May contain material not suited for younger viewers PG 13 Contains content that may not be appropriate for viewers under the age of 13.
  • Page 26 ENGLISH Setup 3. to begin auto search. 4. auto search completed. All receivable stations are stored. OPTION DESCRIPTION Channel Allows you to select the tuner input source to be System Air, Cable-STD, Cable- HRC or Cable -IRC. Channel Allows you to edit the channel name.
  • Page 27 ENGLISH Setup OPTION DESCRIPTION Sleep Time Sets up a certain time to shut off automatically: OFF/15/30/45/60/90/120 minutes. Reset Allows you to restore the factory settings. CC Mode Allows you to select the CC mode to be CC1, CC2, CC3, CC4, TEXT1, TEXT2, TEXT3, TEXT4.

  • Page 28: Troubleshooting

    ENGLISH TROUBLESHOOTING Before consulting service personnel, check the following chart for a possible cause of the trouble you are experiencing and for a solution. PROBLEM SOLUTION TV will not turn on Make sure the power cord is plugged in. The batteries in the remote control may be exhausted. Replace the batteries.

  • Page 29: Specification

    ENGLISH SPECIFICATIONS Model PA-19JK7 Panel System 19 inch LCD panel Display Resolution 1440 pixels (horizontal) x 900 pixels (vertical) Television System NTSC Brightness 450 cd/m Contrast Ratio 500:1 Inputs/Output Composite Video In S-Video In PC Audio In Audio In Speaker Out 3 W+3 W Power Source(MAX) 100-240 V~, 50/60 Hz, 50 W...
  • Page 30 ENGLISH Display Mode For the display modes listed below, the screen image has been optimized during manufacture. VGA TIMING Dot X Line Horizontal Frequency(kHz) Vertical Frequency(Hz) 640 x 480 31.46 59.94 640 x 480 37.86 72.80 640 x 480 37.50 75.00 720 x 400 31.46...
