  • Page 1 User’s Manual (4.2.0.0) Tibet System Co., Ltd.

  • Page 2: Table Of Contents

    3.6.3.2 Motion Detection------------------------------------------------------- 45 3.6.3.3 No Video Signal-------------------------------------------------------- 46 3.6.4 Schedule --------------------------------------------------------------- 46 3.6.4.1 Camera [Manual Recording]- --------------------------------------------- 47 3.6.4.2 Input---------------------------------------------------------------- 48 3.6.4.3 Schedule--------------------------------------------------------------48 3.6.5 Network---------------------------------------------------------------- 49 3.6.5.1 DVR Server----------------------------------------------------------- 49 3.6.5.2 Web Server----------------------------------------------------------- 50 3.6.5.3 Central Station-------------------------------------------------------- 50 Tibet System Co., Ltd.
  • Page 3 3.3.3 Set up ------------------------------------------------------------103 3.4 E-map ----------------------------------------------------------------------104 3.5 Event ----------------------------------------------------------------------105 3.6 Search ----------------------------------------------------------------------106 3.6.1 Save --------------------------------------------------------------------107 3.6.2 Back up -------------------------------------------------------------108 Appendix 4 Access Control DVR-----------------------------------------110 41 Configuration ----------------------------------------------------------111 3.1.1 Start ---------------------------------------------------------------97 3.1.2 Selection of Installation Method ------------------------------- Tibet System Co., Ltd.

  • Page 4: Chapter1. Hardware Specification

    CHAPTER 1 HARDWARE Specification 1.1 Product Specification Models T04 / TS04 / CS04 / CS08 / CD08 / CS16 / CD16 / LS16 / LD16 Displaying Speed 30fps(NTSC), 25fps(PAL)/ 60, 50/120, 100/120, 100/240, 200/120, 100/240, 200/480, 400/480, 400 Recording Speed...

  • Page 5: Chapter 2 Software Installation

    User’s Manual (4.2.0.0) CHAPTER 2 SOFTWARE INSTALLATION Steps: 1. Insert MagicRadar S/W. 2. Double-click “MagicRadar.English(4.2.0.0)”. Tibet System Co., Ltd.

  • Page 6: Automatic Installation

    2.1 Automatic Installation 2.1.1 Definition: It is a method to install all the relevant softwares automatically. Select “Automatic Installation” at all times unless only “MagicRadar Client” is to be installed. 2.1.2 Installation Method Selection 2.1.3 Installing Drivers Tibet System Co., Ltd.

  • Page 7: Dvr File System Installation

    Selecting “Quick Initialization” will lead to the initialization of entire disk capacity added. Otherwise, put in desirable number to initialize. Note that the number can not exceed total capacity added. Initialization process will be performed automatically. Click “Close” upon completion. Tibet System Co., Ltd.

  • Page 8: Completion & Retry

    User’s Manual (4.2.0.0) 2.1.5 Completion & Retry Retry the entire procedure if an error message is displayed. Tibet System Co., Ltd.

  • Page 9: Manual Installation

    2.2.1 Definition: It is a method to install selected softwares manually. Select “Manual Installation” only in the case of “MagicRadar Client” installation. 2.2.2 Installation Method Selection 2.2.2 Software Selection Note: The rest of the procedures are the same as “Automatic Installation”. Tibet System Co., Ltd.

  • Page 10: Remote Client Installation

    User’s Manual (4.2.0.0) 2.3 Remote Client Installation 2.3.1 Using MagicRadar S/W Double-click “magicradar(4.1.0.0).exe”. Select “Manual Installation”. Select “MagicRadar DVR Client” only. Tibet System Co., Ltd.

  • Page 11: Using Web Browser

    User’s Manual (4.2.0.0) 2.3.2 Using Web Browser 1. Type in the IP address of DVR server. 2. Log in first before downloading Remote Client Program. Tibet System Co., Ltd.
  • Page 12 User’s Manual (4.2.0.0) 3. Click the “Install Remote Client” button for downloading. 4. Downloading in progress Tibet System Co., Ltd.
  • Page 13 User’s Manual (4.2.0.0) 5. Click “Next” to proceed. 6. Select “Manual Installation. Tibet System Co., Ltd.

  • Page 14: Uninstallation

    User’s Manual (4.2.0.0) 7. Click “Next” to finish installation process. 2.4 Uninstallation Tibet System Co., Ltd.

  • Page 15: Program Execution

    User’s Manual (4.2.0.0) 2.5 Program Execution Find the icons on the desktop to execute “MagicRadar DVR” and “MagicRadar DVR Client”. Or find “MagicRadar DVR” under “All Programs”. Tibet System Co., Ltd.

  • Page 16: Chapter 3. Main System Application (Control)

    MagicRadar DVR system. To give “admin” a password and to create new users, certain configurations are required (Setup/User). Only “admin” and users with appropriate authorization have access to the Setup menu. Note: Vertual keypad is available wherever typing is required. Tibet System Co., Ltd.

  • Page 17: Exit/Logout

    To end MagicRadar DVR system, select “Exit” and type in password. 3.4 System Information Click on System Information to see DVR system information, such as OS version, CPU, RAM, HDD, IP address, DVR model and DVR software. Tibet System Co., Ltd.

  • Page 18: Control Screen

    User’s Manual (4.2.0.0) 3.5 Control Screen Date/Time User Mode Model Setup Network Adjust PTZ Adjustment Preset Camera Layout Panel Touring E-map I-phone Volume Light PTZ Control Power Camera Selection Manual Output Panel Control Status Search Tibet System Co., Ltd.

  • Page 19: Setup

    User’s Manual (4.2.0.0) 3.6 Setup 3.6.1 System 3.6.1.1 DVR Information Create a DVR name and put in admin. info. They will be displayed on outgoing e-mails. Tibet System Co., Ltd.

  • Page 20: System Time Setup

    User’s Manual (4.2.0.0) 3.6.1.2 System Time Setup By clicking System Time Setup, users can set Date and Time in DVR software. Tibet System Co., Ltd.

  • Page 21: System Power Management

    Camera 1 -> 10 sec. -> Camera 2 ->10 sec. -> Camera 3…. 3.6.1.5 E-map Click on the “E-map” button to design E-map. Click on “Open Map Image”to select an E-map image. Tibet System Co., Ltd.
  • Page 22 User’s Manual (4.2.0.0) The above is a designed E-map sample. Drag mouse to position Camera/Input/Output and design E-map. Tibet System Co., Ltd.

  • Page 23: Tv-Out

    White Camera: Not on Recording, Yellow Camera: On Recording, White Input/White Output: Not Activated, Yellow Input/Yellow Output: Activated 3.6.1.6 TV-OUT TV-OUT is a function that sends selected cameras to a call monitor (external analog monitor). Click on the “TV-OUT” button for setup. Tibet System Co., Ltd.

  • Page 24: On-Screen Display

    * Show Motion Detection Blocks: By checking it, green motion detection blocks will be displayed on camera pictures when recording schedule is set as “M” (Setup/Schedule). * Show Object Detection Blocks: By checking it, blue object detection blocks will be displayed on camera pictures. Tibet System Co., Ltd.
  • Page 25 User’s Manual (4.2.0.0) Note : One right mouse click can be a very useful tool. Manual TV-out and OSD setup can be done. Additionally, instant recording can start by one click. Tibet System Co., Ltd.

  • Page 26: Text Inserter

    * Port No.: The port number for I-Phone use has to be set up. Normally the default value is good to use. * Timeout: It indicates the maximum length of connection trial. If there is no response within the value set, call will be cancelled. Tibet System Co., Ltd.

  • Page 27: Maintenance Log

    Camera, Output, Input, Audio and Alert. All devices in each category can be set up on one same page. Modify Framerate itself :By ticking it, DVR software will automatically allocate proper frames to channels. Tibet System Co., Ltd.

  • Page 28: Camera[Motion/Object Detection/People Counting/Mosaic/Data Retain/Ptz/Access Control]

    (Caution) Under R mode at Recording schedule, this function stop recording the channel. * Pre-alarm (max. 10 sec.): Length of time to be recorded before event * Post-alarm (max. 60 sec.): Length of time to be recorded after event Tibet System Co., Ltd.
  • Page 29 [Object Detection] It is a function that marks all the changes occurred from the original scene. MagicRadar will detect new & missing objects after a certain period of time (detecting interval). Tibet System Co., Ltd.
  • Page 30 Go to the “Control Screen” and find the red-squared “Object Detection” symbol. • One click on the “View Original Frame” button will display original image set. • Click it again to reactivate the “Set Frame” button. • Tibet System Co., Ltd.
  • Page 31 It is a function that counts people coming in and out of a certain place. How to Set up: 1. Set Count Interval. 2. Set zone by dragging mouse. 3. If a directional counting is needed, select one. Tibet System Co., Ltd.
  • Page 32 [Data Retain] It is a function that retains data only for the period set. For example, if 10 days is set, MagicRadar will delete all previous data before 10 days regardless of the capacity remaining in HDD. Tibet System Co., Ltd.

  • Page 33: Ptz Camera Setup

    * Apply All: The same settings will be applied to the rest of the cameras by clicking on “Apply All”. [Preset & Touring] Either click the right mouse on camera picture or click on the Preset (Touring) button for Preset (Touring) setup and use. Tibet System Co., Ltd.
  • Page 34 User’s Manual (4.2.0.0) “Preset” is a function that enables a camera to move from one position to another automatically. [Preset] Tibet System Co., Ltd.
  • Page 35 2. Click the right mouse. 3. Name the preset. 4. Repeat the above for setting up as many as 256 presets. 5. Click the right mouse to run preset and click the “Auto” button to stop it. Tibet System Co., Ltd.
  • Page 36 6. Repeat the above to have more than 1 preset in the tour. 7. Click the right mouse to run the tour. * Dwell: The length of time that camera will pause before moving to the next preset. * Speed: Moving speed for selected preset. Tibet System Co., Ltd.
  • Page 37 User’s Manual (4.2.0.0) Tibet System Co., Ltd.
  • Page 38 User’s Manual (4.2.0.0) Advanced PTZ setup can be done by one right mouse click. Make sure that the PTZ camera to set up supports advanced PTZ control functions first. Tibet System Co., Ltd.
  • Page 39 User’s Manual (4.2.0.0) Access Control It is a function that integrates Access Control into DVR system. For Access control DVR, please refer to another document “Access control DVR”. Tibet System Co., Ltd.

  • Page 40: Output Device

    * Length of Activation: The length of output activation (1-60 sec.). * Length of Standby: The length of output deactivation until reactivation (0-60 sec.). * Apply All: The same settings will be applied to the rest of the output devices. Tibet System Co., Ltd.

  • Page 41: Input Device

    16 input devices. Simply check the boxes for use. Each and every input can be tuned independently. * Signal Types: NO: (+) & (-) detached normally NC: (+) & (-) attached normally Tibet System Co., Ltd.

  • Page 42: Audio

    (e.g.) The above selections indicate that Audio2 will record Camera3, Audio3 will record Camera5, etc. Input Gain (1-15): It is audio level control similar to volume control. Tibet System Co., Ltd.

  • Page 43: Alert

    MagicRadar DVR system is equipped with 1 alert device. Alert is the beep inside the system that sounds in the case of event. Check the box for use and select an alert mode. Length of Activation: The length of alert activation (1-60 sec.). Tibet System Co., Ltd.

  • Page 44: Event

    * Link to Output: One Input device can have as many as 8 activating output devices on activation. The above example shows that Output1 will be activated in the case of Input1 activation. * Link to Alert: Input device can also be linked to alert. Tibet System Co., Ltd.

  • Page 45: Motion Detection

    User’s Manual (4.2.0.0) 3.6.3.2 Motion Detection The same identical concepts and methods as “Input” are applied to “Motion Detection”. Tibet System Co., Ltd.

  • Page 46: No Video Signal

    Each camera can have different recording options; scheduled recording by time & day and selective recording. * R: Recording at all times * M: Recording only on motion detection * S: Recording only on sensor detection * H: Recording at all times and higher frame recording on sensor/motion detection Tibet System Co., Ltd.

  • Page 47: Camera [Manual Recording]

    Start “Manual Recording” by selecting “Recording On”. Stop “Manual Recording” by selecting “Recording Off”. Note : 1. The purple icon indicates that it is on “Manual Recording”. 2. Only ‘Admin’ can use “Manual recording”. Tibet System Co., Ltd.

  • Page 48: Input

    User’s Manual (4.2.0.0) 3.6.4.2 Input 3.6.4.3 Schedule Tibet System Co., Ltd.

  • Page 49: Network

    * Timeout: The time length of trials to connect to DVR Server from Client * Maximum Users: The maximum number of users that can be logged in remotely. * Details: It shows all the port numbers that are available to use. Tibet System Co., Ltd.

  • Page 50: Web Server

    * Note: “DVR Manager” must be installed on Central Station Server (Client). For more details, refer to Appendix 3. Type in the IP address of Central Station Server (Client with Static IP) and click on “Reported Events” for more setup. Tibet System Co., Ltd.

  • Page 51: E-Mail

    Note : Some e-mail servesr may require authentication for ID and Make sure to put in the right IP address of SMTP server. Then, click on “Reported Events” for more setup. The “Reported Events” menu is the same as Central Station. Tibet System Co., Ltd.

  • Page 52: Dial Alarm

    Type in phone (mobile) number to report. Click on “Reported Events” (same setup as Central Station) for more setup. 3.6.5.6 IP Address Setup Clicking “IP Address Setup” will open a window for Network Connections as below. Tibet System Co., Ltd.

  • Page 53: User

    Click right mouse and select Properties for IP setup MagicRadar DVR’s network functions. 3.6.6 User Users can be added, deleted or modified with different authorized access and control levels. There are no limits in the number of users created. Tibet System Co., Ltd.

  • Page 54: Chapter 4 View Log Application (Status)

    Time Set : It’s a function that enables Administrator to set time for certain users to log in only for the time allowed. CHAPTER 4 View Log Application (Status) Tibet System Co., Ltd.

  • Page 55: Screen Features

    * Delete: If clicked, only the events for a certain selected date will be deleted. * Refresh: If clicked, events will be updated. * Network Client Log : Remote login records will be also kept on DVR server. Tibet System Co., Ltd.

  • Page 56: Chapter 5 Playback Application (Search)

    Zoom: Buttons to zoom in/out Brightness: buttons to adjust brightness Contrast: buttons to adjust contrast Default: Default for Zoom/Brightness/Contrast 5.2 Search Features 2 5.2.1 Playback Clicking right mouse on Time bar for Browse… and select a folder containing backup data Tibet System Co., Ltd.

  • Page 57: Event/Object/Text/People Count Search

    Event/Object/text/People count / Access control search Move to the First Data Move to the Last Data Move1 Frame Backward Move 1 Frame Forward 5.2.2 Event/Object/Text /People Count/Access Control Search [Event Search] Click the Event/Object Search button and select “Event”. Tibet System Co., Ltd.
  • Page 58 Motion Detection Zone: Select “Set” and mark areas for object search by dragging mouse. “Clear” is used to erase certain areas inside motion detection zones. Sensitivity: Set motion detection sensitivity level. Clear All: Click on it to clear all the motion detection zones set. Tibet System Co., Ltd.
  • Page 59 Put in an item (Reference), select time period and click on “Search”, and a list with transactions will be displayed. Searched words will be retained in the combo ox in down-list format so the data can be easily shown in next serch. Tibet System Co., Ltd.
  • Page 60 Through this function, the results of people count and POS transaction can be analyzed by the hour and cameras. Select date, camera & time, and statistics will be shown as below. Statistics can also be saved as text file. Tibet System Co., Ltd.

  • Page 61: Monitoring & Searching

    It is a feature that enables user to view live video while searching recorded data. Click the right mouse and select “Monitoring On” to view live video. Click the right mouse again and select “Monitoring Off” to go back to “Search Mode”. Tibet System Co., Ltd.

  • Page 62: Bookmark & Go To

    BMP: For saving images. Watermarked images can be saved. JPEG: For saving regular still images. Quality is not as good as BMP but less HDD is used. Save in JPEG with Time Period: For scheduled save in JPEG Tibet System Co., Ltd.
  • Page 63 User’s Manual (4.2.0.0) [Save in AVI Format] Click “Start” to start saving and “Stop” to stop saving. Mute: Saving video only (no audio) High Speed: Saving in high speed Tibet System Co., Ltd.
  • Page 64 User’s Manual (4.2.0.0) Click “Start”and select “BMP” as you save images. [Save in BMP Saved images can be checked using “Watermark Format] Proofer”. [Watermark Proofer] Execute “Watermark Proofer” and check if certain saved images are forged or not. Tibet System Co., Ltd.

  • Page 65: Print

    Select time period and select channels to be saved [Save in JPEG with Time Period] in JPEG. 5.2.6 Print Click the “Print” button and follow the same printing procedure as you would normally print out documents. Tibet System Co., Ltd.

  • Page 66: Backup

    User’s Manual (4.2.0.0) 5.2.7 Backup The recorded data can be copied from the hard disk to external storage devices, such as CD-R, DVD. Back up recorded data using various backup devices. 5.2.7.1 DFS Back up Tibet System Co., Ltd.
  • Page 67 1 minute. If password is set, viewing backup data will be possible only when it is typed Backup Folder : Click the “Browse” button, select a drive to back up and enter a desired folder name. Tibet System Co., Ltd.
  • Page 68 User’s Manual (4.2.0.0) Tibet System Co., Ltd.

  • Page 69: Exe Backup

    5.2.7.2 EXE Back up Any recorded data can be saved as “.exe” file. No viewer program is required to see saved data. Note : 1. file size limited up to 1 GB. 2. 1 channel backup only. Tibet System Co., Ltd.
  • Page 70 4. Specify file size up to ONE GB. If it is larger than 1GB, multiple exe files will be created. 5. Tick the “Once Make EXE File” box to create only one file with the file size specified. 6. Double-click the exe file created to see data. Tibet System Co., Ltd.

  • Page 71: Run Cd Burner(For Non Windowsxp Users)

    1. Install bundle CD and install INCD. 3.After installing INCD, run “InCDL.exe” which is the INCD Launch Program. 4. Insert a blank RW CD and then start formatting it (If it is a brand-new one, click “Format” instead of “Quick Format”). Tibet System Co., Ltd.
  • Page 72 User’s Manual (4.2.0.0) Tibet System Co., Ltd.
  • Page 73 5. Leave the MagicRadar Program and insert the blank RW CD which has been formatted. 6. Select “Backup” and click “Next” to start. 7. Select time period & password and click “Browse” to create a folder. Tibet System Co., Ltd.
  • Page 74 User’s Manual (4.2.0.0) Tibet System Co., Ltd.

  • Page 75: Run Cd Burner(For Windowsxp Users Only)

    5.2.7.4 Run CD Burner ( For WindowsXP Users Only) Windows XP users can back up data directly in a CD without exiting the MagicRadar Program. 1. Tick the “Save in CD data of backup” box and click “Next”. Tibet System Co., Ltd.
  • Page 76 User’s Manual (4.2.0.0) Select Time Period : Specify time period and password. Select CD-RW drive. Create folder name if it should be used and click “Next”. CD information will be shown as below. Tibet System Co., Ltd.
  • Page 77 User’s Manual (4.2.0.0) Select 1 channel to back up. Identify the maximum file size indicated. An attempt to back up more than the size indicated will result in a failure. Tibet System Co., Ltd.
  • Page 78 User’s Manual (4.2.0.0) After completing back up, find the files created in the CD. Tibet System Co., Ltd.
  • Page 79 User’s Manual (4.2.0.0) 5.2.7.5 Playback 1. Click the “Start” button and run the “DVR’s Playback Program”. 2. Select a folder (subfolder) to see saved data. Tibet System Co., Ltd.

  • Page 80: Chapter 6 Remote Monitoring System (Client)

    6.1 Program Execution Double-click on the “MagicRadar DVR Client” icon on the desktop to execute Remote Monitoring System (Client). Click “Add” to register DVR servers. Note: Make sure to put the same Port No. as DVR server. Tibet System Co., Ltd.
  • Page 81 “Servers”, click on “Login” and type in password to log in. * Edit: Login info. changes can be made here. * Delete: Registered servers can be deleted with one click. Full Screen Display on Event: If checked, full screen will be displayed on events. Tibet System Co., Ltd.

  • Page 82: Remote Save And Backup

    The instant AVI file save of real time video can be done remotely. 1. Click the right mouse to start saving. 2. Click the right mouse to stop saving. Remote Backup can also be done. The same procedure is used as “DFS Backup”. Tibet System Co., Ltd.

  • Page 83: Real Time Audio

    User’s Manual (4.2.0.0) 6.3 Real Time Audio Click the right mouse and select “Enable Audio” to hear real time audio. Note: Changing “Setup” remotely can be done if remote user is “Admin” or “Admin Mode”. Tibet System Co., Ltd.

  • Page 84: Appendix 1 Pos Dvr

    User’s Manual (4.2.0.0) Appendix 1 POS DVR TABLE OF CONTENTS 1.1 Hardware Installation 1.1.1 Parts 1.1.2 Installation 1.2 Software Installation 1.2.1 Installation & Setup Tibet System Co., Ltd.

  • Page 85: Hardware Installation

    User’s Manual (4.2.0.0) 1.1 Hardware Installation 1.1.1. Parts Tibet System Co., Ltd.

  • Page 86: Part Names

    2. RS232 Serial Cable 3. RS232 Serial Cable 4. RS232 Serial Converter (9 pins into 25 pins) 5. Gender Changer 6. #1 + #4 + #5 7. DVR 8. POS Printer 9. Point of Sales (POS) Tibet System Co., Ltd.
  • Page 87 Part # 2 goes into the COM Port 1 of Part # 7. Part # 1 goes into the serial port of Part # 8. Part # 3 goes into the serial port of Part # 9. Tibet System Co., Ltd.

  • Page 88: Installation

    User’s Manual (4.2.0.0) 1.2 Software Installation 1.2.1 Installation & Setup Install “text_inserter_plugin_for_pos” on DVR Server. Click “Next” to start. Tibet System Co., Ltd.
  • Page 89 Select camera channels and click the com port buttons for serial port configuration. Make sure to select “COM1” if POS printer is connected to com port 1. The Baud rate value is normally 9600. Tibet System Co., Ltd.
  • Page 90 User’s Manual (4.2.0.0) Click “Finish” to complete. Go to “Text Inserter” in the DVR setup and choose different fonts and different display corners. Tibet System Co., Ltd.

  • Page 91: Appendix 2 I-Phone

    User’s Manual (4.2.0.0) Appendix 2 I-phone TABLE OF CONTENTS 2.1 Installation 2.2 Execution 2.3 Audio Setup Tibet System Co., Ltd.

  • Page 92: Installation

    User’s Manual (4.2.0.0) 2.1 Installation Any system used for “Two-way Communication” must have static IP and “iphone(1.0.1.0).exe” must be installed. I-phone installation, double-click “iphone(1.0.1.0).exe”. Click “Next” to start installation process and select “Automatic Installation”. Tibet System Co., Ltd.

  • Page 93: Execution

    User’s Manual (4.2.0.0) Click “Finish” to complete the process. 2.2 Execution Go to “Start”, “All Programs”, find “I-phone” and select it for execution. Find the I-phone icon at the right bottom and click it for the next step. Tibet System Co., Ltd.

  • Page 94: Audio Setup

    Leave them as they are unless other values must be used. 2.3 Audio Setup Go to “Control Panel”, ”Sounds, Speech and Audio Devices” and “Sounds and Audio Devices”. Then, go to “Audio”, “Sound playback” and click “Volume”. Tibet System Co., Ltd.
  • Page 95 User’s Manual (4.2.0.0) Recording Control should be set up this way. Tibet System Co., Ltd.

  • Page 96: Appendix 3 Mdvr

    User’s Manual (4.2.0.0) Appendix 3 MDVR Tibet System Co., Ltd.

  • Page 97: Installation

    User’s Manual (4.2.0.0) 3.1 Installation 3.1.1 Start: Click “Next” to start installation process. 3.1.2 Selection of Installation Method: Select “Automatic Installation”. Tibet System Co., Ltd.

  • Page 98: On Installing

    User’s Manual (4.2.0.0) 3.1.3 On Installing 3.1.4 Finish: Click “Finish” to complete installation. Tibet System Co., Ltd.

  • Page 99: Overveiw

    User’s Manual (4.2.0.0) 3.2 Overview Multi-site Search Exit Management Site Name Screen Mode Camera Control Setup E-Map Log in & Log Event Live Viewing Properties Tibet System Co., Ltd.

  • Page 100: Execution

    User’s Manual (4.2.0.0) 3.3 Execution 3.3.1 Properties. Click on the “Properties” button to register group and site. Registration Steps: 1. Click “Add group” to make group. One group can have up to 64 sites (cameras). Tibet System Co., Ltd.
  • Page 101 Click on the “Add site” button. 3. Type in all the required info. as below. Make sure to put in the same user and password used on DVR. 4. Repeat the above steps to register more sites. Tibet System Co., Ltd.

  • Page 102: Log In & Log Out

    User’s Manual (4.2.0.0) 3.3.2 Log in & Log out Click on the “Log in & out” button to log in. Tibet System Co., Ltd.

  • Page 103: Set

    Click on the “Setup” button to use different opions. By tickinging the box, camera name, status, and POS text will be displayed on camera picture. By ticking the box, MDVR user and password will be asked in the event of the execution of MDVR. Tibet System Co., Ltd.

  • Page 104: E-Map

    User’s Manual (4.2.0.0) 3.4.1.0 E-Map Click on the “E-Map” button to configure E-Map. To create an E-Map image, click on the right mouse and select “Open E-Map”. Only BMP file can be in use. Tibet System Co., Ltd.

  • Page 105: Event

    User’s Manual (4.2.0.0) Click on the right mouse and select “Camera Lock” to be able to position DVRs at desired locations. Click on the right mouse and select “Save Setting” to save image and camera locations. Tibet System Co., Ltd.

  • Page 106: Search

    Any DVR (camera-shaped icon) blinking in red and blue has event occurred. 3.4.2.0 Event “Event” displays all the events coming in from registered DVRs. Select a site and click on the right mouse to connect. Tibet System Co., Ltd.

  • Page 107: Save

    User’s Manual (4.2.0.0) 3.5 Search Save Backup Search Steps: 1. Select date from the calendar. 2. Select time from the time bar. 3.5.1.0 Save Image can be saved either in BMP File or in JPEG File Tibet System Co., Ltd.

  • Page 108: Back

    User’s Manual (4.2.0.0) 3.5.2.0 Backup Back up recorded data using various backup devices. If password is set, viewing backup data will be possible only when it is typed in. Tibet System Co., Ltd.
  • Page 109 User’s Manual (4.2.0.0) Tibet System Co., Ltd.

  • Page 110: Appendix 4 Access Control Dvr

    User’s Manual (4.2.0.0) User’s Manual for Access Control DVR Tibet System Co., Ltd.

  • Page 111: Configuration

    User’s Manual (4.2.0.0) 1. Configuration Diagram Client PC TCP/IP Install “access Control Cleint” TCP/IP Network Server (FP Server) TCP/IP TCP/IP 1. Install “FPServer_Setup_V2.09” 2. Install “Access control Server” Tibet System Co., Ltd.
  • Page 112 2.1 Installing FP Server Start: Click “Next” to start installation process. * Do not install “Hamster installation” For more information for “Virdi terminal Setup”, please refer “300N user’s guide and “FPS Server Program manual” 2.2 Installing ““Access control Server” Tibet System Co., Ltd.
  • Page 113 User’s Manual (4.2.0.0) 2.2.1 On Installing 2.2.2 Finish: Click “Finish” to complete installation. Tibet System Co., Ltd.

  • Page 114: Dvr Setup

    User’s Manual (4.2.0.0) 3.1 DVR setup 3.1.1 Set up. 1) Click “Access control” button in camera set up page. Tibet System Co., Ltd.
  • Page 115 User’s Manual (4.2.0.0) 1 ) Type Access control(Virdi)’s IP address. 2 ) Click “OK” to finish set up. Tibet System Co., Ltd.

  • Page 116: Access Control Search

    User’s Manual (4.2.0.0) 3.2 Access Control Search 1. Click the “access control” Search button 2. Set the time period for search. 3. Click “search”. 4. Double click the filtered data, it shows the image. Tibet System Co., Ltd.
  • Page 117 User’s Manual (4.2.0.0) 4.1 “Access Control Client” 4.1.1 Installing Start: Click “Next” to start installation process. Tibet System Co., Ltd.
  • Page 118 User’s Manual (4.2.0.0) 4.2 Execution Tibet System Co., Ltd.
  • Page 119 User’s Manual (4.2.0.0) “Access Control Client” setup 4.3.1 1. DoubleClick Access Control Client program. 2. Click “set up” button. Tibet System Co., Ltd.
  • Page 120 User’s Manual (4.2.0.0) 3. Fill out Server(DVR)’s information. 4. Type IP Address and User name / PW of DVR server. Tibet System Co., Ltd.
  • Page 121 User’s Manual (4.2.0.0) 5. Click “OK” to logon to DVR server. 6. Set the time period that you want to search. 7. Click “OK” to search. Tibet System Co., Ltd.
  • Page 122 User’s Manual (4.2.0.0) Tibet System Co., Ltd.

This manual is also suitable for:

Ts04Cd08Cs16Cd16Ls16Ld16 ... Show all

Table of Contents

Save PDF
