- Page 1 COMPACT DISC PLAYER PROFESSIONAL DUAL CD MP3 PLAYER WITH SEAMLESS LOOP & SOUND EFFECT INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS NOTE ON USE ............3 FOR SAFE AND EFFICIENT OPERATION . -
Page 3: Note On Use
Keep away from sources of hum such as Laser Diode Properties transformers or motors. Material: Ga.-Al-As • Do not use this compact disc player where there are Wavelength: 755-815 nm (25 extremes in temperature ( below 41 C or Laser Output: Continuous Wave max. -
Page 4: Description Of The Functions
DESCRIPTION OF THE FUNCTIONS Function of the Main Unit : This unit is able to read CDDA and MP3 files, 1. POWER(Power Switch) 11.TACT-LOCK option Press the power switch to turn the unit on, and the LED Select the type of switch in the mixer for FADERSTART indicator will be light. -
Page 5: Function Of The Control Unit
Function of the Control Unit 1. UNIT 1-CONTROL OPERATION PANEL 8. TRACK BUTTON This operation panel remotely controls the main unit 1. These buttons select the track to be played. 2. UNIT 2- CONTROL OPERATION PANEL 9. +10 BUTTON This operation panel remotely controls the main unit 2. Pressed the button to forward 10 tracks. - Page 6 16. ON/OFF BUTTON (PITCH) SCRATCH: Move the JOG Wheel backward or forward like scratching a turntable record. Press the button to be PITCH ON mode, press it again on the This sound effect can be performed independently, or in parallel with other effect. PITCH ON mode, and blinks with unit on the PITCH OFF mode.
-
Page 7: Lcd Instruction
LCD INSTRUCTION 1. TOTAL TRACK – 16. SECONDS – the track number of the CD or CARD. Shows the seconds elapsed or remaining depending on mode setting. – The unit is in playing. 17. FRAMES – The CD Player breaks down a second into 75 frames –... -
Page 8: Parameter Setting Instruction
PARAMETER SETTING INSTRUCTION Effect Menu Default Scope Note BRAKE BK/START_T 20 (1 unit = 0. 1 sec) 0 ~100 (0. 1 ~ 10 sec) BK/STOP_T 20 (1 unit = 0. 1 sec) 0 ~100 (0. 1 ~ 10 sec) PHASER PS/BPM_SYNC ON / OFF PS/GAIN... - Page 9 PARAMETER SETTING INSTRUCTION NOTE : 1. BK/START_T : The period time before starting music FL/GAIN: Determine the volume of FILTER effect signal. The higher 2. BK/STOP_T : The period time before stopping music ratio with stronger effect. 3. PS/BPM_SYNC: Add the PHASER effect to the music in a cycle 16.
-
Page 10: Connetions
Connections Typical connections with a mixer is illustrated below. Please use it for reference. * Connect the connection cords to the line inputs of your mixer. * The connection cords and the remote control connection cable are supplied with the main unit. * Be sure to use the remote control connection cable which has been supplied. -
Page 11: Basic Operation
BASIC OPERATION Loading and Ejecting the Disc When the disc is loaded, press the EJECT button to eject the disc (This may be done on either the player or the remote control side.) Place a disc in the disc loader Push the disc to the loader While the disc is loaded, the preparation for disc play will begin When preparation is completed, the total tracks... -
Page 12: Track Skip
TRACK SKIP To advance through the tracks To go back through the tracks Tracks change as follows Tracks change as follows (This is for a disc containing 4 tracks) When this button is pressed once, the CD player When this button is pressed once, the CD player will will advance to the beginning of the next track. -
Page 13: Matching The Beats Per Minute
MATCHING THE BEATS PER MINUTE Match the pitch by monitoring the music of both UNIT 1 and UNIT 2 by ear. When the tempo of the music of the selected CD player is slow compared to the tempo of the other player, move the slider to the + side and match the tempo. -
Page 14: Operation Of Cue And Loop
OPERATION OF CUE (WITH PLAY/PAUSE) 1. In pause mode, press CUE button to memorize a point for playing back. We mean it “cue point”. 2. After “cue point” is memorized, in play mode, pressing CUE button will return the music back to the cue point and keep it in pause mode. 3. -
Page 15: Before Switching Off The Power
POWER OFF TROUBLESHOOTING GUIDE If difficulties arise with your compact disc player, locate the apparent problem in the left-hand column of the table and follow the corrective action suggested in the right-hand column. 1. Is the compact disc player properly connected to the amplifier? 2. - Page 16 USB Driver Installation and Operating Instructions For running program properly, please install the Driver before installing the Application program I. The driver Setup 1. There are two directories on installation CD, please select the Driver directory. 2. Run setup.exe and finish installation. 3.
- Page 17 II. Application Setup 1. There are two directories on installation CD. Please select the DJMP3 directory. 2. Follow the onscreen instructions to complete the setup. 3. Run DJMP3 program on START menu after finishing application installation. III. Application instructions • The files in SD card will automatically be listed in SD card box after running application program. •...
- Page 18 7. The refresh button : Refresh ID information of SD card. For avoiding crash, Please press the refresh button after you changed SD card. 8. The format button : Format SD card, and all the file will be deleted. If the SD card is fresh, format it before the first use. 9.
