(2) FRONT PANEL SECTION
LCD901
60
TE
L 13942296513
52
51
Ref. No.
Part No.
51
3-040-980-01 BUTTON (SOURCE)
52
3-040-981-11 KNOB (VOL)
53
3-041-005-11 BUTTON (D)
54
3-040-989-01 BUTTON (OPEN)
www
55
3-037-267-01 SPRING (OPEN)
56
3-040-987-01 BUTTON (OFF)
57
3-040-988-01 BUTTON (1-6)
.
58
3-040-985-11 BUTTON (DIR/ENTER)
59
3-040-986-01 BUTTON (MENU/SOUND)
* 60
3-040-997-01 PLATE (LCD), GROUND
http://www.xiaoyu163.com
not supplied
(KEY board)
64
63
62
61
59
56
67
Description
x
ao
u163
y
i
http://www.xiaoyu163.com
2 9
8
66
Q Q
3
6 7
1 3
1 5
58
55
54
53
Remark
Ref. No.
Part No.
* 61
3-041-371-02 SHEET (REFLECTOR)
* 62
3-040-993-01 PLATE (LCD), LIGHT GUIDE
63
1-694-660-11 CONDUCTIVE BOARD, CONNECTION
* 64
3-040-992-01 HOLDER (LCD)
65
X-3378-398-1 PANEL ASSY, FRONT BACK
co
66
3-045-596-01 CUSHION (OFF)
67
X-3378-578-1 PANEL SUB ASSY (4950X)
.
67
X-3378-579-1 PANEL SUB ASSY (4954X)
LCD901 1-803-907-41 DISPLAY PANEL, LIQUID CRYSTAL
9 4
2 8
#6
65
0 5
8
2 9
9 4
2 8
57
Description
m
9 9
#6
9 9
Remark
33
