Table of Contents ....................4 OPYRIGHT ................4 EGULATORY TATEMENT Federal Communications Commission Statement ......................4 Declaration of Conformity ............................... 4 RF exposure warning................................ 5 European Notice ................................5 R&TTE (CE) MANUAL REGULATORY REQUIREMENT (WLAN - IEEE 802.11b/g)..........5 Canadian Department of Communications........................6 Battery Disposal................................ - Page 3 ................27 SING THE EMORY ARDS Inserting a Memory Card ...............................27 Removing a Memory Card .............................27 MAKING CONNECTIONS ............28 ............28 ONNECTING XTERNAL ISPLAY EVICES Connecting a Projector or Display Monitor .........................28 Connecting a TV ................................28 USB D ................
-
Page 4: Copyright
Preface Copyright © Copyright 2013. All rights reserved. No part of this user manual may be transmitted, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, without the prior written permission of the manufacturer. Information is subject to change without prior notice. -
Page 5: Rf Exposure Warning
Preface RF exposure warning This equipment must be installed and operated in accordance with provided instructions and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. -
Page 6: Canadian Department Of Communications
Preface Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations. Battery Disposal THIS PRODUCT CONTAINS A LITHIUM-ION OR NICKEL-METAL HYDRIDE BATTERY. IT MUST BE DISPOSED OF PROPERLY. CONTACT LOCAL ENVIRONMENTAL AGENCIES FOR INFORMATION ON RECYCLING AND DISPOSAL PLANS IN YOUR AREA. -
Page 7: Safety Instructions
Preface Safety Instructions DO NOT block the opening vents provided for ventilation. Blocking these vents may cause the notebook processor to overheat. Always keep strong magnetic or electrical objects away from your notebook. DO NOT use or store your notebook in extreme temperatures. DO NOT place your notebook near fire or other sources of heat. -
Page 8: Caution For Adapter
Preface DO NOT attempt to service your notebook yourself. Any attempt to do so will make the warranty invalid. When servicing, refer to qualified service personnel. For better environmental protection, waste batteries should be collected separately for recycling or special disposal. CAUTION FOR ADAPTER THIS NOTEBOOK IS FOR USE WITH DEDICATED AC ADAPTER. -
Page 9: Before You Start
Before You Start Before You Start Congratulations on your purchase of this notebook. This business notebook is portable and suits a wide-range of user requirements, providing users with maximum computing experience. Before you begin using your notebook, read this chapter to familiarize yourself with the main components installed in the system. ... -
Page 10: Features
Before You Start Features Intel HM75 platform (Optional HM77 with i-core CPU) ® Operating system supports Microsoft Windows 7 12.1” convertible LCD display High capacity hard disk drive Light weight Spill Proof Intel WLAN capability ... -
Page 11: Components
Before You Start Components Front View Item Description Camera Use to take picture, record videos, or video conference. -
Page 12: Brightness Control
Before You Start Item Description Brightness control Press to increase the LCD panel brightness by one button level. Brightness control Press to decrease the LCD panel brightness by one button level. SAS button Press to exit Windows and switch to Standby mode. -
Page 13: Left View
Before You Start Left View Item Description USB port Connects USB peripheral devices. Card reader Use to insert memory cards to transfer pictures, music, and data between your notebook and flash compatible devices. The card reader supports SD (Secure Digital), SDHC, Mini-SD (with adapter), MMC (Multi-media card), MMC+, Mini-MMC (with adapter) cards. -
Page 14: Back View
Before You Start Back View Item Description Kensington lock slot Connects to a Kensington-compatible notebook security lock. VGA port Connects to a display device. (e.g. external monitor, LCD projector). LAN (RJ-45) port Connects to a local area network (LAN) using an Ethernet cable. -
Page 15: Bottom View
Before You Start Bottom View Item Description Docking station port* Connects the notebook to a docking station. Modular I/O port Use for user changeable modular I/O bay to bays accommodate various devices applications. -
Page 16: Status Indicators
Before You Start Status Indicators The status indicators in the upper left corner of the keyboard light up when a particular function of the notebook is active. Each indicator is marked with a symbol. Icon Item Description The LED always lights on (blue) when the... -
Page 17: Getting Started
Getting Started Getting Started This chapter will guide you on how to use your notebook. Powering Up Your Notebook Your notebook can be powered up using the AC adapter or the Lithium-ion battery. Connecting the AC Adapter The AC adapter powers up your notebook and charges the battery. 1. -
Page 18: Installing The Battery
Getting Started Installing the Battery To install the battery, follow the steps below: 1. Slide and hold the battery latch to the unlock position. 2. Align and insert the battery to the battery compartment. 3. Push completely until the battery locks into place. 4. -
Page 19: Removing The Battery
Getting Started Removing the Battery To remove the battery, follow the steps below: 1. Slide and hold the battery latch to the unlock position. 2. Remove the battery out of the battery compartment. Starting Your Notebook Using the Display Panel •... -
Page 20: Turning On Your Notebook
Getting Started • To switch to tablet mode operation, twist the LCD panel 180°, then place it back on the notebook chassis. Lock the chassis latch to secure the LCD panel. Turning On Your Notebook Press the button until the Power LED lights up. ... -
Page 21: Changing The Display Orientation
Getting Started Changing the Display Orientation You can rotate the display orientation to suit your preference. Press the button repeatedly to rotate the display 90°, 180°, and 270° clockwise. Shutting Down Your Notebook It is important to properly shut down your notebook to avoid the loss of unsaved data. -
Page 22: Using The Keyboard
Getting Started Using the Keyboard Keys Description These function keys are used to perform designated tasks. Function keys The tasks for each key may vary from one application to another. Press the [Fn] key in combination with other keys to [Fn] execute a command. -
Page 23: Using The Touch Pad
Getting Started Using the Touch Pad The touch pad is a cursor-pointing device that provides all the features of a two- button mouse. Its primary function is to move the cursor around the screen. You can also point, select, or drag items or objects on the screen. Main touchpad Left button Right button... -
Page 24: Using The Stylus
Getting Started Using the Stylus This notebook comes with an integrated stylus for accurate control input to the LCD touch panel and digitizer. You can use the stylus to point, select, or drag items or objects on the screen. To use the stylus, simply remove it from the back of the notebook. - Page 25 Getting Started 3. Tap Calibrate. 4. Follow the on-screen instructions to complete screen calibration. 5. After calibration process is complete, tap Yes to save the calibration data. 25 ...
-
Page 26: Using The Quick Menu
Getting Started Using the Quick Menu Press the button to enter the Quick menu. Tap on the icon to enable the respective function including wireless network, Bluetooth, Tap the icon to 3G, GPS, and set up the media file airplane mode. -
Page 27: Using The Memory Cards
Getting Started Using the Memory Cards Your notebook supports different types of memory cards to provide faster data transfer. Supported types are as follows: SD card SDHC card Mini-SD card (with adapter) MS card (Memory Stick/PRO) ... -
Page 28: Making Connections
Making Connections Making Connections This chapter will guide you on installing peripheral devices to maximize the use of your notebook. Connecting External Display Devices You can connect your notebook to other display devices, such as a projector, another display monitor, or a TV. Your notebook is equipped with a VGA port which provides both digital and analog video signals. -
Page 29: Connecting Usb Devices
Making Connections Connecting USB Devices You can connect your notebook to other USB devices, such as a mouse, keyboard, digital camera, printer, or an external hard disk drive. 1. Open the I/O port cover. 2. Connect one end of a USB cable to the USB port of your notebook. 3. -
Page 30: Connecting Headphones
Making Connections Connecting Headphones You can connect your notebook to a headphone or external speakers. 1. Open the I/O port cover. 2. Plug the audio jack of the headphone or speakers to the Headphone jack of your notebook. NOTE The headphone is not included in the package. It is sold separately. Connecting External Microphone You can connect your notebook to an external microphone. -
Page 31: Connecting To A Local Area Network (Lan)
Making Connections Connecting to a Local Area Network (LAN) You can connect your notebook to a local area network (LAN) using the RJ-45 LAN port. 1. Open the I/O port cover. 2. Connect one end of an RJ-45 cable to the LAN port of your notebook. 3. -
Page 32: Connecting To Wireless Connections
Making Connections Connecting to Wireless Connections You can connect your notebook to a wireless local area network, WWAN, Bluetooth, or GPS. Before using a wireless built-in device, you need to turn the respective built-in wireless functions on. Connecting to a Wireless Local Area Network Your notebook comes with a WLAN module. -
Page 33: Connecting To A Bluetooth Device
Making Connections NOTE Wi-Fi access requires service from a wireless service provider. Contact your service provider for more information. Actual wireless connectivity will depend on system configuration. Please contact your dealer for more information. Connecting to a Bluetooth Device Your notebook can connect and communicate with other Bluetooth-enabled devices. - Page 34 Making Connections 6. Tap on a device, then tap Next to continue. 7. Tap Close to complete the pairing connection. NOTE Most Bluetooth-enabled devices need to be paired with your notebook. The PIN you enter on the notebook must be the same PIN to be entered on the other Bluetooth device.
-
Page 35: Power Management
Power Management Power Management This chapter will guide you on how to manage the system power. Using the Power Plan To improve energy efficiency, you can use the power plan to reduce the amount of power your notebook uses, maximize the performance, or balance the two. 1. -
Page 36: Using The Power Saving Mode
Power Management Using the Power Saving Mode When you are not using the notebook, turn off the notebook or set the notebook to enter sleep mode. To set the notebook to enter sleep mode, follow the steps below: 1. Tap Start. 2. -
Page 37: Using The Bios Setup Utility
Using the BIOS Setup Utility Using the BIOS Setup Utility Your notebook has a BIOS setup utility which allows you to configure important system settings, including settings for various optional functions of the notebook. This chapter explains how to use the BIOS setup utility. BIOS Setup Menu The BIOS setup Utility allows you to configure your notebook basic settings. -
Page 38: Main Menu
Using the BIOS Setup Utility press Enter to enter into the submenu. Press Esc to return to the previous configuration page. Main Menu Display the system overview information about BIOS version, CPU features, and total memory size. You can also set the system date and time. Advanced Menu View and configure SATA mode, FAN calibration, battery calibration, wake up ... -
Page 39: Boot Menu
Using the BIOS Setup Utility Boot Menu Configure the boot type and boot, network device BBS, and hard drive BBS sequence. Security Menu Set or change the Administrator and User passwords. 39 ... -
Page 40: Save & Exit Menu
Using the BIOS Setup Utility Save & Exit Menu Save or discard the changes, or restore the default values for all setup options before leaving the BIOS Setup Menu. ... -
Page 41: Troubleshooting
Troubleshooting Troubleshooting This chapter contains a list of common problems that you might experience when using your notebook, and techniques to try and overcome the problem. If you need additional help, contact your retailer. Problems Solutions • Check if the power adapter is properly connected. -
Page 42: Specifications
Specifications Specifications Features Specifications Intel Ivy Bridge Intel Core i5-3427U Intel Ivy Bridge Intel Core i7-3517U Type & Speed Intel Sandy Bridge-ULV-Celeron-Dual core- 867-1.3GHZ-BGA-2MB Processor Install Method Power Consumption Major Chipsets Chipsets Intel HM75 (Optional HM77 with i-core CPU) Type DDR-III 1333 Two 204-pin DDRIII SODIMM sockets each... - Page 43 Specifications Features Specifications Networking Integrated Gigabit bps Ethernet devices Support PXE function One Mini Express card slot One is for WLAN (PCI-e only) © Intel WiFi Link 1000 (1x2) with PCI-e Half Wireless MiniCard form factor networking Communications ...
- Page 44 Specifications Specifications Features MIL-STD-810G, Method 516.6, Procedure Drop 4 feet high with 26 drops to 2” plywood over concrete with unit off MIL-STD-810G, Method 514.6, Procedure I, Category 24, Fig. 514.6E-1, Fig. 514.6E-2 (Non-operating) Rugged Standard Vibration ...
