- Page 1 eBuddy & User’s Manual 10262 Battleview Parkway Manassas, VA 20109 7033931940 wwwearthwalkcom...
-
Page 2: Table Of Contents
Table of Contents CHAPTER 1 GETTING STARTED Getting Started ................... 2 Inventory ..................... 3 Safety and Maintenance ..............4 Checklists ................... 5 Features ....................6 Where to Look For Information............7 Quick Start ..................8 Loading Windows ................9 Adjusting the Volume ..............10 Adjusting the Brightness .............. - Page 3 CHAPTER 3 MAKING CONNECTIONS Making Connections ................ 36 Left Side Connectors ............... 36 Right Side Connectors ..............37 Front Side Connectors ..............38 CHAPTER 4 SYSTEM SOFTWARE System Software ................40 System Recovery ................41 CHAPTER 5 POWER MANAGEMENT Power Management ................. 46 Power Saving Modes ...............
- Page 4 UL CAUTION ..................70 Canadian Department of Communications ........72 Battery Disposal................73 CAUTION FOR ADAPTER..............73 BATTERY CAUTION................. 73 CLASS 1 LASER PRODUCT ............73...
-
Page 6: Getting Started
Chapter 1 — Introduction Getting Started Congratulations on your purchase of the Notebook computer! Your new notebook features the most innovative advances in portable computing technology. It combines state-of-the-art ergonomics with sophisticated architecture to provide you with a personal computer that is compact, powerful, and easy to use. -
Page 7: Inventory
Introduction — Inventory Inventory This computer system is designed for years of productive and pleasurable computing. Use this section to keep details of your purchase. This information will be required should you need to make repairs to your notebook during the warranty period. Update this section when you add new options. -
Page 8: Safety And Maintenance
Chapter 1 — Introduction Safety and Maintenance You can use your computer under a wide range of environmental conditions. However, to ensure long use and continued high performance, consider the following factors when setting up your computer: • Follow all warnings and instructions noted in this documentation and in the Windows Help program. -
Page 9: Checklists
Introduction — Checklists • Set the computer on a flat, stable surface. To prevent damage to the computer’s hard disk drive, avoid using the computer where it will be exposed to strong vibration. Checklists After opening the package, carefully inspect the contents. If any of the items is missing or appear damaged, contact your dealer. -
Page 10: Features
Chapter 1 — Introduction Caution: When purchasing any of the accessories listed above, purchase only those accessories that are approved for use with your computer. The above accessories are proprietary items. Your system vendor can obtain these approved accessories. If you use items that are not approved for use with this computer, you may cause your computer to malfunction, or to emit or receive electro-magnetic... -
Page 11: Where To Look For Information
Introduction — Where to Look For Information Scrolling Button Comfortably scroll through documents with the ergonomically designed scrolling button. Where to Look For Information About Your Computer This User’s Manual describes the key elements of your computer. New users can find a simple step-by-step orientation in the Quick Start section of this chapter. -
Page 12: Quick Start
Chapter 1 — Introduction Quick Start Turning on the Computer for the First Time 1. Connect the AC adapter power cord to the AC adapter. 2. Connect the AC adapter to the DC power port on the right side of your computer. -
Page 13: Loading Windows
Introduction — Loading Windows Loading Windows The following section is for installing the Windows operating system only. If you are installing a different operating system, please check with your vendor for installation details. Your computer will begin loading Windows once you turn on the power. -
Page 14: Adjusting The Volume
Chapter 1 — Introduction Adjusting the Volume You can adjust the volume with the volume control knob located below the touchpad. Volume control button Alternatively, you can adjust the volume with the Windows volume control applet located on the taskbar. Adjusting the Brightness Use the following hot key combinations to adjust the LCD panel brightness:... -
Page 15: Turning Off Your Computer
Introduction — Turning off Your Computer Turning off Your Computer Turning off the computer properly is important to maintaining your computer. 1. On the Start menu, click 2. Click the radio button next to Shut Down. Shut Down in the Shut Down Windows screen, and then click If you are going to be away from the computer for a short period, there are ways of conserving power without shutting down the system. -
Page 16: Tips For New Owners
Chapter 1 — Introduction Tips for New Owners Take responsibility for backup Back up files often. Users who need to manage large amounts of data may wish to use backup devices such USB drive. If you use your notebook as a networked workstation with system backup, talk to the system administrator about backup procedures for your notebook. - Page 17 Introduction — Tips for New Owners Never take the notebook anywhere without the carrying case A broken screen or case can be costly to repair. Prevent accidents by carrying the computer in a suitable carrying case. Consider using a lock For added security, consider purchasing a Kensington lock to put into the Kensington lock hole on the left side of your computer (see Chapter 2, Left View).
- Page 18 Chapter 1 — Introduction...
-
Page 20: Getting Started
Chapter 2 — Getting Started Hardware and Software This chapter introduces the different components and controls of your notebook computer, including the hardware components, the software, and the audio and video systems. Getting Started Before you begin using your computer, read this chapter to familiarize yourself with the main components installed in the system. -
Page 21: Front View
Getting Started — Front View Front View 1. LCD release latch 9. Audio-out jack for external speakers or headphones 2. LCD panel 10. Status indicators 3. Keyboard 11. PCMCIA card slot 4. Speakers 12. LAN RJ-45 jack 5. Touchpad 13. RJ-11 jack 6. -
Page 22: Left View
Chapter 2 — Getting Started Left View 1. VGA port external video display 2. RJ-11 jack 3. LAN RJ-45 jack 4. PCMCIA card slot... -
Page 23: Right View
Getting Started — Right View Right View USB ports DVD-ROM/Combo or DVD-dual drive DVD-ROM/Combo or DVD-dual drive eject button AC-adapter port... -
Page 24: Bottom View
Chapter 2 — Getting Started Bottom View Ventilation slots SO-DIMM RAM compartment Battery Battery release button... -
Page 25: Led Status Indicators
Getting Started — LED Status Indicators LED Status Indicators The status indicators in the upper left corner of the keyboard light up when a particular function of the computer is active. Each indicator is marked with a symbol. The computer is reading information CD ROM Drive from the DVD-ROM or the Combo drive. -
Page 26: Function Keys
Chapter 2 — Getting Started Function Keys Hold the Fn key while pressing the numbered function key. Function key Description Toggles display on/off Fn + F3 Fn + F4 Suspend to RAM/HDD Fn + F5 Toggles between LCD/CRT displays Fn + F6 Decreases LCD brightness Fn + F7 Increases LCD brightness... -
Page 27: Touchpad
Getting Started — Touchpad Touchpad The touchpad is a pressure sensitive pointing device that provides all the features of a two-button mouse. Its primary function is to move the cursor around the screen. Touchpad buttons Touchpad The instructions listed below describe how to use the touchpad. 1. -
Page 28: The Dvd-Rom, Or Combo Drive
Chapter 2 — Getting Started launching programs from icons. Once you have moved the pointer over the object you wish to select, rapidly press the left button two times. This action is commonly referred to as “double- clicking” an object. Dragging There are two ways to drag: •... - Page 29 Getting Started — The DVD-ROM, or COMBO Drive Inserting a Disk 1. Press the button on the front of the drive to open the disk tray and pull the tray open. 2. Place the disk on the tray, label side up. 3.
-
Page 30: Connecting The Printer
Chapter 2 — Getting Started • Do not bend or drop the discs. • Do not place objects on top of discs. Warning: Do not insert any foreign objects into the disc tray. Do not force the tray to open or close manually. -
Page 31: Memory
Getting Started — Memory Push the button to eject the card. Installing a Card 1. The top side of a PC card is usually identified with a label. Insert the card into the slot with the label side up and the edge with pinhole contacts going in first. - Page 32 Chapter 2 — Getting Started Note: Use only 1-inch DDR SODIMM (200 pin) modules. Removing a Memory Card Turn off the computer and disconnect the AC adapter. Turn the computer upside down and lay it on a flat surface. Carefully remove the two RAM compartment cover screws and remove the RAM compartment cover.
-
Page 33: The Graphics System
Getting Started — The Graphics System Press the card downwards so that it is flat inside the compartment (4). You may hear an audible click as the latches of the connector lock the card in place. Replace the RAM compartment cover and secure it with the two screws. - Page 34 Chapter 2 — Getting Started Settings tab. The dialog box indicates the monitor resolution. 2. Use the slide bar to adjust the resolution. Normally, you should use the resolution the LCD or monitor was designed for. Note: Using a lower resolution than the screen was designed for will reduce the area of the display.
- Page 35 Getting Started — The Graphics System disable the LCD or only use the LCD. To do this you may first need to enable the multiple display settings in Windows. Open the Control Panel. Double-click Display. The Display Properties window opens. Click the Settings tab.
- Page 36 Chapter 2 — Getting Started Tip: To ensure trouble-free video output, the first time you use an external monitor, change the output in the Display Properties dialog box. After successfully switching modes, you may use the video function keys. Note: Light or dark dots may appear on the LCD due to technical limitations of LCD manufacturing.
-
Page 37: Communication Components
Getting Started — Communication Components Communication Components This system provides powerful communication functions, including built-in Fax/Modem and PCMCIA card slot. Fax/Modem A phone jack on the left side of the computer allows you to connect to the Internet to send and receive data. When used with fax software, it can be used as a fax. - Page 38 Chapter 2 — Getting Started uilt-in Wireless Local Area Network The built-in Wireless Local Area Network (WLAN) interface card can provide a quick access without using cables for the connection to the network equipments. The interface card adopts the IEEE 802.11 b/g protocol and uses the 2.4 GHz ISM electric wave frequency band as the transmission interface to set up the communications between the host computer and other computers.
-
Page 40: Making Connections
Chapter 3 — Making Connections Making Connections Your computer is equipped with a full array of ports and connectors, including standard input/output (I/O) ports for quickly and easily adding peripheral devices such as printers, keyboards, and mice. Refer to documentation included with individual devices for details on connecting these devices to your computer. -
Page 41: Right Side Connectors
Making Connections — Right Side Connectors Right Side Connectors 1. USB (Universal Serial Bus) Ports The Universal Serial Bus (USB) is the latest standard for attaching monitors, input devices, scanners, and other devices to a PC. USB devices can be chained together on a single cable. 2. -
Page 42: Front Side Connectors
Chapter 3 — Making Connections Front Side Connectors 1. Audio-out Jack Connect a stereo headset or external speakers to this jack to listen to multimedia. 2. Microphone-in Jack Connect a microphone this jack to record audio. 3.Volume Control Knob Adjust the sound volume by turning it left or right. 4. - Page 44 Chapter 4 — System Software System Software Software List Operating System Your hard drive already contains all the software you need to operate the computer. Audio and Video Drivers These utility programs and drivers are included for the PC Card drive, the sound system, and the graphics sub-system.
-
Page 45: System Recovery
System Software — System Recovery System Recovery Before you start Your system includes Recovery CD-ROMs. Follow the steps in the appropriate section below to reinstall the operating system, the system software, or add a new hard disk. • The factory has pre-partitioned your system's hard disk, so you may directly install the system software;... - Page 46 Chapter 4 — System Software Recovering Windows and Original Software If your Windows operating system is lost or damaged, use the Recovery CD (Windows). Enter BIOS setup. Set first boot device to “CD-ROM.” (See Chapter 6: BIOS Settings.) Put the Windows Recovery CD into the CD- ROM drive and reboot the computer.
- Page 47 System Software — System Recovery Partitioning the Hard Drive Hard drive is not partitioned. When the Microsoft Windows startup menu appears, select (2) Go to MS-DOS PROMPT. Press Enter to repartition your hard disk. At the A:\ prompt, type fdisk and press Enter. Note: If your computer is set to boot from the CD- ROM drive, “A”...
- Page 48 Chapter 4 — System Software Windows XP Reinstallation Enter BIOS setup. Set first boot device to “CD-ROM.” (See Chapter 6: BIOS Settings.) Put the Recovery CD for Windows XP. Disc#1 into the CD-ROM drive and reboot the computer. When the Microsoft Windows XP. Menu appears, choose option 1: Recovery CD for Windows XP.
-
Page 50: Power Management
Chapter 5 — Power Management Power Management Battery Calibration The first time you use a battery, you should calibrate it. The calibration process empties and charges the battery one time. This allows the Windows battery gauge to accurately monitor battery status. To calibrate a battery, follow these steps: 1. - Page 51 Power Management — Monitoring Battery Power Monitoring Battery Power There are two ways to monitor how much power the battery has left. 1. Click start/Control Panel/Power Options; then click Power Meter. 2. Moving the cursor to the battery icon on the taskbar is the simplest way to check on battery power status.
-
Page 52: Power Saving Modes
Chapter 5 — Power Management • Save your work, turn off the computer and replace the discharged battery with a charged battery (See Changing the Battery below). Do not restart the computer until you have connected to an AC adapter, or replaced the discharged battery with a charged battery. Battery Charging When you use the AC adapter to connect your Notebook to a power outlet, the internal battery will automatically begin to recharge. -
Page 53: Power Saving Tips
Power Management — Power Saving Tips • The computer will automatically enter suspend mode when not used for a set period of time. • Selecting the Stand by button in the Shut Down Windows dialog box. • Closing the screen cover (assuming no external monitor has been connected). -
Page 54: When To Replace The Battery
Chapter 5 — Power Management When to Replace the Battery Over time, the battery's capacity gradually decreases. We recommend that you replace your battery when you notice that it begins to store significantly less charge. Changing the Battery Change the main battery pack as follows: 1. -
Page 55: Heat Considerations
Power Management — Heat Considerations Heat Considerations The computer's processor has been specially designed to consume little power, and generates very little heat. However, working in a hot environment, or working for long periods may raise the temperature. Your computer takes the following steps to lower temperature: 1. - Page 56 Chapter 5 — Power Management...
-
Page 58: Using The Bios Setup Utility
Chapter 6 — Using the BIOS Setup Utility Using the BIOS Setup Utility Your notebook has a BIOS setup utility which allows you to configure important system settings, including settings for various optional functions of the computer. This chapter explains how to use the BIOS setup utility. -
Page 59: Navigating And Entering Information In Bios
Using the BIOS Setup Utility — Navigating and Entering Information in BIOS Navigating and Entering Information in BIOS Use the following keys to move between fields and to enter information: Select Screen Push the up and down arrow keys to move among selections, then press Enter to make a ↑... -
Page 60: The Main Menu
Chapter 6 — Using the BIOS Setup Utility The Main Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit System Overview Use [ENTER] , [TAB] Or [SHIFT-TAB] to select a field. AMIBIOS Version : R0.XX Use [+] or [-] to Build Date: 01/01/04 Configure system Time Processor... -
Page 61: Advanced Menu
Using the BIOS Setup Utility — Advanced Menu Advanced Menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Select amount Advanced Setting system memory used Graphics Mode Select [Enabled, 8MB] internal graphics Auto DIM function [Enable] device.. Legacy USB Support [Enable] Battery Learning [Enter]... -
Page 62: Boot Menu
Chapter 6 — Using the BIOS Setup Utility Boot menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Specifies the boot 1st Boot Device [CDROM: SM-QSI DVD-R] sequence from the Boot Device [HDD:PM-FUJITSU MHT2040AT] available devices. 3rd Boot Device [Network:Realtek Boot] A device enclosed in Parenthesis has been disabled in the... -
Page 63: Security Menu
Using the BIOS Setup Utility — Security menu Security menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Security Settings Install Change password. Supervisor Password : Not Installed User Password : Not Installed Change Supervisor Password Change User Password ←→ Select Screen ↑↓... -
Page 64: Exit Menu
Chapter 6 — Using the BIOS Setup Utility Exit menu BIOS SETUP UTILITY Main Advanced Boot Security Exit Exit Options Exit system setup after saving the changes. Save Changes and Exit Discard changes and Exit F10 key can be used Discard Changes for this operation. -
Page 65: Change User Password
Using the BIOS Setup Utility — Change User Password Change User Password With a User password, you can enter the Setup Utility and change or remove the User password, but you cannot enter the Setup Utility and change or remove the Supervisor password, nor enable diskette access if it has been disabled. - Page 66 Chapter 6 — Using the BIOS Setup Utility...
-
Page 68: Frequently Asked Questions
Appendix A — Frequently Asked Questions Frequently Asked Questions Q: My screen seems to time out too quickly. I have to constantly hit a key or move the mouse in order to bring it back. How can I adjust the screen time-out? This is part of Windows Power Management. - Page 69 Appendix A — Frequently Asked Questions Double click on the Speaker icon on the task bar. Then, under Microphone Balance, check the Mute box. Q: Because of a software problem, I was unable to shut down power normally. I pressed the power button to force a power off, but it didn't work.
- Page 70 Appendix A — Frequently Asked Questions Save configuration changes and exit setup? [OK] [Cancel]...
-
Page 72: Statements
Appendix B — Statements Statements Federal Communications Commission Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 73 Appendix B — Statements About The Modem This equipment complies with Part 68 of FCC rules. On the bottom of this equipment is a label that contains, among other information, the FCC registration number and ringer equivalence number (REN) for this equipment.
-
Page 74: European Notice
Appendix B — Statements The Telephone Consumer Protection Act of 1991 marks it unlawful for any person to use a computer or other electronic device, including fax machines, to send any message unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business or other entity, or other individual sending the message and the telephone number of the sending... -
Page 75: Ul Caution
Appendix B — Statements CE Declaration of Conformity Is herewith confirmed to comply with the requirements set out in the Council Directive on the Approximation of the Laws of the Member States relating to Electromagnetic Compatibility (89/336/EEC), Low- voltage Directive (73/23/EEC) and the Amendment Directive (93/68/EEC), the procedures given in European Council Directive 99/5/EC and 89/3360EEC. -
Page 76: Canadian Department Of Communications
Appendix B — Statements Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may explode. Check with local codes for possible special disposal instructions. Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations. -
Page 77: Battery Disposal
Appendix B — Statements loop may consist of any combination of devise subject only to the requirement that the total of the Load Numbers of all the devices does not exceed 100." Battery Disposal THIS PRODUCT CONTAINS A LITHIUM-ION OR NICKEL-METAL HYDRIDE BATTERY.
