Installation and User Guide
Camera and Electronic Products for Integrators
V
™
A
P
V
™
A
P
A
D
D
I
O
U
T
O
R
E
S
E
N
T
E
R
A
D
D
I
O
U
T
O
R
E
S
E
N
T
E
R
Automated Content Presentation System
HD/SD Seamless Video Switching System with Video Transitions, Switchable PIP, Integration with the
Vaddio AutoTrak and PresenterPOD Systems, Up/Down Converting of Inputs and Outputs and Preset
PTZ Camera Control
Model Number 999-5675-000 (NTSC)
Model Number 999-5675-001 (PAL)
©2013 Vaddio - All Rights Reserved. AutoPresenter - Document Number 342-0029 Rev D

Advertisement

loading
Need help?

Need help?

Do you have a question about the AutoPresenter 999-5675-000 and is the answer not in the manual?

Questions and answers

Related Manuals for VADDIO AutoPresenter 999-5675-000

Summary of Contents for VADDIO AutoPresenter 999-5675-000

  • Page 1 ™ Automated Content Presentation System HD/SD Seamless Video Switching System with Video Transitions, Switchable PIP, Integration with the Vaddio AutoTrak and PresenterPOD Systems, Up/Down Converting of Inputs and Outputs and Preset PTZ Camera Control Model Number 999-5675-000 (NTSC) Model Number 999-5675-001 (PAL)
  • Page 2 Auto Presenter Inside Front Cover - Blank AutoPresenter Manual 342-0029 Rev D Page 2 of 28...
  • Page 3 Camera Auto-Sensing: The AutoPresenter is capable of auto-sensing each PTZ camera attached. Control codes for the following cameras are built-in:  Vaddio PowerVIEW HD-22, and HD- 30 PTZ Cameras and all WallVIEW Packages using he HD-22 or HD-30  Vaddio ClearVIEW HD-18, HD-19,HD- 20 PTZ Cameras ...
  • Page 4 Save These Instructions: The information contained in this manual will help you install and operate your Vaddio AutoPresenter. If these instructions are misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product drawings for the Vaddio product line on the Vaddio website.
  • Page 5 Unpack and identify the following parts:  One (1) AutoPresenter Enclosure and Rack Mount Ears  One (1) Vaddio PowerRite 12 VDC, 3A Power Supply  One (1) AC Cord Set (US or UK & Europe)  Documentation and Manuals AutoPresenter (Figure 2): ⑩...
  • Page 6 * The Network port will be active on a future software release. Notes:  Vaddio accessory cables for SD (NTSC or PAL composite video) and HD/SD component (YPbPr) are sold separately. (Part Number 440-5600-000)  Strain relief for the DE-15 (15-pinHD) connectors is highly recommended on the back of the AutoPresenter for permanent installations to ensure that the cables do not negatively affect the PCB.
  • Page 7 Auto Presenter AutoPresenter IR Remote Control ⑥ 1) Power: Pressing the Power button will turn the system on. Press and hold the Power button for 3 ① ⑦ seconds to turn on or off the system. 2) Transition Select: Pressing the up or down button will switch the type of transition from wipe, fade or ②...
  • Page 8 PIP to the previous size and position with a different background. AutoPresenter with Built-in PresenterPOD Support The Vaddio Presenter Pod System (consisting of the PresenterPOD and Pod Interface) is a unique presenter control device that employs three trigger outputs and an ultrasonic presenter sensor that allows any presenter to easily control the content in the meeting as well as turn On/Off the PIP video within any AutoPresenter preset.
  • Page 9 999-1111-000 PresenterPOD North America Automatic Ultrasonic Presenter Sensor and Manual Preset Trigger Device for 999-1111-001 the Vaddio AutoPresenter International Vaddio MicVIEW Microphone Switcher and Trigger Devices Part Number Description Picture 999-0001-000 MicVIEW - 12 input Mic North America Switcher/Mixer 999-0001-001...

  • Page 10: Setup And Programming

    Port 1 (i.e. if a Canon PTZ camera is connected, select CANON ONLY). Repeat the process for each port, based on the type of camera that is connected. For Vaddio PTZ cameras, select AUTO SEARCH. NOTE: If no PTZ camera is connected to specific Control Ports, select “No Camera” in the “Cam Search Menu”...
  • Page 11 Vaddio HD-18W HD PTZ Camera MicVIEW with six (6) Push to Talk Mics Vaddio Video White Board Vaddio CeilingVIEW HD Ceiling Document Camera • Video Destinations: Vaddio PreVIEW HD Dual 7.0 Rack Monitors Laptop PC - RGBHV Videoconferencing System 1280x768@60Hz Dual HD Monitors...
  • Page 12 Auto Presenter AutoPresenter Sample Configuration 2: AutoPresenter connected to Vaddio’s Precision Camera Controller via the Vaddio Link control bus and used as a Professional operator controlled system. Vaddio WallVIEW CCU H700 Camera Video, Power and Systems x 4 Control on CAT 5e Up to 500’/154.2m...
  • Page 13 – note which presets each mat will trigger. If there are additional trigger devices, such as microphones connected to Vaddio’s MicVIEW product, then make a note of which presets are assigned to which triggering device.
  • Page 14 Auto Presenter Configuring Multi-Step Presets Notes Regarding Multistep:  Multi-Step is available only on the first 12 preset trigger inputs on AutoPresenter and allows a camera preset to be programmed into the system to display two trigger devices.  If there are multiple cameras in a room and the triggers that activate Multi Step are linked to different cameras, either camera, or a different camera can be programmed as the Multi Step camera preset position to allow the camera with the best angle of view of both positions to be configured for the multi-step preset camera position.
  • Page 15 Auto Presenter Power & Preset Disable If AutoPresenter is configured to used automated, presenter controlled system, StepVIEW mats, AutoVIEW IR sensors and other devices, the mats, sensors and third-party trigger devices can be placed at locations, such podiums, white boards, etc. Pressing the Preset Disable button on the front panel or via the IR remote control will disable all trigger devices (StepVIEW mats, AutoVIEW IR sensors, etc.).
  • Page 16 Auto Presenter AutoPresenter Menu Structure: The AutoPresenter has an 8-line LCD that displays the system menus. The menus are navigated with the up/down arrows, select and cancel buttons. The menu structure is as follows: Menu Section Screen AutoPresenter V01.02.0x (software version) MAIN MENU Rescan Cameras Rescan Video...
  • Page 17 Auto Presenter Menu Structure Continued SD Video Format >Select >Letter Box >Crop >Squeeze Enables the use of some SD signals to be mixed with HD video signals while avoiding aspect ratio problems Default Preset No Default Preset Number >Select > 01 – 72 Assigns camera preset 1 through 72 as Default Preset on the default camera (default is 01) Default Timer >Select...
  • Page 18 Auto Presenter System Menu (continued) >Clear Presets >Select >Start Clears only the camera presets >Transition Time >Select >0.1 to 4.0 Seconds Allows user to adjust transition time from menu or through RS-232 (i.e. control systems) Transition Time is also adjustable from front panel and can be stored in the presets if the Transition Mode (below) is set to “By Preset”.
  • Page 19 6 presets when used with the AutoPresenter. PIP Trigger >Select >1 through 24 Allows triggers 1 through 24 to turn the PIP stored within a preset ON/OFF - for use with Vaddio PresenterPOD or other triggering device PIP Trigger Mode >Select >...
  • Page 20 This device must accept any interference including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by Vaddio can affect emission compliance and could void the user’s authority to operate this equipment. ICES-003 Compliance...

  • Page 21: Warranty Information

    Vaddio Customer service – Vaddio will test, repair, or replace the product or products without charge if the unit is under warranty and is found to be defective. If the product is out of warranty, Vaddio will test then repair the product or products. The cost of parts and labor charge will be estimated by a technician and confirmed by the customer prior to repair.
  • Page 22 All of these elements can make it tricky to set up and display/project a computer display. There are a ton of variables and not all scalers are created equal. Vaddio video switchers/mixers use the best video processors and scalers available today. Other companies do not. If you can not get a certain resolution to display correctly, simply choose a different resolution.

  • Page 23: Appendix 1: Rs-232 Control

    With AutoPresenter, all cabling configurations are home-run wiring configurations. Each Channel will auto-configure the input channel for control of the camera attached. Vaddio uses simple control protocols to accomplish custom programming with the AutoPresenter. The Communication Specification, API and Programming Language are listed below and definitions are listed on the next page.
  • Page 24 Auto Presenter Appendix 1: Continued API and Programming Language +--------------------------------------------------------------------------+ Vaddio AutoPresenter +--------------------------------------------------------------------------+ - This Menu +------------------------ System Access -----------------------------------+ |Power x- Power(On/Off) |Mix - Mix/FTB Button |Input x- Switch to Input(1-6) |Cut - Cut Button |Store x- Store Preset(1-138)
  • Page 25 Auto Presenter Appendix 1: Continued Command Structure Definitions Command Parameters Description Camera Camera [9](cr) Select indicated camera (1-6) ClearAll ClearAll(cr) Clear all presets Config Config(cr) Display system configuration Cut(cr) Select Cut Transition DspCams DspCams(cr) Display cameras connected(and Port) Home Home(cr) Home Camera IdleRtn IdleRtn [9](cr)

  • Page 26: Appendix 2: Pin-Outs Pin-Outs For Connectors On Autopresenter Video Pin-Out (Both Input And Output Connectors)

    Auto Presenter Appendix 2: Pin-Outs Pin-outs for Connectors on AutoPresenter Video Pin-out (both input and output connectors) RGBHV YPbPr Y/C & Composite Adapter Cable PN# 440-5600-000 Green Blue Red GND Pr GND Green GND Y GND Blue GND Pb GND No Pin Y - Luminance C - Chrominance...
  • Page 27 Auto Presenter Inside Rear Cover - Blank AutoPresenter Manual 342-0029 Rev D Page 27 of 28...
  • Page 28 Toll Free: 800-572-2011 ▪ Phone: 763-971-4400 ▪ FAX: 763-971-4464 www.vaddio.com ©2013 Vaddio - All Rights Reserved. Reproduction in whole or in part without written permission is prohibited. Specifications and pricing are subject to change without notice. Vaddio, ControlVIEW, TouchVIEW, Quick-Connect, StepVIEW, PreVIEW AutoVIEW, PresenterPOD, AutoPresenter, CeilingVIEW, WallVIEW, EZCamera, MicVIEW and PowerRite are registered trademarks of Vaddio.
