Challenge Xtreme CXPHT22 Quick Start Manual

22 cc petrol hedge trimmer
Hide thumbs Also See for CXPHT22:

Advertisement

Table of Contents

22 CC Petrol Hedge Trimmer
please read these safety rules before you use this machine

General Safety Rules

Read user manual before using the machine
Wear safety goggles to guard your eyes from possible injury
Wear gloves to protect your hands
Wear safety shoes to protect your feet
Wear hearing protection
Note - This quick start guide is intended for experi-
enced users who have already assembled the tool,
please refer to the manual for further details
Your Safety is most important
CXPHT22
