CoolingTech CS01-200 User Manual

Cs01-200 digital microscope
Hide thumbs

Advertisement

Quick Links

C
oolingTech
CS01-200 Digital Microscope
User Manual
（English）
（中
文）
P
C
repared by
oolingtech Digital Engineering Dept.
2010.3.25
1/45

Advertisement

loading
Need help?

Need help?

Do you have a question about the CS01-200 and is the answer not in the manual?

Questions and answers

Related Manuals for CoolingTech CS01-200

Summary of Contents for CoolingTech CS01-200

  • Page 1 CS01-200 Digital Microscope User Manual （English） （中 文） repared by oolingtech Digital Engineering Dept. 2010.3.25 1/45...
  • Page 2 oolingTech 返回首页 前 言 首先非常感謝貴司（ 您）購買了CS01-200X數碼顯微鏡 數碼顯微鏡應用範圍非常廣泛,主要有以下方面. 1工業方面： a 工業檢視，例如電路板、精密機械等 b 印刷檢視，SMT焊接檢查 c 紡織檢視 d IC表面檢查 …… 2美容方面 a皮膚檢視 b發根檢視 C紅外理療（特定產品） …… 3生物應用 a微生物觀察 b動物切片觀察 …… 4其他 a擴視器，協助視障人士閱讀 b寶石鑒定 …… CS02-500數碼顯微鏡使用簡單，只需要同電腦USB接口連接就可以使用， 本產品還配備測量軟體，可做簡單的量測，非常的方便。爲了更詳細的介紹 本產品，敬請耐心的閱讀產下麵的產品介紹，使用方法，注意事項。 2/45...
  • Page 3 oolingTech 目 錄 首頁··········································································································· 1 前言··········································································································· 2 目錄··········································································································· 3 各部位介紹 ······························································································ 4 產品規格···································································································· 4 安全警告及注意事項 ················································································ 5 配件說明 ·································································································6 安裝說明 ···································································································6 硬體需求 ·············································································· ····················6 安裝過程····································································································6 驅動的安裝說明 ·························································································7 量測軟體安裝與使用說明··········································································· 12 測量軟體使用說明······················································································ 15 工具欄上的各圖示說明··············································································· 16 標定的使用方法 ························································································ 19 Dotnetfx 安裝·····························································································23 3/45...
  • Page 4 oolingTech 部位說明規格 USB 線 調焦滾輪 放大倍數 按鍵 金屬底座 LED 燈罩 規格： 傳 感 器 ： 高性能感光芯片 主控芯片 ： 專用主控16Bit DSP 放大倍率 ： 25X ~ 200X 拍照/錄影： 內置 輔助光源 ： 8顆白光LED燈 靜態解析度： 640x480,最高可達1600x1200(可按需定制) 數碼變焦 ： 5段式 成像距離 ： 手動調節15~40mm 影像解析度 ：標準640*480 4/45...
  • Page 5 oolingTech 固定底座 ： 萬向金屬底座 光 盤 ： 內含驅動，測量軟體，說明書 支持系統 ： WIN XP/VISTA；WIN 7 32位和64位 源 ： USB（5V DC) 電 電腦界面 ： USB 2.0 & USB 1.1 相容 動態幀數 : 30f/s Under 600 LUX Brightness 照度範圍 ： 0 ~ 30000LUX線控可調 硬體需求 ：奔騰 主頻700M Hz或以上；1G硬碟 CD ROM 光碟機； 64MB 內存...
  • Page 6 oolingTech 配件說明 1. 數碼顯微鏡主體（1台） 2. USB 連接線 (1.5m) 3. 萬向底座（1個） 4. 光碟(驅動程式，測量軟體，安裝說明書) 硬體要求   Windows 2000、XP、VISTA、WIN 7 操作系統。奔騰 IV 1.5G, Celeron, AMD 或以上的CPU。64MB 內存。150MB 以上之硬盤空間(安裝驅動 程式及應用軟體) 支援16-bit的顯示卡，CD-ROM 光機，USB2.0或 USB1.1 安裝說明 CS01數碼顯微鏡為無驅動產品，如果不需要一些特殊操作的話，在 windows2000以上版本可直接運行。 1直接將本產品同過USB線連接到電腦上，然後點擊 2雙擊紅色標示內的設備圖標就可以正常使用。 如需要特殊的操作，請參考本產品附送光碟，安裝步驟（以Win XP為例） 將安裝光盤放入光驅後，安裝程式將自動執行，出現如下畫面（如果無法 自動執行，可點擊光驅圖標手動操作） 6/45...
  • Page 7 oolingTech 1驅動安裝 1 點擊 幾秒鐘后 7/45...
  • Page 8 oolingTech 2选择’下一步’ 8/45...
  • Page 9 oolingTech 3.选择’安装 4,驅動“完成”，驅動安裝完成，如果是初次安裝，建議重啟電腦。若在驅動 安裝過程中出現警告資訊，請直接點選“仍然繼續”即可 5,驅動安裝完成後，桌面上會出現如下圖標 ，雙擊顯示 9/45...
  • Page 10 oolingTech 5. 菜單欄中的選項可根據自己的需求設定，例如點擊“選項”—“視頻捕捉篩 檢程式”，出現 10/45...
  • Page 11 oolingTech 顯微鏡光學參數做些簡單的設置。點擊“基本設置”，出現： 根據需求，可對對圖形特效處理，如下 11/45...
  • Page 12 oolingTech 如需要回復到初始參數，請點擊“默認”。 2測量軟體安裝 1 點擊 出現： 12/45...
  • Page 13 oolingTech 2 點擊“下一步” 3 選擇程序安裝路徑，點擊“下一步” 4 如果需要在桌面上創建快捷方式，相應框中打‘√’，點擊‘下一步’ 13/45...
  • Page 14 oolingTech 5 點擊‘安裝’，程序就進入安裝狀態 6 幾秒鐘后，程序安裝過程結束 14/45...
  • Page 15 oolingTech 7 點擊完成，程序就可以使用了。 8 程序安裝成功后，點擊桌面圖標 ，進入如下界面 9 按照提示，連接好設備，程序自動運行到主界面。 15/45...
  • Page 16 oolingTech 10 點擊 選擇視頻分辨率，視頻分辨率範圍320*240 ~1600*1200，分辨率默認值為 640*480. 16/45...
  • Page 17 oolingTech 11 點擊 ，採集圖片，可執行數據量測功能。由於動態影像不是很穩定，本 軟件將採用靜態模式下進行量測，測量精度會相應的提高 12 點擊 可以打開之前存儲的圖片；點擊 可以保存圖片到電腦指定文檔 17/45...
  • Page 18 oolingTech 視頻暫停和終止 14 點擊 圖像放大 16 點擊圖標 ，顯示如下帶標尺線界面 18/45...
  • Page 19 oolingTech 17 點擊圖標 ，進入測量精度校正功能 爲了提高測量精度， 每次使用顯微鏡測量軟件前， 倍率改變， 校正也要改變， 測量精度就可以達到99%。當然校正后的校正值可以保存，下次如有同樣倍 率也可以使用，測量誤差相對較高。精度校正時，建議對同一個實際值進行 多次測量取平均值的方式進行。另外本產品還配備專用校正尺，請不要使用 其他標尺校正，以免影像測量精度。 輸入測量值，和相應的單位 校正就完成了，在這個倍率下就可以做量測了。 注意： 放大倍率改變，必須重新校正。 19/45...
  • Page 20 oolingTech ，標注方式和顏色選擇 ，測量的結果可以以Word，Excel，或郵件格式輸出。 下麵是一個測量結果Word的輸出範例 20/45...
  • Page 21 oolingTech 從左到右： 直線測量，圓測量。矩形測量，多邊形測量，折綫測量，橢圓測量 圓弧測量，點對點測量，點到線測量，平行線測量，角度測量。 如下圖： 範例1：平行線測量 21/45...
  • Page 22 oolingTech 範例2：矩形測量 範例3，圓測量 22/45...
  • Page 23 oolingTech 3在安裝驅動時如提示需要安裝Net Framework 2.0，請點 擊 按照提示，繼續下去就可以了 23/45...

  • Page 24: Table Of Contents

    返回首页 Thank you for purchasing our CS01-200 Digital Microscope, it is a slim type tool and can be easily used in different fields including: 1. Textile industrial for textile inspection 2. Printing inspection 3. Industrial inspection: PCB, Precision machinery…...

  • Page 25: Parts Of Microscope

    oolingTech Function options ·························································································45 How to do the calibration ······················································································47 Parts of Microscope Focus roller USB Line Magnification Ratio Snap LED Light Metal Fixed Stand Specification Image CMOS Sensor Controller High Speed DSP (Driver Free available) Focus Range 15mm ~ 40mm Snap Shot Software and Hardware Video Capture Resolution 0.3M.

  • Page 26: Notes Before Use

    oolingTech Brightness Control Manual adjustment Magnification Range 25 X ~ 200X (Manually) Power Supply USB Port ( 5V DC ) USB 2.0 & USB 1.1 Compatible Operation System Windows XP, Vista, Win 7 32 bit and 64 bit. Language: English, Chinese and other language by selection System Requirement: Pentium Computer with 700M Hz &...

  • Page 27: Hardware And System Requirements

    128MB Memory, 150MB Hard Disc memory space,16-bit & above VGA ,CD-ROM, USB2.0 or USB1.1. How to install the Driver CS01-200 Digital Microscope is a free Driver Product，it can be worked immediately after connected to the computer with operation system above win2000 version.

  • Page 28: How To Install The Driver Software

    oolingTech manually by click “My Computer” → ”DVD/CD Driver” → run”AUTORUN.EXE”) 1. Driver installation 1Click to continue, the screen will show the installation progress. 28/45...
  • Page 29 oolingTech Click“next”to continue，as followings: Click“next”to continue，as followings: 29/45...
  • Page 30 oolingTech Click “continue Anyway”,as followings: Click“Finish”to continue，as followings 30/45...
  • Page 31 oolingTech Select ’Yes, I want to restart my computer now’, and click “finish”. After restart your computer, Plug-in the USB port of Digital Microscope into Computer USB port. Following the user guide by steps and complete by click “Next” -> “Continue anyway” -> “Finish”. 31/45...

  • Page 32: How To Install The Measurement Software

    oolingTech 2 Measurement installations: 1 Click to continue, as followings 32/45...
  • Page 33 oolingTech 2 Click “next” to continue, as followings 3. Click “next” to continue, as followings 33/45...
  • Page 34 oolingTech 4. Click “next” to continue, as followings 5. Click “next” to continue, as followings 34/45...
  • Page 35 oolingTech 6 Click “Install” to continue, as followings Wait a few seconds while the installation taking place. 35/45...
  • Page 36 oolingTech 7.Click “Finish” and the installation completes. 8.After the installation completes, double click at computer desktop to start using the software. Plug-in the devices, Display in operation window 36/45...
  • Page 37 oolingTech 9 Click ,open the operation system Choose the Image resolution from 320*240 to 1600*1200, default at VGA Mode640*480 10 Click to use measurement function. 37/45...
  • Page 38 oolingTech 11 Click to open pictures, and click to save pictures Video PLAY(Pause) ,STOP 38/45...
  • Page 39 oolingTech Image Parameter including Image setting and special effects Magnifier 16 Click Ruller, as followings 39/45...
  • Page 40 oolingTech 17 Click start calibration make sure certain accuracy. Our experience told us that measurement could be controlled at 99% high precision. Measure tolerance could be caused from human eye distortion and defocus. More practice is helpful to measurements. 18 Key in the Measure data(Pixel),Unit, and Click’ OK’ 40/45...
  • Page 41 oolingTech Warning: Please do calibration again once Magnification Ratio changed. Color setting of display character 20 Click to export word or excel format. 41/45...
  • Page 42 oolingTech Example: Measure data under word file From Left to right: Line ring Square Polygon Set-line Length Oval Point to Point distance Point to Line distance Parallel line Angle (as below show) 42/45...
  • Page 43 oolingTech For example 1 Line measurement: For example 2 43/45...
  • Page 44 oolingTech Rectangular measurements: For example3 Ring measurements: For example 4 Arc measurements: 44/45...
  • Page 45 oolingTech 3Please click to Continue when the NET Framework2.0 is necessary 45/45...
