Alpine CDE-153BT Owner's Manual
  1. Manuals
  2. Brands
  3. Alpine Manuals
  4. Car Receiver
  5. CDE-153BT
  6. Owner's manual

Alpine CDE-153BT Owner's Manual

Cd/usb receiver with advanced bluetooth
Hide thumbs Also See for CDE-153BT:
Table of Contents

Advertisement

Quick Links

CD/USB RECEIVER WITH ADVANCED BLUETOOTH
USB RECEIVER WITH ADVANCED BLUETOOTH
Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by
registering your product now at the following address: www.alpine-usa.com/registration.
You will be informed of product and software updates (if applicable), special promotions, news
about Alpine, and entered for a chance to win prizes.
Merci d'avoir acheté ce produit Alpine. Nous vous invitons à consacrer un moment à la protection
de votre achat en enregistrant votre produit dès maintenant à l'adresse suivante :
www.alpine-usa.com/registration.
Vous serez tenu informé des mises à jour des produits et des logiciels (le cas échéant), des
promotions spéciales, de l'actualité d'Alpine, et vous aurez une chance de remporter des prix.
Gracias por adquirir este producto Alpine. Con solo unos pocos pasos podrá proteger su producto,
registrándolo a través de la siguiente dirección: www.alpine-usa.com/registration.
Recibirá información sobre nuevos productos y software, promociones especiales, novedades sobre
Alpine y participará en el sorteo de premios.
ALPINE ELECTRONICS OF AMERICA, INC.
19145 Gramercy Place, Torrance,
California 90501, U.S.A.
Phone 1-800-ALPINE-1 (1-800-257-4631)
CDE-153BT
UTE-52BT
Work s With
• OWNER'S MANUAL
Please read before using this equipment.
• MODE D'EMPLOI
Veuillez lire avant d'utiliser cet appareil.
• MANUAL DE OPERACIÓN
Léalo antes de utilizar este equipo.
R R
Alpine Tunelt App
Designed by ALPINE Japan
EN
FR
ES
68-24567Z32-A

Advertisement

Table of Contents
loading

Related Manuals for Alpine CDE-153BT

Summary of Contents for Alpine CDE-153BT

  • Page 1 • MANUAL DE OPERACIÓN Léalo antes de utilizar este equipo. Thank you for purchasing this Alpine product. Please take a moment to protect your purchase by registering your product now at the following address: www.alpine-usa.com/registration. You will be informed of product and software updates (if applicable), special promotions, news about Alpine, and entered for a chance to win prizes.
  • Page 2 ALPINE ELECTRONICS MARKETING, INC. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. ALPINE ITALIA S.p.A. 1-7, Yukigaya-Otsukamachi, Ota-ku, 161-165 Princes Highway, Hallam Viale C. Colombo 8, 20090 Trezzano Tokyo 145-0067, JAPAN Victoria 3803, Australia Sul Naviglio (MI), Italy Phone: 03-5499-4531 Phone 03-8787-1200 Phone 02-484781 ALPINE ELECTRONICS FRANCE S.A.R.L.

  • Page 3: Table Of Contents

    Adjusting the sound via the Smartphone ...20 Frequency Search Function........11 Facebook Notification Function......20 CD/MP3/WMA Receiving Notification ..........20 Displaying Notification List........21 (CDE-153BT only) SETUP Playback ..............12 Repeat and Random Play ........12 Setting ................21 General Setting .............22 Searching for CD Text ..........12 Setting the AUX SETUP mode........22...
  • Page 4 Application Setting (APP) ......... 23 Voice Control Operation ........28 Setting the communication mode with a Call waiting function ...........28 Smartphone (ALPINE APP)........23 Preset a number in the Phone Menu Setting the TTS (Text To Speech) volume..23 (Shortcut dial) ............28 Dialing the preset number........29...
  • Page 5 Contents ENGLISH SiriusXM Satellite Radio Operation Installation and Connections (Optional) WARNING ............ 46 Receiving Channels with the SiriusXM CAUTION............46 Tuner................36 SiriusXM Setting ............36 PRECAUTIONS ..........46 Managing Artist and Song Alerts....36 Installation ..............47 Setting the Favorite Sports Team Alerts ..37 Removal ..............47 Setting the Parental Control ......

  • Page 6: Operating Instructions

    If you have problems, do not attempt to repair the unit yourself. result in fire, etc. Return it to your Alpine dealer or the nearest Alpine Service Station for servicing. KEEP SMALL OBJECTS SUCH AS BATTERIES OUT OF THE REACH OF CHILDREN.
  • Page 7 We remove the bumps, rub the inside edge of the hole and outside edge recommend not using these accessories on discs played in Alpine of the disc with a ballpoint pen or other such instrument, and then CD players.
  • Page 8 • Pandora, the Pandora logo, and the Pandora trade dress are trademarks or registered trademarks of Pandora Media, Inc., used Alpine accepts no responsibility for lost data, etc., even if data, with permission. Pandora is currently available in the U.S., etc., is lost while using this product.

  • Page 9: Getting Started

    *5 Displayed only when BT IN is set to ON, refer to “Setting the BLUETOOTH Connection (BT IN)” on page 25. *6 Not displayed when ALPINE APP is set to OFF, refer to “Setting the communication mode with a Smartphone (ALPINE APP)”...

  • Page 10: Initial System Start-Up

    Initial System Start-Up Controllable with Remote Control This unit can be controlled with an optional Alpine remote control. For details, consult your Alpine dealer. Be sure to press the RESET switch when using the unit for the first time, Point the optional remote control transmitter at the remote control sensor.

  • Page 11: Radio

    Presetting Stations Automatically Radio Press BAND repeatedly until the desired radio band is displayed. Rotary encoder  /ENTER /SOURCE Press and hold TUNEA.ME for at least 2 seconds.  The frequency on the display continues to change while the automatic memory is in progress. The tuner will automatically seek and store 6 strong stations in the selected band.

  • Page 12: Cd/Mp3/Wma (Cde-153Bt Only)

    Repeat and Random Play CD/MP3/WMA (CDE-153BT only) During playback, Press z 4 or x 5 repeatedly until the setting appears. RPT ONE: Track/file is played back repeatedly. Rotary encoder RPT FOLDER  /ENTER Files in a folder are played back repeatedly.

  • Page 13: Folder/File Name Search (Concerning Mp3/Wma)

    Folder/File Name Search About MP3/WMA (concerning MP3/WMA) CAUTION Folder and file names may be searched and displayed during playback. Except for private use, duplicating audio data (including MP3/ WMA data) or distributing, transferring, or copying it, whether Folder Name Search mode for free or for a fee, without permission of the copyright holder is strictly prohibited by the Copyright Act and by international treaty.

  • Page 14: Terminology

    Producing MP3/WMA discs Terminology MP3/WMA files are prepared, then written to a CD-R or CD-RW using CD-R writing software. A disc can hold up to 509 files/255 folders. Playback may not be performed if a disc exceeds the limitations Bit rate described above.

  • Page 15: Sound Setting

    Sound Setting Sound Setting You can flexibly customize the unit to suit your own preference and usage. From the AUDIO SETUP menu, Audio Setting can be modified. AUDIO/SETUP Rotary encoder Use steps 1 to 5 to select the category you wish to modify. For ...

  • Page 16: Setting Bass Engine Sq On/Off

    Adjusting the Parametric Equalizer Curve Setting contents: (9BAND P-EQ) −14 dB ~ +14 dB * CDE-153BT only. You can modify the Equalizer settings to create a response curve more appealing to your personal taste. Adjusting the High Pass Filter After selecting a BAND (BAND1 ~ BAND9) from the 9BAND...

  • Page 17: Adjusting The Low Pass Filter

     USB  iPod  BT AUDIO  PANDORA  AUX The speakers are driven by the built-in amplifier. * Be applied for MP3/WMA files in disc. (CDE-153BT only) OFF: Use this mode when the line output of this unit is used to drive an Turn the Rotary encoder to select the Media Xpander external amplifier.

  • Page 18: Bass Engine Sq Function

    BASS ENGINE SQ Function Other Functions With the BASS ENGINE SQ function on this unit, several parameters affecting Bass performance are adjusted simultaneously. The Bass Level /SOURCE Rotary encoder adjustment varies these parameters uniformly for optimum Bass effect  /ENTER/OPTION at different levels.

  • Page 19: About "Text

    *6 Refer to “Setting the Media Xpander mode” on page 17. *7 PLAY MODE can be selected in this mode. For details, refer to “Playing MP3/WMA Data (PLAY MODE) (CDE-153BT only)” on page 22. *8 Refer to “Setting the iPod Control” on page 31.

  • Page 20: Applying Tuneit

    Google Play. For details, consult your Alpine dealer. the TTS (Text To Speech) volume” on page 23. Before these operations, set ALPINE APP to USB or BT depending on LIKE: The Smartphone feedbacks to Facebook with “Like”, the connected Smartphone.

  • Page 21: Displaying Notification List

    TUNER FREQ  FM SET iPod: iPod LIST APP: ALPINE APP  TTS VOLUME *1 Refer to “Sound Setting” on page 15. *2 Refer to “SiriusXM Setting” on page 36. *3 Refer to “BLUETOOTH SETUP” on page 25. *4 Refer to “Setting Time” on page 10.

  • Page 22: General Setting

    Playing MP3/WMA Data (PLAY MODE)  Setting item: DIMMER (CDE-153BT only) Setting contents: This unit can play back CDs containing both CD and MP3/WMA data DIM MANUAL / DIM AUTO (Initial setting) (created in Enhanced CD (CD Extra) format).

  • Page 23: Scroll Setting (Textscroll)

    When the display is filled, it is cleared and the remaining words are displayed the same way until all words of the title have been shown. Set ALPINE APP to USB when an iPhone is connected, or set to BT when an Android Smartphone is paired. Tuner Setting ...

  • Page 24: Bt Hands Free Calling

    Connect an iPod/iPhone to this unit’s USB port. is not guaranteed. For handling of the BT compatible device, consult your ALPINE dealer or ALPINE website. Turn the Rotary encoder to select “PAIR YES”, and then • Depending on the surroundings, BLUETOOTH wireless connection press ENTER.*...

  • Page 25: Bluetooth Setup

    BLUETOOTH SETUP Auto pair when an iPod/iPhone is connected to this unit via the USB port. Note The following steps 1 to 5 are common to the various BLUETOOTH • USB Auto-Pairing cannot take place if either device has been paired functions.

  • Page 26: Sound Auto Setting (Type Set)

    MIC GAIN: Setting the Phone Book Manual Update ON/OFF −5 dB ~ +5 dB (MANUAL) Sound Auto setting (TYPE SET) When you select UPDATE YES in this step, the phone book will be updated immediately regardless if the Auto update function is on or off. Depending on your calling environment, choose one of the settings Setting contents: below which gives the best sound quality.

  • Page 27: Displaying The Firmware Version

    The outgoing method list is displayed. For information to update your BLUETOOTH firmware, please visit your local Alpine website or choose your country from Alpine home Turn the Rotary encoder to select the outgoing mode. page (http://www.alpine-usa.com). Setting contents: DIALED / RECEIVED / MISSED / PHONE BOOK ...

  • Page 28: Dialing A Number In Incoming Missed Call History

    Dialing a Number In Incoming Missed Call • Press  in step 3 or 4 to delete the current entry and return to the previous step. History • You can search for a name by its first letter, first two letters or first three letters.

  • Page 29: Dialing The Preset Number

    Notes BLUETOOTH Audio Operation • If the name has several numbers registered in the phone book, press ENTER after selecting the name. Turn the Rotary encoder to choose the desired number. Press and hold any one of the preset With a Bluetooth compatible Smartphone or music player, it’s possible to buttons (1 through 6) for at least 2 seconds.

  • Page 30: Flash Memory (Optional)

    • This unit plays back files in Flash Memory with the same controls and modes used for playback of CDs containing MP3/WMA. For details, refer to “CD/MP3/WMA (CDE-153BT only)” on page 12. • Before disconnecting Flash Memory, be sure to change to another source or set to pause.

  • Page 31: Setting The Ipod Control

    iPod nano (4th generation): Ver.1.0.4 • An episode may have several chapters. The chapter can be changed by pressing  or . iPod classic (120 GB): Ver.2.0.1 iPod touch (1st generation): Ver.3.1.3 iPod nano (3rd generation): Ver.1.1.3 Searching for a desired Song iPod classic (80 GB, 160 GB): Ver.1.1.2 •...

  • Page 32: Direct Search Function

    • If no operation is performed for 60 seconds, the search mode is canceled. Select Playlist/Artist/Album/Genre/ • In the search mode, pressing t will return to the previous mode. • When search is made during M.I.X. play, the M.I.X. play mode will be Composer/Episode canceled.

  • Page 33: Random Play Shuffle (M.i.x.)

    Random Play Shuffle (M.I.X.) Displaying the Text The Shuffle function of the iPod/iPhone is displayed as s on this unit. You can display the tag information of a song in the iPod/iPhone. Press k. Shuffle Albums: The songs on each album are played back in the order they were Each press changes the display.

  • Page 34: Pandora ® Internet Radio (Optional)

    ® • Pandora is available on iOS and Android OS with this unit. then press ENTER. • Before this operation, set ALPINE APP to USB or BT depending on the ® Pandora will play that station. connected Smartphone. For details, refer to “Application Setting (APP)”...

  • Page 35: Quickmix

    QuickMix Search Position Memory Use QuickMix to create a playlist based on two or more of your During playback, you can quickly return to the last-selected hierarchy ® Pandora stations. Edit your QuickMix station selections on the level in the search mode. ®...

  • Page 36: Siriusxm Satellite Radio Operation (Optional)

    Press  or  to select the desired channel. SiriusXM Satellite Radio Holding down  or  will rapidly browse through the channels. Alternatively, you can enter the number of the desired channel Operation (Optional) using the numeric keypad on an optional remote control. SiriusXM Setting /SOURCE Rotary encoder...

  • Page 37: Setting The Favorite Sports Team Alerts

    A S ALERT Repeat steps 2 to 3 until the 4 digits of the passcode are This menu option allows you to enable the alerts of all sources. entered, and then press ENTER. Turn the Rotary encoder to select ON or OFF, and then press After the correct passcode is entered, the CLEAR ALL/LOCKED ENTER.

  • Page 38: Checking The Siriusxm Radio Id Number

    Checking the SiriusXM Radio ID Number Tune Scan Function To subscribe to the SiriusXM Satellite Radio service, it is necessary to While listening to SiriusXM Satellite Radio, you can scan through all the locate and identify the Radio ID of your SiriusXM Tuner. The Radio ID songs you missed from your current band of preset channels.

  • Page 39: Receiving And Tuning To An Alert

    • You can manage the stored Alert memory setting on Setup mode, for Searching by My Music details, refer to “Managing Artist and Song Alerts” on page 36. • If no operation is performed for 60 seconds, the setting mode is canceled.

  • Page 40: Using Jump Memory And Jump Recall Function

    Notes Parental Lock Function • Pressing t will return to the previous mode. • If no operation is performed for 60 seconds, the unit will return to normal mode automatically. This function can help restrict the listening of channels to children of •...

  • Page 41: Changing The Display

    Otherwise, make sure the rest of your system is properly  Content info.  Category Name  Clock  Song Title connected or consult your authorized Alpine dealer. Band/Channel Number * If there is no text information, nothing will be displayed. Basic No function or display.

  • Page 42: Mp3/Wma

    – Clean the disc. (refer to “Initial System Start-Up” on page 10) and press  again. • The disc has scratches. If the disc still cannot be ejected, consult your Alpine dealer. – Change the disc. • The pick-up lens is dirty.

  • Page 43: Indication For Ipod Mode

    Application on the Smartphone. • There are no songs in the iPod/iPhone. NO SERVICE – Download songs to the iPod/iPhone. ® • You switched CDE-153BT/UTE-52BT to Pandora mode by pressing VSOURCE with a Smartphone connected, without launching or ® installing the Pandora Application.

  • Page 44: Bluetooth Mode

    CH UNSUB • The active channel has become unsubscribed or the requested channel is not available in your subscription package. Note • The unit will revert to the previous selected channel or to channel 1 automatically. – Visit www.siriusxm.com for information on subscribing to this channel.

  • Page 45: Specifications

    • S/N: 80 dBA (reference: 1 W into 4 Ohms) Maximum Pre-Output Voltage 2 V/10 k ohms Bass ±9.1 dB at 100 Hz Treble ±9.1 dB at 10 kHz Weight 1.37 kg (3 lbs) (CDE-153BT) 1.1 kg (2 lbs. 6 oz) (UTE-52BT)

  • Page 46: Installation And Connections

    When connecting CHILDREN. the CDE-153BT/UTE-52BT to the fuse box, make sure the fuse for Swallowing them may result in serious injury. If swallowed, consult the intended circuit of the CDE-153BT/UTE-52BT has the a physician immediately.

  • Page 47: Installation

    This unit • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information. Note •...

  • Page 48: Mounting The Microphone

    Mounting the Microphone For the sake of safety, mount the microphone in the following location. • In a stable and secure location. • In a location that does not inhibit safely driving the vehicle. • Mount the microphone in a location where the driver’s voice can easily be picked up.

  • Page 49: Connections

    Connections (Pink/Black) AUDIO INTERRUPT IN To External Unit (AUX) POWER ANT (Blue) To power antenna REMOTE TURN-ON (Blue/White) To amplifier ILLUMINATION (Orange) To the instrument cluster illumination lead IGNITION (Red) Ignition Key (Yellow) BATTERY (Black) Battery (Gray) Speakers SPEAKER RIGHT FRONT Front Right (Gray/Black) (Violet/Black)
  • Page 50  Steering Remote Control Interface Connector To steering remote control interface box. You can operate this unit from the vehicle’s control unit when an Alpine Steering Remote Control Interface Box (optional) is connected. For details, contact your Alpine dealer.  MIC Input Connector To Microphone.

  • Page 51: Limited Warranty

    ALPINE ELECTRONICS OF AMERICA, INC. (“Alpine”), is dedicated to quality craftsmanship and is pleased to offer this Warranty. We suggest that you read it thoroughly. Should you have any questions, please contact your Dealer or contact Alpine at one of the telephone numbers listed below.
  • Page 52 N’oubliez pas de consacrer un moment à la protection de votre achat en enregistrant votre produit dès maintenant à l’adresse suivante : www.alpine-usa.com/registration. Recuerde que con solo unos pocos pasos podrá proteger su producto, registrándolo a través de la siguiente...
