- Page 1 BA165 Electronic Balance 6000g x 0.1g Impact Test Equipment Ltd www.impact-test.co.uk & www.impact-test.com User Guide User Guide...
- Page 2 Impact Test Equipment Ltd. Building 21 Stevenston Ind. Est. Stevenston Ayrshire KA20 3LR T: 01294 602626 F: 01294 461168 E: sales@impact-test.co.uk Test Equipment Web Site www.impact-test.co.uk Test Sieves & Accessories Web Site www.impact-test.com...
-
Page 3: Table Of Contents
CONTENTS INTRODUCTION....................2 LOCATING THE BALANCE ................2 TECHNICAL DATA..................... 3 INSTALLATION ....................4 INDICATORS & KEY FUNCTIONS ..............4 INTERNAL BATTERY ..................5 OPERATION....................... 5 POWER ....................... 5 WEIGHING ....................6 FUNCTION MENU ....................6 = Display Averaging Rate..............8 = Digital Filtering Selection .............. -
Page 4: Introduction
INTRODUCTION • The ADG series of precision electronic balances offers a range of capacities from 3000 grams to 10 kilograms. • The balances are very simple to use and are applicable for general weighing. The user can also use the parts counting and weighing functions for special applications. -
Page 5: Technical Data
TECHNICAL DATA SPECIFICATIONS ADG 3000 ADG 6000 ADG 10 Maximum weighing 3000g 6000g 10000g capacity (Max) Tare range - 3000g -6000g -10000g Interval d= 0.1g 0.1g 0.2g Verification scale interval Operating temperature +5ºC / 35ºC Internal Battery 12VDC, approximately 20 hours operation Power supply 14VDC, 100mA minimum Supplied from external power supply... -
Page 6: Installation
INSTALLATION • Unpack the balance carefully. • Place the rubber bumpers for the pan support on the pins then lay the pan on the supports. The spring under the permanent pan support will help eliminate static electricity that may accumulate on some samples. -
Page 7: Internal Battery
KEYS Primary Function Secondary Function Re-zeroes the display to Selects the active digit when setting [Tare] eliminate weight of containers parameters. Return to normal weighing after parts counting, check-weighing or percent weighing Sets new zero point Enters the Function Menu Selects or accepts a parameter [Func] Sends data to the RS-232... -
Page 8: Weighing
WEIGHING • If necessary press the [Tare] key to zero the display. Place the object to be weighed on the pan and read the weight after the stability indicator (STAB) is displayed. • The Zero function only operates within a narrow range (±4% of the capacity of the scale) around the original zero point. - Page 9 The following functions are available. For details on how each function is used refer to the respective sections. Set the display averaging Set the digital filtering Set the baud rate- adjustable from 300 to 9600 baud Enter parts counting function Enable check-weighing function and set the low and high limits Enter calibration mode Auto or manual print...
-
Page 10: Display Averaging Rate
= Display Averaging Rate • Select the required averaging rate for the display update. • Press the [Func] key until “ ” is displayed. • Press [Print] to view the current setting. • Press [Print] again to select the desired value. •... -
Page 11: Parts Counting Function
• Press the [Func] key until “ ” is displayed. • Press [Print] to select the desired value. 300 Baud 600 Baud = 1200 Baud = 2400 Baud " * = 4800 Baud = 9600 Baud • Press the [Func] key to return to weighing. = Parts Counting Function Parts counting function is used to display the number of items placed on the balance after a sample of the items is used to calibrate the balance. - Page 12 To achieve the best accuracy while counting: • The best accuracy is obtained with larger sample sizes. • It is possible to use a smaller sample size to determine a larger sample accurately. • If the sample items are not uniform the results may be inaccurate. •...
-
Page 13: Calibration Procedure
• The display will indicate when the weight on the scale is below the low setpoint, between or above the high setpoint. • To disable the function press [Func] until either “ ” or “ ” is displayed and then press [Tare]. = Calibration Procedure •... -
Page 14: Print When Stable Or Instantaneous
= Print when stable or instantaneous When the balance is set to manual print, i.e. = 0, it can be set to print either immediately after [Print] is pressed or only after the balance is stable after [Print] is pressed. The function can also be enabled from the RS-232 interface. See Section 7 on Communications with a Computer or Printer. -
Page 15: Automatic Power Switch Off
= Automatic Power Switch Off The ADG balance includes an internal rechargeable battery. The typical operation time using only the battery is 20 hours. The balance includes the TIME function to turn the power off after 5 minutes if the balance is not being used. -
Page 16: Newton Unit Of Weight
8.11 = Newton Unit of Weight The balance can display the unknown weight in Newtons. When Newtons are selected the “* ” legend on the display will be turned off and an arrow will be turned on under the second digit. •... - Page 17 PARAMETER The interface parameters are: 300 - 9600 Baud as selected, default 4800 baud 8 data bit No parity 1 stop bit CONNECTION Output Connector: 9 pin D-Subminiature plug Pin 2, Data to the balance Pin 3, Data from the balance Pin 5, Signal Ground Handshaking is not implemented.
-
Page 18: Error Messages
NOTE: Continuous output is not recommended when a printer is connected as often the printers cannot keep up with the number of values sent from the RS- 232 interface. The RS-232 will output about 3 lines per second at the fastest baud rate (9600 baud). - Page 19 Manufacturer’s Declaration of Conformity This product has been manufactured in accordance with the harmonised European standards, following the provisions of the below stated directives: Electro Magnetic Compatibility Directive 89/336/EEC Low Voltage Directive 73/23/EEC Adam Equipment Co. Ltd. Bond Avenue Denbigh East Estate Milton Keynes, MK1 1SW United Kingdom FCC COMPLIANCE...
- Page 20 ADAM EQUIPMENT is an ISO 9001:2000 certified global organisation with more than 30 years experience in the production and sale of electronic weighing equipments. Products are sold through a world wide distributor network -supported from our company locations in the UK, USA and SOUTH AFRICA. The company and their distributors offer a full range of Technical Services such as on site and workshop repair, preventative maintenance and calibration facilities.
