3-Phase Alternators ("Delta" Configuration) - Generac Power Systems 45kW Owner's Manual

Figure 7.4 — Stator Power Winding
Connections - 3-phase, 120/208V (6 Lead)
INTERNAL CONNECTIONS
E1
S1
S4
S6
S3
S6 S5
E3
S3
Figure 7.5 — Stator Power Winding
Connections - 3-phase, 120/208V (12 Lead)
E1
S7
S10
S12
S9
S6 S11
E3
S3
Figure 7.6 — Stator Power Winding
Connections - 3-phase, 346/600V (6 Lead)
E1
S1
INTERNAL
CONNECTIONS
S4
S6
S5
S3
E3
General Information
S1
L-L
S4
00 (NEUTRAL)
S5
S2
E2
S2
L-N
S1
L-L
S4
S5
S2
E2
S8
L-N
L - L
00 (NEUTRAL)
S2
E2
L - N

3-PHASE ALTERNATORS ("DELTA" CONFIGURATION)

The Stationary Emergency Generator is designed to supply
3-phase electrical loads. Electric power is produced in the alterna-
tor power windings. These windings were connected at the factory
to the main circuit breaker with a "Delta" configuration as shown
in Figures 7.7 and 7.8.
The rated voltage between circuit breaker terminals E1-E2, E1-E3
and E2-E3 is 240V.
The rated voltage between E1 or E3 and the neutral point 00 is
120V.
Figure 7.7 — Stator Power Winding
Connections - 3-phase, 120/240V (6 Lead)
INTERNAL
CONNECTIONS
S5
E1
S1
Figure 7.8 — Stator Power Winding
Connections - 3-phase, 120/240V (12 Lead)
S5
S8
S11
E1
S1
7-2
E2
S6
S2
S4
L - N
00 (NEUTRAL)
E2
S12
S2
S9
L - L
S6
S3
E3
S10
L - N
00 (NEUTRAL)
L - L
S3
E3
