Summary of Contents for Hyundai VERACRUZ

  • Page 2: Instrument Panel

    InstRUmEnt PAnEl 04 05 06 07 08 09 10 11 01 Headlights 09 All Wheel Drive (AWD) Lock* 02 Trip Computer** 10 Parking Brake 03 Fog Lights* 11 Steering Wheel Audio Controls 04 Instrument Panel Illumination (Dimmer) 12 Tire Pressure Monitoring System (TPMS) 05 Electronic Stability Control (ESC)** 13 Tilt and Telescopic Steering Wheel 06 Adjustable Pedals*...
  • Page 3 16 Audio System / Rear Seat Entertainment (RSE)* 17 Automatic Climate Control 18 Clock Adjustment 19 Occupant Classification System *If equipped **Behind steering wheel...

  • Page 4: Instrument Panel Features

    InstRUmEnt PAnEl FEAtUREs HEADlIGHts HEADlIGHt sWItCH To operate the headlights, rotate the switch on the end of the lever: OFF – Headlights off – Parking lights on – Headlights on AUtO – Auto Light (if equipped) nOtE: The ignition must be in the “ON”...
  • Page 5 3 seconds after the key is turned ON. If the light remains illuminated, take your vehicle to an authorized Hyundai dealer. ADJUstABlE PEDAls (if equipped) LOCK With the transmission selector lever in the “P” position, turn the ignition key to “ON”.

  • Page 6: Hood Release

    HOOD RElEAsE To unlatch the hood, pull the release lever. The hood should pop up slightly. Go to the front of the vehicle, pull the secondary latch under the hood to the left, and lift the hood. LOCK AC InVERtER (if equipped) 115V The AC inverter supplies 115VAC/150W electric power to...
  • Page 7 Illuminates and stays illuminated when there is a problem with the Tire Pressure Monitoring System. If this happens, the system may not monitor tire pressure. Have the system checked by an authorized Hyundai dealer as soon as possible. Please refer to the Owner’s Manual for more detailed information.

  • Page 8: Tilt And Telescopic Steering Wheel

    tIlt AnD tElEsCOPIC stEERInG WHEEl POWER ADJUstABlE stEERInG COlUmn (if equipped) To adjust the steering wheel to the desired position, operate the adjusting switch on the left side of the steering wheel. mAnUAl ADJUstABlE tIlt and tElEsCOPIC stEERInG COlUmn Push the lock release lever downward to unlock the steering wheel.
  • Page 9 AUDIO DISC DISC SCAN LOAD AM/FM CD/RSE INFO POWER AUDIO ENTER 6-DISC CHANGER SYSTEM PUSH CTRL PUSH SEEK FLDR 03 02 TRACK MARK FILE TUNE VOLUME sEttInG PREsEt mEmORY BUttOns sEEKInG nEXt AVAIlABlE CHAnnEl (Am/Fm OR Xm (Am/Fm OR Xm) ®...

  • Page 10: Rear Seat Entertainment System

    REAR sEAt EntERtAInmEnt sYstEm * (if equipped) GEttInG stARtED Insert a disc into the rear CD/DVD slot (the front CD slot does NOT support DVD playback). Open the overhead LCD display if playing a DVD. To enable audio: • Press CD/RSE until “RSE MODE” appears on the front audio display screen. •...

  • Page 11: Automatic Climate Control

    AUtOmAtIC ClImAtE COntROl (if equipped) FROnt ClImAtE COntROl PASSENGER TEMP TEMP DUAL FRONT PUSH REAR – MANUAL REAR AUTO MODE REAR ClImAtE COntROl TEMP Climate Control Recirculating Button or Air Quality Control Button (if equipped) Driver’s Temperature Control Button OFF Button Front Windshield Defrost Button Fan Speed Control Knob Rear Window Defrost Button...

  • Page 12: Clock Adjustment

    ClOCK ADJUstmEnt There are three control buttons for the digital clock. Their functions are: Push “H” to advance the hours. PASSENGER Push “M” to advance the minutes. AIR BAG OFF Push “R” to reset minutes to “:00”. Continue to press and hold the “R”...

  • Page 13: Automatic Transmission

    AUtOmAtIC tRAnsmIssIOn To select automatic mode, with the ignition ON and brake pedal depressed, shift to “R, ” “N” or “D.” To select “SHIFTRONIC” mode, move the shift lever right to the manual shift gate. The instrument cluster displays the selected gear. Refer to the Owner’s Manual for detailed information.

  • Page 14: Central Door Locks

    CEntRAl DOOR lOCKs Central door locking switches are located on the driver’s and front passenger’s armrests. Pushing down on the front portion locks all doors. Pushing down on the rear portion unlocks all doors. nOtE: If the key is in the ignition switch and any front door is open, the doors will not lock.

  • Page 15: Seatback Angle

    POWER sEAt ADJUstmEnt (if equipped) sEAt HEIGHt AnD FORWARD / BACKWARD to adjust seat height: • Raise or lower control switch to adjust seat height. to adjust seat bottom angle: • Raise or lower the front or rear portion of the control switch according to the desired angle.

  • Page 16: Height Adjustable Shoulder Belt

    HEIGHt ADJUstABlE sHOUlDER BElt To adjust, press the button and raise or lower the height adjuster to an appropriate position. POWER tAIlGAtE (if equipped) There are four ways to open and close the power tailgate: mAIn COntROl BUttOn tAIlGAtE BUttOn tAIlGAtE HAnDlE KEYFOB (Press and hold sWItCH...

  • Page 17: Interior Light

    sUnROOF COntROls (if equipped) You can slide or tilt your sunroof by using the control lever located on the overhead console. To open/close the sunroof, move the control forward or backward to the first detent position. To completely open or close the sunroof, even if the lever is released, move the control forward or backward to the second detent position.

  • Page 18: Compass Function

    REARVIEW mIRROR / COmPAss / HOmElInK (if equipped) ® Homelink Channel 1 Button ® Homelink Channel 2 Button ® Status Indicator LED Homelink Channel 3 Button ® Rear Light Sensor Dimming On/Off Button Compass Control Button Display DImmInG On/OFF When turned on, this feature will automatically detect and reduce rearview mirror glare. HOmElInK ®...

  • Page 19: To Fold Down The Rear Seatback

    WAlK-In sEAt tO GEt In OR OUt OF tHE 3RD ROW sEAt: Pull up on the walk-in lever located on the 2nd row seatback. The 2nd row seatback will fold over and the seat will slide forward FOlDInG tHE 2nd and 3rd ROW sEAts tO FOlD DOWn tHE REAR sEAtBACK: Stow the rear seat belt buckle in the pocket.
  • Page 20 VERACRUZ CUstOmER DElIVERY CHECK lIst: sAlEs COPY HYUnDAI OWnER DEAlERsHIP nAmE sAlEs COnsUltAnt DAtE Exterior – Walk around vehicle; check for cleanliness, dents and scratches. • Confirm tire pressure and oil level has been checked. Interior – Check for loose papers and cleanliness.
  • Page 21 • Set customer’s first service appointment Auto Lock/Auto Unlock – Your new Hyundai Veracruz is equipped with an Auto Door Lock and Unlock feature. This feature can automatically lock and unlock all the vehicle’s doors when a pre-selected condition has been met. To help us...

  • Page 22: Maintenance

    Manual. If you require additional information or are unsure of a specific issue, you should always refer to the vehicle’s Owner’s Manual or contact your dealer. *NP150-J7000* Hyundai Roadside Assistance 800-243-7766 Consumer Affairs 800-633-5151 XM Radio 800-967-2346 NP150 - J7000 02/07 (rev 02/07)
